Avalue Technology FPC 17 W Series User manual

Part No. E2017FPC0B1R
FPC 17”~21”W Series
17”/18”W/21”W Flexible TFT Touch Panel PC
Quick Reference Guide
2nd Ed –8 August, 2011

FPC 17”~21”W Series
2 FPC 17”~21”W Series Quick Reference Guide
Contents
1. Getting Started............................................................................................................3
1.1 Safety Precautions ................................................................................................3
1.2 Packing List...........................................................................................................3
1.3 System Specifications ...........................................................................................4
1.3.1. 17” Series....................................................................................................................................... 4
1.3.2. 18.5” “widescreen” Series ........................................................................................................... 7
1.3.3. 21” “widescreen” Series ............................................................................................................ 10
1.4 System Overview.................................................................................................13
1.4.1 Rear View................................................................................................................................... 13
1.5 System Dimensions.............................................................................................14
1.5.1 FPC 17” Series .......................................................................................................................... 14
1.5.2 18.5” “widescreen” Series .......................................................................................................... 15
1.5.3 FPC 21” Widescreen Series ...................................................................................................... 16
2. Hardware Configuration...........................................................................................17
2.1 Jumper and Connector Setting, Driver and BIOS Installing.................................17
2.2 Installing Hard Disk & Memory ............................................................................18
2.2.1 Install HDD................................................................................................................................. 19
2.2.1.1 2.5” SATA HDD ..............................................................................................................................................19

Quick Reference Guide
FPC 17”~21”W Series Quick Reference Guide
3
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x FPC 17”/18”W/21”W Series Panel PC
1 x CD/DVD-ROM contains the followings:
—Quick Reference Guide (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
—Wi-Fi drivers and utilities
—Touch controller drivers and utilities
—Chipset drivers and utilities
1 x packing set includes the followings
—1 x power cord
—1 x cable set for IDE, SATA, COM
—1 x antenna (for optional Wi-Fi)

FPC 17”~21”W Series
4 FPC 17”~21”W Series Quick Reference Guide
1.3 System Specifications
1.3.1. 17”Series
Panel
FPC-1701
FPC-1702
FPC-1705
LCD size
17.0", 4:3
Display type
SXGA TFT
Resolution
1028 x 1024
Color
16.7M
Pixel pitch
0.264mm(H) x 0.264mm(V)
Luminance
350 cd/m²
Contrast ratio
1000
Viewing angle
80(U), 85(D), 85(L), 85(R)
Response time
5 ms
Backlight
4 x CCFL
Touch Type
5 Wires resistive
Touch Light Transmission
80%
Touch Interface
USB
System
Board
EMX-945GME3
EMX-965GME
EMX-PNV
CPU
Supports Intel μFC-PGA
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Supports Intel® socket P
Core™Duo
/Core™Solo/Core™2
Duo with 65nm process
technology
Onboard Intel® Atom™
Dual-Core 1.8 GHz CPU
Cooling method
Active CPU cooler
Passive CPU heatsink
System Chipset
Intel® 82945GME GMCH
/ ICH7-M
Intel® GME965 GMCH /
ICH8-M
Intel® ICH8-M
I/O Chip
Winbond W83627DHG-A
Winbond 83627DHG
Memory
Two 240-pin DIMM
socket supports up to
4GB DDR2 533/667
Two 200-pin SODIMM
socket supports up to
4GB DDR2 533/667
1 SODIMM socket
supports upt to 2GB
SDRAM
SSD
One CompactFlash Type I/II socket (Purchase from Avalue Highly
recommended)
HDD Drive Bay
1 x 2.5" SATA

