Avalue Technology FPC 15 Series User manual

Part No. E2017FPC0A0R
FPC 15”~22”W Series
15”/17”/15”W/17”W/22”W Flexible TFT Touch Panel PC
Quick Reference Guide
1st Ed – 13 November, 2008
Copyright Notice
Copyright © 2007-2008 Avalue Technology Inc., ALL RIGHTS RESERVED.

FPC 15”~22”W Series
2 FPC 15”~22”W Series Quick Reference Guide
Contents
1. Getting Started............................................................................................................3
1.1 Safety Precautions ................................................................................................3
1.2 Packing List ...........................................................................................................3
1.3 System Specifications ...........................................................................................4
1.4 System Overview.................................................................................................14
1.4.1 Rear View................................................................................................................................... 14
1.5 System Dimensions.............................................................................................15
1.5.1 FPC 15” Series .......................................................................................................................... 15
1.5.2 FPC 17” Series .......................................................................................................................... 16
1.5.3 FPC 15.4” Widescreen Series ................................................................................................... 17
1.5.4 FPC 17” Widescreen Series ...................................................................................................... 18
1.5.5 FPC 22” Widescreen Series ...................................................................................................... 19
2. Hardware Configuration...........................................................................................20
2.1 Jumper and Connector Setting, Driver and BIOS Installing.................................20
2.2 Installing Hard Disk & Memory ............................................................................21
2.2.1 Install HDD ................................................................................................................................. 22
2.2.2 Install PCI Expansion Card ........................................................................................................ 24
2.2.3 Install Antenna for USB WiFi Module ........................................................................................ 25
2.3 Optional Side Bracket..........................................................................................26

Quick Reference Guide
FPC 15”~22”W Series Quick Reference Guide 3
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x FPC 15”/17”/15”W/17”W/22”W Series Panel PC
1 x Quick Reference Guide
1 x CD/DVD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
—WiFi drivers and utilities
—Touch controller drivers and utilities
1 x packing set includes the followings
—1 x power cord
—1 x cable set for IDE, SATA, COM
—1 x antenna (for optional WiFi)

FPC 15”~22”W Series
4 FPC 15”~22”W Series Quick Reference Guide
1.3 System Specifications
Panel
Specifications FPC-1501 FPC-1502 FPC-1503
LCD size 15.0", 4:3
Display type XGA TFT
Resolution 1024x768
Color 16 Million
Pixel pitch 0.297mm(H) x 0.297mm(V)
Luminance 250 cd/m²
Contrast ratio 550
Viewing angle 45(U), 55(D), 60(L), 50(R)
Response time 8 ms
Backlight 2 x CCFL
Touch Type 5 Wires resistive
Touch Light Transmission 80%
Touch Interface RS-232
System
Board EMX-945GM3 EMX-965GME EMX-910GMLE-C9E
CPU
Supports Intel µFC-PGA
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Su
pports Intel® socket P
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Onboard Intel uFC-BGA
479 Celeron M 900MHz
w/512K 2nd Level
Cache with 90nm
process technology
Cooling method Active CPU cooler Active CPU cooler Passive CPU heatsink
BIOS Award 1 MB Flash BIOS
AMI 16 MB SPI ROM Award 512 KB Flash
BIOS
System Chipset
Intel®82945GME GMCH
/ ICH7-M
Intel® GME965 GMCH /
ICH8-M
Intel 82910GMLE
GMCH / ICH6-M
I/O Chip Winbond W83627DHG-A
Memory
Two 240-pin DIMM
socket supports up to
4GB DDR2 533/667
Two 200-pin SODIMM
socket supports up to
4GB DDR2 533/667
Two 240-pin DIMM
socket supports up to 2
GB DDR2 400
SSD One CompactFlash Type I/II socket
HDD Drive Bay 1 x 3.5" SATA or 1 x 2.5" SATA
Expansion Slot 1 x PCI slot

Quick Reference Guide
FPC 15”~22”W Series Quick Reference Guide 5
Rear Panel I/O
Serial Port 3 x RS-232
Ethernet 1 x Realtek GigLAN port
2 x Realtek GigaLAN ports 1 x Realtek GigaLAN port
WIFI Optional USB WiFi 802.11 b/g (occupy one USB port)
VGA 1 x DB-15
DVI 1 x DVI
Audio Line out, Line in, Mic in
USB 6 x USB 2.0 (optional extra 2 USB ports by request)
Speaker 2W X 2
Mouse & KB 1 x PS/2 Keyboard connector
Mechanical & Evironmental
System Fan 1 x System Fan
Front panel Silver
Color Rear panel Black
Power input 100-240 VAC (150 W)
Operating temperature 0°C to 40°C.
Storage temperature -10°C to 50°C.
Relative humidity 10% to 95% @ 40℃, non-condensing
Mounting Wall/Stand/VESA 75 mm X 75 mm and 100 mm X 100 mm
Dimensions 382mm X 280 mm X 89.15 mm
Weight 6.8 kgs / 15 lbs

