Audiovox VODDLX10 User manual

VODDLX10
10.1" OVERHEAD LED BACKLIT
LCD MONITOR WITH
DVD PLAYER
OPERATION
MANUAL

FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has
been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
-Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any change or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate this
equipment.
Radiation Exposure Statement
This equipment complies with FCC radiation limits set forth for an uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.

2
Important Notice
Installation of overhead products requires careful planning and preparation. Be extremely careful when working on a vehicle with side curtain air bags.
Do not route wires near any portion of the side curtain air bag assemblies. This includes any anchor points in A, B, C or D pillars of the vehicle. Routing
wires in these areas or running wires by the side curtain air bags can prevent the side curtain air bag from fully deploying which can result in personal
injury to vehicle occupants. If you have any questions regarding wire routing in a vehicle, please contact Audiovox Technical Support at 1-800-225-6074.
When connecting power and ground in a mobile video installation ensure that the ACC wire is fused at the point where it is connected to the vehicle
ACC wiring. Failure to do so can result in damage to the vehicle if a short circuit develops between the vehicle connection point and the mobile video
product.
An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if the LCD panel or video monitor is used for vehicle
information, system control, rear or side observation or navigation. If the LCD panel or video monitor is used for television reception, video or DVD play,
the LCD panel or video monitor must be installed so that these features will only function when the vehicle is in “park” or when the vehicle's parking
brake is applied.
An LCD panel or video monitor used for television reception, video or DVD play that operates when the vehicle is in gear or when the parking brake is not
applied must be installed to the rear of the driver's seat where it will not be visible, directly or indirectly, to the operator of the motor vehicle.
Warnings
• Do not use any solvents or cleaning materials when cleaning the video monitor.
• Do not use any abrasive cleaners, they may scratch the screen.
• Use only a lightly dampened lint free cloth to wipe the screen if it is dirty.
• Lock the LCD screen in the fully closed position when not in use.
• Before putting on headphones always adjust the volume setting to the lowest position.
• Remember to leave the dome light switch in the o or auto positions when the vehicle is unattended, as the dome lights, if left on, can drain
the vehicle's battery.
• Do not put pressure on the screen.
• Caution children to avoid touching or scratching the screen, as it may become dirty or damaged.
Licensed under one or more of the following patents,
Patent NOS. 5,775,762 , 5,927,784 and 6,678,892

3
Congratulations
Congratulations on your purchase of the AUDIOVOX VODDLX10 DVD
Player with drop-down video / monitor. The VODDLX10 has been designed
to give you and your family many years of video entertainment in the
mobile environment. Please read the directions that follow to familiarize
yourself with the product to ensure that you obtain the best results from
your equipment.
Note: Installation options vary, see the individual owner's manuals for
each component in your system to obtain a full understanding of each
component's operation.
Safety Precaution
For safety reasons, when changing video media, it is recommended that
the vehicle is not in motion, and that you do not allow children to unfasten
seat belts to change video media or make any adjustments to the system.
System adjustments can be accomplished using the remote control, while
seat belts remain fastened. Enjoy your AUDIOVOX entertainment system
but remember the safety of all passengers remains the number one
priority.
FEATURES
• 10.1” TFT (Thin Film Transistor) Active Matrix LCD (Liquid Crystal
Display) Monitor
• LED Backlighting
• Built-in DVD Player
• OSD (On Screen Display) for Control of Picture Quality and Functions
Selectable (M1 and M2) IR Receive and Transmit Codes
(See page 5)
• Switchable Dual Channel IR Infrared Transmitter
(See page 5)
• Four Audio / Video Source Inputs (DVD/USB, AV, AUX)
(See page 4)
• Dome Lights with Built-in Three Way Switch
• Built-in 100 Channel Wireless FM Modulator
• Last Position Memory for DVD
• Screen Mode Selection (4:3, 16:9)
• Full Function Remote Control
• Backlit Controls
• AV Output via RCA Jacks
• Plays DVD, CD and MP3 Discs

