Automatic Technology Easy Slider User manual

Easy Slider
INSTALLATION INSTRUCTIONS | OWNERS COPY
Sliding Gate Opener

2Easy Slider - Sliding Gate Opener Owner Installation Instructions
WARNING: It is vital for the safety of persons to follow all
instructions. Failure to comply with the installation instructions
and the safety warningsmay result in serious personal injury
and/or property and remote control opener damage. Please
save these instructions for future reference.
Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all
conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of an
Automatic Technology Australia Pty Ltd Sliding Gate Opener and Automatic Technology Australia Pty Ltd hereby further
expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any person
as a result whether directly or indirectly from failure to install the Automatic Technology Australia Sliding Gate Opener in
accordance with these installation instructions.

Owner Installation Instructions Easy Slider - Sliding Gate Opener 3
Important safety instructions 5
Features 7
Product description 9
Drive unit installation 10
Rack installation 11
Control board layout 12
Menu structure 14
Initial electrical installation 15
Powering up drive unit 16
Setting travel limits for single leaf gate 16
Setting travel limits for dual leaf gate 18
Setting pedestrian position 20
Description of standard operation 21
Control board adjustments 22
Menu 2 Obstruction margins 22
Menu 3 Auto-close times 22
Menu 4 Lock times 23
Menu 5 Light times 23
Menu 6 Motor settings 23
Menu 7 Operating modes 24
Viewing and editing parameter 25
Coding transmitter 26
Transmitter edit procedure 27
Transmitter management 29
Code operation (location empty) 30
Code operation (location used) 30
Delete operation 30
Edit operation 30
Copy operation 30
Easy Slider
Sliding Gate Opener
Remote code set procedure 31
Diagnostic tools (menu 8) 32
Menu 8.1 Test inputs 32
Menu 8.2 Test tx’ers 32
Menu 8.3 Display history 32
Menu 8.4 Memory usage 32
Menu 8.5 Service counter 33
Menu 8.6 Counters 33
Memory tools (menu 9) 34
Menu 9.1 Clr control 34
Menu 9.2 Clr tx’ers 34
Menu 9.3 Backup memory 34
Menu 9.4 Restore control 34
Menu 9.5 Restore tx’ers 34
Menu 9.6 Import labels 34
Accessories installation 35
Trouble shooting guide 36
Specifications 37
Parts list 38
Warranty and exclusion of liability 40

4Easy Slider - Sliding Gate Opener Owner Installation Instructions
FOR ADDITIONAL SAFETY protection we strongly recommend the fitting of a Photo
Electric Beam. In most countries Photo Electric Beams are mandatory on all gates fitted
with automatic openers. For a small additional outlay ATA recommends that Photo
Electric Beams be installed with the automatic opener ensuring additional safety
and peace of mind.
DO NOT operate the gate opener unless the gate is in full view and free from objects such as
cars and children/people. Make sure that the gate has finished moving before entering or
leaving the driveway.
DO NOT operate the gate opener when children/persons are near the gate. Children
must be supervised near the gate at all times when the gate opener is in use. Serious
personal injury and/or property damage can result from failure to follow this warning.
DO NOT allow children to operate the sliding gate opener. Serious personal
injury and/or property damage can result from failure to follow this warning.
Make sure that the safety obstruction detection system is working correctly,
and is tested every month. Test as per the Installation Instructions Manual.
Adjust if necessary and recheck. Failure to follow this rule could result
in serious personal injury and/or property damage. This test must be
repeated at regular intervals and the necessary adjustments made as
required.
DO NOT disengage the sliding gate opener to manual operation
with children/persons or any other objects including motor vehicle
within the gateway.
If using a key switch or keypad or any device that can operate
the sliding gate opener, make sure it is out of reach of
children and that the gateway is in full view at all times.
If the power supply cord is damaged, it must be
replaced by an ATA service agent or suitably qualified
person.
Make sure that remote controls are kept out of
reach of children.
WARNING: It is vital for the safety of persons to follow
all instructions. Failure to comply with the following
Safety Rules may result in serious personal injury and/or
property damage.
Important safety instructions

