Automatic Technology NES-24V3 NeoSlider User manual

NES-24V3 NeoSliderTM
Sliding Gate Opener
Ne Slider™
Doc # 160056_00
Part # 13428
Released 17/03/15

2NeoSliderTM - Sliding Gate Opener NES-24V3 Owner Installation Instructions
Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory
or otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology Australia Pty Ltd Garage Door Opener.
Automatic Technology Australia Pty Ltd hereby further expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever
suffered by any person as a result whether directly or indirectly from failure to install the Automatic Technology Australia Pty Ltd Garage Door Opener in
accordance with these installation instructions.
NeoSliderTM
Sliding Gate Opener NES-24V3
Contents
1. Important Safety Instructions 3
2. Control Board Layout 4
3. Set Up Requirements 5
3.1 Kit Contents 5
3.2 Choosing your Set up 5
4. Drive Unit Installation 6
4.1 Initial Checking 6
4.2 Mounting the Drive Unit 6
4.3 Installing antenna 6
5. Rack & Limit Actuator Installation 7
5.2 Fixing limit actuator to rack 7
5.1 Mounting rack to gate 7
6. Programming The NeoSliderTM 8
6.1 Common Programs 8
6.2 Powering up the NeoSliderTM 8
7. Safety Beams 9
7.1 Installation of Safety Beams to the NeoSliderTM 9
7.2 Safety Beam Failure Emergency Close (SBFEC) 9
8. Setting Limits 10
8.1 Setting Travel Limits 10
8.2 Setting the left/right installation side settings 10
8.3 Setting close travel limit 10
8.4 Setting open travel limit 10
8.5 Automatic limit adjustment and load profile 11
8.6 Pedestrian access position 11
8.7 Errors during setting of travel limit 11
9. Safety Obstruction Force Test 12
9.1 Testing Close Cycle 12
9.2 Testing Open Cycle 12
9.3 Force Pressure For Close and Open Cycle. 12
9.4 Reprofiling Travel 12
10. Coding Transmitter 13
10.1 Coding Transmitter Button 13
10.2 Selecting Function Of The Button 13
10.3 Returning To Main Screen 13
11. Remotely Coding Transmitters 14
11.1 Selecting The Function To Be Coded 14
11.2 Activate Remote Code Set Mode 14
12. Battery Replacement 15
13. Battery Disposal 15
14. Setting Pedestrian Position 16
14.1 Setting pedestrian position 16
14.2 Pedestrian Position Set 16
14.3 Error Displays 16
15. Auto-Close Mode 17
15.1 Setting Up Standard Auto-Close 17
15.2 Safety Beam Triggered Auto Close 17
15.3 Pedestrian Auto-Close 17
15.4 Auto-Close After Obstruction 17
16. Accessories Installation 18
16.1 Fitting Solenoid Or Magnetic Locks 18
16.2 Fitting Courtesy Lights 18
17. Specifications 19
18. Troubleshooting 20
19. Appendix 21
A - Console Menu Structure 21
B - Viewing and Editing Parameters 23
C - Wiring Dual NeoSlider Kit 24
D - Control Board Adjustments 25
E- Diagnostic Tools 27
F - Memory Tools 28
G- Transmitter Editing 29
H- Transmitter Managment 31
20. Warranty and Exclusion of Liability 32

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-24V3 3
WARNING! • The gate may operate unexpectedly, therefore do not allow anything to stay in the
path of the gate.
• Do not disengage the gate opener to manual operation with children/persons or any
objects including motor vehicles within the gateway.
• Remove or disengage all gate locks and mechanisms prior to installation of the
opener.
• Make sure the gate is fully open before driving into or out of the driveway.
• When using auto close mode, a Photo Electric beam must be fitted correctly and
tested for operation at regular intervals. Extreme caution is recommended when
using auto close mode. All safety rules must be followed.
ELECTROCUTION! • Do not immerse in or spray the NeoSlider with water .
• Disconnect the power cord from mains power before making any repairs or
removing covers. Only experienced service personnel should remove covers from
the gate opener.
• If the power supply cord is damaged, it must be replaced by an Automatic Technology
service agent or suitably qualified person.
• Connect the gate opener to a properly earthed general purpose 240V mains power
outlet installed by a qualified electrical contractor.
CAUTION:
Entrapment from
operating gate • DO NOT operate the gate opener unless the gate is in full view and free from objects
such as cars and children/people. Make sure that the gate has finished moving before
entering or leaving the driveway.
• Do not allow children to play with gate controls or transmitters.
• In order for the NeoSliderTM to sense an object obstructing the gateway, some force
must be exerted on the object. As a result the object, gate and/or person may suffer
damage or injury.
• Regularly check to make sure that the Safety Obstruction Force is working correctly,
and is tested and set as per Section 12 of this manual. Failure to follow these
instructions could result in serious personal injury and/or property damage. This
test must be repeated at regular intervals and the necessary adjustments made as
required.
• If using a key switch, keypad or any device that can operate the gate opener, make sure
it is in a location where the gateway is visible, but out of the reach of children at a
height of at least 1.5m.
• For ADDITIONAL SAFETY protection we STRONGLY recommend the fitting of a
Photo Electric (Safety) Beam. In most countries Safety Beams are mandatory on all
gates fitted with automatic openers.
Installation • Ensure the gate(s) is in good working order . Faulty gates must be repaired by a qualified
technician prior to NeoSliderTM installation.
Security • Make sure that the gate is fully closed before leaving the driveway.
Entanglement in
or laceration from
moving gate
• Keep hands and loose clothing clear of gate at all times
• Keep clear of gate during operation as severe lacerations can occur on sharp edges of
gate.
1. Important Safety Instructions
The safety alert symbols below indicate a personal safety or property
damage instruction exists. READ THESE INSTRUCTIONS CAREFULLY.
This NeoSliderTM NES-24V3 Sliding Gate Opener is designed and tested to offer safe
service provided it is installed and operated in strict accordance with the following
safety rules. Failure to comply with the following instructions may result in death, serious
personal injury or property damage.