CONTROLS AND INDICATORS DIAGRAM FRONT VIEW
1. POWER ( ) Button
Used to turn the system on/o (standby).
2. Infrared Transmitter/Remote Sensor
(Location)
3. Source Select (S) Switch
Used to select one of the four sources: DVD/USB, AV, AUX
Note: USB source selection is only available when a USB memory
device is connected to the unit.
4
1
2
3
4
5
6
7
8
9
10
12
11
4. PLAY (u) Button
This button is used to start playback of a disc.
5. STOP (n) Button
-Press the STOP button once: Stops playback.
- Pressing the PLAY button again will resume normal playback from
where movie was stopped.
- Press the STOP button twice and then press the PLAY button to start
playback from the beginning of the DVD.
6. EJECT ( ) Button
This button is used for ejecting disc from the disc compartment.
7. Three Position Dome Light Switch
ON - Turns on the dome lights.
OFF - The dome lights will not turn on in this position.
AUTO - Automatically switches on the dome lights in conjunction with
the vehicle's interior illumination.
8. Dome Lights
Provide additional interior illumination.
9. Ventilation Openings
10. LCD Cut O Switch
Used to turn o the LCD backlight when the LCD is in the closed
position.
11. LCD Panel
12. Screen Release
Press to release the screen.

5
CONTROLS AND INDICATORS DIAGRAM
SIDE VIEWS
1. DVD Disc Insertion Slot
For loading and removing discs. Insert disc with label side facing up.
2. AUX IN
This jack is used to supply external audio and video inputs to the unit.
Note: In order to connect an external A/V source, the 3.5mm to RCA
connectors pigtail is required.
3. USB INPUT
Allows for the connection of an USB memory device.
VODDLX10 System
The VODDLX10 System has an option that allows the user to select from
two IR transmit and receive codes (M1 or M2). This feature can be used
when using two VODDLX10 sytems in the same installation or if the vehicle
has RSA (Rear Seat Audio) that uses an “A” channel headset. The VODDLX10
system comes factory set to M1. When in the M1 mode, the unit will
respond to remote commands when M1 is selected on the remote control
and will transmit audio on the A channel. When in the M2 mode, the unit
will respond to remote commands when M2 is selected on the remote
control and will transmit audio on the B channel.
Note: Use 2-channel IR headphones set to CH B when the monitor is set to
M2 mode.
Note: M1 will appear on the screen for 4~5 seconds.
Selecting a Monitor Code (M1 or M2)
1. Power ON the unit and wait until M1 on the OSD appears. M1 will
appear on the screen for 4~5 seconds.
2. To change the monitor code, press the System Menu button.
3. Use the p or q cursor buttons to select the Monitor Mode menu
option. Press OK to conrm the setting.
4. Use the p or q cursor buttons to select the desired monitor mode,
then press OK to conrm the setting.
5. Press the M2 button on the remote.
6. Press the System Menu button on the remote to exit.
2 3
1
FMM OFF
M2
DVD
IRT OFF
FMM 88.3MHz
M1
AUX/GAME
IRT ON
SYSTEM MENU
OSD LANGUAGE
DEFAULT DVD ON/OFF
SCREEN MODE
FM MODULATOR
MONITOR MODE
WARNING
SETTING THE MONITOR TO THE M2 MODE WILL
REQUIRE USING 2-CHANNEL HEADPHONES.
USE THE DOWN KEY ON THE REMOTE CONTROL
TO SELECT M2 AND PRESS OK TO SET THE
MONITOR TO M2 MODE
TO REMAIN IN THE M1 MODE PRESS OK
M1
M2

6
REMOTE CONTROL OPERATION
Initial Use
When purchased, the remote control has a battery installed with a Pull Tab
to prevent battery discharge. Remove the Pull Tab before attempting to
use the remote control.
Battery Replacement
1. Remove the battery holder.
2. Insert one CR2025 battery into the battery holder. Be sure to observe
the correct polarity.
3. Align the battery holder with the remote control and insert. Push it in
until the holder clicks.
CR2025
REMOTE CONTROL FUNCTIONS
1
3
2
4
5
6
7
8
9
10
12
14
11
13
15
16
17
18
19
20 21
22
23
24
25
26
27
28
29
30
31
32

