Autonics KRN50 SERIES User manual

Thank you for purchasing anAutonics product.
This user manual contains information about the product and its proper use,
and should be kept in a place where it will be easy to access.
www.autonics.com
User Manual
Recorder
KRN50 Series
AEP-K-0104-AA

Preface
ii © Copyright Reserved Autonics Co., Ltd.
Preface
Thank you for purchasing autonics product.
Please familiarize yourself with the information contained in the Safety Precautions section
before using this product.
This user manual contains information about the product and its proper use, and should be kept
in a place where it will be easy to access.

User Manual Guide
© Copyright Reserved Autonics Co., Ltd. iii
User Manual Guide
Please familiarize yourself with the information in this manual before using the product.
This manual provides detailed information on the product's features. It does not offer any
guarantee concerning matters beyond the scope of this manual.
This manual may not be edited or reproduced in either part or whole without permission.
A user manual is not provided as part of the product package.
Visit our web site (www. autonics.com) to download a copy.
The manual's content may vary depending on changes to the product's software and other
unforeseen developments within autonics, and is subject to change without prior notice.
Upgrade notice is provided through out homepage.
We contrived to describe this manual more easily and correctly. However, if there are any
corrections or questions, please notify us these on our homepage.

User Manual Symbols
iv © Copyright Reserved Autonics Co., Ltd.
User Manual Symbols
Symbol Description
Supplementary information for a particular feature.
Failure to follow instructions can result in serious injury or death.
Failure to follow instructions can lead to a minor injury or product damage.
An example of the concerned feature's use.
※1 Annotation mark.

Safety Precautions
© Copyright Reserved Autonics Co., Ltd. v
Safety Precautions
Please follow safety precautions to ensure the safe and proper use of the product and
prevent accidents, as well as minimizing possible hazards.
Safety precautions are categorized as Warnings and Cautions, as defined below:
Warning Cases that may cause serious injury or fatal accident if
instructions are not followed.
Caution Cases that may cause minor injury or product damage if
instructions are not followed.
Fail-safe device must be installed when using the unit with machinery that may cause serious
injury or substantial economic loss. (e.g. nuclear power control, medical equipment, ships,
vehicles, railways, aircraft, combustion apparatus, safety equipment, crime/disaster prevention
devices, etc.)
Failure to follow this instruction may result in personal injury, economic loss or fire.
Do not connect, repair, or inspect the unit while connected to a power source.
Failure to follow this instruction may result in fire or electric shock.
Check 'Connections' before wiring.
Failure to follow this instruction may result in fire.
Do not touch the product during operation or for a certain period of time after stopping.
Failure to follow this instruction may result in burn or fire.
Do not use the unit in the place where flammable/explosive/corrosive gas, high humidity, direct
sunlight, radiant heat, vibration, impact, or salinity may be present.
Failure to follow this instruction may result in explosion or fire.
Install on the device panel or DIN rail, and ground to the F.G. terminal separately.
When connecting the F.G. terminal, use AWG16(1.25mm²) or over.
Failure to follow this instruction may result in fire or electric shock.
Do not disassemble or modify the unit.
Failure to follow this instruction may result in fire or electric shock.
Since Lithium battery is embedded in the product, do not disassemble or burn the unit.
Failure to follow this instruction may result in fire.

Safety Precautions
vi © Copyright Reserved Autonics Co., Ltd.
Use the unit within the rated specifications.
Failure to follow this instruction may result in fire or product damage.
Use a dry cloth to clean the unit, and do not use water or organic solvent.
Failure to follow this instruction may result in fire or electric shock.
Keep the product away from metal chip, dust, and wire residue which flow into the unit.
Failure to follow this instruction may result in fire or product damage.
When connecting the power input or measurement input, use AWG20(0.50mm²) cable or over
and tighten the terminal screw with a tightening torque of 0.74 to 0.9N.m.
Failure to follow this instruction may result in fire or malfunction due to contact failure.
Do not use the load beyond rated switching capacity contact.
Failure to follow this instruction may result in fire, relay broken, contact melt, insulation failure or
contact failure.
※The above specifications are subject to change and some models may be discontinued
without notice.
※Be sure to follow cautions written in the instruction manual and the technical descriptions
(catalog, homepage).

