Avalue Technology LPC-1231 User manual

Part No. E2017L210A0R
LPC-1231/1531
12.1"/15" Intel® Celeron® SoC N3000 family Processor
Fanless Rugged Touch Panel PC
Quick Reference Guide
1st Ed –21 September 2015
Copyright Notice
Copyright 2015 Avalue Technology Inc., ALL RIGHTS RESERVED.

LPC-1231/1531
2 LPC-1231/1531 Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright 2015 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that

Quick Reference Guide
LPC-1231/1531 Quick Reference Guide
3
these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose
failure to perform can be reasonably expected to cause the failure of the life
support device or system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

LPC-1231/1531
4 LPC-1231/1531 Quick Reference Guide
Content
1. Getting Started.................................................................................................5
1.1 Safety Precautions.............................................................................................5
1.2 Packing List.......................................................................................................5
1.3 System Specifications ........................................................................................6
1.4 System Overview...............................................................................................8
1.4.1 Top View........................................................................................................................8
1.4.2 Bottom View...................................................................................................................8
1.5 System Dimensions ......................................................................................... 10
1.5.1 LPC-1231 Front and Rear side ......................................................................................10
1.5.2 LPC-1531 Front and Rear side ......................................................................................11
2. Hardware Configuration................................................................................. 12
2.1 LPC-1231/1531 connector mapping ..................................................................13
2.1.1 Serial port 1/2 connector (COM1/2)................................................................................13
2.2 Installing Hard Disk & Memory (For LPC-1231)...................................................14
2.3 Installing Hard Disk & Memory (For LPC-1531)...................................................16

Quick Reference Guide
LPC-1231/1531 Quick Reference Guide
5
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x LPC-1231/1531 Panel PC
1 x DVD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
—WiFi drivers and utilities
—Touch controller drivers and utilities
—Chipset drivers and utilities
1 x Power Adapter
1 x Stand for Panel PC (optional)

LPC-1231/1531
6 LPC-1231/1531 Quick Reference Guide
1.3 System Specifications
Panel
Model
LPC-1231
LPC-1531
LCD size
12.1", 4:3
15", 4:3
Display type
XGA
Resolution
1024 x 768
Pixel pitch
0.240mm(H) x 0.240mm(V)
0.297mm(H) x 0.297mm(V)
Luminance
600 cd/m²
400 cd/m²
Contrast ratio
700
Viewing angle
70(U), 70(D), 80(L), 80(R)
Response time
16 ms
Backlight
LED
Touch type
5 Wires resistive
Touch Light
transmission
80%
Touch Controller
Onboard USB touch (EETI)
System
Board
EBM-BSW
Processor
Intel® Pentium® /Celeron® processor
I/O Chipset
Nuvoton NPCE388N
System Memory
1 x 204-pin DDR3L 1600MHz up to 8GB
Watchdog Timer
H/W Reset, 1sec. ~ 65535sec./1sec.step
H/W Status Monitor
Monitoring SYSTEM Temperature and Voltage with Auto Throttling Control
Expansion
Expansion
1 x Mini PCIe Support mSATA
1 x Mini PCIe Supports SIM Card
Storage
Storage
1 x 2.5" Drive Bay
Optional onboard eMMC
I/O
USB
4 x USB 3.0
SATA
1 x SATA III
COM Port
2 x RS-232/422/485 (Factory Optional)
Other
1 x HDMI
1 x Knockouts for Antenna Mounting
Display
Chipset
Intel® Braswell SoC integrated Graphics
Supports dual display

Quick Reference Guide
LPC-1231/1531 Quick Reference Guide
7
Resolution
HDMI: Max. resolution 1920 x 1200@ 60Hz
Audio
Chipset
Realtek ALC233 supports 2.1-CH Audio
Audio Interface
Line out
Speaker Output
N/A
2 x 1W
Ethernet
Chipset
2 x Realtek RTL8119
Ethernet Interface
10/100/1000 Base-Tx Gbe compatible
LAN Port
2 x RJ-45
Power Requirement
Power Connector
Lockable DC Jack
Power Requirement
+12V ~ +26V
ACPI
Single Power ATX Support S0, S3, S4, S5
ACPI 3.0 Compliant
Power Type
AT/ATX (ATX is default setting)
Adapter
Input: 100 ~ 240Vac/ 50 ~ 60Hz
Output: 60W Adapter (12V @ 5A Adapter)
Mechanical & Environment
System Fan
Fanless
Construction-Front
Silver Aluminum
Construction-Rear
Black
Dimensions
283 x 222 x 45 mm
Weight
2.84 Kgs
Operating
-10°C ~ 50°C
Storage Temp.
-20°C ~ 60°C
Operating Humidity
0% ~ 90% Relative Humidity, Non-condensing
Vibration Test
With SSD/mSATA : 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 30min/axis
Mounting
Wall / Stand / VESA 75mm x 75mm
Shock Test
With CF/SSD : 10Grms, IEC 60068-2-27, Half Sine, 11ms
Certifications
Certification
Information
CE
FCC Class B
Software Support
OS Information
Win 7, 8.1, 10
Linux
Note: Specificationsare subject to change without notice.

