AutomationDirect D0-DEVNETS User manual

D0–DEVNETS
DeviceNet Slave Module
User Manual
Manual Number D0–DEVNETS–M

WARNING
Thank you for purchasing automation equipment from Automationdirect.com. We want your new DirectLOGIC
automation equipment to operate safely. Anyone who installs or uses this equipment should read this publication (and
any other relevant publications) before installing or operating the equipment.
To minimize the risk of potential safety problems, you should follow all applicable local and national codes that regulate
the installation and operation of your equipment. These codes vary from area to area and usually change with time. It is
your responsibility to determine which codes should be followed, and to verify that the equipment, installation, and
operation are in compliance with the latest revision of these codes.
At a minimum, you should follow all applicable sections of the National Fire Code, National Electrical Code, and the
codes of the National Electrical Manufacturer’s Association (NEMA). There may be local regulatory or government
offices that can also help determine which codes and standards are necessary for safe installation and operation.
Equipment damage or serious injury to personnel can result from the failure to follow all applicable codes and
standards. We do not guarantee the products described in this publication are suitable for your particular application,
nor do we assume any responsibility for your product design, installation, or operation.
Our products are not fault–tolerant and are not designed, manufactured or intended for use or resale as on–line control
equipment in hazardous environments requiring fail–safe performance, such as in the operation of nuclear facilities,
aircraft navigation or communication systems, air traffic control, direct life support machines, or weapons systems, in
which the failure of the product could lead directly to death, personal injury, or severe physical or environmental
damage (”High Risk Activities”). Automationdirect.comspecifically disclaims any expressed or implied warranty of
fitness for High Risk Activities.
For additional warranty and safety information, see the Terms and Conditions section of our Desk Reference. If you
have any questions concerning the installation or operation of this equipment, or if you need additional information,
please call us at 770–844–4200.
This publication is based on information that was available at the time it was printed. At Automationdirect.comwe
constantly strive to improve our products and services, so we reserve the right to make changes to the products and/or
publications at any time without notice and without any obligation. This publication may also discuss features that may
not be available in certain revisions of the product.
Trademarks
This publication may contain references to products produced and/or offered by other companies. The product and
company names may be trademarked and are the sole property of their respective owners. Automationdirect.com
disclaims any proprietary interest in the marks and names of others.
Copyright 2001, Automationdirect.comIncorporated
All Rights Reserved
No part of this manual shall be copied, reproduced, or transmitted in any way without the prior, written consent of
Automationdirect.comIncorporated. Automationdirect.comretains the exclusive rights to all information
included in this document.

AVERTISSEMENT
Nous vous remercions d’avoir acheté l’équipement d’automatisation de Automationdirect.comE. Nous tenons à ce que
votre nouvel équipement d’automatisation DirectLOGICfonctionne en toute sécurité. Toute personne qui installe ou
utilise cet équipement doit lire la présente publication (et toutes les autres publications pertinentes) avant de l’installer ou de
l’utiliser.
Afin de réduire au minimum le risque d’éventuels problèmes de sécurité, vous devez respecter tous les codes locaux et
nationaux applicables régissant l’installation et le fonctionnement de votre équipement. Ces codes diffèrent d’une région à
l’autre et, habituellement, évoluent au fil du temps. Il vous incombe de déterminer les codes à respecter et de vous assurer
que l’équipement, l’installation et le fonctionnement sont conformes aux exigences de la version la plus récente de ces
codes.
Vous devez, à tout le moins, respecter toutes les sections applicables du Code national de prévention des incendies, du
Code national de l’électricité et des codes de la National Electrical Manufacturer’s Association (NEMA). Des organismes de
réglementation ou des services gouvernementaux locaux peuvent également vous aider à déterminer les codes ainsi que
les normes à respecter pour assurer une installation et un fonctionnement sûrs.
L’omission de respecter la totalité des codes et des normes applicables peut entraîner des dommages à l’équipement ou
causer de graves blessures au personnel. Nous ne garantissons pas que les produits décrits dans cette publication
conviennent à votre application particulière et nous n’assumons aucune responsabilité à l’égard de la conception, de
l’installation ou du fonctionnement de votre produit.
Nos produits ne sont pas insensibles aux défaillances et ne sont ni conçus ni fabriqués pour l’utilisation ou la revente en tant
qu’équipement de commande en ligne dans des environnements dangereux nécessitant une sécurité absolue, par
exemple, l’exploitation d’installations nucléaires, les systèmes de navigation aérienne ou de communication, le contrôle de
la circulation aérienne, les équipements de survie ou les systèmes d’armes, pour lesquels la défaillance du produit peut
provoquer la mort, des blessures corporelles ou de graves dommages matériels ou environnementaux (”activités à risque
élevé”). La société Automationdirect.comEnie toute garantie expresse ou implicite d’aptitude à l’emploi en ce qui a trait
aux activités à risque élevé.
Pour des renseignements additionnels touchant la garantie et la sécurité, veuillez consulter la section Modalités et
conditions de notre documentation. Si vous avez des questions au sujet de l’installation ou du fonctionnement de cet
équipement, ou encore si vous avez besoin de renseignements supplémentaires, n’hésitez pas à nous téléphoner au
770–844–4200.
Cette publication s’appuie sur l’information qui était disponible au moment de l’impression. À la société
Automationdirect.comE, nous nous efforçons constamment d’améliorer nos produits et services. C’est pourquoi nous
nous réservons le droit d’apporter des modifications aux produits ou aux publications en tout temps, sans préavis ni quelque
obligation que ce soit. La présente publication peut aussi porter sur des caractéristiques susceptibles de ne pas être offertes
dans certaines versions révisées du produit.
Marques de commerce
La présente publication peut contenir des références à des produits fabriqués ou offerts par d’autres entreprises. Les
désignations des produits et des entreprises peuvent être des marques de commerce et appartiennent exclusivement à
leurs propriétaires respectifs. Automationdirect.comEnie tout intérêt dans les autres marques et désignations.
Copyright 2001, Automationdirect.comEIncorporated
Tous droits réservés
Nulle partie de ce manuel ne doit être copiée, reproduite ou transmise de quelque façon que ce soit sans le consentement
préalable écrit de la société Automationdirect.comEIncorporated. Automationdirect.comEconserve les droits
exclusifs à l’égard de tous les renseignements contenus dans le présent document.

