3
1 m from flammable materials, such as: furniture, pillows, duvets, pa-
per, clothes, curtains, etc. ATTENTION! Do not handle the power cord
and the power cord plug with wet hands. ATTENTION! Unplug the
product from the electric network every time before cleaning, and
also if you do not use it. When connecting the product to an electri-
cal network do not use an adapter. Avoid using an extension cord.
ATTENTION! The power cord plug has a wire and a grounding prong.
Connect the product only to a properly grounded socket. ATTEN-
TION! To avoid overloading the electric network, do not connect the
product with other powerful electrical appliances to the same elec-
tric network. The heater is filled with a certain amount of special oil,
so repairs that require its opening should be performed only in an
authorized (authorized) service center. To avoid extraneous smell,
turn on the radiator at maximum power for at least 2 hours. Dur-
ing the operation of the oil radiator, it is necessary to ventilate the
room to eliminate the smell that may appear when the heater body
is heated. Crackling of the radiator housing when the heater is first
turned on is a normal phenomenon. WARNING! Power cord with Y-
mount. If the power cord is damaged, it must be replaced by the
manufacturer, service center or similarly qualified personnel in or-
der to avoid a hazard. ATTENTION! For additional protection in the
power circuit, it is advisable to install a residual current device with
a rated operating current not exceeding 30 mA. To install the device,
contact a specialist. If the product has been kept for a while at a tem-
perature below 0ºC, it must be left at room temperature for at least
2 hours before switching it on.
ADJUSTMENT
The oil heater is supplied with removed castors (7). You must at-
tach them before starting the radiator yourself. ATTENTION: It is
forbidden to use the oil heater without installed bars with wheels
(7). Use the oil radiator only in a vertical position (bar with wheels
at the bottom, control handles at the top), any other position can
create a dangerous situation.
1. Turn the radiator body over and place it on a flat and stable sur-
face, to avoid damage to the paintwork, place a piece of cardboard
or cloth under the radiator.
2. Screw off the wing nuts from the U-shaped bolt provided
(Fig. 1).
3. Attach the U-shaped bolt between first and second fins (near the
front cover) (Fig.2).
4. Insert the U-shaped bracket into the holes of the bar with the
wheels (Fig. 3).
5. Tighten the wing nuts and secure the wing nuts properly.
Note: Do not over-tighten the wing nuts, as this may damage the
radiator housing.
6. Insert the U-bracket between the penultimate and last fin sections
on the other side of the radiator and repeat steps 4 and 5.
7. Check the radiator and place it on the wheel.
8. Align the wheels and tighten the wing nuts.
OPERATION
Before inserting the plug of the mains cord into the electrical
socket, it is necessary to make sure that the voltage of the elec-
trical network corresponds to the voltage value indicated on the
device and that the electrical socket and the wiring are able to
withstand this load. Connect the heater only to those electrical
outlets that have a reliable grounding system. To avoid the risk of
fire, do not use adapters when connecting the device to an elec-
trical outlet. Install the radiator on a flat, dry and stable surface.
Make sure that the mode switch (4) is set to the “0” position. Plug
the power cord into an electrical outlet. Turn the temperature reg-
ulator (3) clockwise to the “MAX” stop, and the indicator light (2)
will light up. Turn on the radiator by turning the operating mode
switch knob (4):
“1” – low power level of 600 W for small rooms;
“2” – average power level of 900 W for medium-sized rooms;
“3” – high power level of 1500 W for large rooms;
“0” – the radiator is turned off.
When the room temperature reaches the required value, slowly turn
the thermostat knob (3) counterclockwise until the light indicator
(2) turns off. The temperature set in this way will be automatically
maintained. After finishing work, set the thermostat regulator to the
leftmost position, the operating mode switch (4) to the off position
“0”and remove the plug of the power cord from the outlet. Note: the
light indicator (2) will light up only if the room temperature is below
the temperature set by the thermostat knob (3). The room where
the oil radiator is used must have good thermal insulation, other-
wise, due to the inflow of cold air, the operation of the radiator will
not bring the desired results. The ventilation holes on the oil radia-
tor housing must be well ventilated, otherwise the thermostat may
not work properly. Hold the handle (1) when moving the oil radiator.
CLEANING AND CARE
Switch off the radiator and remove the mains plug from the
socket, allow it to cool and wipe the sections with a damp cloth,
then wipe dry. Regularly wipe the oil radiator housing to avoid
accumulation of dust on the surface of the sections. Do not use
abrasive cleaners or solvents to clean the radiator. Avoid scratch-
ing or denting the surface of the sections, as this can cause rust
and premature failure due to oil leakage. After cleaning the radia-
tor, wind the power cord to the winding point (6). Before the next
use of the oil radiator, it is recommended to check the body of the
radiator for damage, the condition of the insulation of the mains
cord and the integrity of the plug of the mains cord, as well as the
device’s operability.
STORAGE
Before storage, make sure that the product is disconnected from electric network. Complete all the requirements of the CLEANING AND CARE
section. Keep the product in a dry, cool place and out of the reach of children.
When disposing of the device, it is necessary to follow the instructions regarding the removal of oil.
ЗАХОДИ БЕЗПЕКИ
Уважно прочитайте цю інструкцію перед експлу-
атацією виробу, щоб уникнути поломок при ви-
користанні. Перед включенням виробу перевірте,
чи відповідають технічні характеристики виробу,
позначені на наклейці, параметрам електромере-
жі. Неправильне використання може призвести
до поломки виробу, завдати матеріальної шкоди
або заподіяти шкоду здоров’ю користувача. Ви-
користовувати тільки в побутових цілях згідно
з цим Керівництвом по експлуатації. Виріб не
призначений для комерційного застосування.
Використовуйте виріб тільки за прямим його
призначенням. Не використовуйте виріб в без-
посередній близькості від кухонної раковини, на
вулиці і в приміщеннях з підвищеною вологістю
повітря. Не користуйтеся приладом у ванній кім-
наті, басейні і т.д. Завжди відключайте виріб від
електромережі, якщо він не використовується, а
також перед чищенням. Виріб не повинен бути без
нагляду, поки він підключений до мережі живлен-
ня. Слідкуйте, щоб мережевий шнур не торкався
гострих кромок меблів і гарячих поверхонь. Не
