MediaPack™ 20x FXS Telephone Adapter
Quick Setup Guide
Welcome
Congratulations on purchasing your AudioCodes MediaPack 20x Telephone Adapter (MP-20x),hereafter
referred to as device!
This document provides basic setup instructions for cabling the device and for connecting it to the Internet.
Before you begin, please read the Safety Precautions on page 7.
Package Contents
Make sure that the following items (in addition to any separate-orderable items that you may have purchased)
are included with your shipped device:
1 x 12V AC power adapter
1 x RJ-11 telephone cable
1 x RJ-45 Ethernet cable
Regulatory Information document
This Quick Guide

2 |Page
Rear-Panel Description
[Number of FXS Phone Ports and Presence of USB Port Depend on MP-20x Model]
1
12VDC
AC power socket.
2
RST
Reset pinhole button for resetting the device or restoring it to factory defaults.
To reset: With a paper clip (or any other similar pointed object), press the
button for at least 1 second, but no more than 5 seconds.
To restore to factory defaults: With a paper clip (or any other similar pointed
object), press the button for at least 7 seconds, but no more than 25 seconds.
3
USB
USB 2.0 port which can be used for connecting a 3G/4G LTE cellular modem (USB
dongle) for primary or secondary (backup) WAN, a network printer for LAN users,
or an external storage device.
Note: The USB port is available only on these MP-20x models: MP-204B/4S/SIP,
MP-202R/2S/SIP/CER/R, and MP-204R/4S/SIP/CER/R.
4
WAN
WAN Ethernet port interface (RJ-45) for connecting to the WAN.
Note: The Ethernet port speed depends on the MP-20x model:
Fast Ethernet (100Base-T): MP-202B/2S/SIP
Gigabit Ethernet (10/100/1000Base-T): MP-204B/4S/SIP, MP-
202R/2S/SIP/CER/R, and MP-204R/4S/SIP/CER/R
5
LAN/PC
LAN Ethernet port interface (RJ-45) for connecting to a LAN computer.
Note: The Ethernet port speed depends on the MP-20x model:
Fast Ethernet (100Base-T): MP-202B/2S/SIP
Gigabit Ethernet (10/100/1000Base-T): MP-204B/4S/SIP, MP-
202R/2S/SIP/CER/R, and MP-204R/4S/SIP/CER/R
6
PHONE
Foreign Exchange Subscriber (FXS) ports for connecting analog telephones.
Note: The number of FXS ports depends on the MP-20x model:
2: MP-202B/2S/SIP and MP-202R/2S/SIP/CER/R

4: MP-204B/4S/SIP and MP-204R/4S/SIP/CER/R
1
2
3
4
5
6

3 |Page
Front-Panel Description
[Number of PHONE LEDs and Presence of USB LED Depend on MP-20x Model]
1
PHONE
LED indicating FXS port (phone) status:
Green Slow-Flashing
SIP user account for the analog line has been successfully
registered to a proxy server
Phone is in on-hook state
Green On
Phone is in off-hook state
Green Fast-Flashing
Phone is ringing
Red On
SIP user account registration failure for the analog line
Off
No SIP user account has been configured for this analog line
2 / 3
LAN / WAN
LED indicating LAN and WAN status:
Green On
Ethernet link is connected:
100 Mbps: MP-202B/2S/SIP
1000 Mbps: MP-204B/4S/SIP, MP-202R/2S/SIP/CER/R, and MP-
204R/4S/SIP/CER/R
Green Flashing
Ethernet link is active (data is received or transmitted):
100 Mbps: MP-202B/2S/SIP
1000 Mbps: MP-204B/4S/SIP, MP-202R/2S/SIP/CER/R, and MP-
204R/4S/SIP/CER/R
Yellow On
Ethernet link is connected:
10 Mbps: MP-202B/2S/SIP
100 Mbps: MP-204B/4S/SIP, MP-202R/2S/SIP/CER/R, and MP-
204R/4S/SIP/CER/R
Yellow Slow-Flashing
Ethernet link is active (data is received or transmitted):
10 Mbps: MP-202B/2S/SIP
100 Mbps: MP-204B/4S/SIP, MP-202R/2S/SIP/CER/R, and MP-
204R/4S/SIP/CER/R
Yellow Fast-Flashing
10-Mbps Ethernet link is active (MP-204B/4S/SIP, MP-
202R/2S/SIP/CER/R, and MP-204R/4S/SIP/CER/R)
Off
No Ethernet link
4
USB
LED indicating USB port status:
Green On
USB device connected to USB port
Off
No USB device connected
1
2
3
4
5
6