FPC 15”~22”W Series
6 FPC 15”~22”W Series Quick Reference Guide
Panel
Specifications FPC-1701 FPC-1702 FPC-1703
LCD size 17.0", 4:3
Display type SXGA TFT
Resolution 1028 x 1024
Color 16 Million
Pixel pitch 0.264mm(H) x 0.264mm(V)
Luminance 300 cd/m²
Contrast ratio 400
Viewing angle 60(U), 55(D), 60(L), 50(R)
Response time 16 ms
Backlight 4 x CCFL
Touch Type 5 Wires resistive
Touch Light Transmission 80%
Touch Interface RS-232
System
Board EMX-945GM3 EMX-965GME EMX-910GMLE-C9E
CPU
Supports Intel µFC-PGA
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Su
pports Intel® socket P
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Onboard Intel uFC-BGA
479 Celeron M 900MHz
w/512K 2nd Level
Cache with 90nm
process technology
Cooling method Active CPU cooler Active CPU cooler Passive CPU heatsink
BIOS Award 1 MB Flash BIOS
AMI 16 MB SPI ROM Award 512 KB Flash
BIOS
System Chipset
Intel®82945GME GMCH
/ ICH7-M
Intel® GME965 GMCH /
ICH8-M
Intel 82910GMLE
GMCH / ICH6-M
I/O Chip Winbond W83627DHG-A
Memory
Two 240-pin DIMM
socket supports up to
4GB DDR2 533/667
Two 200-pin SODIMM
socket supports up to
4GB DDR2 533/667
Two 240-pin DIMM
socket supports up to 2
GB DDR2 400
SSD One CompactFlash Type I/II socket
HDD Drive Bay 1 x 3.5" SATA or 1 x 2.5" SATA
Expansion Slot 1 x PCI slot

Quick Reference Guide
FPC 15”~22”W Series Quick Reference Guide 7
Rear Panel I/O
Serial Port 3 x RS-232
Ethernet 1 x Realtek GigLAN port
2 x Realtek GigaLAN ports 1 x Realtek GigaLAN port
WIFI Optional USB WiFi 802.11 b/g (occupy one USB port)
VGA 1 x DB-15
DVI 1 x DVI
Audio Line out, Line in, Mic in
USB 6 x USB 2.0 (optional extra 2 USB ports by request)
Speaker 2W X 2
Mouse & KB 1 x PS/2 Keyboard connector
Mechanical & Evironmental
System Fan 1 x System Fan
Front panel Silver
Color Rear panel Black
Power input 100-240 VAC (150 W)
Operating temperature 0°C to 40°C.
Storage temperature -10°C to 50°C.
Relative humidity 10% to 95% @ 40℃, non-condensing
Mounting Wall/Stand/VESA 75 mm X 75 mm and 100 mm X 100 mm
Dimensions 402 mm X 322 mm X 88 mm
Weight 8.2 kgs /18 lbs

FPC 15”~22”W Series
8 FPC 15”~22”W Series Quick Reference Guide
Panel
Specifications FPC-15W01 FPC-15W02 FPC-15W03
LCD size 15.4", 16:10
Display type WXGA TFT
Resolution 1280 x 800
Color 262144
Pixel pitch 0.255(H) x 0.255(V)
Luminance 500cd/m²
Contrast ratio 800
Viewing angle 40(U), 60(D), 60(L), 60(R)
Response time 5 ms
Backlight 2 x CCFLs
Touch Type 5 Wires resistive
Touch Light Transmission 80%
Touch Interface RS-232
System
Board EMX-945GM3 EMX-965GME EMX-910GMLE-C9E
CPU
Supports Intel µFC-PGA
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Su
pports Intel® socket P
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Onboard Intel uFC-BGA
479 Celeron M 900MHz
w/512K 2nd Level
Cache with 90nm
process technology
Cooling method Active CPU cooler Active CPU cooler Passive CPU heatsink
BIOS Award 1 MB Flash BIOS
AMI 16 MB SPI ROM Award 512 KB Flash
BIOS
System Chipset
Intel®82945GME GMCH
/ ICH7-M
Intel® GME965 GMCH /
ICH8-M
Intel 82910GMLE
GMCH / ICH6-M
I/O Chip Winbond W83627DHG-A
Memory
Two 240-pin DIMM
socket supports up to
4GB DDR2 533/667
Two 200-pin SODIMM
socket supports up to
4GB DDR2 533/667
Two 240-pin DIMM
socket supports up to 2
GB DDR2 400
SSD One CompactFlash Type I/II socket
HDD Drive Bay 1 x 3.5" SATA or 1 x 2.5" SATA
Expansion Slot 1 x PCI slot