7
* Function control is available on the unit and the Remote Control.
** Function not available in this model.
1. POWER*
Press this button to turn the unit ON and OFF.
2. SOURCE*
Each time the button is pressed, the unit will cycle through modes DVD/USB, AV, AUX.
3. MONITOR SELECT
M1 Button – Set the remote control code to allow control of the unit in M1 mode.
M2 Button – Set the remote control code to allow control of the unit in M2 mode.
4. SCAN BACKWARD ( )
Press to search in a backward direction. Press repeatedly to change the search speed from 2, 4, 8, 16 times and normal speed.
5. SCAN FORWARD ( )
Press to search in a forward direction. Press repeatedly to change the search speed from 2, 4, 8, 16 times and normal speed.
6. TV Mode Select
Switches certain function keys on the remote control for monitor functions.
7. PREVIOUS ( )
Press to return to the previous chapter or track.
8. NEXT ( )
Press to skip to the next chapter or track.
9. PLAY (u)*
Press to activate the play mode while a disc is loaded into the disc compartment.

10. SYSTEM MENU
Allows the user to access the system menu when the unit has been placed in TV mode. Press the cursor buttons (pq) to select FM MODULATOR,
OSD LANGUAGE, DEFAULT DVD ON/OFF, SCREEN MODE, MONITOR MODE.
Note: Press once to access the System Menu, press twice to exit the System Menu.
11. CURSOR (pqt u)
Use these buttons to access menu selections on the screen.
12. DISPLAY
Press to display the current disc information while the disc is playing. Use the cursor buttons (pq) to select the Title or Chapter. For Title/Chapter
selection use the numeric buttons to enter the desired Title /Chapter selection.
13. OK
Used to implement a selected setting or menu option.
14. SETUP
Allows the user to access the Setup Menu when the unit has been placed in DVD mode. Use the cursor buttons pqt u to select options such as
language, video, rating, Misc.
15. REPEAT
Allows the user to repeat a selected title, chapter, or track.
16. A-B REPEAT
Allows user to repeat the playback from point A to point B.
Press A-B button On-Screen Display DVD player
Once Repeat A Mark the beginning of the section to repeat (Set point A)
Twice A-B Mark the end of the section to repeat (Set point B)
3 times AB O Cancel the A-B repeat function
17. SUBTITLE
Press to display and select the subtitle language in DVD mode. Each time you press the button, the subtitle language changes.
Note: The type and number of languages for subtitles vary from disc to disc.
8

9
18. NUMBERS
Allows the user to enter the numbers 0-9 for selection of the tracks, titles, chapters or password setting.
19. ZOOM
Press this button to enlarge the picture when playing a DVD disc.
Press ZOOM button DVD player
Once Q1- Enlarges the picture twice the original size
Twice Q2- Enlarges the picture 3 times the original size
3 times Q3- Enlarges the picture 4 times the original size
4 times Q o- Picture is returned to original size
20. AUDIO
Press to display and select audio language in DVD mode. Each time you press the button, the language changes.
Note: The available languages vary from disc to disc.
21. FM MODULATOR CHANNEL SELECT (C)
The unit has a 100 channel built-in wireless FM Modulator. The FM Modulator can be set from 88.1 to 107.9 in 0.2 MHz steps, i.e. 88.1, 88.3, 88.5, 88.9,
90.1 etc. Each time the C button on the remote control is pressed, the FM Modulator frequency will increase by 0.2 MHz steps. The FM Modulator
menu can accessed by pressing the System Menu button on the remote control and selecting the FM Modulator menu. Refer to the SYSTEM MENU
SETTINGS AND ADJUSTMENTS for more details.
22. FMM ON/OFF
Turns the FM Modulator power on/o.
23. IRT ON/OFF
Turns the Infrared Transmitter on or o for IR wireless headphones.

