Avalue Technology C Series User manual

Part No. E20171511A0R
LPC-1511
C Series Fanless Touch Panel PC
Quick Reference Guide
1st Ed –07 July 2020
Copyright Notice
Copyright 2020 Avalue Technology Inc., ALL RIGHTS RESERVED.

LPC-1511
2 LPC-1511 Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright 2020 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that

Quick Reference Guide
LPC-1511 Quick Reference Guide
3
these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose
failure to perform can be reasonably expected to cause the failure of the life
support device or system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

LPC-1511
4 LPC-1511 Quick Reference Guide
Content
1. Getting Started ........................................................................................................7
1.1 Safety Precautions....................................................................................................7
1.2 Packing List...............................................................................................................7
1.3 System Specifications...............................................................................................8
1.4 System Overview....................................................................................................11
1.4.1 Top View................................................................................................................................ 11
1.4.2 Bottom View........................................................................................................................... 11
1.5 System Dimensions ................................................................................................12
1.5.1 Front and Rear side............................................................................................................... 12
2. Hardware Configuration .......................................................................................13
2.1 LPC-1511 connector mapping ................................................................................14
2.1.1 Serial port 1~6 connector (COM1~6) .................................................................................... 14
2.1.2 VGA connector (VGA) ........................................................................................................... 14
2.3 Installing Hard Disk & Memory (For LPC-1511).....................................................15
2.4 Installing VESA Mount (For LPC-1511).................................................................16
2.5 EMX-VX11P Overview...........................................................................................17
2.6 EMX-VX11P Jumper and Connector List...............................................................19
2.7 EMX-VX11P Jumper and Connector settings........................................................21
2.7.1 Serial port 1/2 pin9 signal select (JRI1/JRI2).......................................................................... 21
2.7.2 LVDS Back Light power selection (JSBKL1) .......................................................................... 21
2.7.3 AT/ATX Power Mode Select (JSATX1) .................................................................................. 22
2.7.4 Clear CMOS (JCMOS1).......................................................................................................... 22
2.7.5 LCD Inverter connector (JBKL1)............................................................................................. 23
2.7.6 General purpose I/O connector (DIO1)................................................................................... 23
2.7.7 Serial port 1 connector (COM1).............................................................................................. 24
2.7.8 Serial port 2 connector (COM2).............................................................................................. 24
2.7.9 Power connector (PWR1)....................................................................................................... 25
2.7.10 SATA Power connector 1 (SPWR1)..................................................................................... 25
2.7.11 Serial Port 1/2 RS485/422 Mode connector (JRS485_1)..................................................... 26
2.7.12 Serial Port 1/2 RS485/422 Mode connector (JRS485_2)..................................................... 26
2.7.13 Serial port 3/4/5/6 connector (COM3/4/5/6).......................................................................... 27
2.7.14 USB connector 1 (JUSB1).................................................................................................... 28
2.7.15 LPC connector (JLPC1)........................................................................................................ 28
2.7.16 Audio connector (FAUD1)..................................................................................................... 29

