Autostart Redefining the Ultimate Control AS-DSP706 User manual

GUIDE DE
L'UTILISATEUR
OWNER’S GUIDE
The company behind Autostart®
Systems is Directed Electronics.
Autostart was one of the first to
design and build remote control
vehicle starters. Over the years,
a continuing commitment
to quality and reliability has
allowed Autostart to gain a
respected reputation as a high-
end designer of remote start
and security systems. Today,
Autostart continues to set
standards in the industry.
Call [phone] for more
information about our products
and services.
La compagnie à l'origine des
Systèmes Autostart®est
Directed Electronics.
Autostart a été l'un des premiers
à concevoir et à fabriquer des
démarreurs à distance pour
véhicules. Au fil des ans, son
engagement à la qualité et
la fiabilité continu a permis
à Autostart d'obtenir une
réputation enviable en tant
que concepteur de systèmes
de démarrage à distance et
de sécurité haut de gamme.
Aujourd'hui, Autostart continue
d'établir les normes de
l'industrie.
Appelez au (800)876-0800 pour
de l'information supplémentaire
au sujet de nos produits et
services.
Systèmes de démarrage à distance et de sécurité
Remote Start & Security Systems
Redéfinition du contrôle absoluMD
Redefining the Ultimate ControlTM
Directed s'engage à offrir des produits et
services de qualité de classe mondiale qui
raviront les clients.
Directed Electronics is committed to
delivering world class quality products
and services that excite and delight our
customers.
Vista, CA 92801
www.directed.com
Featuring DS4 Tech n olo g y
Technologie DS4 Intégrée
©2017 Directed Electronics, Inc. Tous droits réservés./All rights reserved. 590-10105 ML 2017-07
MODÈLE/MODEL
AS-DSP706

Congratulations
Congratulations on the purchase of your state-of-the-art Autostart Digital System.
Reading this Owner’s Guide prior to using your system will help maximize
the use its many features. For any additional questions please contact your
authorized Autostart dealer.
Note: Your system is configurable and may or may not include features such
as remote start or security. This guide also covers optional features which
may not be applicable to your system. Please speak with your installation
specialist to find out which features are applicable.
Important Information
Government Regulations and Safety Information
Read the Government Regulations and Warning! Safety First sections
of this manual prior to operating this system.
WARNING! Failure to heed this information can result in death,
personal injury or property damage and may also result in the illegal
use of the system beyond its intended purpose.
Your Warranty
Your system comes with a warranty. The warranty terms are detailed at the end
of this guide. Make sure that you receive the proof of purchase from your dealer,
indicating the product was installed by an authorized Autostart dealer.
Replacement Remote Controls
Please see your authorized dealer to order additional remote controls. Remote
control part numbers are typically found on the back of the device.
500-10726-01 2017-07-07

2© 2017 Directed. All rights reserved.

3
© 2017 Directed. All rights reserved.
Table of Contents
Congratulations .................................................................................................. 1
Important Information ......................................................................................... 1
Government Regulations and Safety Information ..................................... 1
Your Warranty..................................................................................... 1
Replacement Remote Controls................................................................ 1
Getting Started.................................................................................................... 4
Charging the remote control.................................................................. 4
Keys to using this manual...................................................................... 5
Introduction ........................................................................................................ 6
ASDS-7506 Remote Control.................................................................. 6
Antenna ............................................................................................. 6
Status Screen Icons.............................................................................................. 7
Using the System............................................................................................... 10
Commands and Confirmations ............................................................ 10
Performing Commands ....................................................................... 10
2-way LCD Remote Control Command Table ....................................................... 11
Basic Commands............................................................................................... 12
Arm/Lock ......................................................................................... 12
Panic Mode ...................................................................................... 12
Disarm/Unlock.................................................................................. 12
Trunk................................................................................................ 12
Remote Start/Stop ............................................................................. 13
Valet Modes...................................................................................... 14
Emergency Override .......................................................................... 14
ASDS-7506 Configuration................................................................................. 15
ASDS-1554 Companion Remote Control............................................................. 16
Battery Information (ASDS-7506) ....................................................................... 17
Low Battery....................................................................................... 17
Battery Information (ASDS-1554) ....................................................................... 18
Battery Replacement........................................................................... 18
Battery Disposal ................................................................................ 18
Patent Information ............................................................................................. 18
Government Regulations .................................................................................... 19
Warning! Safety First......................................................................................... 20
Limited Lifetime Warranty...................................................................................22

