Avalue Technology LPC-15P5 User manual

Part No. E201715P5A0R
LPC-15P5
15" Fanless Multifunctional Touch Panel Computer
Quick Reference Guide
1st Ed –09 October 2013
Copyright Notice
Copyright 2013 Avalue Technology Inc., ALL RIGHTS RESERVED.

LPC-15P5
2 LPC-15P5 Quick Reference Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x LPC-15P5 Series Panel PC
1 x DVD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
—WiFi drivers and utilities
—Touch controller drivers and utilities
—Chipset drivers and utilities
1 x Power Adapter
1 x Stand for Panel PC (optional)

Quick Reference Guide
LPC-15P5 Quick Reference Guide
3
1.3 System Specifications
Panel
LCD size
15", 4:3
Display Type
XGA TFT
Resolution
1024 x 768
Pixel pitch
0.297mm(H) x 0.297mm(V)
Luminance
400 cd/m²
Contrast ratio
700
Viewing angle
60(U), 80(D), 80(L), 80(R)
Response time
16 ms
Backlight
LED
Touch Type
5 Wires resistive
Touch Light
transmission
80%
Touch Interface
USB
System
Board
EMX-PNV
CPU
Onboard Intel® Atom™ D525 Dual Core 1.8GHz CPU
System Chipset
Intel ICH8-M
I/O Chip
Winbond W83627DHG
System Memory
One SODIMM socket supports up to 4GB DDR3 SDRAM
SSD
One CF socket supports Type I / II Compact Flash Card.
Hard Driver Bay
One 2.5" SATA HDD
Watchdog Timer
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor
Monitoring system temperature, voltage, and cooling fan status. Auto
throttling control when CPU overheats
Expansion
1 x PCI slot, 1 x Mini PCIe slot
Rear I/O
Serial Port
2 x RS-232 D-sub 9 pin
Ethernet
2 x RJ-45
VGA
1 x VGA D-sub 15 pin
Audio port
1 x Line-out, 1 x Mic-in, 1 x Line-in
USB
4 x USB 2.0
Mouse & K/B
2 x PS/2 KB & MS
Expansion Slots
1 x PCI slot
Display
Chipset
Intel Pineview integrated graphics

LPC-15P5
4 LPC-15P5 Quick Reference Guide
Dual Display
VGA + LVDS
Audio AC97 Codec
Realtek ALC 888 supports 5.1CH Audio
Audio Interface
Connector: Line out, Line in, Mic-in
Ethernet LAN Chip
Intel® 82583V Gigabit LAN
Ethernet Interface
10/100/1000 Base-Tx Fast Ethernet compatible
Mechanical &
Environmental
Color
Front Silver & Rear panel Black
Mounting
Wall/Stand/VESA 75 x 75 & 100 x 100mm
System Power
Requirement
+12V DC Power Input
Power Adapter
Input: 100 ~ 250VAC/ 47 ~ 63Hz
Power Type
ATX
Operating Temp.
0°C ~ 40°C (32°F ~ 104°F)
Storage Temp.
-10°C ~ 60°C (14°F ~ 140°F)
Operating Humidity
5%~90% relative humidity, non-condensing
Dimensions
350mm x 274mm x 88.6mm
Weight
4.2 Kgs

Quick Reference Guide
LPC-15P5 Quick Reference Guide
5
1.4 System Overview
1.4.1 Front View
1.4.2 Rear View
Connectors
Label
Function
Note
POWER
Power on button
VGA
VGA connector
COM1/2
Serial port
DB-9 male connector
Line-out
Line-out audio jack
Line-in
Line-in audio jack
USB
4 x USB 2.0 connector
Dock USB
2Gbe
RJ-45 Ethernet connector
PS/2 Keyboard
Keyboard connector
PS/2 Mouse
Mouse connector
Mic-in
Mic-in audio jack
12V DC-IN
DC Power-in connector

LPC-15P5
6 LPC-15P5 Quick Reference Guide
1.5 System Dimensions

Quick Reference Guide
LPC-15P5 Quick Reference Guide
7
2.Hardware
Configuration
Please refer to EMX-PNV Quick Installation Guide or User’s Manual for
advanced information.
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

LPC-15P5
8 LPC-15P5 Quick Reference Guide
2.1 LPC-15P5 connector mapping
2.1.1 Serial Port 1/2 connector (COM1/2)
Signal
PIN
PIN
Signal
DCD
1
2
RxD
TxD
3
4
DTR
GND
5
6
DSR
RTS
7
8
CTS
RI
9
10
NC
2.1.2 VGA connector (VGA)
PIN
Signal
PIN
Signal
PIN
Signal
1
R
6
GND
11
NC
2
G
7
GND
12
DATA
3
B
8
GND
13
HSYNC
4
NC
9
VCC
14
VSYNC
5
GND
10
GND
15
CLK

Quick Reference Guide
LPC-15P5 Quick Reference Guide
9
2.2 Installing Hard Disk & Memory
Step 1. Unfasten 8 screws from the case to take off the top chassis.

LPC-15P5
10 LPC-15P5 Quick Reference Guide
Step 2-1. HDD Installation: Unfasten 4 screws of the HDD bracket and take it off.
Step 2-2. Insert the HDD into the bracket and fasten 4 screws.

Quick Reference Guide
LPC-15P5 Quick Reference Guide
11
Step 2-3. Insert the HDD back and fasten 4 screws.
Step 3. Memory Installation: Insert the SODIMM into the memory socket.
HDD

LPC-15P5
12 LPC-15P5 Quick Reference Guide
Step 4. Place back the chassis with 8 screws locked.