Quick Reference Guide
FPC 15”~22”W Series Quick Reference Guide 9
Rear Panel I/O
Serial Port 3 x RS-232
Ethernet 1 x Realtek GigLAN port
2 x Realtek GigaLAN ports 1 x Realtek GigaLAN port
WIFI Optional USB WiFi 802.11 b/g (occupy one USB port)
VGA 1 x DB-15
DVI 1 x DVI
Audio Line out, Line in, Mic in
USB 6 x USB 2.0 (optional extra 2 USB ports by request)
Speaker 2W X 2
Mouse & KB 1 x PS/2 Keyboard connector
Mechanical & Evironmental
System Fan 1 x System Fan
Front panel Silver
Color Rear panel Black
Power input 100-240 VAC (150 W)
Operating temperature 0°C to 40°C.
Storage temperature -10°C to 50°C.
Relative humidity 10% to 95% @ 40℃, non-condensing
Mounting Wall/Stand/VESA 75 mm X 75 mm and 100 mm X 100 mm
Dimensions 395mm X 260 mm X 77.2 mm
Weight 6 kgs / l3 lbs

FPC 15”~22”W Series
10 FPC 15”~22”W Series Quick Reference Guide
Panel
Specifications FPC-17W01 FPC-17W02 FPC-17W03
LCD size 17", 16:10
Display type WXGA TFT
Resolution 1440 x 900
Color 262144
Pixel pitch 0.255mm(H) x 0.255mm(V)
Luminance 400cd/m²
Contrast ratio 600
Viewing angle 60(U), 60(D), 70(L), 70(R)
Response time 10 ms
Backlight 2 x CCFLs
Touch Type 5 Wires resistive
Touch Light Transmission 80%
Touch Interface RS-232
System
Board EMX-945GM3 EMX-965GME EMX-910GMLE-C9E
CPU
Supports Intel µFC-PGA
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Su
pports Intel® socket P
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Onboard Intel uFC-BGA
479 Celeron M 900MHz
w/512K 2nd Level
Cache with 90nm
process technology
Cooling method Active CPU cooler Active CPU cooler Passive CPU heatsink
BIOS Award 1 MB Flash BIOS
AMI 16 MB SPI ROM Award 512 KB Flash
BIOS
System Chipset
Intel®82945GME GMCH
/ ICH7-M
Intel® GME965 GMCH /
ICH8-M
Intel 82910GMLE
GMCH / ICH6-M
I/O Chip Winbond W83627DHG-A
Memory
Two 240-pin DIMM
socket supports up to
4GB DDR2 533/667
Two 200-pin SODIMM
socket supports up to
4GB DDR2 533/667
Two 240-pin DIMM
socket supports up to 2
GB DDR2 400
SSD One CompactFlash Type I/II socket
HDD Drive Bay 1 x 3.5" SATA or 1 x 2.5" SATA
Expansion Slot 1 x PCI slot

Quick Reference Guide
FPC 15”~22”W Series Quick Reference Guide 11
Rear Panel I/O
Serial Port 3 x RS-232
Ethernet 1 x Realtek GigLAN port
2 x Realtek GigaLAN ports 1 x Realtek GigaLAN port
WIFI Optional USB WiFi 802.11 b/g (occupy one USB port)
VGA 1 x DB-15
DVI 1 x DVI
Audio Line out, Line in, Mic in
USB 6 x USB 2.0 (optional extra 2 USB ports by request)
Speaker 2W X 2
Mouse & KB 1 x PS/2 Keyboard connector
Mechanical & Evironmental
System Fan 1 x System Fan
Front panel Silver
Color Rear panel Black
Power input 100-240 VAC (150 W)
Operating temperature 0°C to 40°C.
Storage temperature -10°C to 50°C.
Relative humidity 10% to 95% @ 40℃, non-condensing
Mounting Wall/Stand/VESA 75 mm X 75 mm and 100 mm X 100 mm
Dimensions 432 mm X 272 mm X 80.7 mm
Weight 6.5 kgs / 14.5 lbs