Quick Reference Guide
FPC 17”~21”W Series Quick Reference Guide
5
Rear Panel I/O
Serial Port
3 x RS-232
Ethernet
1 x Realtek GigLAN port
2 x LAN ports (Realtek
RTL8111B Gigabit LAN)
2 x LAN ports (Intel
82583V Gigabit LAN)
WIFI
Optional USB WiFi 802.11 b/g (occupy one USB port)
VGA
1 x DB-15
DVI
1 x DVI
n/a
HDMI
n/a
Audio
Line out, Line in, Mic in
USB
5 x USB 2.0
Speaker
5W X 2
Mouse & KB
1 x PS/2 Keyboard connector
Mechanical & Environmental
System Fan
1 x System Fan
Color
Front panel Black
Rear panel Black
Power input
100-240 VAC (180 W)
Operating temperature
'-20°C to 50°C.
Storage temperature
'-20°C to 60°C.
Relative humidity
10% to 95% @ 40℃, non-condensing
Mounting
Wall/Stand/VESA 75 mm X 75 mm and 100 mm X 100 mm
Dimensions
387.5 mm X 346 mm X 75.6 mm
Weight
6.14 kgs
Panel
FPC-1706
FPC-17A3
LCD size
17.0", 4:3
Display type
SXGA TFT
Resolution
1028 x 1024
Color
16.7 M
Pixel pitch
0.264mm(H) x 0.264mm(V)
Luminance
350 cd/m²
Contrast ratio
1000
Viewing angle
80(U), 85(D), 85(L), 85(R)
Response time
5 ms
Backlight
4 x CCFL
Touch Type
5 Wires resistive
Touch Light Transmission
80%
Touch Interface
USB

FPC 17”~21”W Series
6 FPC 17”~21”W Series Quick Reference Guide
System
Board
EMX-QM57
EMX-780E
CPU
Intel® Arrandale/ Ibex-M Support
Intel® 32nm Arrandale BGA1288 SV/
LV/ ULV Processors, TDP Up to 35W
by iMVP-6.5
Supports AM2/ AM2+/ AM3 Socket
Support 65W Athlon/ Athlon
X2/Quad-Core™ AMD Phenom™ II
Processors
Cooling method
Active CPU cooler
System Chipset
Intel® QM57
AMD RS780E/ SB710
I/O Chip
Winbond W83667HG-A
FINTEK F71863FG
Memory
Two SODIMMs Up to 8GB DDR3
Dual-channel 1066/800MHz SDRAM
Two 200-pin SODIMMs Support Up to
4GB DDR2 800 SDRAM
SSD
One CompactFlash Type I/II socket (Purchase from Avalue Highly
recommended)
HDD Drive Bay
1 x 2.5" SATA
Rear Panel I/O
Serial Port
2 x RS-232 COM ports
Ethernet
2 x LAN ports (Intel® 82577LM &
Realtek RTL8111D Gigabit LAN)
2 x LAN ports (Realtek RTL8111D
Gigabit LAN)
WIFI
Optional USB WIFI 802.11 b/g (occupy one USB port)
VGA
1 x DB-15
DVI
n/a
HDMI
1 x HDMI
Audio
Line out, Line in, Mic in
USB
5 x USB 2.0
Speaker
5W X 2
Mouse & KB
1 x PS/2 Keyboard connector
Mechanical & Environmental
System Fan
1 x System Fan
Color
Front panel Black
Rear panel Black
Power input
100-240 VAC (180 W)
Operating temperature
'-20°C to 50°C.
Storage temperature
'-20°C to 60°C.
Relative humidity
10% to 95% @ 40℃, non-condensing
Mounting
Wall/Stand/VESA 75 mm X 75 mm and 100 mm X 100 mm
Dimensions
387.5 mm X 346 mm X 75.6 mm
Weight
6.14 kgs

Quick Reference Guide
FPC 17”~21”W Series Quick Reference Guide
7
1.3.2. 18.5”“widescreen”Series
Panel
FPC-18W01
FPC-18W02
FPC-18W05
LCD size
18.5", 16:9
Display type
WXGA TFT
Resolution
1366 x 768
Color
16.7M
Pixel pitch
0.300mm(H) x 0.300mm(V)
Luminance
300cd/m²
Contrast ratio
1000
Viewing angle
80(U), 85(D), 85(L), 85(R)
Response time
5 ms
Backlight
4 x CCFL
Touch Type
5 Wire resistive
Touch Light Transmission
80%
Touch Interface
USB
System
Board
EMX-945GME3
EMX-965GME
EMX-PNV
CPU
Supports Intel μFC-PGA
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Supports Intel® socket P
Core™Duo
/Core™Solo/Core™2
Duo with 65nm process
technology
Onboard Intel® Atom™
Dual-Core 1.8 GHz CPU
Cooling method
Active CPU cooler
Passive CPU heatsink
System Chipset
Intel® 82945GME GMCH
/ ICH7-M
Intel® GME965 GMCH /
ICH8-M
Intel® ICH8-M
I/O Chip
Winbond W83627DHG-A
Winbond 83627DHG
Memory
Two 240-pin DIMM
socket supports up to
4GB DDR2 533/667
Two 200-pin SODIMM
socket supports up to
4GB DDR2 533/667
1 SODIMM socket
supports upt to 2GB
SDRAM
SSD
One CompactFlash Type I/II socket (Purchase from Avalue Highly
recommended)
HDD Drive Bay
1 x 2.5" SATA