1
Manual Revisions i
If you contact us in reference to this manual, be sure to include the revision number.
Title: D0–DEVNETS DeviceNet Slave Module User Manual
Manual Number: D0–DEVNETS–M
Edition Date Description of Changes
Original 11/01 Original issue
Rev. A 11/02 Added DL06 references

1i
Table of Contents
Chapter 1: Getting Started
Introduction 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The Purpose of this Manual 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supplemental Manuals 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Who Should Read this Manual 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Support 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conventions Used 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Topics for Each Chapter 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction to DeviceNet 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DeviceNet Concepts 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The ODVA 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Information about the D0–DEVNETS 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mini Glossary 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2: Installing the DeviceNet Slave Module
Installing the D0–DEVNETS Slave Module 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting the DIP Switch (SW1) 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remove the Slot Cover 2–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Insert the Module 2–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Set the Node Address 2–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring the Adapter to a DeviceNet Network 2–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configure the Adapter 2–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring the DeviceNet Adapter 2–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Status Indicators 2–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D0–DEVNETS Parameter Setup 2–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D0–DEVNETS Default Parameters 2–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Software and Firmware Requirements 2–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Update Your DirectSOFT32 Programming Software 2–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Update Your DL05 Firmware 2–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the D0–DEVNETS Setup Parameters 2–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix A: Specifications
Appendix B:Tables
Data Input and Output Tables B–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Device Profile Tables B–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ii Table of Contents
Appendix C: Image Table Mapping
Image Table Mapping C–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PLC Mode Image Table Mapping C–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix D: Special Relays and DIP Switch Parameter
Initializing
Network Status Speicial Relays D–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Initializing Parameter Values D–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix E: D0–DEVNETS Think & Do/Entivity Setup
D0–DEVNETS Think & Do/Entivity Setup E–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
T&D/Entivity setup for PC control E–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup Think & Do with DL05 on a network E–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
T & D Studio setup E–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix F: OIT with D0–DEVNETS
Using an OIT with D0–DEVNETS F–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
T&D Studio F–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix G: D0–DEVNETS and Allen–Bradley Set up
Setup D0–DEVNETS with Allen–Bradley RSNetWorxt G–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RSLinx G–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RSLogix G–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configure D0–DEVNETS with RSNetWorx G–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the EDS file G–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Go on line G–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Set up I/O parameters G–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map the nodes G–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Set Class Instance Attribute G–18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1
Getting Started 1
In This Chapter. . . .
— Introduction
— Introduction to DeviceNet
— General Information About D0–DEVNETS