Owner Installation Instructions Easy Slider - Sliding Gate Opener 5
The opener is showerproof - it should not be immersed in water or sprayed directly by a hose or other water
carrying device.
The gate(s) must be well balanced. and in good working order. Faulty gates must be repaired by a
qualified technician prior to opener installation.
Remove or disengage all gate locks and mechanisms prior to installation of the opener.
Connect the gate opener to a properly earthed general purpose 240V mains power outlet
installed by a qualified electrical contractor.
Disconnect the power cord from mains power before making any repairs or removing
covers. Only experienced service personnel should remove covers from the gate opener.
Keep hands and loose clothing clear of the gate and opener at all times.
When using auto close mode a photo electric beam must be fitted correctly and
tested for operation at regular intervals. extreme caution is recommended when
using auto close mode. all safety rules above must be followed.
In order for the gate opener to sense an object obstructing the gateway, some
force must be exerted on the object. As a result the object, gate and/or
person may suffer damage or injury.
Make sure that the gate is fully open before driving into or out of the
driveway. And make sure the gate is fully closed before leaving the
driveway.
The gate opener is not intended for use by young children or
infirm persons without adequate supervision. Children should
be supervised to ensure that they do not play with the remote
transmitters or the opener.
Frequently examine the installation, in particular guides
and mountings for signs of wear, damage or imbalance.
DO NOT use if repair or adjustment is needed since
a fault in the installation or an incorrectly balanced
gate may cause injury.
Important safety instructions
Please read this instruction manual fully before attempting
to install or use the opener. Failure to comply with the
installation instructions may result in serious injury and/or
property damage.

6Easy Slider - Sliding Gate Opener Owner Installation Instructions
Dual leaf gate
The opener’s integrated controller is able to control a two leaf sliding gate with
the addition of a slave opener. Interconnection is via 5 wire with mains power
only required for the master drive unit.
Operation
To activate the gate simply press a button on the remote control transmitter,
keypad or many other devices such as key switch, loop detector, etc. During an
open or close cycle the gate can be stopped by pressing the button while it is in
motion. The next actuation will move the gate in the opposite direction.
Operator console
The EasySlider features a LCD display operator console which simplifies installation,
adjustments and status indication. Features include editing transmitter storage and
names, setting parameters, selecting specialised operating modes and preforming
system diagnostics.
Hopping code transmitters
Every time a transmission is made from the remotetransmitter a new security code is generated.
The number of possible code combinations is over 4.29 billion. This greatly enhances the security
of the system. Code “grabbing” is made a thing of the past.
Security code store
The EasySlider Sliding Gate Opener uses state of the art technology in storing your selected transmitter
codes. Up to thirty (30) transmitters can be stored in the opener’s memory with the facility to assign an 11
character name to each transmitter.
ALPS (Automatic Limits Positioning System)
A revolutionary gate travel limit setting system. The ALPS technology eliminates manual adjustment of the
gates limits position using mechanical parts such as micro switches and cams. In addition, the opener’s
display console guides you through the installation and set up.
Features
Thank you for purchasing the ATA EasySlider
Automatic Gate Opener. This opener is designed
to suit residential sliding gates. The components
and materials used in this opener are of the latest
technology and highest quality. Listed below
are some of the many features.

