Avalue Technology OFP-15W33 User manual

Part No. E2017O153A2R
OFP-15W33
15.6" Open Frame Panel PC
Quick Reference Guide
1st Ed –26 April, 2022
Copyright Notice
Copyright 2022 Avalue Technology Inc., ALL RIGHTS RESERVED.

OFP-15W33
2 OFP-15W33 Quick Reference Guide
Federal Communication Commission Interference Statement
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT
MAY CAUSE UNDESIRED OPERATION.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction, may cause
harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Notice:
(1) A Unshielded-type power cord is required in order to meet FCC emission limits and also to prevent
interference to the nearby radio and television reception. It is essential that only the supplied
power cord by used.
(2) Use only shielded cables to connect I/O devices to this equipment.
(3) Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.

Quick Reference Guide
OFP-15W33 Quick Reference Guide
3
FCC RF Radiation Exposure Statement
This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65 and found compliant
to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF
Exposure from radio frequency devices. The radiated output power of this Wireless LAN device is far
below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a
manner that the potential for human contact during normal operation is minimized. When nearby
persons has to be kept to ensure RF exposure compliance, in order to comply with RF exposure limits
established in the ANSI C95.1 standards, the distance between the antennas and the user should not
be less than 20 cm.

OFP-15W33
4 OFP-15W33 Quick Reference Guide
WARNING
“CAUTION – Use suitable mounting apparatus to avoid risk of injury.”
“CAUTION – This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures”
“CAUTION –Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions.”
“CAUTION - Use a power cord that matches the voltage of the power outlet, which has been approved
and complies with the safety standard of your particular country.”
“WARNING – To avoid risk of electric shock, this equipment must only be connected to a supply
mains with protective earth.”

Quick Reference Guide
OFP-15W33 Quick Reference Guide
5
Content
1. Getting Started............................................................................................................8
1.1 Safety Precautions ................................................................................................8
1.2 Packing List...........................................................................................................8
1.3 System Specifications ...........................................................................................9
1.4 System Overview.................................................................................................12
1.4.1 Right View.................................................................................................................................. 12
1.4.2 Left View .................................................................................................................................... 12
1.4.3 Bottom View............................................................................................................................... 12
1.5 System Dimensions.............................................................................................13
1.5.1 Front and Rear side ................................................................................................................... 13
1.6 Panel Mounting ........................................................................................................14
1.7 Wall Mounting...........................................................................................................25
2. Hardware Configuration...........................................................................................35
2.1 OFP-15W33 connector mapping.........................................................................36
2.1.1 Serial Port connector (COM)...................................................................................................... 36
2.1.2 DC power-in connector (DC in).................................................................................................. 37
2.2 Product Overview................................................................................................38
2.3 Jumper and Connector List..................................................................................40
2.4 Setting Jumpers & Connectors............................................................................43
2.4.1 Serial port 1/2/3/4/5/6 pin9 signal select (JRI1/JRI2/JRI3/JRI4/JRI5/JRI6)............................... 43
2.4.2 SATA2/MSATA1 mPCIe slot selector (JMSW1)........................................................................ 43
2.4.3 LVDS Back Light power selection (JSBKL1) ............................................................................. 44
2.4.4 AT/ATX Power Mode Select (JSATX1) ..................................................................................... 44
2.4.5 Clear CMOS (CMOS1) .............................................................................................................. 45
2.4.6 LCD Inverter connector (JBKL1)................................................................................................ 45
2.4.7 Serial port 1/2 connector (COM1/2)........................................................................................... 46
2.4.8 Serial port 3/4/6 connector (COM3/4/6)..................................................................................... 46
2.4.9 Serial port 5 connector (COM5)................................................................................................. 47
2.4.10 Serial Port 1 RS485/422 Mode connector (JRS485)............................................................. 47
2.4.11 General purpose I/O connector (DIO1) ................................................................................. 48
2.4.12 SATA Power connector 1/2 (SPWR1/2)................................................................................ 48
2.4.13 Power connector (PWR1)...................................................................................................... 49
2.4.14 USB2.0 connector (USB3)..................................................................................................... 49
2.4.15 USB2.0 connector (USBH1).................................................................................................. 50
2.4.16 USB2.0 connector (USBH2).................................................................................................. 50