4NeoSliderTM - Sliding Gate Opener NES-24V3 Owner Installation Instructions
2. Control Board Layout
26
V+
0V
SB2 (Safety Beam (2), two, three
wire or wireless)
SB1 (Safety Beam(1), two, three
wire or wireless)
0V
OPN Programmable N/O or
N/C input terminal
STP Programmable N/O or
N/C input terminal
CLS N/O input terminal
OSC N/O input terminal
SWP N/O input terminal
28
29
13
30
30
01
02
03
04
05
06
07
08
09
10
11
12
Fig 2.1
PED N/O input terminal
0V
V+
OUT 2 (optional relay
module coil drive)
V+
OUT 1 N/C relay contact
Engage sensor microswitch
input
Console Previous button
Console Up/Open button
Console Next button
13
Console Exit button
Console Down/Close button
Console SET button
Antenna connector
Console display
PG3 programmer / network connector
Motor connector
24VAC input connector
10 AMP slow blow fuse
Standby battery charger/solar
connector
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
01
02
03
04
05
06
07
08
09
10
11
12
27
15
17
20
22
18
25
14
16
19
21 23
24
26

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-24V3 5
Console Exit button
Console Down/Close button
Console SET button
Antenna connector
Console display
PG3 programmer / network connector
Motor connector
24VAC input connector
10 AMP slow blow fuse
Standby battery charger/solar
connector
3. Set Up Requirements
Fig 3.1
3.1 Kit Contents
3.2 Choosing your Set up
The NeoSlider™ can be set up in various ways and therefore may
require additional items. Common Set ups are as follows;
ITEM DESCRIPTION QTY ORDER
CODE
1 DRIVE UNIT NES-24V3 1 60188
2 TRIO-CODE 4B PTX-5V2 TRANSMITTER 2 61160
3 ACCESSORY ACTUATOR PACK 2 61463
1
2
3
Set Up Items Required
Automated Set Up Drive Unit and transmitter
Automated Set Up
with Safety Beams Drive Unit, transmitter and safety beams (optional)
CAUTION: Cables which have a green/yellow coloured
insulation are for earthing purposes only.
Never use these cables for any other purpose.
IMPORTANT WARNING!
A qualified electrician must
perform the installation where
240V AC power is used.

6NeoSliderTM - Sliding Gate Opener NES-24V3 Owner Installation Instructions
The Automatic Technology NeoSlider™ sliding gate opener is
designed to operate most residential sliding gates. The gates
must be in good working condition and should operate freely
by hand.
4.1 Initial Checking
Before commencing installation of the NeoSlider™, check the
following:
a. The gate moves freely and easily by hand for the full opening
and closing travel.
b. The mounting point must be solidy constructed, e.g
concrete, brick or steel, and must be capable of withstanding
the full force applied to the gate.
c. Select a suitable location for mounting the drive unit. This
position is usually established by fully opening the gate and
mounting the drive unit within a suitable distance of the
gate edge.
d. A weather-proof 240v 10 amp power outlet must be located
within one (1) metre of the NeoSlider™ mounting point.
e. If Safety Beams are to be installed, provision for underground
cabling should be made from one side of the gateway to
the other.
4.2 Mounting the Drive Unit
The NeoSlider™ mounting holes are slotted for fine adjustment
of pinion gear and gate rack alignment. Follow the procedure
below to ensure final adjustments can be made later.
We recommend that four 8mm (5 /
16”) or 10mm (3
/
8”) loxins and
bolts are used to secure the Drive Unit into position. These
loxins usually require a 16mm (5 /
8”) masonry drill bit (if drilling
concrete).
a. Prior to mounting the NeoSlider™, determine the distance
from the gate to the outer edge of the rack (i.e. the rack
width) and to the datum line (see Fig. 4.2 and Fig. 5.1).
If using an Automatic Technology plastic rack, the width is
40mm. If using a different brand of rack, please ensure it is
Module 4 and then confirm the width, as this will vary.
b. Mark a line parallel to the face of the gate for the mounting
holes. The distance from the gate is determined by
the formula (38mm + Rack Width). Therefore, if using
an Automatic Technology rack, the distance is 78mm.
Otherwise, if using a non-Automatic Technology rack, add
your rack width (and spacers if required) to the 38mm (see
Fig. 4.2).
c. Another 100mm back, mark another line parallel to that
described in point 2 for fixing. (see Fig. 4.2).
d. Open the gate to the desired open position. Mark a line at
a right angle to the gate 120-150mm from the open edge
of the gate for the mounting holes.
e. Then mark another line 268mm parallel to this line
(see Fig. 4.2).
f. Place the Drive Unit in position where the lines intersect to
check the mounting position. If satisfied with the position,
remove the Drive Unit.
g. Drill the four mounting holes where the lines intersect.
4. Drive Unit Installation
Fig 4.1
Cover
release
screw
Disengage lever
Cover
release
screw
Fig 4.2
h. Hammer the loxins into position, place the NeoSlider™
and fix with the four bolts. Remember when tightening
the bolts to allow fine adjustement of the NeoSlider™
later on.
4.3 Installing antenna
Mount the antenna at or above the height of the gate or
fence (whichever is higher) for optimal reception. Do not
cut the coaxial cable.

