Automatic Technology NeoSlider NES-500 User manual

NeoSliderTM
NES-500 & NES-800 Sliding Gate Openers
Ne Slider™
Doc # 160065_03
Part # 13448
Released 17/03/17

2Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800
Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory
or otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology Australia Pty Ltd Garage Door Opener.
Automatic Technology Australia Pty Ltd hereby further expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever
suffered by any person as a result whether directly or indirectly from failure to install the Automatic Technology Australia Pty Ltd Garage Door Opener in
accordance with these installation instructions.
NeoSliderTM
Sliding Gate Opener NES-500 / NES-800
Contents
1. Important Safety Instructions 3
2. Control Board Layout 4
3. Set Up Requirements 5
3.1 Kit Contents 5
3.2 Choosing your Set up 5
3.3 Initial Checking 5
4. Drive Unit Installation 6
4.1 Mounting the Drive Unit 6
4.2 Installing antenna 6
5. Rack & Limit Actuator Installation 7
5.1 Mounting rack to gate 7
5.2 Fixing limit actuator to rack 7
6. Programming The NeoSliderTM 8
6.1 Common Programs 8
6.2 Powering up the NeoSliderTM 8
7. Safety Beams 8
7.1 Installation of Safety Beams to the NeoSliderTM 8
7.2 Safety Beam Failure Emergency Close (SBFEC) 8
8. Setting Limits 9
8.1 Setting Travel Limits 9
8.2 Setting the left/right installation side settings 9
8.3 Setting close travel limit 9
8.4 Setting open travel limit 9
8.5 Automatic limit adjustment and load profile 9
8.6 Pedestrian access position 9
8.7 Errors during setting of travel limit 9
8.8 Recalculate Force Margins 9
9. Safety Obstruction Force Test 10
9.1 Testing Close Cycle 10
9.2 Testing Open Cycle 10
9.3 Force Pressure For Close and Open Cycle. 10
9.4 Reprofiling Travel 10
10. Coding Transmitter 11
10.1 Coding Transmitter Button 11
10.2 Selecting Function Of The Button 11
10.3 Returning To Main Screen 11
10.4 Selecting The Function To Be Coded 11
11. Emergency Release 12
11.1 Your gate CAN NOT be used by the opener when: 12
11.2 Your gate CAN be used when: 12
11.3 To Disengage the Opener: 12
11.4 To Re-Engage the Opener: 12
12. Setting Pedestrian Position 12
12.1 Setting pedestrian position 12
12.2 Pedestrian Position Set 12
12.3 Error Displays 12
13. Auto-Close Mode 13
13.1 Setting Up Standard Auto-Close 13
13.2 Safety Beam Triggered Auto Close 13
13.3 Pedestrian Auto-Close 13
13.4 Auto-Close After Obstruction 13
14. Accessories Installation 14
14.1 Fitting Solenoid Or Magnetic Locks 14
14.2 Fitting Courtesy Lights 14
15. Battery Replacement 15
16. Battery Disposal 15
17. Specifications 16
18. Troubleshooting 17
19. Appendix 18
A - Console Menu Structure 18
B - Viewing & Editing Parameters 21
C - Control Board Adjustments 22
D- Diagnostic Tools 23
E - Memory Tools 24
F- Transmitter Editing 25
G- Transmitter Managment 26
20. Warranty and Exclusion of Liability 27

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800 3
WARNING! • The gate may operate unexpectedly, therefore do not allow anything to stay in the
path of the gate.
• Do not disengage the gate opener to manual operation with children/persons or any
objects including motor vehicles within the gateway.
• Remove or disengage all gate locks and mechanisms prior to installation of the
opener.
• Make sure the gate is fully open before driving into or out of the driveway.
• When using auto close mode, a Photo Electric beam must be fitted correctly and
tested for operation at regular intervals. Extreme caution is recommended when
using auto close mode. All safety rules must be followed.
ELECTROCUTION! • Do not immerse in or spray the NeoSlider with water .
• Disconnect the power cord from mains power before making any repairs or
removing covers. Only experienced service personnel should remove covers from
the gate opener.
• If the power supply cord is damaged, it must be replaced by an Automatic Technology
service agent or suitably qualified person.
• Connect the gate opener to a properly earthed general purpose 240V mains power
outlet installed by a qualified electrical contractor.
CAUTION:
Entrapment from
operating gate • DO NOT operate the gate opener unless the gate is in full view and free from objects
such as cars and children/people. Make sure that the gate has finished moving before
entering or leaving the driveway.
• Do not allow children to play with gate controls or transmitters.
• In order for the NeoSliderTM to sense an object obstructing the gateway, some force
must be exerted on the object. As a result the object, gate and/or person may suffer
damage or injury.
• Regularly check to make sure that the Safety Obstruction Force is working correctly,
and is tested and set as per Section 12 of this manual. Failure to follow these
instructions could result in serious personal injury and/or property damage. This
test must be repeated at regular intervals and the necessary adjustments made as
required.
• If using a key switch, keypad or any device that can operate the gate opener, make sure
it is in a location where the gateway is visible, but out of the reach of children at a
height of at least 1.5m.
• For ADDITIONAL SAFETY protection we STRONGLY recommend the fitting of a
Photo Electric (Safety) Beam. In most countries Safety Beams are mandatory on all
gates fitted with automatic openers.
Installation • Ensure the gate(s) is in good working order . Faulty gates must be repaired by a qualified
technician prior to NeoSliderTM installation.
Security • Make sure that the gate is fully closed before leaving the driveway.
Entanglement in
or laceration from
moving gate
• Keep hands and loose clothing clear of gate at all times
• Keep clear of gate during operation as severe lacerations can occur on sharp edges of
gate.
1. Important Safety Instructions
The safety alert symbols below indicate a personal safety or property
damage instruction exists. READ THESE INSTRUCTIONS CAREFULLY.
This NeoSliderTM Sliding Gate Opener is designed and tested to offer safe service
provided it is installed and operated in strict accordance with the following safety rules.
Failure to comply with the following instructions may result in death, serious personal
injury or property damage.

4Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800
2. Control Board Layout
V+
0V
SB2 (Safety Beam (2), two, three
wire or wireless)
SB1 (Safety Beam(1), two, three
wire or wireless)
0V
OPN Programmable N/O or
N/C input terminal
STP Programmable N/O or
N/C input terminal
CLS N/O input terminal
OSC N/O input terminal
SWP N/O input terminal
28
29
13
30
30
01
02
03
04
05
06
07
08
09
10
11
12
Fig 2.1
PED N/O input terminal
0V
V+
OUT 2 (optional relay
module coil drive)
V+
OUT 1 N/C relay contact
Engage sensor microswitch
input
Console Previous button
Console Up/Open button
Console Next button
13
Console Exit button
Console Down/Close button
Console SET button
Antenna connector
Console display
PG3 programmer / network connector
Motor connector
24VAC input connector
10 AMP slow blow fuse
Standby battery charger/solar
connector
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
01
02
03
04
05
06
07
08
09
10
11
12
27
15
17
20
22
18
25
14
16
19
21 23
24
26

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800 5
Console Exit button
Console Down/Close button
Console SET button
Antenna connector
Console display
PG3 programmer / network connector
Motor connector
24VAC input connector
10 AMP slow blow fuse
Standby battery charger/solar
connector
3. Set Up Requirements
Fig 3.1
3.1 Kit Contents
3.2 Choosing your Set up
The NeoSlider™ can be set up in various ways and therefore
may require additional items. Common Set ups are as
follows;
ITEM DESCRIPTION QTY
1 DRIVE UNIT NES-500 / NES-800 1
2 TRIO-CODE 4B PTX-5V2 TRANSMITTER 2
3 METAL BASE PLATE 1
4 NUTS, BOLTS AND WASHERS 4
5 METAL FEET W/ DYNABOLTS (4) 2
6 ACTUATOR W/ 2 SCREWS 2
7 ANTENNA 1
1
2
3
Set Up Items Required
Automated Set Up Drive Unit and transmitter
Automated Set Up
with Safety Beams
Drive Unit, transmitter and
safety beams (optional)
CAUTION: Cables which have a green/yellow
coloured insulation are for earthing purposes
only.
Never use these cables for any other purpose.
IMPORTANT WARNING!
A qualified electrician must perform the installation
where 240V AC power is used. 4
6
5
7
3.3 Initial Checking
Before commencing installation of the NeoSlider™, check
the following:
a. The gate moves freely and easily by hand for the full
opening and closing travel.
b. The mounting point must be solidy constructed,
e.g concrete, brick or steel, and must be capable of
withstanding the full force applied to the gate.
c. Select a suitable location for mounting the drive unit.
This position is usually established by fully opening
the gate and mounting the drive unit within a suitable
distance of the gate edge.
d. A weather-proof 240v 10 amp power outlet must
be located within one (1) metre of the NeoSlider™
mounting point.
e. If Safety Beams are to be installed, provision for
underground cabling should be made from one side of
the gateway to the other.
Fig 3.2

6Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800
4. Drive Unit Installation
Fig 4.1
>100
25
50>25
1~2mm
Fig 4.2
4.1 Mounting the Drive Unit
The NeoSlider™ mounting holes are slotted for
fine adjustment of pinion gear and gate rack
alignment. Follow the procedure below to ensure
final adjustments can be made later.
a. Prior to mounting the NeoSlider™, determine
the distance from the gate to the outer edge of
the rack (i.e. the rack width) and to the datum line
(see Fig. 4.1 and Fig. 5.1). If using an Automatic
Technology plastic rack, the width is 40mm. If
using a different brand of rack, please ensure it is
Module 4 and then confirm the width, as this will
vary.
b. Mark a line parallel to the face of the gate for the
mounting holes. The distance from the gate is
determined by the formula (38mm + Rack Width).
Therefore, if using an Automatic Technology
rack, the distance is 78mm. Otherwise, if using
a non-Automatic Technology rack, add your rack
width (and spacers if required) to the 38mm
(see Fig. 4.1).
c. Place the metal feet 5, metal base plate 3
and Drive unit 1in position. If satisfied with the
position,removetheDriveUnitandmetalbaseplate
(Fig. 4.2).
d. Mark the position of the four holes in the metal
feet 5. Drill the four holes.
e. Hammer the dynabolts 4into position, place
metal feet 5and fix with the four washers, spring
washers and nuts 4.
f. Place the metal base plate 3onto of metal feet
and align holes with metal feet.
g. Put Drive unit 1onto metal base plate and affix
with bolts and washers provided. Remember
when tightening the bolts to allow fine adjustment
of the NeoSlider™ later on.
4.2 Installing antenna
Mount the antenna 7at or above the height of the
gate or fence (whichever is higher) for optimal
reception.
Do not cut the coaxial cable.
The Automatic Technology NeoSlider™ sliding gate opener is designed to operate most residential sliding gates. The
gates must be in good working condition and should operate freely by hand. (Refer to 3.1 Initial Checking)

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800 7
Fig 4.1
Fig 4.2
5. Rack & Limit Actuator Installation
5.1 Mounting rack to gate
A strong base on the gate is required for
mounting the rack.
a. Manually open the gate and place a rack
section to mesh with the pinion gear on the
Drive Unit. Mark the top of the rack. Move
the gate and mark the rack for the entire
length of the gate (Fig. 5.1).
b. Position the top edge of the rack on this line
and mark the centres of the rack’s mounting
slots. The first section of rack should start
20mm from the edge of the gate.
c. Drill and tap for 6mm (¼”) screws.
d. Once the first section of the rack is mounted,
check that it meshes with the NeoSlider™
pinion gear.
e. When joining subsequent sections of rack,
check the mesh by placing a spare section
upside down (teeth facing upwards) and
putting it into mesh with the racks being
joined (Fig. 5.2).
f. Tighten the racks. This will ensure that the
NeoSlider™ pinion can run along the racks
without obstruction.
Rack
width
Gate
Rack
Drive
gear
Datum line
To top of
pinion
To bottom of
rack tooth
Maximum height of rack
Fig 5.1
Fig 5.2
Screws and
washers
Actuator
Start Fig 5.3
5.2 Fixing limit actuator to rack
a. Manually open the gate to the open
position and mark this on the gate rack
under the actuating arm.
b. Manually open the gate to the open
position and mark this on the gate rack
under the actuating arm.
c. Place the start of the limit actuator 6at
marked position and move it 5 to 10mm
towards the centre of the gate. Screw the
limit actuator to the rack (Fig. 5.3). Repeat
for the close position.
d. Re-check limit positions by manually
opening and closing the gate, checking to
see that the limit is activated at the desired
open and close position. If neccessary,
make adjustments by sliding the actuator
in the required direction.

8Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800
7. Safety Beams
6. Programming The NeoSliderTM
6.1 Common Programs
The two most common programs are;
Program Menu’s required Function Section
Automated Set Up Menu 10.1 Setting the Limits 8.1
Safety Obstruction Force 9.1 and 9.2
Menu 1 Coding the Transmitter 10.1
Automated Set Up with
Safety Beams
Menu 10.1 Setting the Limits 8.1
Safety Obstruction Force 9.1 and 9.2
Menu 1 Coding the Transmitter 10.1
Menu 3 Auto Close Times 13.2, 13.3 and 13.4
NOTE: Fitting Safety Beams enables the Auto-Close feature to become active.
CAUTION: Before plugging the gate control system in, check the
power cord for damage and ensure it cannot become entangled in
any moving parts
6.2 Powering up the NeoSliderTM
a. After checking the initial wiring, apply power to the NeoSlider™. The
controller will go through a startup sequence displaying the STARTUP
SCREEN which indicates the controller type and firmware version
(Fig. 6.2).After a short delay the MAIN SCREEN will be displayed.
b. If this is the first time the NeoSlider™ has been used, the MAIN SCREEN
should indicate that the limits are not set. If the display shows that some
input is active then rectify the situation before proceeding. If a default
setting is to be changed it should be done now before setting the travel
limits.
Fig 6.2
Fig 6.1
A.T.A NES-500
Firmware #.##
Start up screen
WARNING: When using Safety Beams, the
gateway must be clear of all obstructions and
persons at all times. The location of the beams
and manner in which it is installed might not
give safety protection at all times. Check to
make sure that the height of the beam and
type used give maximum protection possible
WARNING: Tampering with Safety Beams
could result in serious personal injury and/or
property damage and will void the warranty.
7.1 Installation of Safety Beams to the NeoSliderTM
a. Follow the Installation Manual provided with the Safety
Beam to correctly install the Safety Beam.
b. By default the NeoSlider™ will take two wire safety beams.
c. Ensure you program the NeoSlider™ to idenitfy what type
of Safety Beam or combination of Safety Beams you have
installed.
i. Press NEXT to Navigate to Menu 7
ii. Press SET to display Menu 7.1 (for SB1).
iii.Ensure the Safety Beam type is set to two wires.
iv. Press SET to accept the selection.
v. Repeat the same process for Menu 7.2 (SB2) if installed.
NOTE: Wireless Safety Beam functionality is equivalent to 2
WIRE Safety Beams
vi. NOTE: The Power control for one or both three wire
beams is controlled via OUT 1 or OUT 2. To use the
OUT 1, connect black wire from SB to OUT 1. To enable
power control from OUT 1, go to Menu 7.13 and change
OUT1 mode to 3 wire SB 0V.
NOTE: In the case that OUT 1 is used for some other function,
OUT 2 can be used to control 3 wire beams power. Connect
the black wire from SB to OUT 2, then change the OUT 2 mode
in Menu 7.14 to 3 wire SB 0V.
7.2 Safety Beam Failure Emergency Close
(SBFEC)
When the user finds that they are unable to move
the gate and suspect that it is due to a faulty
SAFETY BEAM they can attempt to enter Safety
Beam Failure Emergency Close mode by pressing
and holding a pre-coded button on the remote
control or OPEN/CLOSE button on the console for
more than five seconds. the gate will start closing.
See Appendix C Menu 7.16.

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800 9
Navigating To “Set Gate Travel Menu”
a. Press PREV to navigate to Menu 10.
b. Press SET to display MENU 10.1.
c. Press SET two times to enter the limit setting procedure.
Follow LCD prompts.
8.2 Setting the left/right installation side settings
a. Select left or right installation side by pressing open button
for the correct side (Fig. 8.2).
b. Press SET to confirm.
8.3 Setting close travel limit
a. Press and hold Button 4 on the transmitter to close the gate
i. If the gate is closed too far, press Button 1 to “inch” the
gate towards open.
ii. When happy with the close limit position, press Button 2
to store this in the memory.
NOTE: Limit will not be accepted unless the gate is driven in
the close direction.
8.4 Setting open travel limit
a. Press Button 1 to open the gate.
b. If the gate is opened too far, press Button 4 to “inch” the
gate towards close
c. When happy with the open limit position, press Button 2 on
the transmitter to store into memory..
NOTE: Limit will not be accepted unless the gate is driven in
the open direction.
WARNING: The gate will automatically close and
open once next step is performed. Ensure that no
persons or objects are in the gates path
d. The gate will now automatically close and open to calculate the
safety obstruction settings.
8.5 Automatic limit adjustment and load profile
After a brief pause, the controller will automatically close and
open the gate several times. This adjusts the speed at which
the limits are approached and helps to learn the normal load
profile of the gate. When the setup is complete, the MAIN
SCREEN will be displayed with the gate shown to be OPEN.
The Gate can now be used.
NOTE: Do not press transmitter during limit adjustment
process.
Fig 6.2
8. Setting Limits
The NeoSliderTM has the alternate ability to set travel limits using a TrioCodeTM128 transmitter, allowing free movement
around the gate to better assess the desired limit positions. In order to use a transmitter, it must first have at least one of
its buttons coded to the gate controller. The function assigned to the transmitter’s buttons is of no concern here as the
buttons are temporally assigned to OPEN, CLOSE and SET (Fig. 8.1).
Fig 8.1
Button 1
(Inch
Open)
Button 4
(Inch
Close)
Button 2
(Set)
NOTE: Gate should be moved manually to fully open position. When
re-engaging opener, nudge gate until click is heard to confirm pinion
gear has engaged fully.
8.1 Setting Travel Limits
Navigating to “code transmitter” menu
a. Press NEXT to navigate to Menu 1.
b. Press SET to enter the code set procedure.
Storing Transmitter Code
c. Controller will prompt to press one of the transmitter’s Button.
d. Press the transmitter button you wish to use to operate the gate
opener (e.g. button 1) .
e. Press the same transmitter button again as prompted by display.
f. Press the SET button to store the transmitter.
IMPORTANT NOTE:
Only TrioCodeTM128 Technology Transmitters
are compatible with this product.
8.6 Pedestrian access position
After completing the above procedure, the Pedestrian
access position is automatically set to a position which
is five (5) seconds from the fully closed position of the
gate. The position can be manually set by following
the SETTING PEDESTRIAN POSITION procedure (See
Section 12).
8.7 Errors during setting of travel limit
During the above procedure, many error checks are
preformed. If an error is detected, a message will be
displayed indicating the error.
8.8 Recalculate Force Margins
a. Reprofiling is a simplified way of re-learning the travel
characteristic of a previously setup Limit Switch travel
installation. Re-profiling can be used when the travel
characteristics of the gate change due to mechanical
adjustments etc.
b. To initiate a re-profile simply locate “MENU 10.2
Reprofile Travel”
WARNING: The gate(s) will automatically
close and open. Ensure that no persons or
objects are in the gates path.
c. Press SET then follow the prompts. The gate will start
to move and re-calculate force margins. The gate can
move between the open and close limit positions up
to two (2) times (depending on the position of the gate
and the power up condition).
d. A single beep will be heard once the process is
complete and setup complete message will be
displayed

