Avalue Technology APC-1733 User manual

Part No. E2017A731A0R
APC-1733
17.3” PCAP EMX-APLP Apollo Lake N4200 / HDMI/ 2xDP/ 4x
USB 3.0/ 2 x LAN/ FANLESS Panel PC
Quick Reference Guide
1st Ed –28 June 2018
Copyright Notice
Copyright 2018 Avalue Technology Inc., ALL RIGHTS RESERVED.

APC-1733
2 APC-1733 Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

Quick Reference Guide
APC-1733 Quick Reference Guide
3
Content
1. Getting Started ........................................................................................................4
1.1 Safety Precautions....................................................................................................4
1.2 Packing List...............................................................................................................4
1.3 System Specifications...............................................................................................5
1.4 System Overview......................................................................................................8
1.4.1 Front View................................................................................................................................ 8
1.4.2 Rear View................................................................................................................................ 9
1.5 System Dimensions ................................................................................................10
2. Hardware Configuration .......................................................................................11

APC-1733
4 APC-1733 Quick Reference Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x APC-1733 17.3” PCAP EMX-APLP Apollo Lake N4200 / HDMI/
2xDP/ 4x USB 3.0/ 2 x LAN/ FANLESS Panel PC
1 x AC/DC adapter 12V/5A 90 Plug Type
1 x Power cord

Quick Reference Guide
APC-1733 Quick Reference Guide
5
1.3 System Specifications
Component
Mother Board
EMX-APLP
CPU
Intel® Apollo Lake N4200 Processor
CPU Cooler (Type)
Fanless Heatsink
Memory
2 x 204-pin DDR3L 1600 MHz SO-DIMM supports up to 16GB(MAX)
Power Supply
External power adapter
Adapter
AC/DC Adapter 100~240V 50~60Hz, 12V/5A
System Fan
Fanless
Speaker
2 x 8Ω/2W speaker (E175X201304R)
Camera
ACC-NBCAM-05R
2.0M CMOS,1600*1200,USB2.0,60*8*4.5mm
Wireless LAN
(Optional) M.2 Type A 2230 WiFi, ACC-M2-WIFIBT-03R
Operating System
Windows 10
Other Component
NFC: ACC-NFC-USB-03R
(Optional) E971XAP173302R, Handset module with 2D Barcode Scanner
ACC-BARCODE-004R, 2D Barcode scanner reader N3680SR-W1-USB
Storage
Other Storage Device
mSATA
Panel
LCD Panel
17.3 CHIMEI INNOLUX N173HGE-E11 FHD eDP Panel
Touch Screen
17.3” PCAP Touch
Touch Controller
EETI
External I/O
USB Port
4 x USB3.0
Video Port
1 x HDMI/DP, 1 x DP++
LAN Port
1 x RJ-45 Intel® i211AT Gigabit Ethernet
Wireless LAN Antenna
(Optional)
E199TN00012R x 1
E199TN00013R x 1
Expansion Slots
1 x full size Mini PCI-e support mSATA
Mechanical
Power Type
+12V ~ 24V ATX, ACC-ADP-060N-02R
Power Connector
Type
12V ~ 24VDC Input, Screw type
Dimension
445 (L) x 281 (H) x 45 (D) mm

APC-1733
6 APC-1733 Quick Reference Guide
Weight
4.7kg
Color
White
Fanless
Yes
Reliability
EMC
CE FCC Class A
Dust and Rain Test
IP-65 on Front Panel
Vibration Test
Random Vibration Operation
1 PSD: 0.00454G²/Hz, 1.5 Grms
2 Operation mode
3 Test Frequency : 5-500Hz
4 Test Axis : X,Y and Z axis
5 30 min. per each axis
6 IEC 60068-2-64 Test:Fh
Sine Vibration test (Non-operation)
1 Test Acceleration : 2G
2 Test frequency : 5~500 Hz
3 Sweep：1 Oct/ per one minute. (logarithmic)
4 Test Axis : X,Y and Z axis
5 Test time :30 min. each axis
6 System condition : Non-Operating mode
7. Reference IEC 60068-2-6 Testing procedures
Package vibration test
1. PSD: 0.026G²/Hz , 2.16 Grms
2. Non-operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis
5. 30 min. per each axis
6. IEC 60068-2-64 Test:Fh
Mechanical Shock
Test
Standard, With CF/SSD : 10Grms, IEC 60068-2-27, Half Sine, 11ms
Drop Test
1 One corner , three edges, six faces
2 ISTA 2A, IEC-60068-2-32 (96.5cm) Test:Ed
Operating
Temperature
Normal Temperature: 0°C ~ 35°C (32°F ~ 95°F)
Operating Humidity
10% ~ 90% Relative Humidity, Non-condensing
Storage Temperature
Normal Temperature: -20°C ~ 60°C (14°F ~ 122°F)

Quick Reference Guide
APC-1733 Quick Reference Guide
7
Note: Specifications are subject to change without notice.

APC-1733
8 APC-1733 Quick Reference Guide
1.4 System Overview
1.4.1 Front View
Power on/off
Brightness
Up/down
NFC
Notepad
Browser

Quick Reference Guide
APC-1733 Quick Reference Guide
9
1.4.2 Rear View
Connectors
Label
Function
Note
DC Jack
DC-in power connector
HDMI
HDMI connector
DP
DP connector
DP++
DP++ connector
USB3.0
4 x USB 3.0 connector
LAN
RJ-45 Ethernet

APC-1733
10 APC-1733 Quick Reference Guide
1.5 System Dimensions
(Unit: mm)

Quick Reference Guide
APC-1733 Quick Reference Guide
11
2.Hardware
Configuration
For advanced information, please refer to:
1- EMX-APLP User’s Manual
Note: If you need more information, please visit our website:
http://www.avalue.com.tw