Owner Installation Instructions Easy Slider - Sliding Gate Opener 7
The ALPS technology calculates the gates travel limit positions and stores it in memory. If the gate is moved
manually during power failure, the ALPS will re-align the gate limits transparently during the first operations
after power is restored and stop at the correct limit position.
During installation, a hand held transmitter can be used when setting the gate travel limits. This allows the
installer to closely monitor and control the gates movement from any position rather than having to be within
arms reach of the console.
ISS (Intelligent Safety Obstruction System)
Should the gate hit an obstacle while it is performing a close cycle, or be restricted in some
manner, it will automatically reverse. The amount of force the gate should encounter before
reversing is automatically adjusted by the control system during the initialisation of
the automatic opener. The gate will also stop if restricted whilst opening. The Safety
Obstruction Force should be checked at least once a month. See installation manual
for instructions.
Status indicator
The console displays the status of the opener on the LCD screen. When the MAIN
SCREEN is displayed, the current position of the gate or the result of the last
movement can be viewed. The display will also show the count down progress of
auto-close timers. Any active input will also be displayed along with the state of
various features such as periodic service, battery backup operation and vacation
mode.
Control of lock and lights
The incorporated controller has dedicated outputs for operating a electric lock
and warning or courtesy lights. The timing of these outputs can be adjusted to
suit your needs. In addition a button on a remote control can be coded to operate
the light output.
Extensive operating modes via control inputs and remote control
The integrated controller can be configured to operate in many different ways via
its seven (7) control and safety inputs which include P.E, OPEN, STOP, CLOSE, OSC,
SWIPE and PEDESTRIAN.
Remote control operation is provided with each transmitter’s button being able to be
configured to operate one of OSC, PEDESTRIAN, SWIPE, CLOSE, OPEN, STOP, LIGHT or
VACATION functions.
The controllers functionality is further enhanced by 4 auto-close modes, 3 P.E response modes and
two pedestrian response modes.
Battery backup and solar operation
The opener can be fitted with optional battery backup or solar chargers to provide operation during power
outages or at unpowered sites.
Manual operation
The opener is equipped with a unique manual disengaging device. If the power to the opener is disrupted
for any reason the gate can disengaged via a key lock located on the operator. This will allow you to manually
open or close the gate.
Features

8Easy Slider - Sliding Gate Opener Owner Installation Instructions
Product description
The ATA EasySlider sliding gate opener kit consists of one driveunit with integrated controller, two hand held
transmitters and pre-wired antenna.
Integrated controller
The integrated controller is able to control a single or dual leafgate. The antenna is pre-wired, ready to be
mounted on the fence-line. An outdoor type 240V AC power outlet is required to powerthe system. In a dual
leaf gate, the slave drive unit is connected tothe master via a five (5) wire low voltage cable. AC power is not
required by the slave unit.
Mechanical drive unit
The drive unit consists of a powerful 24V DC motor, rugged gearbox assembly and travel limits position
encoder. It also provides a key lockable manual release lever. When used with suitable cable glands the
enclosure meets the IP33 standard for ingress of dust and water.
01
fig

Owner Installation Instructions Easy Slider - Sliding Gate Opener 9
Drive unit installation
The ATA EasySlider sliding gate opener is designed to operate most residential sliding gates. The gates must
be in good working condition and should operate freely by hand.
Step 1. Initial checking
Before commencing installation of the Easy Slider sliding gate opener, check the following:
1. The gate moves freely and easily by hand for the full opening and closing travel.
2. The mounting must be solid construction (concrete, brick or steel. It must be able to withstand the full force
applied to the gate.
3. Select a suitable location for mounting the drive unit. This position is usually established by opening the gate
fully and mounting the drive unit within a suitable distance of the gate edge.
4. A weather-proof 240V 10Amp power outlet is located within one (1) metre of the master drive unit’s mounting
point.
5. If dual gate openers are required provision for underground cabling should be made from one side of the
gateway to the other. This may also be required for wiring of Photo-Electric Beams or other accessories.
02
fig
Cover release screw
Disengage lever
Cover release screw