10 Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800
9. Safety Obstruction Force Test
WARNING! Take care when testing or adjusting the
Safety Obstruction Force. Excessive force may cause
SERIOUS PERSONAL INJURY and/or PROPERTY
DAMAGE.
9.1 Testing Close Cycle
a. Press the OPEN button to open the gate.
b. Place a piece of timber approximately 40mm wide on the
ground directly next to the closing pilon / fence (Fig. 9.1).
c. Press the CLOSE button to close the gate. The gate should
strike the object and start to re-open.
9.2 Testing Open Cycle
a. Press the CLOSE button to close the gate.
b. Press the OPEN button to open the gate. When the gate
reaches the half open point, grab the side rail of the gate
firmly and the gate should stop.
c. If the gate does not reverse readily when closing, or stop when
opening, the force may be excessive and need adjusting.
WARNING! If the gate fails these tests, put the
opener into manual mode, only operate the gate by
hand and call for service.
Fig 9.1
40mm Block of
wood
Safety Obstruction Force
The Safety Obstruction Force is calculated automatically during setup.
Adjusting this is normally only necessitated by environmental conditions
such as windy or dusty areas, and areas with extreme temperature changes.
9.3 Force Pressure For Close and Open Cycle.
Navigating To “Current Trips”
a. Press NEXT or PREV to navigate to Menu 2 Current Trips.
b. Press SET (Fig.9.2)
c. MENU 2.1: CLOSE Margin is displayed (Fig. 9.3).
d. Press UP arrow to increase or DOWN arrow to decrease the value.
e. Press SET to save the new value.
f. Test the force again as per “Safety Obstruction Force Test” in Section
9.1.
9.4 Reprofiling Travel
a. Reprofiling is a simplified way of re-learning the travel characteristic
of a previously setup Limit Switch travel installation. Re-profiling can
be used when the travel characteristics of the gate changes due to
mechanical adjustments etc. To initiate a re-profile, simply locate
“MENU 10.2 Reprofile Travel”, press SET and follow the prompts. The
gate will start to move and re-calculate force margins. The gate can
move between the open and close limit positions up to two (2) times
(depending on the position of the gate and the power up condition).
b. A single beep will be heard once the process is complete.
c. Test the force again as per “Safety Obstruction Force Test” (Section 9.1
and 9.2).
Menu 2
Current Trips
PRESS
Close Margin
(Amps) 0.7
PRESS
Fig 9.2
Fig 9.3

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800 11
Fig 9.1
Fig 9.2
Fig 9.3
Press Tx’er
Button LIST> PRESS
# 1 [ No Name ]
OSC OFF OFF OFF
PRESS
PRESS
10. Coding Transmitter
The NeoSliderTM can store up to thirty (30) transmitters in its
memory. Each transmitter can be allocated an alpha-numeric ID
label up to eleven (11) characters in length and each button can
be assigned to one of several control functions. The settings for a
transmitter are represented in Fig. 10.1. It shows the transmitter’s
store number, ID label or serial number and the functions
assigned to each of the four buttons. To toggle between ID/SN
display, press UP/DOWN with the cursor on the ID/SN indicator.
The procedures below code, delete, replace, edit and copy
transmitter records.
10.1 Coding Transmitter Button
Navigating To Menu 1 “Code Transmitter”
a. Press NEXT to navigate to Menu 1).
b. Press SET to enter the code set procedure.
Storing Transmitter Code
a. The controller will prompt to press one of the transmitter’s
buttons.
b. Press the transmitter button you wish to use to operate the
opener (e.g. button 1) (Fig. 10.2).
c. Press the same transmitter button again as prompted by the
display.
10.2 Selecting Function Of The Button
The controller will now show the transmitter’s record, with a cursor
on the field for the button being coded (Fig. 10.3). Use OPEN/
CLOSE to select the function for the button.
Available functions:
VAC (Vacation Mode) LGT (Courtesy Light)
STP (Stop) OPN (Open)
CLS (Close) SWP (Swipe)
PED (Pedestrian access) OSC (Open/Stop/Close)
OFF (No action)
Press SET to save the settings or STOP to abort without saving.
10.3 Returning To Main Screen
Press EXIT to return to the MAIN SCREEN and test the transmitter.
NOTE: To edit the other settings, refer to transmitter edit
procedure in Appendix F.
123ID Name/SN
OSC PED LGT VAC
I.D label/Serial
number
Button 4
function
Button 3
function
Button 2
function
Button 1
function
Store
number
ID/SN display
indicator
Fig 10.1
Fig 10.2
Fig 10.3
IMPORTANT NOTE:
Only TrioCodeTM128 Technology Transmitters
are compatible with this product.
PRESS
New
transmitter
Existing
transmitter
Fig 10.5
NOTE: To Manage your Transmitters, refer to Transmitter
Management in Appendix G.
Fig 10.4
If a transmitter is already coded into the opener, additional
transmitters can be coded without being in direct contact with
the opener’s wall console unit.
10.4 Selecting The Function To Be Coded
a. Using the existing transmitter, operate the gate with the
transmitter button which has the function to be coded (e.g.
Button 1 has been coded with the OSC function assigned).
b. Use a small pin / pen to press and hold through the Coding Hole
of the existing transmitter for 2 seconds (Fig. 10.4).
c. Within 10 seconds, press the button on the new transmitter
you wish to code for 2 seconds and release (Fig. 10.5).
d. Press the same button again for 2 seconds and release.
e. Test Operation. The new transmitter button should now
function as the existing transmitter.