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-24V3 7
5. Rack & Limit Actuator Installation
5.1 Mounting rack to gate
A strong base on the gate is required for mounting
the rack.
a. Manually open the gate and place a rack section
to mesh with the pinion gear on the Drive Unit.
Mark the top of the rack. Move the gate and mark
the rack for the entire length of the gate.
b. Position the top edge of the rack on this line and
mark the centres of the rack’s mounting slots. The
first section of rack should start 20mm from the
edge of the gate.
c. Drill and tap for 6mm (¼”) screws.
d. Once the first section of the rack is mounted,
check that it meshes with the NeoSlider™ pinion
gear.
e. When joining subsequent sections of rack, check
the mesh by placing a spare section upside down
(teeth facing upwards) and putting it into mesh
with the racks being joined (Fig. 5.2).
Rack
width
Gate
Rack
Drive
gear
Datum line
To top of pinion
To bottom of
rack tooth
Maximum height of rack
Fig 5.1
Fig 5.2
Mounting
holes
M4 x 10 screws
and washers
Actuator mounting
block
M4 x 30 screws
Fig 5.3
5.2 Fixing limit actuator to rack
a. Manually open the gate to the open position and mark this on
the gate rack under the actuating arm.
b. Manually close the gate to the closed position and mark this on
the gate rack under the actuating arm.
c. Place start of limit actuator at marked position and move it 5 to
10mm towards the centre of the gate. Align the face of the limit
actuator with the side of the rack and screw the limit actuator to
the rack (Fig. 5.3).
f. Tighten the racks. This will ensure that the
NeoSlider™ pinion can run along the racks
without obstruction.
d. Re-check limit positions by manually opening and
closing the gate, checking to see that the limit is
activated at the desired open and close position.
If neccessary, make adjustments by sliding the
actuator in the required direction. When the final
settings are established, tighten the limit actuator
screws - each actuator must be secured with two
(2) screws.

8NeoSliderTM - Sliding Gate Opener NES-24V3 Owner Installation Instructions
6. Programming The NeoSliderTM
6.1 Common Programs
The two most common programs are;
Program Menu’s required Function Section
Automated Set Up Menu 10.1 Setting the Limits 8.1
Safety Obstruction Force 9.1 and 9.2
Menu 1 Coding the Transmitter 10.1
Automated Set Up with
Safety Beams
Menu 10.1 Setting the Limits 8.1
Safety Obstruction Force 9.1 and 9.2
Menu 1 Coding the Transmitter 10.1
Menu 3 Auto Close Times 13.2, 13.3 and 13.4
NOTE: Fitting Safety Beams enables the Auto-Close feature to become active.
CAUTION: Before plugging the gate control system in, check
the power cord for damage and ensure it cannot become
entangled in any moving parts
6.2 Powering up the NeoSliderTM
a. After checking the initial wiring, apply power to the NeoSlider™. The
controller will go through a startup sequence displaying the STARTUP
SCREEN which indicates the controller type and firmware version
(Fig. 6.2). After a short delay the MAIN SCREEN will be displayed.
b. If this is the first time the NeoSlider™ has been used, the MAIN SCREEN
should indicate that the limits are not set (Fig. 6.3). If the display shows
that some input is active then rectify the situation before proceeding. If
a default setting is to be changed it should be done now before setting
the travel limits.
Fig 6.2
Fig 6.3
Fig 6.1
A.T.A NES-24V2
Firmware #.##
Limits not Set!
Press <> to access MENUS
Start up screen
Main screen

