INBOXR8
COBRANET® AUDIO INTERFACE
INBOX R8 DATA SHEET
TheInBoxR8CobraNet®AudioInputInterfaceisa
costeffectiveeightinput,linelevelwallbox.The
R8featureseightunbalancedRCAinputs,which
canbeusedaseithereightmonoinputsorfour
stereoinputs.TheR8isdesignedtofitintomost
dualgangjunctionboxesandisPoEenabled,so
allconnectivity(bothpowerandaudiodata)to
theR8isprovidedbyasingleCAT‐5cable.
•
•Fullybalancedinputsandoutputswithhighq
•
•
•
•
•
•
•
•
FEATURESANDBENEFITS
•EightunbalancedRCAinputconnectors
•Mountsinastandarddualgangjunction
box
•RCAinputsmaybeusedinmonomode
(eightin)orinstereomode(fourin)
•PoEpoweredfromastandardPoEnetwork
switch
•Enclosuresizeis3.60”Wx2.75”Hx1.88”D
(excludingprojections‐SeeUserManual
forcompletemechanicaldetails)
AtteroTechisaleadingproviderofCobraNet®audio
interfaces.Theseinnovativenetworkedaudioproducts
makeitcosteffectiveforaudioinstallationstoinclude
CobraNet.AtteroTechisheadquarteredinFortWayne,
Indiana.Contactusat:
APPLICATIONS
•Convenient,wallmountedlinelevelinput
dropsfor:
•Hotelballrooms
•Conference/meetingcenters
•Conferencerooms
•Sportsfacilities
•Conventioncenters
•Healthclubs
•RestaurantsandBars
AtteroTechisaleadingproviderofCobraNet®audio
interfaces.Theseinnovativenetworkedaudioproducts
makeitcosteffectiveforaudioinstallationstoinclude
CobraNet.AtteroTechisheadquarteredinFortWayne,
Indiana.Contactusat:
260.496.9668
ABOUTATTEROTECH
AtteroTechisaleadingproviderofCobraNet®®audio
interfaces.Theseinnovativenetworkedaudioproducts
makeitcosteffectiveforaudioinstallationstoinclude
CobraNet®.AtteroTechisheadquarteredinFortWayne,
Indiana.Contactusat:
260.496.9668www.atterotech.com

2011 Attero Tech, LLC. All rights reserved. InBox R8 Product Brief. 01/2011
ARCHITECTS&ENGINEERSSPECS
TheCobraNet®interfaceunitshallprovide
eightlinelevelanaloginputsonthefrontpanel
withRCAconnectors.Theinternalanalogto
digitalsignalconversionshallbeperformedat
24‐bitresolutionwithasamplingfrequencyof
48kHzor96kHz.TheCobraNet®interfaceunit
shallreceivepowerovertheEthernetcable
froman802.3afPoEcompliantnetworkswitch.
TheCobraNet®interfaceshallbewallmounted
inastandarddualgangjunctionbox.
TheCobraNet®interfaceshallbecompatible
withAtteroTechControlCentersoftwarefor
flexiblecontrolandmonitoringinsystemappli‐
cations.TheCobraNet®interfaceshallbecom‐
pliantwiththeRoHSdirective.
TheCobraNet®interfaceshallbetheAttero
TechInBoxR8.
CobraNet
Interface IC
Isolated
PoE
Power Supply
2 CH
ADC
2 CH
ADC
2 CH
ADC
2 CH
ADC
Stereo
RCA
MAC/PHY Ethernet
Magnetics RJ-45
SPECIFICATION
S

LineInputType:
MaximumInputLevel:
InputImpedence:

Unbalanced
+8dBuwithoutclipping
10kΩ
FrequencyResponse:

SystemTHD:

Inputs:
POEClass:

PowerConsumption
Dimensions:

OperatingTemperature:

20Hz‐10kHz,
21+/‐1dB
<0.05%,1kHz,
3dBbelowinput
clipping
EightRCAinputs
Class2802.3afPoE
PDCompliant
4w
3.60”Wx2.75”Hx1.88”D
(excludingprojections)
0ºC‐40ºC