10 Easy Slider - Sliding Gate Opener Owner Installation Instructions
Drive unit installation
Mounting the drive unit
The Drive Unit mounting holes are slotted for fine adjustment of pinion gear and gate rack alignment. Follow
the procedure below to ensure final adjustments can be made later.
We recommend that four 8mm (5 /
16”) or 10mm (3
/
8”) loxins and bolts are used to secure the Drive Unit into
position. These loxins usually require a 16mm ( 5 /
8”) masonry drill bit (if drilling concrete).
1. Prior to mounting of the driver unit determine the distance from the gate to the outer edge of the rack (ie the rack
width) to the datum line (see Fig. 03 and Fig. 04). For the ATA plastic racks the width is 40mm. The rack distance
may vary depending on the type of rack used. If you must use a different rack, make sure that it is Module 4.
2. Mark a line 78mm parallel to the face of the gate for the mounting holes when using the ATA plastic rack.
When using a non ATA rack, add your rack width (and spacers if required) and 38mm and mark a line this
distance from the face of the rack (see Fig. 03).
3. Then mark another line 100mm from the first line (see Fig. 03).
4. Open the gate to the desired open position. Mark a line at right angle to the gate 120-150mm from the open
edge of the gate for the mounting holes.
5. Then mark another line 268mm parallel to this line (see Fig. 03).
6. Place the Drive Unit in position where the lines intersect to check the mounting position. If satisfied with the
position remove the Drive Unit.
7. Drill the four mounting holes where the lines intersect.
8. Hammer the loxins into position. Place the Drive Unit into position and fix with the four bolts so that you are
still able to move the Drive Unit.
03
fig
Rack width
Datum line
Mounting holes
Gate

Owner Installation Instructions Easy Slider - Sliding Gate Opener 11
Rack installation
04
fig
Mounting rack to gate
A strong base on the gate is required for mounting
the rack.
1. Manually open the gate and place a rack section to
mesh with the pinion gear on the Drive Unit. Mark
the top of the rack. Move the gate and mark the rack
for the entire length of the gate.
2. Position the top edge of the rack on this line and
mark the centres of the racks mounting slots. The
first section of rack should start 20mm from the edge
of the gate.
3. Drill and tap for 6mm (¼”) screws.
4. Once the first section of the rack is mounted on the
gate, check that it meshes with the pinion gear on
the drive unit.
5. When joining subsequent sections of rack, check the
mesh by placing a spare section upside down (teeth
facing upwards) and putting it into mesh with the
racks being joined (Fig. 05).
6. Tighten the racks. This will ensure that the drive unit
pinion canrun along the racks without obstruction.
05
fig
Drive unit
Rack
width
Gate
Rack
Drive gear
Datum line
To top of pinion
To bottom of
rack tooth

12 Easy Slider - Sliding Gate Opener Owner Installation Instructions
*24VDC output for powering accessories 3A(max)
*Lock relay output N/C contact
*Lock relay output COM contact
*Lock relay output N/O contact
Slave/Master connections
*COM terminal for inputs terminals 8 - 14
*P.E N/C input terminal
*OPN N/C input terminal
*STP N/C input terminal
*CLS N/O input terminal
*OSC N/O input terminal
*SWP N/O input terminal
*PED N/O input terminal
*PE input jumper (remove when 8 is used)
*OPN input jumper (remove when 9 is used)
*STP input jumper (remove when 10 is used)
*Console Exit button
*Console Previous button
*Console Down/Close button
*Console Up/Open button
*Console SET button
*Console Next button
*Antenna connector
*Console Display
Motor installation side selector
*Optional light module interface connector
*Standby battery charger/solar connector
* Not present on slave unit
01
03
02
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Control
board layout

Owner Installation Instructions Easy Slider - Sliding Gate Opener 13
Control board layout
01
03
02
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
24
25
28
22
23
2627

