Mediant™ 2600 Session Border Controller
Quick Setup Guide
Welcome
Congratulations on purchasing your AudioCodes Mediant 2600 Session Border Controller (SBC), hereafter
referred to as device!
This document is only intended to provide basic setup instructions for initial access to the device and
connecting it to your network. For advanced configuration and cabling, refer to the Mediant 2600 SBC User's
Manual and Hardware Installation Manual respectively, which can be downloaded from
https://www.audiocodes.com/library/technical-documents.Before you begin, please read the Safety
Precautions on page 7.
Package Contents
Make sure that the following items (in addition to any separate-orderable items that you may have purchased)
are included with your shipped device:
4 x anti-slide bumpers for desktop mounting
2 x mounting brackets for 19-inch rack mounting
Two-meter serial interface cable adaptor
2 x AC power cables

2 |Page
Physical Description of Front Panel
[The number and type of port interfaces depends on the ordered hardware configuration.]
1
Fan Tray Module #2 with a schematic displayed on its front panel showing the chassis’
slot numbers.
2
Power Supply module #2.
3
Power Supply module #1.
4
(Slots 1-2) Covered with blank AMC modules for unused AMC slots. The slots can house
an optional, customer-ordered Media Processing Module (MPM), providing additional
digital signaling resources (DSP) for transcoding sessions.
5
(Slots 3-4) Covered with blank AMC modules for unused AMC slots.
Note:
If you purchased this device in an initial release, Slots 3-4 may be occupied by the
E-SBC CPU AMC module (instead of Slots 5-6).
If this slot is occupied by the E-SBC CPU AMC module and you have subsequently
purchased an MPM, you must re-locate the E-SBC module to Slots 5-6 instead.
6
(Slots 5-6) E-SBC CPU AMC module (hereafter referred to as E-SBC), providing CPU, serial
interface, and Ethernet interface functionalities.
Eight 1000Base-T GE (Gigabit Ethernet) LAN ports. The LAN ports can operate in
pairs, where one port is active and the other standby, providing 1+1 LAN
redundancy. The ports support half-and full-duplex modes, auto-negotiation,
straight-through or crossover cable detection.
RS-232 port (IOIO) for serial communication.
Reset pinhole button (//). To reset the device, press the button for at least 1
second (no longer than 10 seconds). To reset to factory defaults, press the
button for at least 11 seconds (no longer than 20 seconds).
Note: If you purchased this device in an initial release, the E-SBC module may be
occupied in Slots 3-4 (instead of Slots 5-6).
7
(Slots 7-8) Covered with blank covers for unused AMC slots.
Note: These slots are currently reserved for future use.
5
1
2
3
4
6
7

3 |Page
Physical Description of Rear Panel
1
AC power supply inlet (100-240V~2.5A, 50-60 Hz) for Power Supply module #1.
2
AC power supply inlet (100-240V~2.5A, 50-60 Hz) for Power Supply module #2.
3
Electrostatic Discharge (ESD) lug.
4
Protective earthing (grounding) screw.
Mounting the Device
You can mount the device on a desktop using the four anti-slide bumpers (supplied), which you need to stick on
the grooves located on the underside of the device.
You can also mount the device in a standard 19-inch rack, by placing it on a pre-installed rack shelf (not
supplied), and then securing the device to the rack frame using front-mounting brackets (supplied).
For additional 19-inch rack mounting options, refer to the Mediant 2600 E-SBC Hardware Installation Manual.
Powering Up the Device
The device is powered from a standard alternating current (AC) electrical wall outlet. The device provides two
hot swappable, power supply modules for power load sharing and 1+1 AC power redundancy in case of failure
of one of the modules.
If you are using both Power Supply modules, ensure that you connect each one to a different AC power
supply source. The two AC power sources must have the same ground potential.
The device must be connected (by service personnel) to a socket-outlet with a protective earthing
connection.
1
2
3
4

4 |Page
1. Connect the line socket of the AC power cord (supplied) to the device's AC power socket located on the
rear panel.
2. Connect the plug at the other end of the AC power cord to a standard electrical outlet.
Assigning an IP Address
Use the device's factory default IP address (192.168.0.2/24 and Default Gateway 0.0.0.0) to initially access the
device's Web-based management interface and then change it to suit your network's addressing scheme for
subsequent connectivity.
1. Using a CAT-5e/6 straight-through RJ-45 Ethernet cable, connect the device's Ethernet port GE #1
(front panel) to the LAN port on a computer.
2. Change the IP address of your computer to correspond with the device's default IP address and subnet
mask.

5 |Page
3. On your computer, open a standard Web browser, and then in the URL field enter the device's default
IP address; the Web Login screen appears:
4. Type in the default username (Admin) and password (Admin), and then click Login.
5. Open the Interface table (Configuration tab > VoIP > Network > IP Interfaces Table).
6. Select the OAMP interface ('Application Type' with OAMP + Media + Control), click Edit, and then in
the dialog box, change the device's IP address to suit your networking address scheme.
7. Click Save to submit your changes.
8. On the toolbar, click Reset to access the Maintenance Actions page.
9. On the Maintenance Actions page, click Reset to save your new settings to flash memory with a device
reset.
10. Disconnect the device's Ethernet cable from the computer and connect it to your network.
11. Access the device's management interface using the newly assigned IP address.

6 |Page
Obtaining Documentation and Software
If you are a registered user, you can download the device's latest software version from AudioCodes' Services
Portal at https://services.audiocodes.com. For documentation relating to the device such as the User's Manual
and Hardware Installation Manual, go to https://www.audiocodes.com/library.
Customer Support
Customer technical support and services are provided by AudioCodes or by an authorized AudioCodes Service
Partner. For more information on how to buy technical support for AudioCodes products and for contact
information, please visit our website at https://www.audiocodes.com/services-support/maintenance-and-
support.

7 |Page
Safety Precautions
This device is an indoor unit and therefore, must not be installed outdoors. Ethernet cabling must be
routed only indoors and must not exit the building.
The device must be installed and serviced only by qualified service personnel.
Do not open or dismantle the device.
Do not expose the device to water or moisture.
Make sure the device is installed in a well-ventilated location to avoid over heating of internal
components and subsequent damage.
Do not place any object on top of the device and make sure that sufficient clearance from the top and
sides are maintained to ensure proper airflow to avoid over heating of internal components. The side
panels of the chassis where the air vents are located must remain unobstructed to ensure adequate
airflow and prevent overheating of the chassis components.
Operate the device in an ambient temperature (Tma) that does not exceed 40°C (104°F).
The device must be installed only in restricted access locations.
Use only the supplied AC power cord for connection to the power source.
The device must be connected to an electrical socket-outlet providing a protective earthing connection.
Operate the device only from the type of power source indicated on the chassis.
Installation of the device must be in accordance with national wiring codes and conform to local
regulations.
The device must be installed only in telecommunication sites in compliance with ETS 300-253
requirements "Earthing and Bonding of Telecommunication Equipment in Telecommunication
Centers".
