Avalon A10-TL User manual

The World’s Most Reliable Water Coolers
USER’S MANUAL
Model: A10-TL
Please read the manual carefully before operang your water
dispenser. Retain it for future reference.

A. SAFETY PRECAUTIONS
B. FUNCTION INTRODUCTION
H. MACHINE INSTALLATION
C. PART NAME
1
2
3
D. OPERATION INSTRUCTION
E. CAUTION 4
F.
G.
6
4
6
7

The water cooler shall plug into a ground fault interrupter receptacle.
A:SAFETY PRECAUTIONS
Warning: Do not damage the refrigerant circuit.
1

B: FUNCTION INTRODUCTION
This appliance can be used by children aged from 8 years and above if
they have been given supervision or instrucon concerning use of the
appliance in a safe way and if they understand the hazards involved.
Cleaning and user maintenance shall not be made by children unless they
are older than 8 and supervised. Keep the appliance and its cord out of
reach of children aged less than 8 years.
Appliances can be used by persons with reduced physical, sensory, or mental
cappsbilies or lack of experience and knowledge if they have been given
supervision or instrucon concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance.
This appliance is intended to be used in household and similar applicaons
such as: kitchen areas in shops, offices, and other working environments,
hotels, motels, and other residenal type environments, bed and breakfast
type environments, catering, and similar non-retail applicaons.
Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
If the supply cord is damaged, it must be replaced by a special cord
assembly avaiable from the manufacturer or its service agent.
Never turn the machine upside down or lean it more than 45 .
Thermostat has been adjusted. No need to adjust it by yourself. When the
machine is below the freezing point and blocked by ice, the cooling switch be
turned off for 4 hours before turning it on again to connue its operaon.
This machine should not be turned on unl 3 minutes aer turning
power switch.
off the
The appliance shall plug into electrical socket which is protected by
a ground-fault circuit interrupter.
1. This model can sasfy the need of tea, coffee, and cold water.
2. With the adopon of disncve thermal isolaon technology, this machine
can minimize thermal exchange between hot & cold water.
3. Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
2

C:PART NAME
SIDE
1
2
3
5
6
7
8
9
10
11
4
13
12
14
Hot Water Spout
PART NAME
Bole Receptacle
Top cover
Cold Water Buon
Room Temperature Water Buon
Hot water Buon
Cold Water Spout
Room Temperature Water Spout
Condenser
Drip Tray
Cooling switch
Heang switch
Power supply cord
Drain Outlet
NO. PART NAMENO.
NOTE:
This machine is suitable for both 3 or 5 gallon boles. Do not use
hard water.
3

C:OPERATION INSTRUCTION
1. Remove any scker or label from the opening or cap of the bole.
2. Vercally insert the bole into the bole receptacle
on top of the machine. Don't plug the power cord or
turn on the heang or cooling switches unl water is
dispensed from the hot and cold water spouts.
3. Insert the plug to into an electrical outlet.
4. Dispense a drop of water from both the hot and cold
spouts to ensure the inner tanks have water in them.
5. Turn on the heang and cooling switches.
6. Indicators will light up accordingly once the machine starts to work.
7. Vercally pull out the bole with two hands when the bole is empty, then
replace it with another bole of water.
8. This appliance should be kept in temperature from 50°F-110°F.
9. This appliance is not suitable for installaon in an area where a water jet
could be used.
D:CAUTION
1. Keep this machine in a dry place and avoid direct sunlight.
Rear of the machine should be at least 25cm away from the
wall. Never put the machine on paper or foam as it will cause
an unstable surface. Never put anything flammable near this
machine.
2. To avoid damage to the machine, don't turn on the heang or
cooling switches unl some water is dispensed from the hot
and cold spouts.
3. In case hot or cold water is not needed for a long me, turn
off the switch to save power.
4

4. In case when not using this machine for a long me, turn
off the switches, then pull the plug out from socket and
drain the remaining water through draining outlet
5. Never use organic liquid to clean the machine. Strictly
prohibit using water to the splash it。
6. If the power cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard
7. Never turn the machine upside down or lt it more than 45℃
8. When the machine is below the freezing point and blocked
by ice, the cooling switch must be closed for 4 hours before
turning it on again to connue its operaon
9. This machine should not be turned back on unl 3 minutes
aer turning off the power switch.
5

F:TROUBLE SHOOTING
Please check the followings before having the machine repaired.
Noisy operaon
PROBLEMS
No hot or cold water
No water running
out from taps
Leakage from bole
receptacle
1. Empty bole
2. Inlet of bole supporter blocked by
bole seal
POSSIBLE CAUSES
1. Over consumpon of hot or cold
water in short me
2. No power supply
Loose bole or loose tank seal
Not installed on leveled surface
1. Replace it with another one
2. Clean out wasted paper & bole seal,
install bole again.
ELIMINATION
1. Just wait a moment ,for hot/cold water
to be available again.
2. Connect plug to socket, turn on heang
and cooling switch
Place the machine on flat surface
Reposion bole and check tank seal
G:CLEANING
To avoid accident, cut off the power supply before following the following
instrucons.
The machine had been disinfected before leaving the factory. However you
may want to clean the dispenser prior to installing a full bole or water for the
first me.
1. Cleaning and draining instrucons:
1)Before cleaning, make sure to unplug the water dispenser.
2)Vercally insert the bole into the receptacle on top of the machine.
3)Press the dispensing buons and allow about 1 liter of water to flow into
a container.
4)Remove the water bole from the dispenser.
5)Place a large bucket beneath the drain outlet. Remove the drain cover and
plug and allow water to drain.
6)Aer draining, replace the drain plug and cover and you can use the machine.
Aenon: The dispenser heats water to a temperature of approximately
185 F/85 C. It can cause sever scalding. Please operate it carefully.
2. Sanizing
The machine should be disinfected with disinfectant separately bought from
drugstore or marketplace according to the instrucon manual or the
disinfectant and the clean it with water (see cleaning and draining instrucon).
Generally this should be done every three months.
6

H:MACHINEINATALLATION
3. To Remove Mineral Deposits:
Mix 4 liters water with 200g citric acid crystals, inject into the machine and
make sure the water can flow out of the hot water tap. Switch on the hot switch
and heat it about 10 minutes. Aer 30 minutes, drain out the liquid and clean it
with water two or three mes as per the cleaning and draining instrucons.
Generally this should be done every six months.
Never disassemble this machine by yourself to avoid danger from damaged
machine.
Instrucons for installaon:
1. Use the screw to fix the bracket on the hole of the
middle boom of the water dispenser.
2. Make a hole on the floor's (or the desk's) surface
where the water dispenser will be installed.
3. Fix the bracket on the floor by screw ghtly.
4. Tighten the screw.
WARNING! To avoid a hazard due to instability of the appliance, it must be
fixed in accordance with the instrucons.
5. Never disassemble this machine by yourself to avoid danger from
damaging machine.
7
If you encounter any issues or have any concerns,
please email us at [e-mail]
or call 1800-256-0695 .
Please see our website to learn more about our products
www.avalonproducts.com
©Copyright Avalon ® 2018 and Distributed by BHRS Group LLC