14 Easy Slider - Sliding Gate Opener Owner Installation Instructions
Menu structure
Menu 8
Diagnostics
Menu 9
Memory tools
Menu 10
Travel limits
Menu 1
Code
transmitter
Menu 2
Obstruct
margins
Menu 3
Auto-close
times
Main Screen
Gate status &
information
Menu 10.1
Set gate
travel
Menu 10.2
Set pedestrian
Code/edit
transmitter
procedure.
See page XX
Parameter list
1. M1 margin
2.M2 margin
See page XX
Parameter list
1. STD
autoclose
2. P.E. autoclose
3. Ped’n
autoclose
4. P.E. Ped’n
autoclose
See page XX
Travel limit set
up procedure.
See page XX
Ped’n position
set up
procedure.
See page XX
Menu 9.1
CLR control?
Menu 9.2
CLR Tx’ers?
Menu 9.4
Restore Tx’ers?
Menu 9.5
Import labels?
Menu 9.3
Backup Tx’ers?
Memory reset/reload operations see page XX
Menu 8.1
Test inputs
Menu 8.2
Test tx’ers
Menu 8.3
Display history
Menu 8.5
Service counter
Menu 8.6
Counters
Menu 8.4
Memory Usage
Control input
status display.
See page XX
Transmitter
testing
See page XX
Event history
display
See page XX
Periodic service
cycle counter
See page XX
Cycle and
event counter
See page XX
Memory usage
See page XX
Parameter list 1. On after cycle time 2. On before opn time 3. On before cls time See page XX
Parameter list 1. Full speed voltage 2. Gate leaf sync delay 3. Extra delay on close See page XX
Parameter list 1. PE input response 2. Ped input response 3. Remote code enable 4. Activity report ETC See page XX
Parameter list 1. Open lock time 2. Close lock time 3. Pre-opn lock time 4. Pre-cls lock time. See page XX
NOTES 1. Press PREV/NEXT buttons move to Left/Right. 2. Press OPEN/CLOSE buttons to change setting. 3. Press SET button to save changes. 4. Press EXIT to return to MENU without saving changes. Note: System will automatically return to the main screen after 30 secs if a menu screen is displayed and no buttons are pressed.
Menu 5
Light times
Menu 6
Motor settings
Menu 7
Operating
Modes
Menu 4
Lock times

Owner Installation Instructions Easy Slider - Sliding Gate Opener 15
Initial electrical installation
CAUTION: Cables which have a green/yellow
coloured insulation are for earthing purposes
only. Never use these cables for any other
purpose.
Step 1. Installing antenna
Mount the antenna at or above the height of the gate
or fence (which ever is higher) for optimal reception.
Do not cut the coaxial cable.
Step 2. Connecting motor1 (master) and
motor2 (slave) drive units
When dual gates are to be used the master and
slave openers are connected via a five (5) wire cable
(Fig. 07). Ensure that each end of the cable passes
through a suitable cable gland which in turn is securely
tightened to prevent ingress of dust, pests and water.
NOTE: The controller permits either Motor 1 or Motor
2 to be selected to open first, therefore, the side that
each drive unit is mounted on is not fixed to which
gate opens first.
Step 3. Selecting left or
right hand installation
Refer to (Fig. 08) and (Fig. 09), place the motor
connector for each drive unit as required.
07
fig
08
fig
09
fig
Left hand
Right hand