Quick Reference Guide
LPC-1511 Quick Reference Guide
5
2.7.17 EC Debug (JEC_PG1).......................................................................................................... 29
2.7.18 LVDS connector (LVDS1)..................................................................................................... 30
2.7.19 SPI connector (JSPI1) .......................................................................................................... 31
2.7.20 Sony/Philips Digital Interface (SPDIF1)................................................................................ 31
2.7.21 Miscellaneous setting connector 1 (FPT1) ........................................................................... 32
2.7.22 Miscellaneous setting connector 2 (FPT2) ........................................................................... 32
2.7.23 LED indicator connector 1 (LED1)........................................................................................ 33
2.7.24 LED indicator connector 2 (LED2)........................................................................................ 33
2.7.25 Speaker connector (SPK1)................................................................................................... 34
2.7.26 JSMB connector (JSMB1)..................................................................................................... 34
2.7.27 PS2 keyboard/mouse connector (JKBMS) ........................................................................... 35
2.7.28 Connector reserved for CH7511 FW flash jig (JROM) ......................................................... 35
2.7.29 FAN connector (FAN1) ......................................................................................................... 36
2.7.30 Battery connector (JBAT1).................................................................................................... 36
3.BIOS Setup....................................................................................................................37
3.1 Introduction .............................................................................................................38
3.2 Starting Setup .........................................................................................................38
3.3 Using Setup ............................................................................................................39
3.4 Getting Help............................................................................................................40
3.5 In Case of Problems................................................................................................40
3.6 BIOS setup..............................................................................................................41
3.6.1 Main Menu............................................................................................................................. 41
3.6.1.1 System Language ............................................................................................................. 41
3.6.1.2 System Date...................................................................................................................... 41
3.6.1.3 System Time ..................................................................................................................... 41
3.6.2 Advanced Menu..................................................................................................................... 42
3.6.2.1 ACPI Settings.................................................................................................................... 42
3.6.2.2 S5 RTC Wake Settings ..................................................................................................... 43
3.6.2.3 Trusted Computing............................................................................................................ 44
3.6.2.4 CPU Configuration ............................................................................................................ 44
3.6.2.5 SATA Configuration........................................................................................................... 45
3.6.2.6 USB Configuration............................................................................................................. 46
3.6.2.7 H/W Monitor ...................................................................................................................... 47
3.6.2.7.1 Smart Fan Mode Configuration......................................................................................... 47
3.6.2.8 IT8528 Super IO Configuration ......................................................................................... 48
3.6.2.8.1 Serial Port 1 Configuration................................................................................................ 49
3.6.2.8.2 Serial Port 2 Configuration................................................................................................ 49
3.6.2.8.3 Serial Port 3 Configuration................................................................................................ 50
3.6.2.8.4 Serial Port 4 Configuration................................................................................................ 50
3.6.2.8.5 Serial Port 5 Configuration................................................................................................ 51

LPC-1511
6 LPC-1511 Quick Reference Guide
3.6.2.8.6 Serial Port 6 Configuration................................................................................................ 51
3.6.3 Chipset................................................................................................................................... 52
3.6.3.1 North Bridge .................................................................................................................... 52
3.6.3.1.1 Video Configuration........................................................................................................... 53
3.6.3.1.2 PCIE Configuration............................................................................................................ 54
3.6.3.2 South Bridge...................................................................................................................... 55
3.6.3.2.1 USB Configuration............................................................................................................. 55
3.6.3.2.2 HDAC Configuration.......................................................................................................... 56
3.6.4 Boot ....................................................................................................................................... 56
3.6.4.1 CSM16 Parameters........................................................................................................... 57
3.6.4.2 CSM Parameters............................................................................................................... 58
3.6.5 Security.................................................................................................................................. 59
3.6.5.1 Secure Boot menu............................................................................................................. 59
3.6.6 Save and exit....................................................................................................................... 60
3.6.6.1 Save Changes and Reset ................................................................................................. 61
3.6.6.2 Discard Changes and Reset ............................................................................................. 61
3.6.6.3 Restore Defaults................................................................................................................ 61
3.6.6.4 Launch EFI Shell from filesystem device.......................................................................... 61

Quick Reference Guide
LPC-1511 Quick Reference Guide
7
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x LPC-1511 C Series Fanless Touch Panel PC
1 x Adapter
1 x Power Cord (CN)

LPC-1511
8 LPC-1511 Quick Reference Guide
1.3 System Specifications
Component
Mother Board
Mini ITX Motherboard EMX-VX11P
CPU
ZX-C Series Processor with VX11PH
Memory
One x 204-pin DDR3 1333MHz SO-DIMM supports up to 8GB
Adapter
84W Adapter (DC in 12V@7A)
Speaker
2 x 2w8Ω
Wireless LAN
Optional expansion module
Bluetooth
Optional expansion module
Operating System
Win 7
Storage
Hard Disk Drive
Optional
Solid State Drive
Optional
Panel
LCD Panel
SHARP LQ150X1LG93(C9689315002R)
Touch Screen
MX150R5B09(C968XR15001R)
Touch Controller
EETI ETP-MB-R4502UPEG(C968X000001R)
External I/O
Serial Port
6 x RS232
USB Port
1 x USB2.0, 1 x USB3.0
DIO Port
8bit for DB9(Optional)
Video Port
1 x VGA
Audio Port
2 x Audio jack
LAN Port
2 x Lan
Wireless LAN Antenna
2 x Antenna
Mechanical
Power Type
12V@7A DC in(84W)
Power Requirement
DC Jack
Dimension
375.4 x 299.3 x 63.0 mm (L x W x H)
Weight
4.05 Kgs
Color
Silvery(Positive) & Black(Back)
OS Support
Windows 7
Reliability
EMI Test
CE, FCC Part 15 Class A
Safety
CE / FCC / VCCI / CCC
Vibration Test
Random Vibration Operation
1 Test PSD : 0.00454G²/Hz , 1.5 Grms