Table of Contents
© Copyright Reserved Autonics Co., Ltd. vii
Table of Contents
Preface ............................................................................................................................. ii
User Manual Guide ..........................................................................................................iii
User Manual Symbols ..................................................................................................... iv
Safety Precautions ........................................................................................................... v
Table of Contents ........................................................................................................... vii
1Overview ......................................................................................................9
1.1 Features...............................................................................................................9
1.2 Component and sold separately........................................................................10
1.2.1 Components ............................................................................................... 10
1.2.2 Sold separately........................................................................................... 11
1.3 Ordering information.......................................................................................... 11
1.4 Part descriptions ................................................................................................12
2Specifications............................................................................................13
2.1 Input type and range..........................................................................................15
3Dimensions................................................................................................16
4Connections ..............................................................................................17
5Installation .................................................................................................18
5.1 Installation places ..............................................................................................18
5.2 Installation..........................................................................................................19
5.2.1 Panel mounting .......................................................................................... 19
6Functions...................................................................................................20
7General operation and parameter setting menu.....................................21
7.1 Operation mode .................................................................................................21
7.2 Operation procedure..........................................................................................21
7.3 Setting keys .......................................................................................................22
7.4 Parameter groups ..............................................................................................25
8Recording ..................................................................................................26
8.1 Recording preparation .......................................................................................26
8.2 Explanation for input function and setup ...........................................................27
8.2.1 Input type setup.......................................................................................... 27
8.2.2 Alarm function setup .................................................................................. 34
8.2.3 Recording setup ......................................................................................... 43
8.2.4 Display information function ....................................................................... 59
9Communication.........................................................................................63
9.1 ModBus address Map........................................................................................65
10 DAQMaster ................................................................................................69
10.1 Overview ............................................................................................................69
10.2 Features.............................................................................................................70
10.3 Dedicated function for KRN50...........................................................................71

1 Overview
© Copyright Reserved Autonics Co., Ltd. 9
1Overview
1.1 Features
50mm thermal transfer method of paper recorder
Data logger function for recording without paper
2-channel simultaneous recording
- graphic mode, digital mode
RS485 communication and dedicated communication port to set or monitor parameters in
real-time by PC/PLC
Multi-input with high accuracy 0.2% level (TC, RTD, Voltage, Current(shunt))
Various option I/O function
Small size (W96×H96×L100mm), light weight

1 Overview
10 © Copyright Reserved Autonics Co., Ltd.
1.2 Component and sold separately
1.2.1 Components
Before using KRN50, check the component.
If any component is left out or damaged, contact our company or seller.

1 Overview
© Copyright Reserved Autonics Co., Ltd. 11
1.2.2 Sold separately
Communication converter
SCM-38I (RS232C to RS485 converter) SCM-US48I
(USB to RS485 converter)
SCM-US
(USB to Serial converter)
SCM-WF48(available soon)
(Wi-Fi to RS485/USB converter)
1.3 Ordering information
(1) Ordering information
※1. When selecting this for 2 CH model, 2EA alarm outputs for CH1 are available. In other
words, you cannot set 1EA for CH1 and 1EA for CH2.
※2. It is selectable only for 2 CH model.

1 Overview
12 © Copyright Reserved Autonics Co., Ltd.
1.4 Part descriptions
①CH 1 alarm(AL1) output indicator: Turns ON when AL1 of input channel 1 operates.
②CH 1 alarm(AL2) output indicator: Turns ON when AL2 of input channel 1 operates.
③CH 2 alarm(AL1) output indicator: Turns ON when AL1 of input channel 2 operates.
④CH 2 alarm(AL2) output indicator: Turns ON when AL2 of input channel 2 operates.
⑤Recording run()/Recording stop( ) indicator: turns ON when start recording
(RUN). turns ON when stopping recording (STOP).
⑥Digital input indicator: Turns ON when setting digital input.
⑦Recording reservation(RE) indicator: RE turns ON when recording reservation operates.
⑧Recording paper status( )indicator: turns ON if running out of recording paper
during recording (RUN).
⑨Channel(CH) display part: Displays input channel of currently displayed PV on the PV
display part.
⑩PV display part: In RUN mode, displays PV of the current channel.
In setting mode, displays parameters and mode setting values.
⑪Unit display part: Unit of relevant channel is indicated.
⑫key: Used to enter setting mode and changing SV mode.
⑬, key: Used to move parameters or increase/decrease digits.
key: Digital memo key, key: Recording Run/Stop key
⑭key: Used to move parameters to upper group or move digits
Paper feeding key (STOP), printing parameter setting information key (RUN)
⑮PC loader port: It is a PC loader port for serial communication to set or monitor
parameters by PC.
Used to connect SCM-US (USB to Serial converter, sold separately).