4 |Page
5
STATUS
LED indicating operating status:
Green On
Device bootup completed successfully
Green Flashing
Firmware upgrade or configuration update in process (all other LEDs
also flash, except POWER LED)
Red On
Device booting up
6
POWER
LED indicating power status:
Green On
Power received by device
Off
No power
Cabling the Device
1. Connect the device's Ethernet port labeled WAN to your Internet router, using an RJ-45 Ethernet cable.
2. Connect the device's Ethernet port labeled LAN/PC to your computer, using an RJ-45 Ethernet cable.
3. Connect the device's telephone ports labeled PHONE to your analog telephones or faxes, using RJ-11
telephone cables.
4. (Optional) For primary or secondary (backup) WAN, connect a 3G/4G cellular modem dongle to the
USB port labeled USB.
5. Connect the device to a standard 110/220 VAC electrical wall outlet, using the supplied AC power
adapter; the POWER LED turns on (green) and when initialization completes (~ 1 minute), the STATUS
LED changes from red to green.

5 |Page
Configuring Initial Network Settings
Once you have cabled the device, as explained in the previous section, you can access the device's Web-based
management tool to configure your Internet connection type.
1. On the computer that you connected to the device, verify that the Local Area Connection status is
"Connected". If the status is "Disconnected", then make sure that your computer is configured to
obtain an IP address automatically. (The device has an embedded DHCP server which allocates a DHCP
pool of IP addresses in the 192.168.2.0/24 subnet.)
2. Open a standard Web browser on your computer, and then in the URL field, enter the device's default
IP address of 192.168.2.1; the Login screen appears:
3. Enter the default, case-sensitive username (admin) and password (admin), and then click Continue; the
Quick Setup page appears:
4. From the 'Connection Type' drop-down list, select the Internet connection method. Consult with your
Service Provider for the required connection type (e.g., DHCP, PPPoE or PPTP).

6 |Page
5. Click OK; the Map View page appears, displaying all the network elements (such as phones, faxes,
router, and Internet) that are connected to your device. (If there is no Internet connection, the icon
is displayed on the "WAN Ethernet" line.)
Obtaining Software and Documentation
If you have a maintenance and support agreement with AudioCodes or with an authorized AudioCodes Service
Partner, you can download the device's latest software version from AudioCodes' Services Portal at
https://services.audiocodes.com (registered users only).
To download the device's technical documentation such as the User's Manual from AudioCodes website,
click here.

7 |Page
Safety Precautions
The device must be installed and serviced only by qualified service personnel.
This device is an indoor unit and therefore, must not be installed outdoors.
Ethernet cabling must be routed only indoors and must not exit the building.
Do not open or dismantle the device.
Do not expose the device to water or moisture.
Make sure the device is installed in a well-ventilated location to avoid over heating of internal
components and subsequent damage.
Do not place any object on top of the device and make sure that sufficient clearance from the top and
sides are maintained to ensure proper airflow to avoid over heating of internal components.
Operate the device in an ambient temperature (Tma) that does not exceed 40°C (104°F).
Use only the supplied AC/DC power adapter for connection to the power source. In case of a
malfunction, do not attempt to fix the power adapter and do not use any other type of power adapter.
Contact AudioCodes support for assistance.
The device must be connected to an electrical socket-outlet providing protective earthing.
Operate the device only from the type of power source indicated on the chassis.
Installation of the device must be in accordance with national electrical codes and conform to local
regulations.

8 |Page
