Avalon A10-TL User manual

A few simple steps to ensure
perfect water, every time.
English

English

www.avalonh2o.com
We’re Here to Help
Let’s Connect
Call Us:
1.800.256.0695
Email Us:
[e-mail]
[e-mail]
Live Chat:
Monday-Thursday: 9 a.m.-5:30 p.m.
Friday: 9 a.m.-4:30 p.m.
@avalon_h2o Avalon Water Coolers Avalonh2o
Follow our social media accounts and stay up to
date on the latest Avalon news.
We are also available
for live video chat!
English

Use and Care Guide
MODELS: A10-TL • A10BLK
Registration
Please visit the website below to register your new water cooler within the first
30 days of purchase. Registration within the first 30 days will activate your one
year warranty.
www.avalonh2o.com/register-my-avalon-cooler
Please keep your model number, order number and purchase date
for future support. You can reach us at 1-800-256-0695.
Model Number
Order Number
Purchase Date
English

Contents
About Your Water Cooler
Meet Your Avalon Product
Part Names
Indicator Lights
Tech Specs
Getting Started
Unpacking
Operation Instructions
Cleaning
Rinsing, Cleaning and Draining
Cleaning
Troubleshooting
Safety
Warranty
1
2-3
4
5
7
8-10
12-14
15-16
18-19
21-22
24
English

1
Meet Your Avalon Product
About Your Water Cooler
English
UL Listed
We design &
manufacture with
your safety in mind
Child Safety Feature
Ensures safe hot
water flow for the
entire family
Attractive Design
Attractive stainless
steel design with 3
water spouts
Top Loading
Suitable for 3 or
5 gallon bottles
Custom Temperature
Piping hot,
cool or crisp
cold water

2
Part Names
8. Bottle Supporter
7. Cold Water
Push Button
6. Cool Water
Push Button
4. Hot Water
Push Button
5. Child Safety Lock
9. Hot Water Spout 11. Cold Water Spout
10. Cool Water Spout
12. Drip Tray
2. Heating Indicator Light
3. Cooling Indicator Light
1. Power Indicator Light
About Your Water Cooler
English

3
Part Names
15. Power Cord
16. Condenser
17. Drain Outlet
13. Cooling Switch 14. Heating Switch
About Your Water Cooler
English

4
Power Indicator Light
This light will remain on as long as the water cooler is plugged in to indicate that
the cooler is on.
Heating Indicator Light
This light will indicate when the water is heating. The light will remain on while the
water is heating and will turn o when it has reached the correct temperature of
185°F. As the water is dispensed the hot tank will refill and the water will heat. As
the water reheats this indicator light will turn on.
Cooling Indicator Light
This light will indicate when the water is cooling. The light will remain on while the
water is cooling and will turn o when it has reach the correct temperature of 47°F.
As the water is dispensed the cold tank will refill and the water will cool. As the
water cools this indicator light will turn on.
Indicator Lights
About Your Water Cooler
English

5
Tech Specs
Model A10-TL
Hot/Cold/Cool Output
Hot Water Capacity
Hot Tank Volume
Cold Water Capacity
Cold Tank Volume
Product Size
Packing Size
Net Weight/Gross Weight
Voltage/Frequency
Cooling Method
Heating Method
Heating Watts / Cooling Watts
Power Consumption
1.8L/min / 2.2L/min / 2.0L/min
4 L/H ( ≥ 185°F)
1.02 Liters
2 L/H ( ≤ 47°F)
3 Liters
13”(L)x12”(W)x40”(H)
16”(L)x15”(W)x42.5”(H)
34.17 lb /38.58 lb
115 V 60Hz
Compressor
Internal Element
420W / 100 W
520 W
Avalon Models A10-TL • A10BLK
About Your Water Cooler
English