2 Specifications
© Copyright Reserved Autonics Co., Ltd. 13
2Specifications
Series
KRN50
Power
supply
AC voltage
100-240VAC 50 to 60Hz
DC voltage
24VDC
Allowable
voltage
range
AC voltage
85 to 110% of rated voltage
DC voltage
90 to 110% of rated voltage
Power
consumpti
on
AC voltage
Max. 34VA
DC voltage Max. 79W
Display method
LCD Dot matrix Display (resoultion 128
×
32 Dot)
Input type
RTD
JPt100
Ω
, DPt100
Ω
, DPt50
Ω
, Cu100
Ω
, Cu50
Ω
(5 type)
TC
K, J, E, T, B, R, S, N, C, G, L, U, PLII (13 types)
Analog
ㆍ
Voltage: - 50.0-50.0mV, - 199.0-200.0mV, - 1.000-1.000V,
- 1.00-10.00V (4 types)
ㆍCurrent: 0.00-20.00mA, 4.00-20.00mA (2 types)
※For current input, connect external 50 Ω B class (0.1%) high-
accuracy resistor.
Event
input
Contact
Input ON : Max. 1k
Ω
, OFF : Min. 100k
Ω
Non-contact
Input ON : Residual voltage max. 1V, OFF : leakage current max.
0.05mA
Outflow current
Approx. 0.3mA
Display
accuracy
※
1
RTD
±
0.2%F.S.
±
1digit(25
±
5
℃
),
±
0.3%F.S.
±
1digit
(0 to 20℃, 30 to 50℃)
Below -100℃for TC is ±0.4%F.S.±1digit
(TC-K2 has same accuracy with TC-K1 and -200 to 1350
℃
range)
TC
Analog
Display accuracy
±
0.5%F.S.
Alarm output
CH1(AL1, AL2), CH2(AL1, AL2)
Relay output(250VAC/30VDC 3A 1a)
Alarm output hysteresis
ON/OFF interval setting for alarm output: 1 to 999digit variable
Alarm output
RS485 communication output(Modbus RTU protocol method)
Set method
Setting by front keys
Sampling cycle
500ms/CH
×
2CHs = 1000ms
Dielectric strength
2300VAC 50/60Hz for 1 min.
(charging terminal of the other polarity)
Vibration
0.75 mm amplitude at frequency of 10 to 55 Hz (for 1 min.)
in each of X, Y, Z directions for 1 hour
Relay life cycle
Mechanical: Over 5,000,000 operations, Electrical: Over 100,000
operations
Insulation resistance
Over 100 MΩ (at 500 VDC megger)
Noise resistance
Square shaped noise by noise simulator (pulse width 1
㎲
)±2 kV

2 Specifications
14 © Copyright Reserved Autonics Co., Ltd.
Print
Method
Direct thermal line print
Resolution
8dot/mm
Dots
384dot/Line
Life cycle
50km
Record
Graphic mode
ㆍ
Record speed (recording paper speed): 10, 30, 60, 120, 240, 480,
960mm/hour
ㆍMemo period: 30s, 1min, 5min, 10min, 15min, 30min, 1hour,
2hour, 3hour, 4hour, 8hour, 16hour, 24hour
Digital mode
TEXT mode record cycle: 00m 05s to 99m 59s
Paper
Thermal Direct Receipt Paper (57mm
×
16m)
Paper supply
method
Clamshell Type
Language
Korean, English
Environm
ent
Ambient
temperature
0 to 50℃, Storage: - 20 to 60℃
Ambient
humidity
35 to 85%RH, Storage: 35 to 85%RH
Approval
Unit weight
Approx. 700g
※1. Exception range for measurement accuracy by each sensor
J: -200≤T≤-100 ±2.7℃
R, S, C, G: 0≤T≤100 ±5.2℃
B: below 400℃, there is no accuracy standard
U, T: -200≤T≤-100 ±3.5℃, -100≤T≤400 ±2.5℃
※Environment resistance is rated at no freezing or condensation.