Getting Started
Installation and
Safety Guidelines
1–2 Getting Started
D0–DEVNETS DeviceNet Slave
Module User Manual, Rev A
Introduction
This manual describes the installation and
operation of the D0–DEVNETS Slave
Module (D0–DEVNETS).
The following manuals are essential for the proper use of your DL05 DeviceNet
Slave Module.
•DL–05 Micro PLC User Manual part number D0–USER–M
This manual contains very important information, including a complete
I/O Module Memory Map. The Memory Map is crucial in designing and
implementing the I/O system.
•The PLC/PC software manual
•The DeviceNet software (if separate) manual
•The DeviceNet Scanner (or Master) manual
If you have a working knowledge of the DeviceNet network, the DeviceNet software
and PLC or PC which you are using, this manual will help you configure and install
your D0–DEVNETS Slave Module.
We strive to make our manuals the best in the industry and rely on your feedback in
reaching our goal. If you cannot find the solution to your particular application, or, if
for any reason you need additional technical assistance, please call us at
770–844–4200.
Our technical support team is glad to work with you in answering your questions.
They are available weekdays from 9:00 a.m. to 6:00 p.m. Eastern Time. We also
encourage you to visit our website where you can find technical and nontechnical
information about our products and our company.
www.automationdirect.com
The Purpose of
this Manual
Supplemental
Manuals
Who Should Read
this Manual
Technical Support

Getting Started Installation and
Safety Guidelines
1–3
Getting Started
D0–DEVNETS DeviceNet Slave
Module User Manual, Rev A
The “light bulb” icon in the left-hand margin indicates a tip or shortcut.
The “note pad” icon in the left–hand margin indicates a special note.
The “exclamation mark” icon in the left-hand margin indicates a warning or caution.
These are very important because the information may help you prevent serious
personal injury or equipment damage.
The beginning of each chapter will list the
key topics that can be found in that
chapter.
1
Conventions Used
Key Topics for
Each Chapter

Getting Started
Installation and
Safety Guidelines
1–4 Getting Started
D0–DEVNETS DeviceNet Slave
Module User Manual, Rev A
Introduction to DeviceNet
DeviceNet is a low-cost control bus used to connect field devices to PLCs and PCs.
DeviceNet is designed to reduce the need for hard–wiring while providing
device–level diagnostics. There are a host of manufacturers of DeviceNet products,
offering an array of products including sensors, motor drives and starters, PLCs,
pushbuttons, remote I/O systems, etc.
Here are some DeviceNet concepts you may find helpful.
•DeviceNet supports various communication structures including Peer to
Peer, Multi-master and Master/Slave. The D0–DEVNETS uses the
predefined Master/Slave connection.
•DeviceNet has two types of messaging: Explicit Messaging and I/O
Messaging.
•Explicit Messaging is low priority, not time-critical and usually
for configuration/diagnostic purposes.
•I/O Messaging is time-critical and high priority
for I/O data transfer. I/O Messaging comes in four types:
•Strobed
•Polled (The D0–DEVNETS only supports Polled.)
•Change of State (or COS)
•Cyclic
•A single DeviceNet network is limited to 64 nodes. A node can be a
single-bit device, such as a limit switch, or a remote I/O slave with
several I/O modules, such as the D0–DEVNETS. The Master (Scanner)
is usually assigned to node address 0, and many Slave devices have a
factory default node address of 63.
•DeviceNet has the following data rates (with maximum bus lengths):
•125 kbps (bus length = 500m max.)
•250 kbps (bus length = 250m max.)
•500 kbps (bus length = 100m max.)
•The 24V DeviceNet power supply must be grounded at only one point.
The V– terminal must be connected to Protective Earth Ground at the
power supply only.
The DeviceNet standard is maintained by the ODVA (Open DeviceNet Vendor
Association, Inc.). Contact the ODVA for detailed information about DeviceNet.
Open DeviceNet Vendor Association, Inc.
20423 State Road 7
Suite 499
Boca Raton, FL 33498
Phone: [phone]
Fax: [phone]
Internet: www.odva.org
Email: [email protected]
DeviceNet
Concepts
The ODVA

