Autel APB112 User manual

APB112 SMART KEY SIMULATOR
Quick Reference Guide
Email: [email protected]
Web: www.autel.com

Thank you for purchasing AUTEL tool. Manufactured to a
high standard, our tool will, if used according to these
instructions and properly maintained, give you years of
trouble-free performance.
APB112 smart key simulator is designed to collect the
data sent from the ignition coil, aiming to identify the
ignition coil troubles and decode the data of the vehicle
key chip. It can also simulate the vehicle key chip.
Currently, it supports to simulate the 4D type chip and
more key chip types will be supported with subsequent
upgrades.
1. Status indicator---Indicates the current status (lights
solid blue - the power supply is working properly and in
default state; flashes green – the data interaction
status; flashes red - the status of upgrading; lights solid
red - the Boot status)
2. USB interface---provides power and data
communication
3. Product Information
Product Description
APB112 Smart Key Simulator
3
1
2

Getting Started
IMPORTANT: Before operating or maintaining this
unit, please read these instructions carefully, pay
extra attention to the safety warnings and
precautions. Use this unit correctly and properly.
Failure to do so may cause damage and/or personal
injury and will void the product warranty.
1. Connect the APB112 Smart Key Simulator to Autel
Diagnostic Device using the supplied USB cable.
2. After connection, the status indicator lights solid blue,
indicating that the APB112 Smart Key Simulator is
working properly and then automatically communicates
with the Diagnostic Device.
3. The APB112 Smart Key Simulator application is
automatically upgraded on Autel Diagnostic Device
according to the selected vehicle system function.
4. Place the Smart Key Simulator close to the ignition coil
for data collection, which is used for decoding the chip.
After decoding, the original car chip data can be
copied.
5. The emulator key chip can generate various types of
key chips with subsequent upgrades according to
requirements.
Connection Diagram
Precautions:
1. The APB112 Smart Key Simulator needs to be used
together with the Autel Diagnostic Device.
2. Do not disconnect the USB cable when use.

Packing List
APB112 Smart Key Simulator USB Cable
Quick Reference Guide
Autel guarantees that the APB112 Smart Key Simulator is
free from material and manufacturing for a period of 12
months, whichever comes first. Autel will at its discretion
replace any merchandise during the warranty period. The
warranty shall be void if any of the following occurs:
1. Improper installation of the product;
2. Improper use;
3. Product damage due to collision, man-made damage
or natural disasters;
4. Exceed the product-specific use restrictions.
Warranty
http://pro.autel.com / www.autel.com / [email protected]
0086-755-86147779 (China HQ) /
1-855-288-3587/1-855-AUTELUS (North America)
0049 (0) 61032000522 (Europe) / ([phone] (South
America) / 03 9480 2978 / [phone] (Australia)
© Autel Intelligent Technology Corp., Ltd. All Rights Reserved.
For service and support, please contact us.