FPC 17”~21”W Series
8 FPC 17”~21”W Series Quick Reference Guide
Rear Panel I/O
Serial Port
3 x RS-232
Ethernet
1 x Realtek GigLAN port
2 x LAN ports (Realtek
RTL8111B Gigabit LAN)
2 x LAN ports (Intel
82583V Gigabit LAN)
WIFI
Optional USB WiFi 802.11 b/g (occupy one USB port)
VGA
1 x DB-15
DVI
1 x DVI
n/a
HDMI
n/a
Audio
Line out, Line in, Mic in
USB
5 x USB 2.0
Speaker
5W X 2
Mouse & KB
1 x PS/2 Keyboard connector
Mechanical & Environmental
System Fan
1 x System Fan
Color
Front panel Black
Rear panel Black
Power input
100-240 VAC (180 W)
Operating temperature
'-20°C to 50°C.
Storage temperature
'-20°C to 60°C.
Relative humidity
10% to 95% @ 40℃, non-condensing
Mounting
Wall/Stand/VESA 75 mm X 75 mm and 100 mm X 100 mm
Dimensions
459.5 mm X 309 mm X 79.6 mm
Weight
5.77 Kgs
Panel
FPC-18W06
FPC-18WA3
LCD size
18.5", 16:9
Display type
WXGA TFT
Resolution
1366 x 768
Color
16.7M
Pixel pitch
0.300mm(H) x 0.300mm(V)
Luminance
300cd/m²
Contrast ratio
1000
Viewing angle
80(U), 85(D), 85(L), 85(R)
Response time
5 ms
Backlight
4 x CCFL
Touch Type
5 Wire resistive
Touch Light Transmission
80%
Touch Interface
USB

Quick Reference Guide
FPC 17”~21”W Series Quick Reference Guide
9
System
Board
EMX-QM57
EMX-780E
CPU
Intel® Arrandale/ Ibex-M Support
Intel® 32nm Arrandale BGA1288 SV/
LV/ ULV Processors, TDP Up to 35W
by iMVP-6.5
Supports AM2/ AM2+/ AM3 Socket
Support 65W Athlon/ Athlon
X2/Quad-Core™ AMD Phenom™ II
Processors
Cooling method
Active CPU cooler
System Chipset
Intel® QM57
AMD RS780E/ SB710
I/O Chip
Winbond W83667HG-A
FINTEK F71863FG
Memory
Two SODIMMs Up to 8GB DDR3
Dual-channel 1066/800MHz SDRAM
Two 200-pin SODIMMs Support Up to
4GB DDR2 800 SDRAM
SSD
One CompactFlash Type I/II socket (Purchase from Avalue Highly
recommended)
HDD Drive Bay
1 x 2.5" SATA
Rear Panel I/O
Serial Port
2 x RS-232 COM ports
Ethernet
2 x LAN ports (Intel® 82577LM &
Realtek RTL8111D Gigabit LAN)
2 x LAN ports (Realtek RTL8111D
Gigabit LAN)
WIFI
Optional USB WIFI 802.11 b/g (occupy one USB port)
VGA
1 x DB-15
DVI
n/a
HDMI
1 x HDMI
Audio
Line out, Line in, Mic in
USB
5 x USB 2.0
Speaker
5W X 2
Mouse & KB
1 x PS/2 Keyboard connector
Mechanical & Environmental
System Fan
1 x System Fan
Color
Front panel Black
Rear panel Black
Power input
100-240 VAC (180 W)
Operating temperature
'-20°C to 50°C.
Storage temperature
'-20°C to 60°C.
Relative humidity
10% to 95% @ 40℃, non-condensing
Mounting
Wall/Stand/VESA 75 mm X 75 mm and 100 mm X 100 mm
Dimensions
459.5 mm X 309 mm X 79.6 mm
Weight
5.77 Kgs