Getting Started Installation and
Safety Guidelines
1–5
Getting Started
D0–DEVNETS DeviceNet Slave
Module User Manual, Rev A
General Information about the D0–DEVNETS
The D0-DEVNETS slave module offers the following
features:
SThe D0–DEVNETS installs into any of the DL05
PLC’s option slot. The PLC must have firmware
version 3.0 or higher installed.
SThe D0–DEVNETS can be installed in any of the
four option slots of the DL06 PLC. The PLC must
have firmware version 1.0 or higher installed.
SOnly one D0–DEVNETS can be installed in the
DL06 PLC.
SThe D0–DEVNETS is an interface for DeviceNet
(slave mode only).
SThe D0–DEVNETS collects and reports all discrete
I/O data to a DeviceNet master as polled data.
SThe D0–DEVNETS does not poll analog I/O data,
the analog I/O is looked at in registers. Refer to the
D0–DEVNETS–M pointer method setup for the
analog module being used.
SThe D0–DEVNETS can either be configured in the
DL05/06 for slave I/O mode without the need for a
ladder program or programmed with ladder control
logic as part of a network.
SLEDs for the Module Status and Network Status.
SNode address switches are easily accessed.
Environmental specifications for the D0–DEVNETS are the same as for the DL05/06
PLCs. UL and CE approvals are pending. See Appendix A for detailed
specifications.
Below is a small glossary of terms used in this manual.
Scanner or Master The DeviceNet Master of which the
D0–DEVNETS is a slave. This can be either a
PLC module or a card in your PC.
Adapter or Slave Short for the D0–DEVNETS Slave Module.
The adapter is also referred to as a Network
Interface Module elsewhere.
Node Address or MAC ID The unique device address on a DeviceNet
network. There are a maximum of 64 total (0–63).
Usually the scanner is node 0.
_________________________________________________________
Specifications
Mini Glossary

1
Installing the
DeviceNet Slave
Module
2
In This Chapter. . . .
— Installing the D0–DEVNETS Slave Module
— Configure the Adapter
— D0–DEVNETS Parameter Setup
— Software and Firmware Requirements
— Writing the D0–DEVNETS Setup

Installation and
Safety Guidelines Installing the DeviceNet
Slave Module
2–2 Installing the D0–DEVNETS Slave Module
D0–DEVNETS DeviceNet Slave
Module User Manual, Rev A
Installing the D0–DEVNETS Slave Module
The DIP switch, SW1 must be set before installing the DeviceNet slave module in the
DL05 option slot or in one of the DL06 option slots. The following diagram shows the
location of the DIP switch.
Note: Be sure to look closely at the default settings below. If you are connecting to
an existing DeviceNet network, you may need to change the DeviceNet Baud Rate
on your D0–DEVNETS. The factory default baud rate is 125kbps.
SW2 SW3
Node Address
1
2
3
4
5
6
O
F
F
SW1
DIP Switch
SW1 1
2
5
6
4
3
DeviceNet Baud Rate
Slave I/O Only Mode
Adapter Diagnostic Information
Hold Outputs (on Comm. Error)
Parameter Initializing
OFF
Set SW1–1 and SW1–2 for the DeviceNet baud rate.
DeviceNet Baud Rate
Baud Rate SW1–1 SW1–2
125 kbps OFF OFF
250 kbps ON OFF
500 kbps OFF ON
Reserved ON ON
Setting the DIP
Switch (SW1)

Installing the DeviceNet
Slave Module
Installation and
Safety Guidelines
2–3
Installing the D0–DEVNETS Slave Module
D0–DEVNETS DeviceNet Slave
Module User Manual, Rev A
Set the DL05/06 to Slave Mode.
When SW1–3 is ON, the DL05/DL06 can be placed in the RUN mode with the
external RUN/TERM/STOP switch (with or without a program in it).
Slave I/O Only Mode
Mode SW1–3
Slave I/O only ON
Normal OFF
Eliminate adapter diagnostic information bits from I/O polling.
When SW1–4 is OFF D0–DEVNETS adds adapter information to the head of I/O
polling.
Adapter diagnostic
information
Mode SW1–4
Disable ON
Enable OFF
Note: Leaving position 4 OFF will add 2 bytes of inputs and 2 bytes of outputs for
diagnostic information at the beginning of your I/O polling. Refer to the Adapter
Input/Output Status Word tables on page C–8.
Position SW1–5 ON will hold the outputs on if there is a communication error.
Hold Outputs
(on Comm. Error)
Outputs SW1–5
Turn Off OFF
Hold ON
Position SW1–6 ON will initialize the D0–DEVNETS system parameters.
Parameter Initializing
Mode SW1–6 Description
Initialize 1 ON Default is set when power is ON *1
Initialize 2 OFF
*1 Initialization parameter value changes with status of DIP switch positions 3 and 6.
Refer to the Initialization Parameter Values table on page D–2.
Note: All DIP switch postions shown are the factory default settings (all OFF).