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-24V3 9
WARNING: When using Safety Beams, the gateway must be clear of all obstructions and persons at all times.
The location of the beams and manner in which it is installed might not give safety protection at all times.
Check to make sure that the height of the beam and type used give maximum protection possible
WARNING: Tampering with Safety Beams could result in serious personal injury and/or property damage and
will void the warranty.
7.1 Installation of Safety Beams to the NeoSliderTM
a. Follow the Installation Manual provided with the Safety Beam to
correctly install the Safety Beam.
b. By default the NeoSlider™ will take two wire safety beams.
c. Ensure you program the NeoSlider™ to idenitfy what type of Safety
Beam or combination of Safety Beams you have installed.
i. Press NEXT to Navigate to Menu 7
ii. Press SET to display Menu 7.1 (for SB1).
iii.Ensure the Safety Beam type is set to two wires.
iv. Press SET to accept the selection.
v. Repeat the same process for Menu 7.2 (SB2) if installed.
NOTE: Wireless Safety Beam functionality is equivalent to 2 WIRE Safety
Beams
vi. NOTE: The Power control for one or both three wire beams is
controlled via OUT 1 or OUT 2. To use the OUT 1, connect black
wire from SB to OUT 1. To enable power control from OUT 1, go to
Menu 7.13 and change OUT1 mode to 3 wire SB 0V.
NOTE: In the case that OUT 1 is used for some other function, OUT 2 can
be used to control 3 wire beams power. Connect the black wire from SB
to OUT 2, then change the OUT 2 mode in Menu 7.14 to 3 wire SB 0V.
7. Safety Beams
7.2 Safety Beam Failure Emergency Close (SBFEC)
When the user finds that they are unable to move the gate and suspect that it is due to a faulty SAFETY BEAM they
can attempt to enter Safety Beam Failure Emergency Close mode by pressing and holding a pre-coded button on
the remote control or OPEN/CLOSE button on the console for more than five seconds. the gate will start closing.
See Appendix C Menu 7.16.

10 NeoSliderTM - Sliding Gate Opener NES-24V3 Owner Installation Instructions
8. Setting Limits
The NeoSliderTM has the alternate ability to set travel limits using a
TrioCodeTM128 transmitter, allowing free movement around the gate to
better assess the desired limit positions. In order to use a transmitter, it
must first have at least one of its buttons coded to the gate controller.
The function assigned to the transmitter’s buttons is of no concern here
as the buttons are temporally assigned to OPEN, CLOSE and SET (Fig.
8.1).
NOTE: Gate should be moved manually to fully open position. When
re-engaging opener, nudge gate until click is heard to confirm pinion
gear has engaged fully.
8.1 Setting Travel Limits
Navigating to “code transmitter” menu
a. Press NEXT to navigate to Menu 1.
b. Press SET to enter the code set procedure (Fig. 8.2).
Storing Transmitter Code
c. Controller will prompt to press one of the transmitter’s Button.
d. Press the transmitter button you wish to use to operate the gate
opener (e.g. button 1) .
e. Press the same transmitter button again as prompted by display.
f. Press the SET button to store the transmitter.
Navigating To “Set Gate Travel Menu”
g. Press PREV to navigate to Menu 10.
h. Press SET to display MENU 10.1.
i. Press SET two times to enter the limit setting procedure. Follow LCD
prompts.
8.2 Setting the left/right installation side settings
a. Select left or right installation side by pressing open button for the
correct side (Fig. 8.2).
b. Press SET to confirm.
8.3 Setting close travel limit
a. Press and hold Button 4 on the transmitter to close the gate
i. If the gate is closed too far, press Button 1 to “inch” the gate
towards open.
ii. When happy with the close limit position, press Button 2 to store
this in the memory.
NOTE: Limit will not be accepted unless the gate is driven in the
close direction.
Fig 8.1
Fig 8.2
Button 1
(Inch
Open)
Button 4
(Inch
Close)
Button 2
(Set)
Menu 1
Code Transmitter
PRESS
8.4 Setting open travel limit
a. Press Button 1 to open the gate.
b. If the gate is opened too far, press Button 4 to “inch” the gate
towards close
c. When happy with the open limit position, press Button 2 on the
transmitter to store into memory..
IMPORTANT NOTE:
Only TrioCodeTM128 Technology
Transmitters are compatible
with this product.
NOTE: Limit will not be accepted unless the
gate is driven in the open direction.
WARNING: The gate will automatically close and open once next step is
performed. Ensure that no persons or objects are in the gates path
d. The gate will now automatically close and open to calculate the safety obstruction settings.

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-24V3 11
Fig 8.1
Fig 8.2
8. Setting Limits
8.5 Automatic limit adjustment and load profile
After a brief pause, the controller will automatically close and open the gate several times. This adjusts the speed at which
the limits are approached and helps to learn the normal load profile of the gate. When the setup is complete, the MAIN
SCREEN will be displayed with the gate shown to be OPEN. The Gate can now be used.
NOTE: Do not press transmitter during limit adjustment process.
8.6 Pedestrian access position
After completing the above procedure, the Pedestrian access position is automatically set to a position which is five (5)
seconds from the fully closed position of the gate. The position can be manually set by following the SETTING PEDESTRIAN
POSITION procedure (See Section 12).
8.7 Errors during setting of travel limit
During the above procedure, many error checks are preformed. If an error is detected, a message will be displayed
indicating the error.
8.8 Recalculate Force Margins
a. Reprofiling is a simplified way of re-learning the travel characteristic of a previously setup Limit Switch travel installation.
Re-profiling can be used when the travel characteristics of the gate change due to mechanical adjustments etc.
b. To initiate a re-profile simply locate “MENU 10.2 Reprofile Travel”
WARNING: The gate(s) will automatically close and open. Ensure that no persons or objects are in the
gates path.
c. Press SET then follow the prompts. The gate will start to move and re-calculate force margins. The gate can move
between the open and close limit positions up to two (2) times (depending on the position of the gate and the power
up condition).
d. A single beep will be heard once the process is complete and setup complete message will be displayed