10
24. PIX ( Picture Select )
Each time this button is pressed, the OSD picture adjustment displays the “Adjustment Bar” for BRIGHTNESS, CONTRAST, COLOR, TINT (For NTSC only)
or RESET. Once the desired adjustment bar is displayed, use the VOLUME +/ VOLUME – buttons to adjust the setting. The display will automatically
turn o if no adjustments are made within 6 seconds.
25. VOLUME DOWN (-) or UP (+)
Press to decrease or increase the level of the picture adjustments after the picture select button (PIX) is pressed.
Note: The volume up/down will not aect the wireless headphones or the FM Modulator output.
26. MUTE
Press this button to mute the audio for wireless FMM and IR headphones.
Pressing the button again restores the audio to the previously set level.
27. DISC MENU
Allows the user to access the disc’s menu mode.
28. STOP (n) *
Press to stop playback. (Playback will resume from the point it is stopped).
Press twice to stop playback fully. (Playback will resume from the beginning of the disc).
29. PAUSE (II)
Press to pause playback.
30. DVD Source
This button is only active when the remote control is in DVD mode. Press to switch between DVD and USB.
31. DVD Mode Select Button
Switches certain function keys on the remote control for DVD function.
32. EJECT ( )*
Press this button to eject the disc.

11
TURNING THE UNIT ON OR OFF
1. Push in the Screen Release button to unlock the LCD screen. The screen will drop down slightly.
2. Pivot the screen downward until a comfortable viewing angle is reached. The hinge friction will hold the screen in position while the system is in use.
3. Press the power button on the unit or the remote control to turn the system on and o. When in use, the internal backlighting will illuminate the
controls.
4. After the unit has been turned on and is displaying a picture, adjust the viewing angle by pivoting the screen to optimize the picture quality.
5. Remember to turn the unit o and pivot the LCD screen to the locked position when not in use.
Power
ON/OFF
Button
Screen Release

12
PICTURE CONTROL SELECT
When watching a program, the picture quality can be adjusted to the user’s preferences.
1. Press the Picture (PIX) button on the remote control and the on screen picture adjustment displays the “adjustment bar” for BRIGHTNESS, CONTRAST,
COLOR, TINT (for NTSC only) or RESET.
2. Use the Volume buttons + or - to adjust the selected adjustment bar for picture quality.
SYSTEM MENU SETTINGS AND ADJUSTMENTS
The System Menu contains features and options that let the user customize the system. For example, the user can change the FM Modulator, OSD
language, source default, screen mode display, and the monitor mode.
Using the System Menu
1. Press the TV button and then the SYSTEM MENU button on the remote. The system menu main page will appear on the screen.
2. Use the cursor buttons p or q to select an item in the sub menu and then press OK to select.
3. Press the System Menu button to exit the System Menu.
Note: The System Menu can be controlled via Remote Control only. (Items selected in the menu will have a green background.)

13
FM MODULATOR
The FM Modulator allows the user to listen to audio through the vehicle’s radio.
ON - Turns the wireless FM Modulator on if audio playback through your vehicle’s radio is preferred.
OFF - Turns the wireless FM Modulator o.
FM CHANNEL - Allows the user to select the wireless FM Modulator frequency. The unit has a 100 channel built-in wireless FM Modulator. The FM
Modulator can be set from 88.1 to 107.9 in 0.2 MHz steps, i.e. 88.1, 88.3, 88.5, 88.9, 90.1 etc.
To choose an FM frequency for audio playback through your vehicle’s radio:
1. Press the TV button on the remote control, then press the SYSTEM MENU button to access the System Menu. Press OK to access the FM Modulator
settings.
2. Use the q cursor button to select FM CHANNEL, then press OK. The FM CHANNEL screen will appear.
3. Use the p q t or u cursor buttons to select a frequency not used by a radio station in the area. Press OK to select the highlighted frequency. There
are a total of 5 FM CHANNEL pages containing frequencies from 88.1 to 107.9 in 0.2 MHz steps. To access the additional FM Channel pages, use the
p q t or u cursor buttons to highlight the on screen left and right arrows and press OK. Once you have selected a frequency, tune your vehicle’s
radio to the selected frequency.
4. Press the System Menu button to restore control of the DVD functions.
Note: The wireless FM modulator will perform well in most applications. However, in certain applications the quality of the wireless signal may be less
than optimal, resulting in static or strong local station bleed through.
SYSTEM MENU
OSD LANGUAGE
DEFAULT DVD ON/OFF
SCREEN MODE
FM MODULATOR
MONITOR MODE
ON
OFF
FM CHANNEL
FM MODULATOR FM CHANNEL
88.1MHz
88.3MHz
88.5MHz
88.7MHz
88.9MHz
89.1MHz
89.3MHz
89.5MHz
89.7MHz
89.9MHz
90.1MHz
90.3MHz
90.5MHz
90.7MHz
90.9MHz
91.1MHz
91.3MHz
91.5MHz
91.7MHz
91.9MHz
92.1MHz
92.3MHz