OFP-15W33
6 OFP-15W33 Quick Reference Guide
2.4.17 LVDS connector (LVDS1)...................................................................................................... 51
2.4.18 Battery connector (BT1) ........................................................................................................ 52
2.4.19 Front Audio connector (FAUD1)............................................................................................ 52
2.3.19.1 Signal Description –Front Audio connector (FAUD1) ....................................................... 52
2.4.20 LPC connector (JLPC1)......................................................................................................... 53
2.4.21 EC_Program (EC1)................................................................................................................ 53
2.4.22 SPI connector (SPI1)............................................................................................................. 54
2.4.23 Sony/Philips Digital Interface (SPDIF1)................................................................................. 54
2.4.24 Speaker connector (SPK1).................................................................................................... 55
2.4.25 Front Panel connector 1 (FPT1)............................................................................................ 55
2.4.26 Front Panel connector 2 (FPT2)............................................................................................ 56
2.4.27 LED indicator connector 1 (LED1)......................................................................................... 56
2.4.28 LED indicator connector 2 (LED2)......................................................................................... 57
2.4.29 CPU fan connector (FAN1).................................................................................................... 57
2.4.30 Digital Microphone connector (DMIC1) ................................................................................. 58
2.4.31 eDP connector (EDP1).......................................................................................................... 58
2.4.32 I2C connector (I2C1)............................................................................................................. 59
3.BIOS Setup....................................................................................................................60
3.1 Introduction..........................................................................................................61
3.2 Starting Setup......................................................................................................61
3.3 Using Setup.........................................................................................................62
3.4 Getting Help.........................................................................................................63
3.5 In Case of Problems............................................................................................63
3.6 BIOS setup..........................................................................................................64
3.6.1 Main Menu ................................................................................................................................. 64
3.6.1.1 System Language ............................................................................................................. 65
3.6.1.2 System Date...................................................................................................................... 65
3.6.1.3 System Time ..................................................................................................................... 65
3.6.2 Advanced Menu......................................................................................................................... 65
3.6.2.1 Trusted Computing............................................................................................................ 66
3.6.2.2 ACPI Settings.................................................................................................................... 66
3.6.2.3 IT8528 Super IO Configuration ......................................................................................... 67
3.6.2.3.1 Serial Port 1 Configuration................................................................................................ 68
3.6.2.3.2 Serial Port 2 Configuration................................................................................................ 69
3.6.2.3.3 Serial Port 3 Configuration................................................................................................ 69
3.6.2.3.4 Serial Port 4 Configuration................................................................................................ 70
3.6.2.3.5 Serial Port 5 Configuration................................................................................................ 70
3.6.2.4 H/W Monitor ...................................................................................................................... 71
3.6.2.4.1 Smart Fan Mode Configuration......................................................................................... 71
3.6.2.5 S5 RTC Wake Settings ..................................................................................................... 72

Quick Reference Guide
OFP-15W33 Quick Reference Guide
7
3.6.2.6 Serial Port Console Redirection........................................................................................ 74
3.6.2.7 CPU Configuration ............................................................................................................ 74
3.6.2.7.1 Socket 0 CPU Information................................................................................................. 75
3.6.2.7.2 CPU Power Management Configuration........................................................................... 76
3.6.2.8 Network Stack Configuration............................................................................................. 77
3.6.2.9 NVMe Configuration.......................................................................................................... 78
3.6.2.10 CSM Configuration............................................................................................................ 78
3.6.2.11 USB Configuration............................................................................................................. 79
3.6.2.12 Security Configuration....................................................................................................... 80
3.6.2.13 System Component........................................................................................................... 81
3.6.3 Chipset..................................................................................................................................... 81
3.6.3.1 North Bridge .................................................................................................................... 82
3.6.3.2 South Bridge.................................................................................................................... 83
3.6.3.3 Uncore Configuration....................................................................................................... 83
3.6.3.4 South Cluster Configuration ............................................................................................ 85
3.6.3.4.1 HD-Audio Configuration .................................................................................................. 85
3.6.3.4.2 PCI Express Configuration.............................................................................................. 86
3.6.3.4.2.1 PCI Express Root Port 3(i210/211) ......................................................................... 87
3.6.3.4.2.2 PCI Express Root Port 4(i210/211) ......................................................................... 88
3.6.3.4.2.3 PCI Express Root Port 5(M.2/PCIe slot) ................................................................. 89
3.6.3.4.2.4 PCI Express Root Port 6(mPCIe)............................................................................ 90
3.6.3.4.3 SATA Drives.................................................................................................................... 91
3.6.3.4.4 SCC Configuration .......................................................................................................... 92
3.6.3.4.5 USB Configuration........................................................................................................... 92
3.6.4 Security .................................................................................................................................... 93
3.6.4.1 Secure Boot..................................................................................................................... 94
3.6.5 Boot.......................................................................................................................................... 95
3.6.6 Save and exit ........................................................................................................................... 96
3.6.6.1 Save Changes and Reset ................................................................................................. 96
3.6.6.2 Discard Changes and Reset ............................................................................................. 96
3.6.6.3 Restore Defaults................................................................................................................ 96
3.6.6.4 Launch EFI Shell from filesystem device.......................................................................... 96
4. Drivers Installation.......................................................................................................97
4.1 Install Chipset Driver ...........................................................................................98
4.2 Install VGA Driver................................................................................................99
4.3 Install Serial IO Driver........................................................................................100
4.4 Install TXE Driver...............................................................................................101
4.5 Install Audio Driver (For Realtek ALC662 HD Audio) ........................................102
4.6 Install LAN Driver (For Intel I211AT)..................................................................103
5. Development Resource..........................................................................................105