12 NeoSliderTM - Sliding Gate Opener NES-24V3 Owner Installation Instructions
9. Safety Obstruction Force Test
WARNING! Take care when testing or adjusting the
Safety Obstruction Force. Excessive force may cause
SERIOUS PERSONAL INJURY and/or PROPERTY
DAMAGE.
9.1 Testing Close Cycle
a. Press the OPEN button to open the gate.
b. Place a piece of timber approximately 40mm wide on the
ground directly next to the closing pilon / fence (Fig. 9.1).
c. Press the CLOSE button to close the gate. The gate should
strike the object and start to re-open.
9.2 Testing Open Cycle
a. Press the CLOSE button to close the gate.
b. Press the OPEN button to open the gate. When the gate
reaches the half open point, grab the side rail of the gate
firmly and the gate should stop.
c. If the gate does not reverse readily when closing, or stop when
opening, the force may be excessive and need adjusting.
WARNING! If the gate fails these tests, put the
opener into manual mode, only operate the gate by
hand and call for service.
Fig 9.1
40mm Block of
wood
Safety Obstruction Force
The Safety Obstruction Force is calculated automatically
during setup. Adjusting this is normally only necessitated by
environmental conditions such as windy or dusty areas, and areas
with extreme temperature changes.
9.3 Force Pressure For Close and Open Cycle.
Navigating To “Current Trips”
a. Press NEXT or PREV to navigate to Menu 2 Current Trips.
b. Press SET (Fig.9.2)
c. MENU 2.1: CLOSE Margin is displayed (Fig. 9.3).
d. Press UP arrow to increase or DOWN arrow to decrease the
value.
e. Press SET to save the new value.
f. Test the force again as per “Safety Obstruction Force Test” in
Section 9.1.
9.4 Reprofiling Travel
a. Reprofiling is a simplified way of re-learning the travel
characteristic of a previously setup Limit Switch travel
installation. Re-profiling can be used when the travel
characteristics of the gate changes due to mechanical
adjustments etc. To initiate a re-profile, simply locate “MENU
10.2 Reprofile Travel”, press SET and follow the prompts. The
gate will start to move and re-calculate force margins. The
gate can move between the open and close limit positions up
to two (2) times (depending on the position of the gate and
the power up condition).
b. A single beep will be heard once the process is complete.
c. Test the force again as per “Safety Obstruction Force Test”
(Section 9.1 and 9.2).
Menu 2
Current Trips
PRESS
Close Margin
(Amps) 0.7
PRESS
Fig 9.2
Fig 9.3

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-24V3 13
Fig 9.1
Fig 9.2
Fig 9.3
10. Coding Transmitter
NeoSliderTM can store up to thirty (30) transmitters in its
memory. Each transmitter can be allocated an alpha-numeric
ID label up to eleven (11) characters in length and each
button can be assigned to one of several control functions.
The settings for a transmitter are represented in (Fig. 10.1).
It shows the transmitter’s store number, ID label or serial
number and the functions assigned to each of its four buttons.
To toggle between ID/SN display, press UP/DOWN with the
cursor on the ID/SN indicator. The procedures below code,
delete, replace, edit and copy transmitter records.
Fig 10.1
Fig 10.2
Fig 10.3
Fig 10.4
123
ID
Name/SN
OSC PED LGT VAC
I.D label/Serial
number
Button 4
function
Button 3
function
Button 2
function
Button 1
function
Store
number
ID/SN display
indicator
Menu 1
Code Transmitter
PRESS
Press Tx’er
Button LIST>
PRESS
# 1 [ No Name ]
OSC OFF OFF OFF
PRESS
PRESS
IMPORTANT NOTE:
Only TrioCodeTM128 Technology Transmitters
are compatible with this product.
10.1 Coding Transmitter Button
Navigating To Menu 1 “Code Transmitter”
a. Press NEXT to navigate to Menu 1 (Fig. 13.2).
b. Press SET to enter the code set procedure.
Storing Transmitter Code
c. The controller will prompt to press one of the transmitter’s
buttons.
d. Press the transmitter button you wish to use to operate the
Gate Opener (e.g. button 1) (Fig. 10.3) .
e. Press the same transmitter button again as prompted by
the display (Fig. 10.3).
10.2 Selecting Function Of The Button
The controller will now show the transmitter’s record, with a
cursor on the field for the button being coded (Fig. 10.4).
Use UP/DOWN arrows to select the function for the button.
Available functions:
VAC (Vacation Mode) LGT (Courtesy Light)
STP (Stop) OPN (Open)
CLS (Close) SWP (Swipe)
PED (Pedestrian access) OSC (Open/Stop/Close)
OFF (No action)
Press SET to save the settings or EXIT to abort without saving.
10.3 Returning To Main Screen
The “Code Transmitter” menu will now be shown. Press EXIT
to return to the MAIN SCREEN and test the transmitter.