FPC 17”~21”W Series
10 FPC 17”~21”W Series Quick Reference Guide
1.3.3. 21”“widescreen”Series
Panel
FPC-21W01
FPC-21W02
FPC-21W05
LCD size
21", 16:9
Display type
Full HD TFT
Resolution
1920 x 1080
Color
16.7M
Pixel pitch
0.248mm(H) x 0.248mm(V)
Luminance
300cd/m²
Contrast ratio
1000
Viewing angle
80(U), 85(D), 85(L), 85(R)
Response time
5 ms
Backlight
4 x CCFL
Touch Type
5 Wire resistive
Touch Light Transmission
80%
Touch Interface
USB
System
Board
EMX-945GME3
EMX-965GME
EMX-PNV
CPU
Supports Intel μFC-PGA
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Supports Intel® socket P
Core™Duo
/Core™Solo/Core™2
Duo with 65nm process
technology
Onboard Intel® Atom™
Dual-Core 1.8 GHz CPU
Cooling method
Active CPU cooler
Passive CPU heatsink
System Chipset
Intel® 82945GME GMCH
/ ICH7-M
Intel® GME965 GMCH /
ICH8-M
Intel® ICH8-M
I/O Chip
Winbond W83627DHG-A
Winbond 83627DHG
Memory
Two 240-pin DIMM
socket supports up to
4GB DDR2 533/667
Two 200-pin SODIMM
socket supports up to
4GB DDR2 533/667
1 SODIMM socket
supports upt to 2GB
SDRAM
SSD
One CompactFlash Type I/II socket (Purchase from Avalue Highly
recommended)
HDD Drive Bay
1 x 2.5" SATA

Quick Reference Guide
FPC 17”~21”W Series Quick Reference Guide
11
Rear Panel I/O
Serial Port
3 x RS-232
Ethernet
1 x Realtek GigLAN port
2 x LAN ports (Realtek
RTL8111B Gigabit LAN)
2 x LAN ports (Intel
82583V Gigabit LAN)
WIFI
Optional USB WiFi 802.11 b/g (occupy one USB port)
VGA
1 x DB-15
DVI
1 x DVI
n/a
HDMI
n/a
Audio
Line out, Line in, Mic in
USB
5 x USB 2.0
Speaker
5W X 2
Mouse & KB
1 x PS/2 Keyboard connector
Mechanical & Environmental
System Fan
1 x System Fan
Color
Front panel Black
Rear panel Black
Power input
100-240 VAC (180 W)
Operating temperature
'-20°C to 50°C.
Storage temperature
'-20°C to 60°C.
Relative humidity
10% to 95% @ 40℃, non-condensing
Mounting
Wall/Stand/VESA 75 mm X 75 mm and 100 mm X 100 mm
Dimensions
526 mm X 346.5 mm X 80.4 mm
Weight
7.32 Kgs
Panel
FPC-21W06
FPC-21WA3
LCD size
21", 16:9
Display type
Full HD TFT
Resolution
1920 x 1080
Color
16.7M
Pixel pitch
0.248mm(H) x 0.248mm(V)
Luminance
300cd/m²
Contrast ratio
1000
Viewing angle
80(U), 85(D), 85(L), 85(R)
Response time
5 ms
Backlight
4 x CCFL
Touch Type
5 Wire resistive
Touch Light Transmission
80%
Touch Interface
USB