Installation and
Safety Guidelines Installing the DeviceNet
Slave Module
2–4 Installing the D0–DEVNETS Slave Module
D0–DEVNETS DeviceNet Slave
Module User Manual, Rev A
When the D0–DEVNETS module is ready to be installed the protective option slot
cover must be removed. The protective cover is removed from the option card slot by
squeezing the pinch tabs and lifting the cover off.
Option Module
Slot Covers
Pinch Tabs
C0 C4C2X1 X3 X4 X6 X11 X13 X14 X16 X21 X23 N.C.
C1 C3X2 X5 X7 X10 X12 X15 X17 X20 X22X0 N.C.
AC(N)24V
0V
N.C.
C1 C3Y0 Y15Y12Y10 Y17Y7Y5Y2
C0 C2 Y16Y14Y13Y11Y6Y4Y3Y1
LGG
AC(L)
2.0AOUTPUT: 6–240V 50 – 60Hz 2.0A, 6 – 27V
INPUT: 12 – 24V 3 – 15mA
Y
X
40VA50–60HzPWR: 100–240V
0 1 2 3 4 5 6 7 10 11 12 13 14 15 16 17 20 21 22 23
PORT1 PORT2
TERM
RUN STOP
PWR
RUN
CPU
TX1
RX1
TX2
RX2
D0–06DR
WARNING: Power to the PLC must be disconnected before inserting or removing
the D0–DEVNETS slave module. Failure to disconnect power could result in serious
damage to the module, the PLC or both.
Remove the
Slot Cover

Installing the DeviceNet
Slave Module
Installation and
Safety Guidelines
2–5
Installing the D0–DEVNETS Slave Module
D0–DEVNETS DeviceNet Slave
Module User Manual, Rev A
Insert the D0–DEVNETS slave module into the open card slot. Locate the module so
the printed information is oriented in the same direction as the markings on the PLC.
Be careful to align the female connector on the printed circuit board of the module
with the male connector on the PLC mother board. Press the module into the slot
until the front of the module is flush with the front of the PLC.
STATUS
NS
MS
D0–DEVNETS
C0 C4C2X1 X3 X4 X6 X11 X13 X14 X16 X21 X23 N.C.
C1 C3X2 X5 X7 X10 X12 X15 X17 X20 X22X0 N.C.
AC(N)24V
0V
N.C.
C1 C3Y0 Y15Y12Y10 Y17Y7Y5Y2
C0 C2 Y16Y14Y13Y11Y6Y4Y3Y1
LGG
AC(L)
2.0AOUTPUT: 6–240V 50 – 60Hz 2.0A, 6 – 27V
INPUT: 12 – 24V 3 – 15mA
Y
X
40VA50–60HzPWR: 100–240V
0 1 2 3 4 5 6 7 10 11 12 13 14 15 16 17 20 21 22 23
PORT1 PORT2
TERM
RUN STOP
PWR
RUN
CPU
TX1
RX1
TX2
RX2
D0–06DR
STATUS
NS
MS
D0–DEVNETS
Insert the Module

Installation and
Safety Guidelines Installing the DeviceNet
Slave Module
2–6 Installing the D0–DEVNETS Slave Module
D0–DEVNETS DeviceNet Slave
Module User Manual, Rev A
Once the D0–DEVNETS is installed in the option slot, set the Node Address. The
Node Address rotary switches are accessed by removing the cover located to the
right of Port1 and Port2 on the DL05.
PORT1 PORT2
RUN
TERM
STOP
Node Address
SW3 X10
SW2 X1
Node Address
Rotary Switches
Remove the cover associated with the option slot where the D0–DEVNETS is
installed in for the DL06 Once the access cover is removed, use a small, flat,
screwdriver to set the Node Address to an available address (or MAC ID), from 0 –
63. Note that SW3 sets the tens and SW2 sets the units.
Connect the DeviceNet cable (Belden 3085A, YR–29832 or equivalent) to the
removable connector as shown below. The wire colors are also labeled on the front
of the adapter. Be sure to connect a terminating resistor (121 Ohm 1%, 1/4W). An
external 11–25 VDC power supply is also required.
Connect a terminating
resistor across the CAN
High (white) and CAN
Low (blue) screw
terminals.
The terminating resistor i
s
121 Ohm 1%, 1/4 Watt. (
2
resistors are included wit
h
each D0–DEVNETS).
V– (black)
V+ (red)
CAN* Low (blue)
Shield (bare)
CAN* High (white)
* Controller Area Network (CAN)
Tip: Be sure that each end of the DeviceNet network ’trunk” has a proper terminating
resistor connected as shown above.
Set the Node
Address
Wiring the Adapter
to a DeviceNet
Network