12 Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800
11. Emergency Release
12. Setting Pedestrian Position
NeoSliderTM can be instructed, via its pedestrian control feature, to
partly open and provide pedestrian access but prevent vehicle access.
NOTE: Before setting the pedestrian access position the gate must be
in the fully closed position. As with the Setting Travel Limit procedure,
a transmitter can be used to complete the pedestrian position setting
procedure.
NOTE: The pedestrian default position is set at five (5) seconds from fully
closed position and can be changed as follows:.
12.1 Setting pedestrian position
Navigating to “Menu 10.3 Set Pedestrian”
a. Press PREV to navigate to Menu 10.
b. Press SET - MENU 10.1 is displayed.
c. Press NEXT to go to MENU 10.3.
d. Press SET to enter Set Pedestrian procedure.
To Set pedestrian position
a. Press OPEN to change the pedestrian access position time (Fig. 14.1).
b. Press SET to record new time.
c. Press transmitter coded for pedestrian function to test.
12.2 Pedestrian Position Set
The controller will return to the MAIN SCREEN with the gate status
shown as being in pedestrian access mode (Fig. 14.2).
12.3 Error Displays
During the above procedure many error checks are performed. If an error
is detected, a message will be displayed indicating the error.
Fig 12.1
Fig 12.2
Ped’n Opening
Time 5
PRESS
PRESS
Ped’n Access
Press <> to Access MENU
11.1 Your gate CAN NOT be used by the opener when:
a. There is a power failure.
11.2 Your gate CAN be used when:
a. There is an emergency, by disengaging the opener.
b. There is a power failure, by disengaging the opener.
11.3 To Disengage the Opener:
a. Push the lid of release chamber and move to the right.
b. Insert the key and turn counterclockwise to unlock the device.
c. Turn the lever counter-clockwise to release the motor.
11.4 To Re-Engage the Opener:
a. Turn the lever clockwise to engage the motor.
b. Turn the key clockwise to lock the device.
c. Move the release chamber to the left to close.
Step 1 Step 2 Step 3
Fig 11.1

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800 13
Fig 12.1
Fig 12.2
WARNING! The Auto-Close function is not
available unless Safety Beam is installed.
13.1 Setting Up Standard Auto-Close
Menu 3. Auto-Close Times
Auto-Close mode is a function that automatically closes
the gate a preset time after the Safety Beam recognise that
a vehicle has left the gateway. The Auto-Close timer only
starts after the Safety Beam path is broken and the Auto-
Close timer has been set. If the Safety Beam path is not
broken, the gate will remain open until the path is broken.
If the opener incurs a physical obstruction (i.e. not from the
Safety Beam) while closing, the gate will re-open and not
Auto-Close until the Safety Beam path is broken again.
Menu 3.1 Auto-Close
This mode is selected by entering a non-zero time for the
STD Auto-Close parameter. When selected, the gate will
Auto-Close after being fully opened (except when the gate
has reversed to the open position after a motor obstruction
or overload unless A/C after open and/or close Obstruction
are selected). Countdown is suspended by: S.B., OPN or
SWP input being active. The countdown is aborted if the
STP input is activated. If the gate is already open and the
OPN or the SWP input is activated, then the countdown
will start.
13.2 Safety Beam Triggered Auto Close
Menu 3.2 (SB AC Trig)
This mode is selected by entering a non-zero time for the
“Safety Beam Auto-Close” parameter. This mode is used
to Auto-Close the gate but only after an object has passed
through the gateway and has triggered the Safety Beam
input. Any Safety Beam or combination of Safety Beams
can be configured to activate Safety Beam Auto-Close
mode and combinations are:
One Beam only
i. Safety Beam 1
ii. Safety Beam 2
Either Beam
i. Safety Beam 1 or Safety Beam 2
Combination
ii. Safety Beam 1 and Safety Beam 2
iii. Safety Beam 2 then Safety Beam 1
NOTE: The swipe input can be used to clear the Safety
Beam triggered status so that the Safety Beam input must
be activated again before the countdown will start. As with
the other Safety Beam modes, the STP input will abort
countdown and the OPN and SWP inputs will restart the
countdown if the gate is OPEN.
13. Auto-Close Mode
13.3 Pedestrian Auto-Close
Menu 3.3 Safety Beam Auto-Close
This mode is selected by entering a non-zero time for the
“Safety Beam Auto-Close” parameter. This mode is used
to Auto-Close the gate but only after an object has passed
through the gateway and has triggered the Safety Beam
input
Menu 3.4 Pedestrian Auto-Close
This mode is selected by entering a non-zero time for
the “Ped’n A/C” parameter. When selected, the gate will
Auto-Close after being opened for pedestrian access
unless it was following a reverse from an obstruction.
Menu 3.5 (Safety Beam) Pedestrian Triggered Auto-
Close
This mode is selected by entering a non-zero time for
the “Safety Beam Pedestrian Auto-Close” parameter.
Any Safety Beam or combination of Safety Beams can be
configured to activate Safety Beam Auto-Close mode and
combinations are:
One Beam only
iv. Safety Beam 1
v. Safety Beam 2
Either Beam
i. Safety Beam 1 or Safety Beam 2
Combination
ii. Safety Beam 1 and Safety Beam 2
iii. Safety Beam 2 then Safety Beam 1
Menu 3.6 (Safety Beam) Pedestrian Auto-Close
This mode is selected by entering a non-zero time for
the “Ped’n A/C” parameter. When selected, the gate will
Auto-Close after being opened for pedestrian access but
only after an object has passed through the gateway and
has triggered the Safety Beam input.
13.4 Auto-Close After Obstruction
Two parameters are provided to enable the Auto-Close
feature to be activated after obstructions and power up.
Normally the Auto-Close feature is not enabled after
obstructions for safety reasons. Safety Beams must be
used for these features to be activated.
Menu 3.7
This mode enables the Auto-Close feature to be activated
when a close obstruction occurs (requires Safety Beams).
Menu 3.8
This mode enables the Auto-Close feature to be activated
when an open obstruction occurs.
Menu 3.9
This mode enables Auto-Close feature after power up.
Fig 11.1