OFP-15W33
8 OFP-15W33 Quick Reference Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x OFP-15W33 Open Frame Panel PC

Quick Reference Guide
OFP-15W33 Quick Reference Guide
9
1.3 System Specifications
Board Specification
Mother Board
EMX-APLP (EMX-APLP-34-A1-01R(eDP Ver))
CPU
Intel® Celeron® J3455 (F1 stepping)
CPU Cooler (Type)
Fanless
Memory
2 x 204-pin DDR3L 1600 & 1333MHz SO-DIMM supports up to 16GB
Wireless LAN
IEEE802.11 ac/a/b/g/n 2.4 GHz, 5 GHz (Optional)
Bluetooth
BT4.0 (Optional)
Operating System
Windows 10
Ubuntu 16.04
Expansion Card
1 x full size Mini PCI-e support mSATA (SATA III and mSATA By auto
switch IC) with 1 x SIM card slot
1 x M.2 (2230) A-Key, support WiFi module
Storage
Solid State Drive
N/A (Reserve space for future1 x 2.5” Drive Bay design)
Other Storage
Device
Default by 1 x mSATA (Shared mPCIe)
Panel
LCD Panel
15.6" eDP Panel,
BOE NV156FHM-N42 1920*1080 or
Innolux N156HCE-EBA 1920*1080
LCD Control Board
Built in
Touch Screen
15.6" PCAP Touch,
Henghao: HD-T156WP05-F4SB or ACDC119
External I/O
Serial Port
1 x RS232(default)/422/485
4 x RS232 (option)
USB Port
4 x USB 3.0,
4 x USB 2.0 (option)
Video Port
DP++, HDMI/DP(HDMI/DP: 3840 x 2160 @ 30Hz, 2560 x 1600 @ 30Hz)
Audio Port
Line-out, Mic-in
LAN Port
2 x RJ45 LAN port (2 x Intel® I211AT, 10/100/1000 Base-Tx Gigabit
Ethernet Compatible)
Wireless LAN
Antenna
2 x Antenna Mounting with Dust Cover
Switch
2 pins Phoenix connector for remote power
Mechanical

OFP-15W33
10 OFP-15W33 Quick Reference Guide
Power Type
+12V~24V DC in
Power Connector
Type
3 pins Phoenix connector and Lockable DC in
Dimension
387 x 235 x 47 mm
Weight
2.5 Kg
Color
Silver
Fanless
Fanless
OS Support
Windows 10
Ubuntu 16.04
Android x86 8.1
Reliability
EMI Test
CE/FCC Class A
Vibration Test
Random Vibration Operation
1 Test PSD : 0.00454G²/Hz , 1.5 Grms
2 System condition : operation mode
3 Test frequency : 5~500 Hz
4 Test axis : X,Y and Z axis
5 Test time : 30 minutes per each axis
6 IEC60068-2-64 Test Fh
6 Storage : mSATA
Sine Vibration test (Non-operation)
1 Test Acceleration : 2G
2 Test frequency : 5~500 Hz
3 Sweep：1 Oct/ per one minute. (logarithmic)
4 Test Axis : X,Y and Z axis
5 Test time :30 min. each axis
6 System condition : Non-Operating mode
7. Reference IEC 60068-2-6 Testing procedures
Package Vibration Test:
1 Test PSD : 0.026G²/Hz , 2.16 Grms
2 Test frequency : 5~500 Hz
3 Test axis : X,Y and Z axis
4 Test time : 30 minutes per each axis
5 IEC 60068-2-64 Test Fh
Mechanical Shock
Test
1 Wave from : Half Sine wave
2 Acceleration Rate : 10g for operation mode
3 Duration Time : 11ms
4 No. of shock : Z axis 300 times