Installing the DeviceNet
Slave Module
Installation and
Safety Guidelines
2–7
Installing the D0–DEVNETS Slave Module
D0–DEVNETS DeviceNet Slave
Module User Manual, Rev A
Configure the Adapter
Use the software of your DeviceNet master to configure the controller for your
network. Refer to the software Help file and/or manual for help with configuration.
Follow these basic steps when configuring your D0–DEVNETS adapter.
1. Set the Adapter Node Address:
In the DeviceNet master software, make sure the adapter node address is
set to an available node number on the DeviceNet network (from 0 to 63).
2. Add the EDS file (if required by the software):
In your DeviceNet software, add the D0–DEVNETS Electronic Data Sheet
(EDS) file from the disk which came with this manual or from our web site
www.automationdirect.com. Some software may not provide for the use
of EDS files.
3. Commission the Node:
Use the DeviceNet software to “Commission the Node” of the adapter.
Again, some software may not require this.
4. Add the D0–DEVNETS to the Scan List:
Add the D0–DEVNETS to the Scan List in your DeviceNet Master software.
5. Set the Input/Output Bytes:
If required by your DeviceNet software, set the I/O Parameters to Tx =
Output bytes and Rx = Input bytes, for Polled I/O. Follow the steps in
Appendix G to determine the actual number of Output and Input bytes your
system has.
6. Map the I/O to the Master:
Map the D0–DEVNETS I/O to the Scanner using Auto Map, or map the I/O
to another location if desired.
7. Scan:
Go Online (or Scan) to verify the configuration and check for errors.
8. View Indicators on the adapter:
Refer to the Status Indicators when connecting to the network.
Configuring the
DeviceNet Adapter

Installation and
Safety Guidelines Installing the DeviceNet
Slave Module
2–8 Installing the D0–DEVNETS Slave Module
D0–DEVNETS DeviceNet Slave
Module User Manual, Rev A
STATUS
NS
MS
The adapter has two Status Indicators,
one for Module Status and the other for
Network Status.
MS (Module Status) Indicator
Indication Status
OFF No power to module.
Solid Green Power is ON, normal condition
Solid Red Critical module Failure
NS (Network Status) Indicator
Indication Status
OFF No power to module or no Network Access
Flashing Green Online but not connected (no connection
established)
Solid Green Online, link okay and connected
Flashing Red Recoverable fault
Solid Red Critical module Failure (Duplicate ID or Bus off)
Status Indicators

Installing the DeviceNet
Slave Module
Installation and
Safety Guidelines
2–9
Installing the D0–DEVNETS Slave Module
D0–DEVNETS DeviceNet Slave
Module User Manual, Rev A
D0–DEVNETS Parameter Setup
The DL05/06 PLCs reserve several V–memory locations for storing the DEVNETS
parameters. These special registers store the I/O ranges. The parameters are
stored in the DL05/06 systems FLASH memory, and are not lost when the PLC is
powered off.
System
V-memory
Description of Contents Factory Default Value Range
V7610 Input starting address V40400 V40400 – 40417 (X0–377)
V40500 – 40517 (Y0–377)
V40600 – 40637 (C0–777)
V41000 – 41017 (S0 – 377)
V41100 – 41107 (T0 – 177)
V41140 – 41147 (CT0 – 177)
V41200 – 41237 (SP0 – 777)
V7611 Input number of bytes 2 Bytes 0 – 8 Bytes
V7612 Output starting address V40500 V40400 – 40417 (X0 – 377)
V40500 – 40517 (Y0–377)
V40600 – 40637 (C0–777)
V41000 – 41017 (S0–377)
V41100 – 41107 (T0 – 177)
V41140 – 41147 (CT0 – 177)
V41200 – 41237 (SP0 – 777)
V7613 Output number of bytes 2 Bytes 0 – 8 Bytes
V7614 Input starting V–memory location V3000 V0 – 7777
V7615 Input V–memory number of bytes 58 Bytes 0 – 128 Bytes
V7616 Output starting V–memory location V3100 V0 – 7377
V7617 Output V–memory number of bytes 52 Bytes 0 – 128 Bytes
D0–DEVNETS
Default Parameters