14 Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800
14. Accessories Installation
LIGHT RELAY MODULE
POWER SUPPLY
V+
0V
SAFETY B2
SAFETY B1
OV
OPEN
STOP
CLOSE
OSC
SWIPE
PEDESTRIAN
OV
V+
OUT2
V+
OUT1
Wiring Output1 And Output2
Outputs 1 and 2 are used to control a lock, Light or Safety Beam power. Which output is to control which function and
the way it is controlled is programmable. If using these outputs make sure that the functions are configured for correct
operation prior to setting the travel limits. OUTPUT1 or OUTPUT2 is used to activate an optional external relay module
(RO-1) which in turn is used to switch the load.
14.1 Fitting Solenoid Or Magnetic Locks
Install the lock mechanism on the gate as per the
manufacturers instructions. See Fig. 14.1 for the
wiring diagram.
Menu 4. Lock Times
Lock output can be programmed for both hold
and pulse mode. The operation of the lock can
be programmed to activate prior to the gate and
behave differently on open cycles to that on close
cycles.
a. Press NEXT or PREV on the wall control unit to
navigate to Menu 4 Lock Times.
b. Press SET to select the sub menu.
c. Press NEXT or PREV to navigate through the
sub menu.
d. Press OPEN to increase or CLOSE to decrease
the time.
e. Press SET to save the new time.
f. Press the EXIT button two times to exit and test
the locks operation.
Pulse Lock
LOCK RELAY MODULE
POWER SUPPLY
V+
0V
SAFETY B2
SAFETY B1
OV
OPEN
STOP
CLOSE
OSC
SWIPE
PEDESTRIAN
OV
V+
OUT2
V+
OUT1
Fig 16.1
Fig 16.2
14.2 Fitting Courtesy Lights
An AC or DC courtesy light can be activated via an
output on the gate opener control board. Connect
the light as per the diagram. (Fig. 14.2)
WARNING: A qualified electrician must
perform the installation where 240V
AC power is used.
Menu 5. Light Times
a. Press NEXT or PREV on the wall control unit to
navigate to Menu 5 Light/Lock Times.
b. Press SET to select the sub menu.
c. Press NEXT or PREV to navigate through the
sub menu.
d. Press OPEN to increase or CLOSE to decrease
the time.
e. Press SET to save the new time.
f. Press the EXIT button two times to exit.
g. Test the light operation.

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800 15
15.1 Removing the Battery From the Transmitter
(Battery Type: 3V Lithium Battery CR2032).
Use a non-metallic object (e.g. pen) to remove the battery. (Fig. 15.1). To
test the battery is working, press and hold a transmitter button; (Fig. 15.2).
Light Status Battery Status
Solid OK
Flashing Requires replacement
No light Requires replacement REPLACE
BATTERY WITH
CR2032 ONLY
Fig 15.1
Fig 15.2
Use a pen
to push the
battery down
through the
side opening
to release
battery
When batteries reach the end of their usual life in accordance with
Australian Battery Recycling Initiative please follow the next simple
steps for protecting the environment.
Refer to the Automatic Technology website for information on where
to recycle batteries in Australia.
DO NOT throw the batteries in
municipal waste. This symbol of the
crossed out wheeled bin indicates that
the battery should not be placed in
the municipal waste. Check your local
regulations for appropriate disposal of
the batteries.
Recycling all batteries will have other environmental and social benefits:
•Some batteries are less toxic but hazardous for other reasons. Lithium batteries
can explode or catch fire in landfill, while button cells are dangerous if swallowed
by children. Recycling offers a safe and environmentally responsible solution for
end of life batteries.
•Battery recycling recovers non-renewable materials such as lead, cadmium,
stella, zinc, manganese, cobalt, silver, plastics and rare earth elements.
•Removal of batteries and other hazardous household products from household
waste facilitates the recovery of organic materials through alternative waste
technologies such as composting. Batteries and heavy metals are known
contaminants in compost.
•The community supports recycling because it reduces waste to landfill and
achieves environmental benefits.
WARNING! Prior to disposal,
recycling, or collection, all battery
terminals must be securely insulated
with a non conductive material to
prevent any two batteries from short
circuiting and generating heat during
storage or transport. Battery terminals
may be insulated with electrical tape;
or batteries may be individually
packaged in a non conductive material
(e.g., plastic bag or original packaging).
16. Battery Disposal
15. Battery Replacement

16 Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800
Technical Specifications NES-500 NES-800
Input Voltage: 1, 230 - 240 Vac 230 - 240 Vac
Mains frequency: 50 Hz 50 Hz
Maximum Input Power: 200 W 200 W
Maximum pulling force: 280N 700N
Maximum gate opening: 2, Width:
Weight: 10m Up to 500kg 10m Up to 800kg
Receiver type: TrioCode™128 TrioCode™128
Receiver code storage capacity: 30 x 4 Button Transmitter Codes 30 x 4 Button Transmitter Codes
Transmitter frequency: 433.47, 433.92, 434.37 MHz 433.47, 433.92, 434.37 MHz
Coding type: Hopping Code Hopping Code
No. of code combinations: Over 100 billion random codes Over 100 billion random codes
Code generation: Non-linear encryption algorithm Non-linear encryption algorithm
Transmitter battery: CR2032 CR2032
NOTE:
1. Measurements made at 240Vac.
2. The maximum gate size that the NeoSlider™ NES-500 can be installed on is 10m wide and 500kg and
the NeoSlider™ NES-800 can be installed on is 10m wide and 800kg. The gate must be well balanced.
A person should be able to move the gate manually with very little effort (15kg force max.) in case of an
emergency.
3. Intermittent operations may occur in areas which experience very strong wind gusts. A strong wind puts
extra pressure on the gate and tracks which may in turn trigger the safety obstruction detection system
intermittently.
NOTE:Specifications are subject to change without notice.
17. Specifications