14
OSD LANGUAGE
This function allows the user to select the on-screen display language.
The user can select English, Spanish, French or German for the OSD language.
1. Press the System Menu button.
2. Use the p or q cursor buttons to highlight OSD LANGUAGE and press OK to
access the OSD submenu.
3. Use the p or q cursor buttons to select the language.
4. Press the OK to conrm the setting.
SOURCE DEFAULT DVD ON/OFF
This allows the user to set the system default source to DVD. If source default
is set to ON, every time the unit is turned o then on, the unit will power up
and automatically switch the source to DVD. If source default is set to OFF and
the unit is turned o then on, the unit will power up in the source that was
last selected. The user can set the system default source to DVD
1. Press the System Menu button.
2. Use the p or q cursor buttons to highlight DEFAULT DVD ON/OFF and press
OK to access the submenu.
3. Use the p or q cursor buttons to select ON or OFF.
4. Press the OK to conrm the setting .
Note: The unit is set to source default DVD on as the default mode of operation.
Selection of Source default can only be made from within the system menu.
SCREEN MODE SELECT
This allows the user to change the screen format (aspect ratio 4:3, 16:9).
To select the screen aspect ratio format:
1. Press the System Menu button.
2. Use the p or q cursor buttons to highlight SCREEN MODE and press OK
to access the screen mode submenu.
3. Use the p or q cursor buttons to select 4:3 or 16:9.
4. Press the OK to conrm the setting.
OFF
16:9
ENGLISH
OSD LANGUAGE
DEFAULT DVD ON/OFF
SCREEN MODE
DEFAULT DVD ON/OFF
ON
4:3
SCREEN MODE
SPANISH
FRENCH
GERMAN
SYSTEM MENU
DEFAULT DVD ON/OFF
SCREEN MODE
FM MODULATOR
OSD LANGUAGE
MONITOR MODE
SYSTEM MENU
OSD LANGUAGE
SCREEN MODE
FM MODULATOR
MONITOR MODE
SYSTEM MENU
OSD LANGUAGE
DEFAULT DVD ON/OFF
FM MODULATOR
MONITOR MODE
M1
M2
MONITOR MODE
SYSTEM MENU
OSD LANGUAGE
DEFAULT DVD ON/OFF
SCREEN MODE
FM MODULATOR
MONITOR MODE