16 Easy Slider - Sliding Gate Opener Owner Installation Instructions
Setting travel limits


   
12
fig
Check for damage to the power lead and ensure that
it will not entangle with the drive mechanism. Connect
to power. The controller will go through a startup
sequence displaying the STARTUP SCREEN which
indicates the controller type and firmware version.
After a short delay the MAIN SCREEN will be
displayed. If this is the first time the controller has
been used the MAIN SCREEN should indicate that
the limits are not set. If the display shows that the
gate is disengaged or an input is active then rectify
the situation before continuing with the procedure for
setting the travel limits for single or dual gates.
Powering up the Drive Unit
10
fig
11
fig
Single leaf gate
This section shows how to set the travel limits for a
single gate installation. The procedure can be partly
completed using a transmitter. In order to use a
transmitter it must first have at least one of its buttons
coded to the gate controller. The function assigned
to the transmitter’s buttons is of no concern here as
the buttons are temporally assigned to OPEN, CLOSE
and SET. NOTE: The limit setting procedure can be
aborted at anytime by pressing EXIT.
NOTE: Gate should be moved manually to half open
position. When re-engaging opener nudge gate until
click is heard to confirm pinion gear has engaged fully.
Step 1. Navigating to “set gate travel menu”
1. Press PREV to navigate to the Menu 10 (Fig. 12).
2. Press SET to display MENU 10.1.
3. Press SET again to enter the limit setting procedure.




Start up screen
Main screen

Owner Installation Instructions Easy Slider - Sliding Gate Opener 17
Step 2. Setting the left/right connector
1. Confirm motor connection is set for correct
side (Fig. 13).
2. Press SET to confirm.
Step 3. Confirming single gate mode
The controller will now determine whether a single or
dual gate installation is required by trying to detect the
presence of a second drive unit. As this is a single leaf
gate installation, the screen below will be shown. Press
SET to continue (Fig. 14).
Step 4. Setting close travel limit
1. Press CLOSE to move gate to the desired CLOSE
LIMIT (or press button 4 on transmitter) (Fig. 15).
2. Press SET to record the CLOSE LIMIT (or press
button 2 on Transmitter).
NOTE: Limit will not be accepted unless the gate is
driven in the close direction.
Step 6. Setting open travel limit
1. Press OPEN to move gate to the desired OPEN
LIMIT (or press button 1 on transmitter) (Fig. 16).
2. Press SET to record the OPEN LIMIT (or press button
2 on Transmitter).
NOTE: Limit will not be accepted unless the gate is
driven in the open direction.
Automatic limit adjustment and load profile
After a brief pause the controller will automatically
close and open gate several times to adjust the speed
at which the limits are approached and also to learn
the normal load profile of the gate. When the setup is
complete the MAIN SCREEN will be displayed with the
gate shown to be Closed. The Gate can now be used.
NOTE: Do not press transmitter during limit
adjustment process.
Pedestrian access position
After completing the above procedure the Pedestrian
access position is automatically set to a position which
is in the middle of the gate travel. The position can be
manually set by following the SETTING PEDESTRIAN
POSITION procedure.
Errors during setting of travel limit
During the above procedure many error checks are
preformed. If an error is detected a message will be
displayed indicating the error.
14
fig
15
fig


   


   
13
fig


   

   


   
   

16
fig
Setting travel limits

18 Easy Slider - Sliding Gate Opener Owner Installation Instructions
Setting travel limits


   
17
fig
19
fig
20
fig


   


   
18
fig


   


   
   

21
fig
Dual leaf gate
This section shows how to set the travel limits for
a dual leaf gate installation. The procedure can be
partly completed using a transmitter. In order to use a
transmitter it must first have at least one of its buttons
coded to the gate controller. The function assigned
to the transmitter’s buttons during coding is of no
concern here as the buttons are temporally assigned
to OPEN, CLOSE and SET. NOTE: The limit setting
procedure can be aborted at anytime by pressing EXIT.
NOTE: Gate should be moved manually to half open
position. When re-engaging opener nudge gate until
click is heard to confirm pinion gear has engaged fully.
Step 1. Navigating to “set gate travel menu”
1. Press PREV to navigate to the Menu 10 (Fig. 17).
2. Press SET to display MENU 10.1.
3. Press SET again to enter the limit setting procedure.
Step 2. Setting the left/right connector
1. Confirm motor connection is set for correct
sides (Fig. 18).
2. Press SET to confirm.
Step 3. Confirming dual gate mode
The controller will now determine whether a single or
dual gate installation is required by trying to detect the
presence of a second drive unit. As this is a dual gate
installation, the screen below should be shown. Press
SET to continue. If Single Gate Mode is displayed then
check the connections between the two drive units and
press EXIT to restart from step 2 (Fig. 19).
Step 4. Confirming gates are not closed
Before proceeding, the gates must not be in the closed
position. This is so that each leaf can be moved freely
without interfering with the other. If the gates are
closed, partially open them manually, then re-engage
them. Press SET to continue (Fig. 20).
Step 5. Selecting which motor opens first
during normal operation
The controller prompts to select which motor will open
first during normal operation. The selected motor is
also used for pedestrian access.
1. Use OPEN or CLOSE to change display
to M1 or M2 (Fig. 21).
2. Press SET to save the selection.
NOTE: M1 is selected for the purpose of this
instruction manual.
NOTE: The motor selected will determine the order
in which each motor will be processed in the following
steps. The procedure documented here shows the
steps for when M1 is selected. If M2 is selected to
open first, then the displayed motor numbers will be
the opposite to those shown here.