FPC 15”~22”W Series
12 FPC 15”~22”W Series Quick Reference Guide
Panel
Specifications FPC-22W01 FPC-22W02 FPC-22W03
LCD size 22", 16:10
Display type WSXGA TFT
Resolution 1680 x 1050
Color 16.7 Million
Pixel pitch 0.282mm(H) x 0.282mm(V)
Luminance 300 cd/m²
Contrast ratio 700
Viewing angle 80(T), 80(D), 85(L), 85(R)
Response time 5 ms
Backlight 4 x CCFL
Touch Type 5 Wires resistive
Touch Light Transmission 80%
Touch Interface RS-232
System
Board EMX-945GM3 EMX-965GME EMX-910GMLE-C9E
CPU
Supports Intel µFC-PGA
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Su
pports Intel® socket P
Core™Duo/Core™Solo/
Core™2 Duo with 65nm
process technology
Onboard Intel uFC-BGA
479 Celeron M 900MHz
w/512K 2nd Level
Cache with 90nm
process technology
Cooling method Active CPU cooler Active CPU cooler Passive CPU heatsink
BIOS Award 1 MB Flash BIOS
AMI 16 MB SPI ROM Award 512 KB Flash
BIOS
System Chipset
Intel®82945GME GMCH
/ ICH7-M
Intel® GME965 GMCH /
ICH8-M
Intel 82910GMLE
GMCH / ICH6-M
I/O Chip Winbond W83627DHG-A
Memory
Two 240-pin DIMM
socket supports up to
4GB DDR2 533/667
Two 200-pin SODIMM
socket supports up to
4GB DDR2 533/667
Two 240-pin DIMM
socket supports up to 2
GB DDR2 400
SSD One CompactFlash Type I/II socket
HDD Drive Bay 1 x 3.5" SATA or 1 x 2.5" SATA
Expansion Slot 1 x PCI slot

Quick Reference Guide
FPC 15”~22”W Series Quick Reference Guide 13
Rear Panel I/O
Serial Port 3 x RS-232
Ethernet 1 x Realtek GigLAN port
2 x Realtek GigaLAN ports 1 x Realtek GigaLAN port
WIFI Optional USB WiFi 802.11 b/g (occupy one USB port)
VGA 1 x DB-15
DVI 1 x DVI
Audio Line out, Line in, Mic in
USB 6 x USB 2.0 (optional extra 2 USB ports by request)
Speaker 2W X 2
Mouse & KB 1 x PS/2 Keyboard connector
Mechanical & Evironmental
System Fan 1 x System Fan
Front panel Silver
Color Rear panel Black
Power input 100-240 VAC (150 W)
Operating temperature 0°C to 40°C.
Storage temperature -10°C to 50°C.
Relative humidity 10% to 95% @ 40℃, non-condensing
Mounting Wall/Stand/VESA 75 mm X 75 mm and 100 mm X 100 mm
Dimensions 537 mm X 342 mm X 91.5 mm
Weight 10.5 kgs / 23 lbs

FPC 15”~22”W Series
14 FPC 15”~22”W Series Quick Reference Guide
1.4 System Overview
1.4.1 Rear View
Connectors
Label Function Note
COM Serial port DB-9 male connector
DVI DVI connector
KB PS/2 keyboard connector 6-pin mini DIN
LAN 10/100/1000Base-Tx Ethernet connector RJ-45
LINE IN Line-in audio jack
LINE OUT Line-out audio jack
MIC IN Mic-in audio jack
MS PS/2 mouse connector 6-pin mini DIN
Power System power switch
USB USB 2.0 connector
VGA CRT connector DB-15 female connector
Note: Rear I/O marked in red depending on the mainboard integrated with the
panel PC.

Quick Reference Guide
FPC 15”~22”W Series Quick Reference Guide 15
1.5 System Dimensions
1.5.1 FPC 15” Series
(Unit: mm)

FPC 15”~22”W Series
16 FPC 15”~22”W Series Quick Reference Guide
1.5.2 FPC 17” Series
(Unit: mm)

Quick Reference Guide
FPC 15”~22”W Series Quick Reference Guide 17
1.5.3 FPC 15.4” Widescreen Series
(Unit: mm)

FPC 15”~22”W Series
18 FPC 15”~22”W Series Quick Reference Guide
1.5.4 FPC 17” Widescreen Series
(Unit: mm)

Quick Reference Guide
FPC 15”~22”W Series Quick Reference Guide 19
1.5.5 FPC 22” Widescreen Series
(Unit: mm)

FPC 15”~22”W Series
20 FPC 15”~22”W Series Quick Reference Guide
2. Hardware
Configuration
2.1 Jumper and Connector Setting, Driver and BIOS
Installing
Please refer to EMX-910GMLE/EMX-945GME3/EMX-965GME Quick
Installation Guide or User’s Manual.
Note: If you need more information, please visit our website:
http://www.avalue.com.tw