4© 2017 Directed. All rights reserved.
Getting Started
Your ASDS-7506 remote is powered by an internal rechargeable battery that
can only be serviced by an authorized Autostart dealer. Due to transit and
storage time prior to your purchase, the battery charge may have depleted. To
ensure proper operation, check the battery level and if not fully charged, use the
provided cable to connect to the USB port on a PC/Laptop or a USB power
adapter. See “Battery Information (ASDS-7506)” on page 17 and “Status
Screen Icons” on page 7 for more information about the battery.
Charging the remote control
1. Plug the USB end of the provided USB cable into the USB port on a
computer or a USB power adapter. Insert the micro-USB connector into the
micro-USB port located on the side of the remote control. The text field will
display CHARGE to indicate the remote control is charging (The remote
remains operational while charging and can command the system).
2. Once fully charged the text field will display FULL .
3. The remote control is then ready for use. Disconnect the cable from the
remote control end first.
Note If the battery is excessively depleted when charging, functionality
may be delayed while it charges to the minimum voltage required to
operate the display, after which normal charging resumes.

5
© 2017 Directed. All rights reserved.
Keys to using this manual
Specific actions (in bold type) and style conventions are used consistently
throughout this manual, they are as follows:
• Press: implies pushing in and the remote will play the transmit beep to send
the command.
• Hold: is used after Press actions. By holding the button for more than 3
seconds, the remote sends another command.
• ARMED this style denotes the text which appears in the text field portion
of the Display during operations described in the manual. If the text string
is too long for the text field, it then plays and loops sequentially word by
word.
• An asterisk (*) when used after a word or phrase denotes that additional
details can be found in related sections usually noted at the bottom of the
page or end of the section.

6© 2017 Directed. All rights reserved.
Introduction
ASDS-7506 Remote Control
Feature Description
Display Status screen - the upper portion of the display contains status icons for the
System, Siren, Alarm zones, Remote Start and Remote Control (if alarm
feature installed).
Text field - the lower portion of display - shows the Clock, Runtime or
Temperature during Remote Start, as well as Command confirmations, Page
messages and programming menus
Command buttons (4)
Used to perform arming, disarming, utility channel and remote start
commands
button Used to access function levels for commands, configuration menus for
programming, Car Selection, and to request reports.
Micro-USB Port The USB cable plugs into this port (located on remote control side).
Antenna
Antenna
Status LED Button
The Antenna sends and receives commands or messages to and from the
system. It consists of:
• The Status LED, as a visual indicator of the system’s status.
• Button, for accessing various feature, programming, and reporting
functions of the system.

7
© 2017 Directed. All rights reserved.
Status Screen Icons
1
ALL
Text Field
Status Screen
Icons
The table below describes all the status screen icons.
Icon Description
System Status

ALL
Lock: The doors are locked, and the included alarm features are
enabled (if installed).

ALL
Lock Valet: The doors are locked, and the included alarm features
are disabled (if installed).

ALL
Unlock: The doors are unlocked, and the included alarm features are
disabled (if installed).

ALL
Unlock Valet: The doors are unlocked, and the included alarm
features are disabled (if installed).

8© 2017 Directed. All rights reserved.
Icon Description
Remote Start

ALL
Remote start is active, the engine is running.

ALL
+

ALL
Cold Weather Mode is ON; Remote Start is ON.
Note: When the icon is without an arrow head:
Timer Start is enabled: Remote Start is OFF.
Start Valet is on - the Remote Start features are disabled.

ALL
Low Temperature Mode is ON; Remote Start is ON.

ALL
Ready Mode is enabled, the engine can be started.

ALL
Displays the vehicle interior temperature.

ALL
ON during Remote Start after performing the Defogger ON
command.
Zone Status

ALL
ON during Warn Away and Full Trigger message output.

ALL
ON during Trunk Zone Full Trigger output and Trunk channel
activation and during Fault Report to indicate the Trunk is open when
the system is armed.

ALL
ON during a Sensor Zone Full Trigger output.

ALL
ON during the Door Zone Full Trigger output and during Fault Report
to indicate a Door is open when the system is armed.

ALL
ON during a Hood Zone Full Trigger output during Fault Report to
indicate the Hood is open when the system is armed.

ALL
ON when remote is set to command the system programmed as Car
1*.

ALL
ON when remote is set to command the system programmed as Car
2*.

9
© 2017 Directed. All rights reserved.
Icon Description
Remote Control Status

ALL
Bars indicate battery level is Full, ¾,½,¼ or Empty.

ALL
ON while the remote control is transmitting a command.

ALL
ON while the remote control is receiving a message.

ALL
ON to indicate the remote failed to receive a command
confirmation.

ALL
Pager ON: The remote will wake up to listen for messages.

ALL
Pager OFF: The remote will not wake up to listen for messages.

ALL
The remote will Vibrate when messages are received.

ALL
The remote will emit Beeps and Tones when messages are received.
Text field Displays the Clock, Runtime, Temperature, message text and feature
menus.
* This icon not present until the Car 2 is turned on in the Setup Remote
configuration menu.