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800 17
Symptom Possible cause Remedy
Gate will not operate Mains power not switched on. Switch on mains power.
Opener motor is disengaged Check that the motor is engaged for automatic
operation
Gate is obstructed. Remove obstruction.
The opener is in “Vacation Mode” Turn off “Vacation Mode”(Appendix C Menu 7.4).
Gate starts to close but
automatically reverses to
open position
Adverse weather conditions (wind
or cold) causing gate to stiffen and
become tight in the tracks.
Increase force margin setting (Section 9.4)
Possible obstruction in the
gateway triggering Safety Beams. Remove obstruction
Gate operates from opener
but not from transmitter
Transmitter code not stored in
memory. Code transmitter in to openers memory. (Section 10.1)
Transmitter does not contain
TrioCode™ 128 Technology
Check the transmitter. It should have grey buttons
and the model number should display V3. Contact
dealer for support if otherwise.
Flat battery in transmitter Replace battery (Section 15)
Antenna behind structure (gate or
fence) or not in line of sight Ensure Antenna is in line of sight (Section 5.2)
Gate does not close with
transmitter Safety Beam not working properly. Make sure Safety Beams are operational. and no dirt is on the lens.
Gate will not close fully. Gate limit positions need to be
reset. Reset limits positions.
Gate obstructed and reverses Clear obstruction or adjust force margin
(Section 9.3)
Gate will not open fully. Gate limit positions need to be
reset. Reset limits positions. (Section 8)
Gate obstructed. Clear obstruction or adjust force margin
(Section 9.3)
Auto-Close not working Safety Beam not installed. Install Safety Beam. (Section 6)
Safety Beam or wiring faulty. Repair Safety Beam or replace wiring.
Safety Beam not aligned correctly. Re-align optics.
Safety Beam is obstructed. Remove obstruction from path of Safety Beams.
Gate obstructed when closing. Remove obstruction.
Auto-Close time not set. Set Auto-Close times (Section 13.3).
Auto-Close mode not set Set Auto-Close mode. (Section 13.2)
18. Troubleshooting

18 Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800
Parameter Min Max Default Step Unit Menu Section
Menu 1 - Code Transmitter
STORING TRANSMITTERS 0.0 511 110.1
Menu 2 - Current Trips
M1 MARGIN
Sets obstruction detection margin for M1 0.0 4.0 0.7 0.1 AMPS 2.1 9.3
SETTLE TIME disable the obstruction detection in the start of
the cycle 0.1 2.0 1.0 0.1 SEC 2.2
Menu 3 - Auto Close
STD AUTO-CLOSE TIME
Sets and enables the standard Auto-Close time 0.0 300.0 0.0 1.0 Sec 3.1 15.1
SAFETY BEAM AUTO-CLOSE TIME Sets and enables the SB
triggered Auto-Close time 0.0 60.0 0.0 1.0 Sec 3.3 15.2
PEDESTRIAN AUTO-CLOSE TIME Sets and enables the
Pedestrian Auto-Close time 0.0 60.0 0.0 1.0 Sec 3.4 15.3
SAFETY BEAM PEDESTRIAN AUTO-CLOSE TIME Sets and
enables the SB Pedestrian Auto-Close time 0.0 60.0 0.0 1.0 Sec 3.6 15.3
AUTO-CLOSE AFTER CLOSE OBSTRUCTION
Enables Auto-Close feature after close obstructions Off On Off 3.7 15.4
AUTO-CLOSE AFTER OPEN OBSTRUCTION
Enables Auto-Close feature after open obstructions Off On Off 3.8 15.4
AUTOCLOSE AFTER POWERUP
Enables autoclose feature after powerup Off On Off 3.9 15.4
Menu 4 - Lock Times
OPEN LOCK TIME Set the time the lock is activated for on
open cycles 0.0 Hold 0.5 0.1 Sec 4.1 16.1
CLOSE LOCK TIME Set the time the lock is activated for on
close cycles 0.0 Hold 0.5 0.1 Sec 4.2 16.1
PRE-OPEN LOCK TIME Time the lock is activated for prior to
opening 0.0 25.5 0.0 0.1 Sec 4.3 16.1
PRE-CLOSE LOCK TIME Time the lock is activated for prior to
closing 0.0 25.5 0.0 0.1 Sec 4.4 16.1
Menu 5 - Light Times
ON AFTER CYCLE LIGHT TIME - Time light remains on for
after a cycle 0255 60 1Sec 5.1 16.2
ON BEFORE OPEN CYCLE LIGHT TIME
Minimum time light is activated for prior to opening 0255 0 1 Sec 5.2 16.2
ON BEFORE CLOSE CYCLE LIGHT TIME
Minimum time light is activated for prior to closing 0255 0 1 Sec 5.3 16.2
Menu 6 - Motor Settings
OPEN SPEED VOLTS
Voltage applied to motors when opening 12 24 22 1VOLTS 6.1
CLOSE SPEED VOLTS
Voltage applied to motors when closing 12 24 20 1VOLTS 6.2
SLOW SPEED VOLTS
Voltage applied to motors when slowing down 624 8 1 VOLTS 6.3
SLOW TIME
The time between slow down and end of cycle 0.1 10.0 3.0 0.1 SEC 6.4
OPERATIONAL BUTTONS:
1. Press PREV/NEXT buttons move to Left/Right.
2. Press OPEN/CLOSE buttons to change setting.
3. Press SET button to save changes.
4. Press EXIT to return to MENU without saving changes.
19. Appendix
A - Console Menu Structure