LPC-1231/1531
8 LPC-1231/1531 Quick Reference Guide
1.4 System Overview
1.4.1 Top View LPC-1231
LPC-1531
1.4.2 Bottom View LPC-1231
LPC-1531
Connectors
Label
Function
Note
POWER
Power on button
COM1/2
Serial port 1/2 connector
DB-9 male connector
LINE OUT
Line-out audio jack
USB
4 x USB 3.0 connector
Dock USB
LAN1/2
RJ-45 Ethernet connector 1/2
HDD
HDD indicator

Quick Reference Guide
LPC-1231/1531 Quick Reference Guide
9
PWR
System power indicator
HDMI
HDMI connector
RESET
Reset button
DC IN
DC Power-in connector

LPC-1231/1531
10 LPC-1231/1531 Quick Reference Guide
1.5 System Dimensions
1.5.1 LPC-1231 Front and Rear side
(Unit: mm)

Quick Reference Guide
LPC-1231/1531 Quick Reference Guide
11
1.5.2 LPC-1531 Front and Rear side
(Unit: mm)

LPC-1231/1531
12 LPC-1231/1531 Quick Reference Guide
2.Hardware
Configuration
For advanced information, please refer to:
1- EBM-BSW User’s Manual
Note: If youneed more information, please visit our website:
http://www.avalue.com.tw

Quick Reference Guide
LPC-1231/1531 Quick Reference Guide
13
2.1 LPC-1231/1531 connector mapping
2.1.1 Serial port 1/2 connector (COM1/2)
RS-232
Signal
PIN
PIN
Signal
DCD#
1
6
DSR#
RXD
2
7
RTS#
TXD
3
8
CTS#
DTR#
4
9
RI#
GND
5
RS-422
Signal
PIN
PIN
Signal
422_Tx-
1
6
NC
422_Rx+
2
7
NC
422_Tx+
3
8
NC
422_Rx-
4
9
NC
GND
5
RS-485
Signal
PIN
PIN
Signal
485_Tx-
1
6
NC
NC
2
7
NC
485_Tx+
3
8
NC
NC
4
9
NC
GND
5

LPC-1231/1531
14 LPC-1231/1531 Quick Reference Guide
2.2 Installing Hard Disk & Memory (For LPC-1231)
Step 1. Unfasten 6 screws from the case. Then take off the top chassis.
Step 2. Memory Installation: Insert the SODIMM into the memory socket.
Step 3-1. SATA HDD Installation: By default, the SATA cables had been inserted to the

Quick Reference Guide
LPC-1231/1531 Quick Reference Guide
15
according connectors. Just connect to SATA HDD with the two cables.
Step 3-2. Insert the HDD into the Drive Bay. Remember to place the HDD down to the
bottom exactly in order to screw the device tightly.
Step 4. Place back the chassis with 6 screws locked.
HDD
SATA connector 1
MPCIE connector

LPC-1231/1531
16 LPC-1231/1531 Quick Reference Guide
2.3 Installing Hard Disk & Memory (For LPC-1531)
Step 1. Unfasten 6 screws from the case. Then take off the top chassis.
Step 2. Memory Installation: Insert the SODIMM into the memory socket.
Step 3-1. HDD Installation: Unfasten 2 screwsof the HDD bracket and take it off.

Quick Reference Guide
LPC-1231/1531 Quick Reference Guide
17
Step 3-2. Insert the HDD into the bracket and fasten 4 screws.
Step 3-3. SATA HDD Installation: By default, the SATA cables had been inserted to the
according connectors. Just connect to SATA HDD with the two cables.
SATA connector 1
MPCIE connector

LPC-1231/1531
18 LPC-1231/1531 Quick Reference Guide
Step 3-4. Insert the HDD into the Drive Bay. Remember to place the HDD down to the bottom
exactly in order to screw the device tightly.
Step 4. Place back the chassis with 6 screws locked.
HDD