14 NeoSliderTM - Sliding Gate Opener NES-24V3 Owner Installation Instructions
11. Remotely Coding Transmitters
PRESS
If a TrioCodeTM128 transmitter is already coded into the opener,
additional TrioCodeTM 128 transmitters can be coded without being in
direct contact with the NeoSliderTM.
NOTE: Only the function of the existing TrioCodeTM128 Transmitter
button can be assigned to new transmitter. Please read instructions
prior to proceeding - there is a time-out facility for security reasons.
11.1 Selecting The Function To Be Coded
a. Using the existing transmitter, operate the gate with the transmitter
button which has the function to be coded (Fig. 11.1) (e.g. Button
1 has been coded with the OSC function assigned).
b. If the button’s function activates the gate (PED, SWP, OSC, CLS,
STP or OPN) wait for the gate to complete its cycle.
11.2 Activate Remote Code Set Mode
a. Use a small pin to press and hold through the Coding Hole of the
existing transmitter for 2 seconds (Fig. 11.2).
b. Within 10 seconds, press the button on the new transmitter you
wish to code for 2 seconds (Fig. 11.3).
c. Press the same button again (within 10 seconds) for confirmation.
d. Test Operation. The new transmitter button should now function as
the existing transmitter.
PRESS
Existing
transmitter
New
transmitter
Existing
transmitter
Fig 11.1
Fig 11.2
Fig 11.3
NOTE: When a transmitter is remotely coded, its ID label is set to that
of the existing transmitter. If the existing transmitter does not have an
ID label assigned, then the ID label of the new transmitter is set to:
R/C Tx ###, where ### is the existing transmitters store number. This
ensures that the originator of any remotely coded transmitter can be
identified.

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-24V3 15
Fig 11.1
Fig 11.2
Fig 11.3
When batteries reach the end of their usual life in accordance with Australian Battery Recycling Initiative
please follow the next simple steps for protecting the environment.
Refer to the Automatic Technology website for information on where to recycle batteries in Australia.
DO NOT throw the batteries in municipal waste. This symbol of the crossed out wheeled bin indicates
that the battery should not be placed in the municipal waste. Check your local regulations for appropriate
disposal of the batteries.
Recycling all batteries will have other environmental and social benefits:
•Some batteries are less toxic but hazardous for other reasons. Lithium batteries can explode or catch fire in landfill,
while button cells are dangerous if swallowed by children. Recycling offers a safe and environmentally responsible
solution for end of life batteries.
•Battery recycling recovers non-renewable materials such as lead, cadmium, stella, zinc, manganese, cobalt, silver,
plastics and rare earth elements.
•Removal of batteries and other hazardous household products from household waste facilitates the recovery of
organic materials through alternative waste technologies such as composting. Batteries and heavy metals are known
contaminants in compost.
•The community supports recycling because it reduces waste to landfill and achieves environmental benefits.
WARNING! Prior to disposal, recycling, or collection, all battery terminals must be securely insulated with
a non conductive material to prevent any two batteries from short circuiting and generating heat during
storage or transport. Battery terminals may be insulated with electrical tape; or batteries may be individually
packaged in a non conductive material(e.g., plastic bag or original packaging).
13. Battery Disposal
(Battery Type: 3V Lithium Battery CR2032).
Use a non-metallic object (e.g. pen) to remove the battery.
(Fig. 12.1). To test the battery is working, press and hold a
transmitter button; (Fig. 12.2).
Light Status Battery Status
Solid OK
Flashing Requires replacement
No light Requires replacement
REPLACE BATTERY WITH CR2032 ONLY
12. Battery Replacement
Fig. 12.1
Fig. 12.2
Use a pen
to push the
battery down
through the
side opening
to release
battery

16 NeoSliderTM - Sliding Gate Opener NES-24V3 Owner Installation Instructions
NeoSliderTM can be instructed, via its pedestrian control feature, to
partly open and provide pedestrian access but prevent vehicle access.
NOTE: Before setting the pedestrian access position the gate must be
in the fully closed position. As with the Setting Travel Limit procedure,
a transmitter can be used to complete the pedestrian position setting
procedure.
NOTE: The pedestrian default position is set at five (5) seconds from fully
closed position and can be changed as follows:.
14.1 Setting pedestrian position
Navigating to “Menu 10.3 Set Pedestrian”
a. Press PREV to navigate to Menu 10.
b. Press SET - MENU 10.1 is displayed.
c. Press NEXT to go to MENU 10.3.
d. Press SET to enter Set Pedestrian procedure (Fig. 14.1).
To Set pedestrian position
a. Press OPEN to change the pedestrian access position time (Fig. 14.2).
b. Press SET to record new time.
c. Press transmitter coded for pedestrian function to test.
14.2 Pedestrian Position Set
The controller will return to the MAIN SCREEN with the gate status
shown as being in pedestrian access mode (Fig. 14.3).
14.3 Error Displays
During the above procedure many error checks are performed. If an error
is detected, a message will be displayed indicating the error.
14. Setting Pedestrian Position
Fig 14.1
Fig 14.2
MENU 10.3
Set Pedestrian
PRESS
Ped’n Opening
Time 5
PRESS
PRESS
Ped’n Access
Press <> to Access MENU
Fig 14.3