1
© Copyright Reserved Autonics Co., Ltd. 15
2.1 Input type and range
Input type Display Input range(℃) Input range (℉)
Thermoco
uple
K(CA) 1 TC-K1 -200 to 1350 -328 to 2462
0.1 TC-K2 -199.9 to 999.9 -199.9 to 999.9
J(IC) 1 TC-J1 -200 to 800 -328 to 1472
0.1 TC-J2 -199.9 to 800.0 -199.9 to 999.9
E(CR) 1 TC-E1 -200 to 800 -328 to 1472
0.1 TC-E2 -199.9 to 800.0 -199.9 to 999.9
T(CC) 1 TC-T1 -200 to 400 -328 to 752
0.1 TC-T2 -199.9 to 400.0 -199.9 to 752.0
B(PR) 1 TC- B 100 to 1800 212 to 3272
R(PR) 1 TC-R 0 to 1750 32 to 3182
S(PR) 1 TC-S 0 to 1750 32 to 3182
N(NN) 1 TC-N -200 to 1300 -328 to 2372
C(TT) ※11 TC-C 0 to 2300 32 to 4172
G(TT) ※21 TC-G 0 to 2300 32 to 4172
L(IC) 1 TC-L1 -200 to 900 -328 to 1652
0.1 TC-L2 -199.9 to 900.0 -199.9 to 999.9
U(CC) 1 TC-U1 -200 to 400 -328 to 752
0.1 TC-U2 -199.9 to 400.0 -199.9 to 752.0
Platinel II 1 TC-P 0 to 1390 32 to 2534
RTD
CU 50Ω0.1 CU50 -199.9 to 200.0 -199.9 to 392.0
CU 100Ω0.1 CU100 -199.9 to 200.0 -199.9 to 392.0
JIS
standard
JPt 100Ω(3916) 1 JPT1 -200 to 600 -328 to 1112
JPt 100Ω0.1 JPT2 -199.9 to 600.0 -199.9 to 999.9
DIN
standard
DPt 50Ω0.1 DPT50 -199.9 to 600.0 -199.9 to 999.9
DPt 100Ω(385) 1 DPT1 -200 to 600 -328 to 1112
DPt 100Ω0.1 DPT2 -199.9 to 600.0 -199.9 to 999.9
Analog
Voltage
-50.0 to 50.0mV 50mV
-1999 to 9999
(display range depends on the
decimal point position.)
-199.9 to 200.0mV 200mV
-1.000 to 1.000V 1V
-1.00 to 10.00V 10V
Current 0 to 20mA 0-20
4 to 20mA 4-20
※1. C(TT): Same as exisitng W5(TT).
※2. G(TT): Same as exisitng W(TT).

3 Dimensions
16 © Copyright Reserved Autonics Co., Ltd.
3Dimensions
(1) KRN50
(2) Panel cut-out

4 Connections
© Copyright Reserved Autonics Co., Ltd. 17
4Connections
※Shaded terminals are for the standard model. (power terminal, CH1 input terminal, DI input
terminal)
※Dot line terminals are for the option model. (CH2 input terminal, alarm output terminal,
communication output terminal)
※The DC power model does not have F.G.
※When using 2-wire RTD, short B and b terminals.
※For current input, connect external 50Ω B class(0.1%) high-accuracy resistor.

5 Installation
18 © Copyright Reserved Autonics Co., Ltd.
5Installation
5.1 Installation places
Install this unit in place where the below conditions are satisfied.
Instrument Panel
This recorder is panel mounting type.
Place where ventilation is well
To prevent from malfunction and damage by overheating (use temperature range: 0 to 50℃),
install this unit where ventilation is well.
In case installing several KRN50, space each other by panel cut-out.
Place where vibration is not severe
If there is too much vibration, it may cause malfunction such as print error.
In case of temperature measurement with thermocouple temperature sensor at the place
where temperature is fluctuated, data error may occur. You should warm-up this unit over 30
min. to acquire accurate data before using it.
At the place where temperature and humidity is fluctuated excessively, recording paper
color may be changed.
.