Quick Reference Guide
LPC-1511 Quick Reference Guide
9
2 System condition : operation mode
3 Test frequency : 5~500 Hz
4 Test axis : X,Y and Z axis
5 Test time : 30 minutes per each axis
6 IEC60068-2-64 Test Fh
7 Storage : mSATA
Sine Vibration test (Non-operation)
1 Test Acceleration : 2G
2 Test frequency : 5~500 Hz
3 Sweep：1 Oct/ per one minute. (logarithmic)
4 Test Axis : X,Y and Z axis
5 Test time :30 min. each axis
6 System condition : Non-Operating mode
7. Reference IEC 60068-2-6 Testing procedures
Package Vibration Test:
1 Test PSD : 0.026G²/Hz , 2.16 Grms
2 Test frequency : 5~500 Hz
3 Test axis : X,Y and Z axis
4 Test time : 30 minutes per each axis
5 IEC 60068-2-64 Test Fh
Mechanical Shock
Test
1 Wave from : Half Sine wave
2 Acceleration Rate : 10g for operation mode
3 Duration Time : 11ms
4 No. of shock : Z axis 300 times
5 Test Axis : Z axis
6 operation mode
7 Reference IEC 60068-2-27 testing procedures
Test Eb : Shock Test
Drop Test
Package drop test
Reference ISTA 2A, Method : IEC-60068-2-32 Test:Ed
Test Ea : Drop Test
1 Test phase : One corner, three edges, six faces
2 Test high : 96.5 cm
3 Package weight : 6.0 Kg
4 Test drawing
Operating
Temperature
0°C ~ 40°C
Operating Humidity
40°C @ 95% Relative Humidity, Non-condensing

LPC-1511
10 LPC-1511 Quick Reference Guide
Storage Temperature
-10°C~60°C
Note: Specifications are subject to change without notice.

Quick Reference Guide
LPC-1511 Quick Reference Guide
11
1.4 System Overview
1.4.1 Top View
1.4.2 Bottom View
Connectors
Label
Function
Note
PWR
Power on button
HDMI
HDMI connector
COM1~6
Serial port 1~6 connector
DB-9 male connector
LINE OUT
Line-out audio jack
MIC IN
Mic-in audio jack
USB
1 x USB 2.0 connector
3 x USB 3.0 connector
Dock USB
LAN1~2
RJ-45 Ethernet connector 1~2
VGA
VGA connector
DC IN
DC Power-in connector

LPC-1511
12 LPC-1511 Quick Reference Guide
1.5 System Dimensions
1.5.1 Front and Rear side
(Unit: mm)

Quick Reference Guide
LPC-1511 Quick Reference Guide
13
2.Hardware
Configuration
For advanced information, please refer to:
1- EMX-VX11P User’s Manual
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

LPC-1511
14 LPC-1511 Quick Reference Guide
2.1 LPC-1511 connector mapping
2.1.1 Serial port 1~6 connector (COM1~6)
Signal
PIN
PIN
Signal
DCD#
1
6
DSR#
RXD
2
7
RTS#
TXD
3
8
CTS#
DTR#
4
9
RI#
GND
5
2.1.2 VGA connector (VGA)
PIN
Signal
PIN
Signal
PIN
Signal
1
RED
6
GND
11
NC
2
GREEN
7
GND
12
DDCDAT
3
BLUE
8
GND
13
HSYNC
4
NC
9
+5V
14
VSYNS
5
GND
10
GND
15
DDCCLK

Quick Reference Guide
LPC-1511 Quick Reference Guide
15
2.3 Installing Hard Disk & Memory (For LPC-1511)
Step 1. Unfasten 6 screws from the case to take off the top chassis
Step 2. Secure HDD by means of 8 screws.
Step 3. Insert HDD bracket into designated locations and fasten with 4 screws to complete HDD installation.

