Avalue Technology AID-156ST2 User manual

Part No. E20175ST2A0R
AID-156ST2
15.6” Bedside Terminal
Quick Reference Guide
1st Ed –11 May 2015
Copyright Notice
Copyright 2015 Avalue Technology Inc., ALL RIGHTS RESERVED.

AID-156ST2
2 AID-156ST2 Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

Quick Reference Guide
AID-156ST2 Quick Reference Guide
3
Content
1. Getting Started ........................................................................................................4
1.1 Safety Precautions....................................................................................................4
1.2 Packing List...............................................................................................................4
1.3 System Specifications...............................................................................................5
1.4 System Overview......................................................................................................8
1.4.1 I/O View................................................................................................................................... 8
1.5 System Dimensions ..................................................................................................9

AID-156ST2
4 AID-156ST2 Quick Reference Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x Wall Box
1 x Mother Board With Metal Plate
1 x 15.6” Display
1 x 19V Adapter
1 x Power Cord
1 x Handset (option)

Quick Reference Guide
AID-156ST2 Quick Reference Guide
5
1.3 System Specifications
Monitor
Display Screen
Type
15.6” HD TFT (1366 x 768 resolution)
Colour Depth
24 bit
Interface
LVDS
Backlight
LED
Brightness
200 Cd brightness
Brightness Control
20% to 100% user controllable
Touch Screen
USB 5-wire resistive
Or Projected Capacitive touch
Peripherals and Device Interfaces
Headphone Socket
3.5mm stereo jack x 2
Smart Card Reader
USB interface, integrated on bottom of display terminal
Camera
USB interface, integrated on the top of the bezel (optional)
RFID
USB interface, integrated on the back of the display terminal (optional)
Handset & Cradle
Support pre-installed USB handset control with integrated barcode
scanner, extend audio jack, an USB port and hall effect hook on/off
detection. (Optional)
Grab Handle
Support pre-installed grab handle which provides alternative RFID
location. (Optional)
USB Ports
2 x USB 3.0 ports for external peripherals in lower connector recess
Audio Sub System
Amplifier
2.0W RMS per channel speaker/ headphone output
Software speaker/ headphone speaker mute
Speakers
Infinite baffle rear / downward facing
Capacitive Touch Keys (Default)
Power
On / Off (Backlight on/off)
Volume
Increase / Decrease (Optional)
Brightness
Increase / Decrease (Optional)
Wall Box Interfaces To Support
Cable 1
Standard USB 3.0 cable at 3.2M as default cable deployed in the
A-Frame Arm
Cable 2
HDMI 3.2M as default cable deployed in the A-Frame Arm
Cable 3
DC power cable as default cable deployed in the A-Frame Arm
External I/O User Interface
USB Port
2 x USB3.0 for external peripherals in lower connector recess

AID-156ST2
6 AID-156ST2 Quick Reference Guide
Headphone Socket
2 x 3.5mm stereo jack
Mechanical & Environmental
Power Requirement
19V DC In
Power Connector
DC Jack
Operating Temp
0~40˚C (32~104˚F)
Storage Temp
-20~60˚C (-4~140˚F)
Relative Humidity
5~90% Relative Humidity, Non-condensing
Mounting
1. Hinge mount for RemediA-Frame articulated arm (Optional)
2. VESA mount 75mm x 75mm (Optional)
Water Proof
IP65 on Front Panel
Dimension
521.4 x 340.5 x 66.1 mm
Weight
2.82 KG
Thermal
Full System Fan-less
Reliability
EMI Test
With wall box
a. CB/CE: CE Class B, MDD IEC/EN 60601-1
b. North America: FCC Class A, UL 60601-1. c/UL60601-1
c. Australia: C-Tick / A-Tick (IP grade)
Dust and Rain Test
IP65 on Front Panel
Vibration Test
Standard(0.00454G²/Hz,1.5Grms 5~500Hz)

Quick Reference Guide
AID-156ST2 Quick Reference Guide
7
Wall Box System
External Function & Support
Arm support
Support A-Frame arm for the monitor
Ethernet access
Easy access on the chassis for LAN cable from the central router to the
internal M/B
Power Switch
Power button
Heat dissipation
Venting holes on the lower recess
Internal System Configuration
Mother Board
Intel® Atom™ Processor E3800 Family 3.5” SBC.
System Memory
Support Supports Up to 8GB DDR3 1600 SDRAM, default install DDR3
4GB
Storage
320GB, 2.5" SATAII HDD
Cooling
Fan-less heatsink for the M/B
Power supply
Splitter DC-to-DC
Support DC-in x 1 from PSU and DC-out x 3 to
1. The M/B
2. The Extended DC cable from monitor
Power supply
PSU AC-to-DC
19V/90W AC-to-DC power adaptor
Mechanical & Environmental
Power Requirement
Full range 100V~240V AC-in
Operating Temp
0~40˚C (32~104˚F)
Storage Temp
-20~60˚C (-4~140˚F)
Relative Humidity
5~90% Relative Humidity, Non-condensing
Mounting
4-point mounting per chassis design
Dimension
292 mm x 361.7 mm x 89 mm (Excluding the arm post)
Weight
5.6KG
Reliability
EMI Test
With Display
A. CB/CE: CE Class A, MDD IEC/EN 60601-1
B. North America: FCC Class A, UL 60601-1. c/UL60601-1
C. Australia: C-Tick / A-Tick (IP grade)
Vibration Test
Standard(0.00454G²/Hz,1.5Grms 5~500Hz)
Note: Specifications are subject to change without notice.

AID-156ST2
8 AID-156ST2 Quick Reference Guide
1.4 System Overview
1.4.1 I/O View
Connectors
Label
Function
Note
USB
2 x USB 3.0 + USB 2.0 connector
Audio Jack
Audio Jack
Card Reader
Smart Card Reader
Mini USB
Mini USB port

Quick Reference Guide
AID-156ST2 Quick Reference Guide
9
1.5 System Dimensions
(Unit: mm)