5 Installation
© Copyright Reserved Autonics Co., Ltd. 19
5.2 Installation
5.2.1 Panel mounting
Install KRN50 on the processed panel as panel cut-out diagram. Mount fixing brackets
on upper/lower parts.
Tighten fixing brackets on upper/lower parts to fix on the panel with phillips screwdriver
(+). (Torque: 0.3N•m)
Wire cables to the rear terminal block.
If using only 1 channel in case of 2 channel model, please short-circuit the input channel (+,-
input) not used in order to prevent from noise influence.
If cable connected with recorder has strong power, it may cause damage to recorder or terminal
block.
Input must be installed as far as possible from power line.
Terminal wiring must be divided from high-voltage and high-current power line in order to
prevent from electricity failure and self-induction noise. Also please avoid parallel wiring or same
wiring with power line.
It may be effective if dividing by means of pipe or duct or using shield cable or twisted-pair
cable.
Same compensating wire must be used for precise measurement when thermocouple lead wire
need to extend.
If not, it may cause an accidental error.
When RTD lead wire need to extend, please use it with small resistance value and be equal for
resistive value to 3 lead wires.
Connect wiring after power off in order to prevent from an electric shock.
Check input specifications in order to prevent from any damages.

6 Functions
20 © Copyright Reserved Autonics Co., Ltd.
6Functions
KRN50 recorder is able to measure Thermocouple, RTD, voltage (1V DC,10V DC,50mV
DC,200mV DC), current(DC 0 to 20mA, DC 4 to 20mA) signal by total 2 input channels.
Measured signal records by digital and graph type through setting a variety of recording speed.
Alarm
Input 1 channel can have 2 alarm outputs. Alarm output is operating by a kinds of modes
(None, Latch, Stand-by, Latch+Stand-by) through High-limit, Low-limit, Sensor break, Paper
end function. Alarm outputs by relay contact.
Recording
Measured signal records by digital and graph type. Recording speed is able to set by 5sec
to 99min 59sec in case of digital mode (Numerical record) and by 10 to 960mm/h in case of
graph mode. It has memo function recording data at the necessary time and is able to
output time, date, alarm information, error message, parameter list and so on.
Display
Measured value is indicated by number on LCD display and time, alarm, error information,
etc. are displayed.
Communication function
It is able to use RS-485 communication and communication protocol uses ModBus RTU
and communicates with the upper devices, PC or PLC.
Data backup function (Record Back-up)
It is similar to data logger function. In case of graph mode and 10mm/h recording speed,
approx. 10-day-data is able to be saved in EEPROM memory. Therefore user can output
the saved data from the memory by graph or digital type. Also even though chart paper is
exhausted all, data is able to be saved to the saving space according to recording speed.
Other functions
Feeding function and recording run/stop function are able to be used by front key or
communication at the status of recording stop. Also recording reservation function is able to
start or stop recording at the suitable time period user wants.

7 General operation and parameter setting menu
© Copyright Reserved Autonics Co., Ltd. 21
7General operation and parameter setting menu
7.1 Operation mode
Recorder has 3 kinds of operation modes.
Common operation mode
This mode operates when normal operation. This mode operates when power on.
Setting mode
This mode is to set the parameters as like input range, alarm, recording speed, etc. This
mode is able to set even if operation does not stop on common operation mode.
Backup data recording mode (Record backup data recording mode)
This mode is to record the saved data by means of data logger function. It is also
unnecessary for operation stop.
7.2 Operation procedure
It is the introduction when this recorder operates initially.
Ready to record
Put chart paper in paper holder after cutting the glued part (chart paper is installed in
recorder as factory default). If necessary, change time and date (they are set as factory
default).
Set input and relevant parameter
Set relevant parameter (input type, alarm, record speed) according to input sensor.
Record and display measuring value
If necessary, press key for recording Run / Stop. Also mode is able to be changed by
measuring value display mode relevant key.