7
Getting Started
English

8
Unpacking Your Avalon Water Cooler
The unit has been cleaned prior to departing from the factory. To remove any
dust and debris that may collect during shipping we recommend cleaning the
unit prior to installation. For cleaning instructions see pages 13-17.
Do NOT plug in the power cord yet.
Place dispenser upright on a hard and level surface in a cool and shaded
location near a grounded wall outlet. Position the dispenser so there is about four
inches of clearance from the wall on the back and both sides.
Locating Dispenser
Getting Started
English

9
Operation Instructions
Do not plug in the machine or turn on the heating (#14) and cooling (#13) switches until
water has begun to dispense from the cold (#5) and hot (#8) water spout.
1. Remove any label or sticker from
the mouth of the bottle.
2. Vertically insert the bottle into the
bottle supporter (#1) on the top of
the machine. The bottle supporter
has a built-in puncturing rod to allow
you to use spill proof caps without
opening the plastic bottle seals.
Getting Started
English

10
Operation Instructions
3. Depress the hot (#4) cold (#7) and
the cool (#6) water push button to dis-
pense water from each spout. To dis-
pense the hot water, slide the red child
safety lock (#5) to the left and depress
the hot water push
button (#4) downward to begin the
flow of water. You must slide the child
safety lock (#5) and push the
button simultaneously.
4. Once water is dispensing from
both spouts insert the power plug
into a power socket. Turn on (I) the
heating switch (#14) and the cooling
switch (#13). (If you do not wish to
have hot water please leave the
heating switch (#14) in the o (O)
position. If you do not wish to have
cold water please leave the cooling
switch (#13) in the o (O) position.
Getting Started
English

11
5. Once the switches are in the on (I) position
the heating indicator light (#2) and the
cooling indicator light (#3) will turn on. It will
take about 15 – 20 minutes for the hot water
to heat to the appropriate temperature. It will
take about 1 hour for the cold water to cool
to the appropriate temperature.
6. When the water has reached the
appropriate temperatures for hot and
cold the indicator lights will turn o
and the water is ready for use. The
indicator lights will turn back on
automatically when the machine
needs to reheat or cool again.
7. To replace the bottle vertically, pull out
the empty bottle with two hands. Using
two hands place the new bottle of water
vertically into the bottle supporter (#8).
Operation Instructions
15-20
min
1 hr
HotCold
Getting Started
English

12
Cleaning
English

13
To prolong the lifetime of the machine, it is recommended that the unit be cleaned
and sanitized manually about every six months.
To clean the outside of the unit
Use a disinfectant of your choice to wipe down the outside of the machine.
Disinfectant does not come with this unit. It can be purchased separately from
a local store.
The machine has been disinfected prior to departing from the factory. However, it
is recommended to rinse and drain the unit prior to installation.
1. Before cleaning, make sure that the
cooling switch (#13) and heating switch
(#14) are in the o (O) position and
unplug the machine.
To rinse the inside of the unit
2. Once the machine is o, pour
water into the top of the unit
where the bottle would be placed.
Rinsing, Cleaning, and Draining
Cleaning
English

14
Caution: The dispenser will heat water to a temperature of approximately 185°F.
It can cause severe burns if not handled carefully. Please use caution while
operating and cleaning.
3. Dispense about 2 liters of
water from the unit into a bucket
by pressing dispense buttons for
each temperature.
4. Place a large bucket beneath the
drain outlet (#17) located on the back
of the unit. Remove the drain cover and
plug and allow the water to drain from
the unit. Water will start flowing as
soon as the drain cover is removed.
Rinsing, Cleaning, and Draining
Cleaning
English

15
5. Remove any remaining water in
the tanks by dispensing water from
the hot (#5) and cold (#9) water
spouts into a bucket.
6. After draining is complete,
replace the drain cover and
plug and use the machine
as normal.
Rinsing, Cleaning, and Draining
Cleaning
English

16
1. Twist or lift o the bottle
supporter (#8).
2. Put the mixture into the machine's cold
tank and make sure the water can flow
out of the hot water spout (#9).
To remove mineral deposits that may have built up inside the the cold tank, mix 4 L of
water with 200 g of citric acid crystals (not included) or a cleaning solution of your choice.
Cleaning
Cleaning
English