LPC-1511
16 LPC-1511 Quick Reference Guide
2.4 Installing VESA Mount (For LPC-1511)
Step 1. Position VESA Mount on both sides, matching the holes on the system.
Step 2. Insert and fasten screws on the system to secure Mounting bracket.

Quick Reference Guide
LPC-1511 Quick Reference Guide
17
2.5 EMX-VX11P Overview

LPC-1511
18 LPC-1511 Quick Reference Guide

Quick Reference Guide
LPC-1511 Quick Reference Guide
19
2.6 EMX-VX11P Jumper and Connector List
Jumpers
Label
Function
Note
JRI1/2
Serial port 1/2 pin9 signal select
3 x 2 header, pitch 2.00mm
JSBKL1
LVDS Back Light power selection
3 x 1 header, pitch 2.00mm
JSATX1
AT/ATX Power Mode Select
3 x 1 header, pitch 2.54mm
JCMOS1
Clear CMOS
3 x 1 header, pitch 2.00mm
Connectors
Label
Function
Note
FPT1
Miscellaneous setting connector 1
5 x 2 header, pitch 2.54mm
FPT2
Miscellaneous setting connector 2
5 x 2 header, pitch 2.54mm
DIMM1
206-pin DDR4 SO-DIMM socket
FAUD1
Front Audio connector
5 x 2 header, pitch 2.54mm
VGA
VGA connector
JBKL1
LCD Inverter connector
5 x 1 wafer, pitch 2.00mm
JSPI1
SPI connector
4 x 2 header, pitch 2.00mm
JEC_PG1
EC Debug
3 x 1 header, pitch 2.54mm
COM1
Serial Port 1 connector
5 x 2 header, pitch 2.00mm
COM2
Serial Port 2 connector
5 x 2 header, pitch 2.00mm
COM3-6
Serial Port 3/4/5/6 connector
20 x 2 header, pitch 2.00mm
DIO1
General purpose I/O connector
10 x 2 header, pitch 2.00mm
SPK1
Speaker connector
4 x 1 wafer, pitch 2.00mm
LVDS1
LVDS Connector
20 x 2 wafer, pitch 1.25mm
JUSB2
USB connector
JUSB3/4
USB connector 3/4
SPDIF1
Sony/Philips Digital Interface
3 x 1 header, pitch 2.54mm
LAN1/2
RJ-45 Ethernet 1/2
MPCIE
PCIe connector
LED1
LED indicator connector 1
4 x 1 header, pitch 2.00mm
LED2
LED indicator connector 2
4 x 1 header, pitch 2.00mm
JBAT1
Battery connector
2 x 1 wafer, pitch 1.25mm
M2KA1
M.2 2230 Type A Slot (default no
function)

LPC-1511
20 LPC-1511 Quick Reference Guide
JUSB
USB connector
5 x 2 header, pitch 2.54mm
JRS485_1/2
Serial Port 1/2 RS485/422 Mode
connector
3 x 2 header, pitch 2.00mm
JLPC1
LPC connector
5 x 2 header, pitch 2.00mm
IET-CB1
IET Module connector (default no
function)
JSMB1
SMBus connector
5 x 1 header, pitch 2.00mm
JKBMS1
PS2 keyboard/mouse connector
4 x 2 header, pitch 2.00mm
FAN1
CPU fan connector
4 x 1 wafer, pitch 2.54mm
DCIN1
DC Power-in connector
PWR1
Power connector
2 x 2 wafer, pitch 4.20mm
SATA1/2
Serial ATA connector 1
SPWR1/2
SATA Power connector 1
4 x 1 wafer, pitch 2.54mm
HDMI1
HDMI connector
LOUT1
Line-out audio jack
MIC1
Mic-in audio jack
SIM1
SIM card slot