15
MONITOR MODE
This allows the user to set the system monitor code M1/M2.
1. Press the System Menu button.
2. Use the p or q cursor buttons to highlight MONITOR MODE and press
OK to access the monitor mode submenu.
3. Use the p or q cursor buttons to select M1 or M2.
4. Press the M2 button on the remote control after selecting M2.
5. Press OK to conrm the setting.
DVD SETUP MENU SETTINGS AND ADJUSTMENTS
The DVD Setup Menu contains features and options that let the user customize the DVD player. For example, the user can set a language for the on-
screen display or prevent children from viewing DVD playback of adult DVD Titles.
Using the Setup Menu
Press the DVD button and then the SETUP button on the remote. The Setup Menu appears on the
screen as shown.
1. Use the p or q cursor buttons to highlight the settings to be changed. Use the u cursor button to
highlight the sub-setttings. Use the u cursor button to open the submenu that contains the dierent
options available. Press OK to set the desired option.
2. Use the t cursor button to position the highlight back on the icon side of the setup page to set the
other options. Repeat steps 1-2.
3. Press the SETUP button again to exit the Setup Menu.
LANGUAGE SETUP
DVD Language for On-Screen Display
The Language Menu allows the user to select the language for the on-screen display.
The user can select English, French, Spanish, German or Italian for the OSD language.
1. Press the SETUP button on the remote to enter the Setup Menu.
2. Use the p or q cursor buttons to select the Language menu option
3. Use the u cursor button to select language submenu.
4. Use the u cursor button to select language choices
5. Use the p or q cursor buttons to select the desired language, then press OK to conrm the setting.
6. Press the SETUP button on the remote to exit the Setup Menu.
Subtitle
Audio
Language : English
: O
: English
Language
Video
Rating
Misc
SYSTEM MENU
OSD LANGUAGE
DEFAULT DVD ON/OFF
SCREEN MODE
FM MODULATOR
MONITOR MODE
WARNING
SETTING THE MONITOR TO THE M2 MODE WILL
REQUIRE USING 2-CHANNEL HEADPHONES.
USE THE DOWN KEY ON THE REMOTE CONTROL
TO SELECT M2 AND PRESS OK TO SET THE
MONITOR TO M2 MODE
TO REMAIN IN THE M1 MODE PRESS OK
M1
M2
Subtitle
Audio
Language English
French
Spanish
German
Italian
Language
Video
Rating
Misc

16
DVD SUBTITLE SETUP
The Subtitle Menu allows the user to select the language for the on-screen display subtitles.
1. Press the SETUP button on the remote to enter the Setup Menu.
2. Use the p or q cursor buttons to select the Language menu option.
3. Use the u cursor button to select subtitle submenu.
4. Use the q cursor button to select the subtitle option.
5. Use the u cursor button to select subtitle submenu.
6. Use the p or q cursor buttons to select the desired subtitle language, then press OK to conrm the
setting.
7. Press the SETUP button on the remote to exit the Setup Menu.
Note: The subtitle selection is only available for discs that are recorded in the languages listed in the
diagram. If the selected language is not available, the player will play and display on the screen the
original language contained in the disc.
DVD AUDIO SETUP
The Audio Menu allows the user to select the language for audio.
1. Press the SETUP button on the remote to enter the Setup Menu.
2. Use the p or q cursor buttons to select the Language menu option.
3. Use the u cursor button to select audio submenu.
4. Use the q cursor button to select the audio option.
5. Use the u cursor button to select audio submenu.
6. Use the p or q cursor buttons to select the DVD language you desire, then press OK to conrm the
setting.
7. Press the SETUP button on the remote to exit the Setup Menu.
Note: The audio language selection is only available for discs that are recorded in the listed languages.
If the selected language is not available, the player will play and display on the screen the original
language contained in the disc.
Subtitle
Audio
Language English
French
Spanish
German
Italian
Japanese
Chinese
Thai
O
Language
Video
Rating
Misc
Subtitle
Audio
Language
English
French
Spanish
German
Italian
Japanese
Chinese
Thai
Language
Video
Rating
Misc

17
DVD TV DISPLAY
The TV display setup allows the user to set the screen aspect ratio.
4:3 - This displays the wide picture with black bands on the upper and lower portions of the screen.
16:9 - This displays a wide picture with black bands on the upper and lower portion of the screen.
The bandwidth will vary, depending on the aspect ratio of the disc.
1. Press the SETUP button on the remote to enter the Setup Menu.
2. Use the p or q cursor buttons to select the Video menu option.
3. Use the u cursor button to select TV display submenu.
4. Use the u cursor button to select the desired TV display submenu.
5. Use the p or q cursor buttons to select the desired aspect ratio, then press OK to conrm the
setting.
6. Press the SETUP button on the remote to exit the Setup Menu.
DVD TV Type
The TV Type setup allows the user to select the television standard which corresponds to your TV.
NTSC - Select this type for NTSC TV.
PAL - Select this type for PAL TV.
MULTI - Select this type for multi-system TV.
1. Press the SETUP button on the remote to enter the Setup Menu.
2. Use the p or q cursor buttons to select the Video menu option.
3. Use the u cursor button to select TV type submenu.
4. Use the p or q cursor buttons to select the TV type menu option.
5. Use the u cursor button to select the desired TV type submenu.
6. Use the p or q cursor buttons to select the desired TV standard, then press OK to conrm the
setting.
7. Press the SETUP button on the remote to exit the Setup Menu.
Subtitle
Audio
Language English
French
Spanish
German
Italian
Japanese
Chinese
Thai
O
Language
Video
Rating
Misc
Subtitle
Audio
Language
English
French
Spanish
German
Italian
Japanese
Chinese
Thai
Language
Video
Rating
Misc
TV type
TV display 4:3
16:9
Language
Video
Rating
Misc
Subtitle
Audio
Language English
French
Spanish
German
Italian
Japanese
Chinese
Thai
O
Language
Video
Rating
Misc
Subtitle
Audio
Language
English
French
Spanish
German
Italian
Japanese
Chinese
Thai
Language
Video
Rating
Misc
TV type
TV display 4:3
16:9
Language
Video
Rating
Misc