Quick Reference Guide
OFP-15W33 Quick Reference Guide
11
5 Test Axis : Z axis
6 operation mode
7 Reference IEC 60068-2-27 testing procedures
Test Eb : Shock Test
Drop Test
Package drop test
Reference ISTA 2A, Method : IEC-60068-2-32 Test:Ed
Test Ea : Drop Test
1 Test phase : One corner, three edges, six faces
2 Test high : 96.5cm
3 Package weight : 5Kg
4 Test drawing
4-feet drop resistance without package
MIL-STD-810G
Operating
Temperature
0°C ~ 45°C (32°F ~ 113°F)
Operating
Humidity
0% ~ 90% Relative Humidity, Non-condensing
Storage
Temperature
-20°C ~ 60°C (-4°F ~ 140°F)
Note: Specifications are subject to change without notice.

OFP-15W33
12 OFP-15W33 Quick Reference Guide
1.4 System Overview
1.4.1 Right View
1.4.2 Left View
1.4.3 Bottom View
Connectors
Label
Function
Note
COM
5 x Serial port connector
1 x RS232(default)/422/485
4 x RS232(option)
HDMI
HDMI connector
USB3.0
4 x USB 3.0 connector
USB2.0
4 x USB 2.0 connector(option)
LAN1/2
2 x RJ-45 Ethernet
Line-out
Line-out jack
Mic-in
Mic-in audio jack
DC in
DC power-in connector
DC in
2 pins Phoenix connector
DP1/2
2 x DP connector
Power Switch
2 pins Phoenix connector for remote power

Quick Reference Guide
OFP-15W33 Quick Reference Guide
13
1.5 System Dimensions
1.5.1 Front and Rear side
(Unit: mm)

OFP-15W33
14 OFP-15W33 Quick Reference Guide
1.6 Panel Mounting
Panel mount is the solution for mounting OFP into the opening of wall (or cabinet).
The dimension of opening is as below:
(Installation
surface)
(Opening dimension)
(Opening dimension) (Opening dimension)
A
A
(Panel thickness)
(Unit: mm)

Quick Reference Guide
OFP-15W33 Quick Reference Guide
15
Step1. Insert and fasten 12 pcs Hexagon Studs on each side of the OFP-15W33 Bracket.
2
Hexagon Stud
12
1
OFP-15W33
1
Item
Part Name
Quantity

OFP-15W33
16 OFP-15W33 Quick Reference Guide
Step2. Assemble the Front bracket to OFP-15W33 and fasten 4 screws on the corresponding Hexagon
Studs.
4
Screw
4
3
Front Bracket
1
2
Hexagon Stud
4
Item
Part Name
Quantity

Quick Reference Guide
OFP-15W33 Quick Reference Guide
17
Step3. Assemble the 4pcs Panel Mount Brackets on the Front Bracket and fasten the 8 pcs screws to the
corresponding holes.
5
Panel Mount Bracket
4
4
Screw
8
3
Front Bracket
1
Item
Part Name
Quantity

OFP-15W33
18 OFP-15W33 Quick Reference Guide
(outside the wall (or cabinet) opening)
Step4. Embed the OFP-15W33 semi-finished product into the wall (or cabinet) opening.
6
Wall
1
Item
Part Name
Quantity

Quick Reference Guide
OFP-15W33 Quick Reference Guide
19
(inside the wall (or cabinet))
Step5. Fasten the Panel mount screw*8 to the Panel mount kit bracket*8 (as shown in Figure 5-1), and then
attach them to the Panel Mount Bracket*4 fixing slots.
Figure 5-1
8
Panel mount Screw
8
7
Panel Mount Kit Bracket
8
5
Panel Mount Bracket
4
Item
Part Name
Quantity

OFP-15W33
20 OFP-15W33 Quick Reference Guide