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800 19
Parameter Min Max Default Step Unit Menu Section
Menu 1 - Code Transmitter
STORING TRANSMITTERS 0.0 511 110.1
Menu 2 - Current Trips
M1 MARGIN
Sets obstruction detection margin for M1 0.0 4.0 0.7 0.1 AMPS 2.1 9.3
SETTLE TIME disable the obstruction detection in the start of
the cycle 0.1 2.0 1.0 0.1 SEC 2.2
Menu 3 - Auto Close
STD AUTO-CLOSE TIME
Sets and enables the standard Auto-Close time 0.0 300.0 0.0 1.0 Sec 3.1 15.1
SAFETY BEAM AUTO-CLOSE TIME Sets and enables the SB
triggered Auto-Close time 0.0 60.0 0.0 1.0 Sec 3.3 15.2
PEDESTRIAN AUTO-CLOSE TIME Sets and enables the
Pedestrian Auto-Close time 0.0 60.0 0.0 1.0 Sec 3.4 15.3
SAFETY BEAM PEDESTRIAN AUTO-CLOSE TIME Sets and
enables the SB Pedestrian Auto-Close time 0.0 60.0 0.0 1.0 Sec 3.6 15.3
AUTO-CLOSE AFTER CLOSE OBSTRUCTION
Enables Auto-Close feature after close obstructions Off On Off 3.7 15.4
AUTO-CLOSE AFTER OPEN OBSTRUCTION
Enables Auto-Close feature after open obstructions Off On Off 3.8 15.4
AUTOCLOSE AFTER POWERUP
Enables autoclose feature after powerup Off On Off 3.9 15.4
Menu 4 - Lock Times
OPEN LOCK TIME Set the time the lock is activated for on
open cycles 0.0 Hold 0.5 0.1 Sec 4.1 16.1
CLOSE LOCK TIME Set the time the lock is activated for on
close cycles 0.0 Hold 0.5 0.1 Sec 4.2 16.1
PRE-OPEN LOCK TIME Time the lock is activated for prior to
opening 0.0 25.5 0.0 0.1 Sec 4.3 16.1
PRE-CLOSE LOCK TIME Time the lock is activated for prior to
closing 0.0 25.5 0.0 0.1 Sec 4.4 16.1
Menu 5 - Light Times
ON AFTER CYCLE LIGHT TIME - Time light remains on for
after a cycle 0255 60 1Sec 5.1 16.2
ON BEFORE OPEN CYCLE LIGHT TIME
Minimum time light is activated for prior to opening 0255 0 1 Sec 5.2 16.2
ON BEFORE CLOSE CYCLE LIGHT TIME
Minimum time light is activated for prior to closing 0255 0 1 Sec 5.3 16.2
Menu 6 - Motor Settings
OPEN SPEED VOLTS
Voltage applied to motors when opening 12 24 22 1VOLTS 6.1
CLOSE SPEED VOLTS
Voltage applied to motors when closing 12 24 20 1VOLTS 6.2
SLOW SPEED VOLTS
Voltage applied to motors when slowing down 624 8 1 VOLTS 6.3
SLOW TIME
The time between slow down and end of cycle 0.1 10.0 3.0 0.1 SEC 6.4
OPERATIONAL BUTTONS:
1. Press PREV/NEXT buttons move to Left/Right.
2. Press OPEN/CLOSE buttons to change setting.
3. Press SET button to save changes.
4. Press EXIT to return to MENU without saving changes.
Parameter Option Default Menu Section
Menu 7 - Operating Modes
SB1 TYPE 2 WIRE
3 WIRE 2 WIRE 7.1 Appendix C
SB2 TYPE 2 WIRE
3 WIRE 2 WIRE 7.2 Appendix C
SB1 INPUT MODE
Sets the Input mode for Safety Beam 1.
Only one option can be selected.
NOT USED, CLS TO REV
CLS TO STOP OPN/CLS TO STOP
OPEN INPUT SWIPE INPUT
CLOSE INPUT PED INPUT
DISABLED
NOT USED 7.3 Appendix C
SB2 INPUT MODE
Sets the Input mode for Safety Beam 2.
Only one option can be selected.
NOT USED, CLS TO REV
CLS TO STOP OPN/CLS TO STOP
OPEN INPUT SWIPE INPUT
CLOSE INPUT PED INPUT
DISABLED
NOT USED 7.4 Appendix C
PED INPUT = SWIPE MODE Selects PED
input functions as pedestrian access swipe
input
Off Off 7.5 Appendix C
OPN INPUT N/C OPERATION
Selects operating polarity of OPN input Off Off 7.6 Appendix C
STP INPUT N/C OPERATION
Selects operating polarity of STP input Off Off 7.7 Appendix C
REMOTE CODE ENABLED
Selects remote transmitter coding function On On 7.8 Appendix C
VACATION MODE
Selects vacation mode - disables remote
control
Off Off 7.9 Appendix C
BATTERY/SOLAR MODE
Selects Battery Backup/Solar operation BATTERY ENABLED SOLAR ENABLED BATTERY ENABLED 7.10 Appendix C
PASSWORD
Selects password protection for all changes Off Off 7.11 Appendix C
TX # GROUPING
Selects transmitter number group display
format.
Off Off 7.12 Appendix C
OUTPUTS 1 MODE
Selects function of OUTPUT1 LOCK DRIVE LIGHT DRIVE 3 WIRE SB 0V NOT USED 7.13 Appendix C
OUTPUTS 2 MODE
Selects function of OUTPUT2 LOCK DRIVE LIGHT DRIVE 3 WIRE SB 0V NOT USED 7.14 Appendix C
FAULT AUTO RESET Off Off 7.15 Appendix C
SBFEC MODE AVAILABLE
DISABLED AVAILABLE 7.16 Appendix C
Menu 8 - Diagnostics
TEST INPUTS - Controls input display
status Inactive 8.1 Appendix D
TEST TRANSMITTERS (TX’ERS) 8.2 Appendix D
DISPLAY HISTORY 8.3 Appendix D
MEMORY USAGE 8.4 Appendix D
SERVICE COUNTER 60,000 8.5 Appendix D
EVENT COUNTER 8.6 Appendix D
Parameter Min Max Default Step Unit Menu Section
HOMING / SETUP SPEED VOLTS
Voltage applied to motors when setting up the travel limits 12 24 12 1Volts 6.5
STOP PAUSE TIME
Pause time used between motor direction changes 0.0 2.0 0.3 0.1 SEC 6.6

20 Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-500 / NES-800
A - Console Menu Structure
Appendix
Parameter Option Default Menu Section
Menu 9 - Memory Tools
CLR CONTROL 9.1 Appendix E
CLR TRANSMITTERS (TX’ERS) 9.2 Appendix E
Menu 10 - Setup Travel
LIMIT TRAVEL 10.1 8.1
REPROFILE TRAVEL 10.2 9.5
SET PEDESTRIAN 10.3 14.1
NOTE: The System will automatically return to
the main screen after 30 secs if a menu screen is
displayed and no buttons are pressed.
Fig B.1
Fig B.2
