Avalon A14-S User manual

A few simple steps to ensure
perfect water, every time.
English

English

www.avalonh2o.com
We’re Here to Help
Let’s Connect
Call Us:
1.800.256.0695
Email Us:
[e-mail]
[e-mail]
Live Chat:
Monday-Thursday: 9 a.m.-5:30 p.m.
Friday: 9 a.m.-4:30 p.m.
@avalon_h2o Avalon Water Coolers Avalonh2o
Follow our social media accounts and stay up to
date on the latest Avalon news.
We are also available
for live video chat!
English

Use and Care Guide
MODELS: A14-S  A14BLKS
Registration
Please visit the website below to register your new water cooler within the first
30 days of purchase. Registration within the first 30 days will activate your one
year warranty.
www.avalonh2o.com/register-my-avalon-cooler
Please keep your model number, order number and purchase date
for future support. You can reach us at 1-800-256-0695.
Model Number
Order Number
Purchase Date
English

Contents
About Your Water Cooler
Meet Your Avalon Product
Part Names
Indicator Lights
Tech Specs
BioGuard
Getting Started
Unpacking your Avalon Water Cooler
Install Water Bottle
Install/Remove Drip Tray
Powering the Dispenser
Activate Heating and Cooling
User Guide and Maintenance
Dispensing Water
Touchless Dispensing
Changing the Bottle
Cleaning
Self-Cleaning
Rinsing, Cleaning, and Draining
Cleaning
Troubleshooting
Safety
Warranty
1
2-3
4
5
6
8
9-10
11
12
13
15
16
17-18
20
22-23
24-25
27-28
30-31
33
English

1
Piping hot,
cool or crisp
cold water
Self-cleaning ozone
function for longer
lasting water purification
Meet Your Avalon Product
Custom Temperature Empty bottle indicator
Notifies you when your
bottle is empty
Attractive Design
Stainless steel design
with three water spouts
Bottom loading
No more lifting,
flipping or spills
UL Listed
We design & manufacture
with your safety in mind
Energy Star Approved
Saves the environment
and your wallet
Built-in Nightlight
Makes late night
water trips a breeze
Child Safety Feature
Ensures safe hot water
flow for the entire family
Worry-Free Cleaning
Touchless
Touchless hands-
free dispensing for
cold water
About Your Water Cooler
English

2
4. Cooling Indicator Light
Part Names
9. Panel
11. Nightlight
10. Spout
12. Drip Tray
2. Heating Indicator Light
3. Self-Cleaning Indicator Light1. Empty Bottle
Indicator Light
5. Child Safety
Lock Push Button
8. Cold Water
Push Button
7. Cool Water
Push Button
6. Hot Water
Push Button
Blinking = Heating Blinking = Cooling
Self Clean
Cold
Hot
Unlock
20. Touchless Sensor
About Your Water Cooler
English

3
Part Names
17. Power Cord
14. Nightlight Switch
15. Cooling Switch
16. Heating Switch
13. Self-Cleaning Switch
18. Drain Outlet
19. Condenser
About Your Water Cooler
English

4
Indicator Lights
Self-Cleaning Indicator Light
When the unit is placed into self-cleaning mode this indicator light will blink until
the cycle is complete. When the cycle is complete the light will turn o.
Heating Indicator Light
This light will indicate when the water is heating. The light will blink while the water
is heating and will turn o when it has reached the correct temperature of 185°F.
Cooling Indicator Light
This light will indicate when the water is cooling. The light will blink while the water
is cooling and will turn o when it has reached the correct temperature of 47°F.
Empty Bottle Indicator Light
This light will indicate that the bottle below is empty and will need to be replaced.
This red light will begin to blink to alert you of the empty bottle.
Self Clean
Cooling
Heating
About Your Water Cooler
English

5
Tech Specs
Avalon Models A14-S  A14BLKS
Hot/Cold/Cool Output
Hot Water Capacity
Hot Tank Volume
Cold Water Capacity
Cold Tank Volume
Applicable Environment
Product Size
Packing Size
Net Weight/Gross Weight
Voltage/Frequency
Cooling Method
Heating Method
Heating Watts / Cooling Watts
Power Consumption
1.8L/min / 2.2L/min / 2L/min
4 L/H ( ≥ 185°F)
1.16 Liters
2.5 L/H ( ≤ 47°F)
3.6 Liters
39 ~ 104°F humidity ≤90%
13”(L)x12”(W)x41”(H)
16”(L)x15”(W)x45”(H)
35.5 lb /46.5 lb
115 V 60Hz
Compressor
Internal Element
420W / 100 W
520 W
This product is not recommended to be used at an altitude of above 1500 meters.
About Your Water Cooler
English

6
Benefits:
The drip tray is the most unsanitary part of a water cooler. Water is constantly collecting in the drip
tray and most people do not empty or clean the drip tray unless it is full. This can lead to unwanted
bacteria and viruses building up in the drip tray. The dispensing area and spout can also be areas of
unwanted bacteria growth. These bacteria or viruses can easily spread to drinking cups or other parts
of the cooler. The press buttons are touched by so many people and can lead to bacteria growth as
well. With our anti-microbial coating, you can be assured that the drip tray, dispensing area, spout,
and press buttons all remain bacteria free all the time.
• Certain parts of the water cooler, such as the drip tray, dispensing area, spout, press
buttons or press paddles have been treated with a unique anti-microbial coating using the
BioGuard technology.
• This BioGuard technology is injected into the ABS material through a complex technique during
the injection molding process creating an anti-microbial coating which has been tested to prevent
bacteria such as Escherichia coli from forming on its surface.
• Unlike many other anti-bacterial coatings, BioGuard will not be aected by heat. It will not aect
the strength of the given plastic. It will also not cause the plastic material to become discolored
over time.
• This technology has been tested to be safe and non-toxic according to EPA standards.
• This technology will prevent viruses from remaining on the treated surfaces.
How It Works:
BioGuard is a soluble glass containing anti-microbial metal ions.
Glass is generally considered to be a material with high chemical inertness due to its strong network
structure. It is possible though, to lower this chemical inertness by continuously altering its structure.
Glass also has another interesting property which retains metal as ions. We have combined this
property along with our unique anti-microbial technology enabling the glass to have a low chemical
inertness by retaining anti-microbial metal ions. With the presence of water or moisture, the glass
with BioGuard will release metal ions gradually to function as anti-microbial material. This happens
as Ag ions with positive charges are drawn toward microbes with negative charge and disturb their
electrical balance causing their cell wall to burst and extinguish. It also can cause the Ag ions to
bond to microbes inhibiting the enzyme activity and multiplication of microbes causing them to be
destroyed.
About Your Water Cooler
English