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-24V3 17
Fig 14.1
Fig 14.2
Fig 14.3
WARNING! The Auto-Close function is not
available unless Safety Beam is installed.
15.1 Setting Up Standard Auto-Close
Menu 3. Auto-Close Times
Auto-Close mode is a function that automatically closes
the gate a preset time after the Safety Beam recognise that
a vehicle has left the gateway. The Auto-Close timer only
starts after the Safety Beam path is broken and the Auto-
Close timer has been set. If the Safety Beam path is not
broken, the gate will remain open until the path is broken.
If the opener incurs a physical obstruction (i.e. not from the
Safety Beam) while closing, the gate will re-open and not
Auto-Close until the Safety Beam path is broken again.
Menu 3.1 Auto-Close
This mode is selected by entering a non-zero time for the
STD Auto-Close parameter. When selected, the gate will
Auto-Close after being fully opened (except when the gate
has reversed to the open position after a motor obstruction
or overload unless A/C after open and/or close Obstruction
are selected). Countdown is suspended by: S.B., OPN or
SWP input being active. The countdown is aborted if the
STP input is activated. If the gate is already open and the
OPN or the SWP input is activated, then the countdown
will start.
15.2 Safety Beam Triggered Auto Close
Menu 3.2 (SB AC Trig)
This mode is selected by entering a non-zero time for the
“Safety Beam Auto-Close” parameter. This mode is used
to Auto-Close the gate but only after an object has passed
through the gateway and has triggered the Safety Beam
input. Any Safety Beam or combination of Safety Beams
can be configured to activate Safety Beam Auto-Close
mode and combinations are:
One Beam only
i. Safety Beam 1
ii. Safety Beam 2
Either Beam
i. Safety Beam 1 or Safety Beam 2
Combination
ii. Safety Beam 1 and Safety Beam 2
iii. Safety Beam 2 then Safety Beam 1
NOTE: The swipe input can be used to clear the Safety
Beam triggered status so that the Safety Beam input must
be activated again before the countdown will start. As with
the other Safety Beam modes, the STP input will abort
countdown and the OPN and SWP inputs will restart the
countdown if the gate is OPEN.
15. Auto-Close Mode
15.3 Pedestrian Auto-Close
Menu 3.3 Safety Beam Auto-Close
This mode is selected by entering a non-zero time for the
“Safety Beam Auto-Close” parameter. This mode is used
to Auto-Close the gate but only after an object has passed
through the gateway and has triggered the Safety Beam
input
Menu 3.4 Pedestrian Auto-Close
This mode is selected by entering a non-zero time for
the “Ped’n A/C” parameter. When selected, the gate will
Auto-Close after being opened for pedestrian access
unless it was following a reverse from an obstruction.
Menu 3.5 (Safety Beam) Pedestrian Triggered Auto-Close
This mode is selected by entering a non-zero time for
the “Safety Beam Pedestrian Auto-Close” parameter.
Any Safety Beam or combination of Safety Beams can be
configured to activate Safety Beam Auto-Close mode and
combinations are:
One Beam only
iv. Safety Beam 1
v. Safety Beam 2
Either Beam
i. Safety Beam 1 or Safety Beam 2
Combination
ii. Safety Beam 1 and Safety Beam 2
iii. Safety Beam 2 then Safety Beam 1
Menu 3.6 (Safety Beam) Pedestrian Auto-Close
This mode is selected by entering a non-zero time for
the “Ped’n A/C” parameter. When selected, the gate will
Auto-Close after being opened for pedestrian access but
only after an object has passed through the gateway and
has triggered the Safety Beam input.
15.4 Auto-Close After Obstruction
Two parameters are provided to enable the Auto-Close
feature to be activated after obstructions and power up.
Normally the Auto-Close feature is not enabled after
obstructions for safety reasons. Safety Beams must be
used for these features to be activated.
Menu 3.7
This mode enables the Auto-Close feature to be activated
when a close obstruction occurs (requires Safety Beams).
Menu 3.8
This mode enables the Auto-Close feature to be activated
when an open obstruction occurs.
Menu 3.9
This mode enables Auto-Close feature after power up.