FPC 17”~21”W Series
12 FPC 17”~21”W Series Quick Reference Guide
System
Board
EMX-QM57
EMX-780E
CPU
Intel® Arrandale/ Ibex-M Support
Intel® 32nm Arrandale BGA1288 SV/
LV/ ULV Processors, TDP Up to 35W
by iMVP-6.5
Supports AM2/ AM2+/ AM3 Socket
Support 65W Athlon/ Athlon
X2/Quad-Core™ AMD Phenom™ II
Processors
Cooling method
Active CPU cooler
System Chipset
Intel® QM57
AMD RS780E/ SB710
I/O Chip
Winbond W83667HG-A
FINTEK F71863FG
Memory
Two SODIMMs Up to 8GB DDR3
Dual-channel 1066/800MHz SDRAM
Two 200-pin SODIMMs Support Up to
4GB DDR2 800 SDRAM
SSD
One CompactFlash Type I/II socket (Purchase from Avalue Highly
recommended)
HDD Drive Bay
1 x 2.5" SATA
Rear Panel I/O
Serial Port
2 x RS-232 COM ports
Ethernet
2 x LAN ports (Intel® 82577LM &
Realtek RTL8111D Gigabit LAN)
2 x LAN ports (Realtek RTL8111D
Gigabit LAN)
WIFI
Optional USB WIFI 802.11 b/g (occupy one USB port)
VGA
1 x DB-15
DVI
n/a
HDMI
1 x HDMI
Audio
Line out, Line in, Mic in
USB
5 x USB 2.0
Speaker
5W X 2
Mouse & KB
1 x PS/2 Keyboard connector
Mechanical & Environmental
System Fan
1 x System Fan
Color
Front panel Black
Rear panel Black
Power input
100-240 VAC (180 W)
Operating temperature
'-20°C to 50°C.
Storage temperature
'-20°C to 60°C.
Relative humidity
10% to 95% @ 40℃, non-condensing
Mounting
Wall/Stand/VESA 75 mm X 75 mm and 100 mm X 100 mm
Dimensions
526 mm X 346.5 mm X 80.4 mm
Weight
7.32 Kgs

Quick Reference Guide
FPC 17”~21”W Series Quick Reference Guide
13
1.4 System Overview
1.4.1 Rear View
Connectors
Label
Function
Note
COM1/2/3
Serial port 1/2/3
DB-9 male connector
DVI
DVI connector
KB
PS/2 keyboard connector
6-pin mini DIN
LAN
10/100/1000Base-Tx Ethernet connector
RJ-45
LINE IN
Line-in audio jack
LINE OUT
Line-out audio jack
MIC IN
Mic-in audio jack
MS
PS/2 mouse connector
6-pin mini DIN
Power
System power switch
USB
USB 2.0 connector
VGA
CRT connector
DB-15 female connector
Note: Rear I/O (marked in red) complies with the integrated Main board.
COM2
COM1
COM3

FPC 17”~21”W Series
14 FPC 17”~21”W Series Quick Reference Guide
1.5 System Dimensions
1.5.1 FPC 17”Series
(Unit: mm)

Quick Reference Guide
FPC 17”~21”W Series Quick Reference Guide
15
1.5.2 18.5”“widescreen”Series
(Unit: mm)

FPC 17”~21”W Series
16 FPC 17”~21”W Series Quick Reference Guide
1.5.3 FPC 21”Widescreen Series
(Unit: mm)

Quick Reference Guide
FPC 17”~21”W Series Quick Reference Guide
17
2.Hardware
Configuration
2.1 Jumper and Connector Setting, Driver and BIOS
Installing
Please refer to EMX-945GME3 / EMX-965GME / EMX-PNV /
EMX-780E / EMX-QM57 Quick Installation Guide or User’s Manual.
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

FPC 17”~21”W Series
18 FPC 17”~21”W Series Quick Reference Guide
2.2 Installing Hard Disk & Memory
Remove 12 screws as indicated below to open the back of the chassis.

Quick Reference Guide
FPC 17”~21”W Series Quick Reference Guide
19
2.2.1 Install HDD
2.2.1.1 2.5”SATA HDD
Step 1. Attach the HDD bracket to the 2.5”SATA HDD by means of 4 screws as shown
above, and then connect HDD data and power cables.
Step 2. Position the HDD bracket & 2.5”SATA HDD assembly into the chassis and lock
with 4 screws as indicated above.

FPC 17”~21”W Series
20 FPC 17”~21”W Series Quick Reference Guide