Owner Installation Instructions Easy Slider - Sliding Gate Opener 19
Step 6. Setting close travel limit for M2
1. Press CLOSE to move M2 gate to the desired CLOSE
LIMIT (or press button 4 on transmitter) (Fig. 22).
2. Press SET to record the CLOSE LIMIT for M2 (or
press button 2 on transmitter).
Step 7. Setting close travel limit for M1
1. Press CLOSE to move M1 gate to the desired CLOSE
LIMIT (or press button 4 on transmitter) (Fig. 23).
2. Press SET to record the CLOSE LIMIT for M1 (or
press button 2 on transmitter).
Step 8. Setting open travel limit for M1
1. Press OPEN to move M1 gate to the desired OPEN
LIMIT (or press button 1 on transmitter) (Fig. 24).
2. Press SET to record the OPEN LIMIT for M1 (or press
button 2 on transmitter).
Step 9. Setting open travel limit for M2
1. Press OPEN to move M2 gate to the desired OPEN
LIMIT (or press button 1 on transmitter) (Fig. 25).
2. Press SET to record the OPEN LIMIT for M2 (or press
button 2 on transmitter).
Automatic limit adjustment and load profile
After a brief pause the controller will now auto-
automatically close and open gates several times to
adjust the speed at which the limits are approached
and also to learn the normal load profile of the gates.
When the setup is complete the MAIN SCREEN will be
displayed with the gate shown to be Closed. The Gate
can now be used.
NOTE: Do not press transmitter during limit
adjustment process.
Pedestrian access position
After completing the above procedure the Pedestrian
access position is automatically set to a position which
is in the middle of the gate travel. The position can be
manually set by following the SETTING PEDESTRIAN
POSITION procedure.
Errors during setting of travel limit
During the above procedure many error checks are
preformed. If an error is detected a message will be
displayed indicating the error.


   
   

22
fig
24
fig
25
fig


   
   



   
   

23
fig


   
   


20 Easy Slider - Sliding Gate Opener Owner Installation Instructions
NOTE: Before setting the pedestrian access position
the gate must be in the fully closed position. As with
the Setting Travel Limit procedure, a transmitter can
be used to complete the pedestrian position setting
procedure.
Step 1. Navigating to “set pedestrian menu”
1. Press PREV to navigate to the Menu 10 (Fig. 26).
2. Press SET - MENU 10.1 is displayed.
3. Press NEXT to go to MENU 10.2.
4. Press SET to enter Set Pedestrian procedure.
Step 2. Setting pedestrian position
1. Press OPEN to move gate to desired pedestrian access
position (or press button 1 on transmitter) (Fig. 27).
2. Press SET to record position (or press button 2
on transmitter).
Step 3. Pedestrian position set
The controller will return to the MAIN SCREEN with
the gate status shown as being in pedestrian access
mode (Fig. 28).
Setting pedestrian position


   
26
fig
28
fig


   
   
   



27
fig