18 NeoSliderTM - Sliding Gate Opener NES-24V3 Owner Installation Instructions
16. Accessories Installation
LIGHT RELAY MODULE
POWER SUPPLY
V+
0V
SAFETY B2
SAFETY B1
OV
OPEN
STOP
CLOSE
OSC
SWIPE
PEDESTRIAN
OV
V+
OUT2
V+
OUT1
Wiring Output1 And Output2
Outputs 1 and 2 are used to control a lock, Light or
Safety Beam power. Which output is to control which
function and the way it is controlled is programmable.
If using these outputs make sure that the functions are
configured for correct operation prior to setting the
travel limits. OUTPUT1 or OUTPUT2 is used to activate
an optional external relay module (RO-1) which in turn
is used to switch the load.
16.1 Fitting Solenoid Or Magnetic Locks
Install the lock mechanism on the gate as per the
manufacturers instructions. See Fig. 16.1 for the wiring
diagram.
Menu 4. Lock Times
Lock output can be programmed for both hold and pulse
mode. The operation of the lock can be programmed
to activate prior to the gate and behave differently on
open cycles to that on close cycles.
a. PressNEXTorPREVonthewallcontrolunittonavigateto
Menu 4 Lock Times.
b. Press SET to select the sub menu.
c. Press NEXT or PREV to navigate through the sub
menu.
d. Press OPEN to increase or CLOSE to decrease the
time.
e. Press SET to save the new time.
f. Press the EXIT button two times to exit and test the
locks operation.
Pulse Lock
LOCK RELAY MODULE
POWER SUPPLY
V+
0V
SAFETY B2
SAFETY B1
OV
OPEN
STOP
CLOSE
OSC
SWIPE
PEDESTRIAN
OV
V+
OUT2
V+
OUT1
Fig 16.1
Fig 16.2
16.2 Fitting Courtesy Lights
An AC or DC courtesy light can be activated via an
output on the gate opener control board. Connect the
light as per the diagram. (Fig. 16.2)
WARNING: A qualified electrician must
perform the installation where 240V AC
power is used.
Menu 5. Light Times
a. Press NEXT or PREV on the wall control unit to
navigate to Menu 5 Light/Lock Times.
b. Press SET to select the sub menu.
c. Press NEXT or PREV to navigate through the sub
menu.
d. Press OPEN to increase or CLOSE to decrease the
time.
e. Press SET to save the new time.
f. Press the EXIT button two times to exit.
g. Test the light operation.

Owner Installation Instructions NeoSliderTM - Sliding Gate Opener NES-24V3 19
Fig 16.1
Fig 16.2
Technical Specifications
Protection rating: IP33
Input voltage: 230V - 240V AC 50Hz
Transformer primary voltage: 230V/240VAC
Secondary voltage: 24V AC 150 VA
Controller voltage: 24V DC
Motor type: Permanent Magnet Direct Current
Motor voltage: 24V DC
Maximum pulling force: 200N
Maximum gate opening: 1, Width:
Weight: 10m 250kg
Opener maximum
Opening/closing run time: 30 seconds
Receiver type: TrioCode™128
Receiver code storage capacity: 30 x 4 Button Transmitter Codes
Transmitter frequency: 433.47, 433.92, 434.37 MHz
Coding type: Hopping Code
No. of code combinations: Over 100 billion random codes
Code generation: Non-linear encryption algorithm
Transmitter battery: CR2032
NOTE:
1. The maximum gate size that the NeoSlider™ can be installed on is 10m wide and 250kg. The gate must be
well balanced. A person should be able to move the gate manually with very little effort (15kg force max.)
in case of an emergency.
2. Intermittent operations may occur in areas which experience very strong wind gusts. A strong wind puts
extra pressure on the gate and tracks which may in turn trigger the safety obstruction detection system
intermittently.
NOTE:Specifications are subject to change without notice.
17. Specifications

20 NeoSliderTM - Sliding Gate Opener NES-24V3 Owner Installation Instructions
Symptom Possible cause Remedy
Gate will not operate Mains power not switched on. Switch on mains power.
Opener motor is disengaged Check that the motor is engaged for automatic
operation
Gate is obstructed. Remove obstruction.
The opener is in “Vacation Mode” Turn off “Vacation Mode”(Appendix DMenu 7.4).
Gate starts to close but
automatically reverses to
open position
Adverse weather conditions (wind
or cold) causing gate to stiffen and
become tight in the tracks.
Increase force margin setting (Section 9.4)
Possible obstruction in the
gateway triggering Safety Beams. Remove obstruction
Gate operates from opener
but not from transmitter
Transmitter code not stored in
memory. Code transmitter in to openers memory. (Section 10.1)
Transmitter does not contain
TrioCode™ 128 Technology
Check the transmitter. It should have grey buttons
and the model number should display V3. Contact
dealer for support if otherwise.
Flat battery in transmitter Replace battery (Section 12)
Antenna behind structure (gate or
fence) or not in line of sight Ensure Antenna is in line of sight (Section 4.2)
Gate does not close with
transmitter Safety Beam not working properly. Make sure Safety Beams are operational. and no dirt is on the lens.
Gate will not close fully. Gate limit positions need to be
reset. Reset limits positions.
Gate obstructed and reverses Clear obstruction or adjust force margin
(Section 9.3)
Gate will not open fully. Gate limit positions need to be
reset. Reset limits positions. (Section 8)
Gate obstructed. Clear obstruction or adjust force margin
(Section 9.3)
Auto-Close not working Safety Beam not installed. Install Safety Beam. (Section 6)
Safety Beam or wiring faulty. Repair Safety Beam or replace wiring.
Safety Beam not aligned correctly. Re-align optics.
Safety Beam is obstructed. Remove obstruction from path of Safety Beams.
Gate obstructed when closing. Remove obstruction.
Auto-Close time not set. Set Auto-Close times (Section 15.3).
Auto-Close mode not set Set Auto-Close mode. (Section 15.2)
18. Troubleshooting