7
Getting Started

8
Unpacking your Avalon Water Cooler
The unit has been cleaned prior to departing from the factory. To remove any
dust and debris that may collect during shipping we recommend cleaning the
unit prior to installation. For cleaning instructions, see pages 20-25.
Do NOT plug in the power cord yet.
Place dispenser upright on a hard and level surface in a cool and shaded
location near a grounded wall outlet. Position the dispenser so there is about four
inches of clearance from the wall on the back and both sides.
Unpack the machine, open the cabinet to remove the drip tray, and install it by
inserting it into place at the top of the cabinet door, see page 11.
Locating Dispenser
Unpacking
Getting Started
English

9
Installing the Water Bottle
1. Open the cabinet door.
3. Place a fresh bottle outside of the cabinet.
2. Place the probe assembly
on the probe hanger.
4. Remove the entire plastic cap from the top of the bottle.
5. Clean the outside of the new bottle with a cloth.
Getting Started
English

10
Installing the Water Bottle
7. Slide the collar down until it clicks into
place. If you are using a 3 gallon bottle
rather than a 5 gallon bottle you can
adjust probe by pressing the two tabs
at the head of the probe and sliding the
collar down to the neck of the bottle.
6. Place the probe into the bottle.
collar
collar
head
head
8. Push the head down until
the tube hits the bottom of
bottle.
9. Slide the bottle into cabinet
and close the door.
Getting Started
English

11
Installing and Removing the Drip Tray
1. To install the drip tray, simply slide
it into the area at the top of the door
until it snaps into place.
2. To remove the drip tray, place your
fingers in the grid of the drip tray with
one hand and hold the door of the
cooler shut with the other.
3. Gently pull the drip tray toward
you to release it. Once it has been
released you can remove the drip
tray from the door of the cooler to
empty it.
No external drain is needed, the overflow will collect here. The red float will rise to
indicate when the drip tray needs to be emptied.
Getting Started
English

12
Powering the Dispenser
Plug cord into a properly grounded wall outlet. At this time the pump will begin to
move water from the bottle to the hot and cold tanks. It will take up to 12 minutes to
fill the tanks for the first time. During this period the pump will run continuously. This
is normal.
Getting Started
English

13
Activate Heating and Cooling
To activate the cold water, push the cooling switch (#15) into the on (I) position by
pushing the top of the switch in. If you do not wish to have cold water you can leave
the switch in the o (O) positon.
To activate the hot water, push the heating switch (#16) into the on (I) position by pushing
the top of the switch in. If you do not wish to have hot water you can leave the switch
in the o (O) position.
Please allow 15 minutes for the hot water to be heated. During this time the heating indicator
light (#2) will be steady. The light will turn o when the heating process is complete. Please allow
1 hour for the cold water to be cooled. During this time the cooling indicator light (#4) will be
steady. The light will be turned o when the cooling process is complete. If any error occurs
in the heating or cooling process, the indicator light will blink.
Before turning on the heating (#16) or cooling (#15) switches ensure water is already filling
inside the inner tanks by dispensing a drop of water from the water spout (#11).
Getting Started
English

14
User Guide and Maintenance
English

15
Dispensing Water
Cold Water
Hot Water
Cool Water
Once you have turned the cooling switch (#15) into the on (I) position it will take initially
1 hour for the water to cool. During this time the cooling indicator light (#4) around the
cold water button will blink. During this time the compressor could run continuously. This
is normal. The light will be turned o when the cooling process is complete.
Once you have turned the heating switch (#16) into the on (I) position it will take initially
15 – 20 minutes for the water to heat up. During this time the heating indicator light (#2)
around the hot water button will be steady. The light will be turned o when the heating
process is complete.
1. Position the bottle, glass, pitcher or cooking pot below the water spout (#10).
2. Press the cool water button (#7) to begin the flow of water. You must
continue to press the cool water button in order for the water to continue to flow. While
water is dispensing, the button will light up orange.
3. Once the desired fill level is achieved, release the cool water button (#7) to stop the
flow of water.
1. Position a bottle, glass, pitcher or cooking pot below the water spout (#10).
2. Press the cold water button (#8) to begin the flow of water. You must continue to
press the cold water button in order for the water to continue to flow. While water is
dispensing, the button will light up blue.
3. Once the desired fill level is achieved, release the cold water button (#8) to stop
the flow of water.
1. Position a bottle, glass, pitcher or cooking pot below the water spout (#10).
2. Press the child safety lock push button (#5) and press the hot water button
(#6) to begin the flow of water. You must continue to press the hot water button in order
for the water to continue to flow. While water is dispensing, the button will light up red.
3. Once the desired fill level is achieved release the hot water button (#6) to stop the flow
of water.
User Guide and Maintenance
English