DVD RATING SETUP
Parental
This feature allows the user to limit the content of movie playback from G to Adult. The lower the value, the
more strict the control.
1. G
2. PG
3. PG – 13
4. R
5. NC – 17
6. Adult
The rating level can only be changed when the correct password is provided.
To change the parental control level, perform the following:
1. Press the SETUP button on the remote to enter the Setup Menu.
2. Use the p or q cursor buttons to select the Rating menu option.
3. Use the u cursor button to select parental submenu.
4. Press OK to enter default password (3308) then press OK.
5. Press OK again to select parental submenu.
6. Use the p or q cursor buttons to select the desired rating option, then press OK to conrm the
setting.
7. Press the SETUP button on the remote to exit the Setup Menu.
Change Password
To change the password to a unique password:
1. Press the SETUP button on the remote to enter the Setup Menu.
2. Use the p or q cursor buttons to select the Rating menu option.
3. Use the u cursor button to select parental submenu.
4. Use the p or q cursor buttons to select the change password menu option.
5. Press OK to enter default password (3308) then press OK.
6. Press OK again and key in a new 4 digit password, then press OK to conrm the setting.
7. Press the SETUP button on the remote to exit the Setup Menu.
Note: The Default Password is 3308. This password is always eective even after you have selected your own password and changed it. To avoid the
possibility of others using the default password to set the parental level and change the password, you can record this default password in another area
and delete it from this manual. Some discs can be limited depending on the age of users while some discs cannot.
Parental : 6.Adult
Change Password
Language
Video
Rating
Misc
18
Parental : 6.Adult
Change Password
Enter Password
Language
Video
Rating
Misc

Load Factory
This option allows the user to reset all options to factory settings.
1. Press the SETUP button on the remote to enter the Setup Menu.
2. Use the p or q cursor buttons to select the Misc menu option.
3. Use the u cursor button to select the load factory option, then press OK to enter the submenu.
4. Use the t or u cursor buttons to select the load factory Yes or No, then press OK to conrm the
setting.
5. Press the SETUP button on the remote to exit the Setup Menu.
Note: This function will not aect the Rating control settings.
Screen Saver
This option allows the user to set the Screen Saver mode.
ON - Screen saver will appear
OFF - Screen saver will not appear
1. Press the SETUP button on the remote to enter the Setup Menu.
2. Use the p or q cursor buttons to select the Misc menu option.
3. Use the u cursor button to select the screen saver submenu.
4. Use the q cursor button to select the screen saver option, then press OK to enter the submenu.
5. Use the p or q cursor buttons to select the screen saver on or o, then press OK to conrm the
setting.
6. Press the SETUP button on the remote to exit the Setup Menu.
Note: The DVD player will enter Screen Saver mode if the unit is inactive for approximately 2 minutes.
Screen Saver
Load Factory
Load Factory
Yes No
Language
Video
Rating
Misc
Screen Saver O
Load Factory
On
Language
Video
Rating
Misc
Screen Saver : On
Load Factory
Language
Video
Rating
Misc
Screen Saver
Load Factory
Load Factory
Yes No
Language
Video
Rating
Misc
Screen Saver O
Load Factory
On
Language
Video
Rating
Misc
19
