Avalue Technology Rity 10R Series User manual

Part No. E2017R15RA0R
Rity8R/10R/12R/15R
Series
8"/10"/12"/ 15" Android POS
Quick Reference Guide
1st Ed –02 March 2015
Copyright Notice
Copyright 2015 Avalue Technology Inc., ALL RIGHTS RESERVED.

Rity8R/10R/12R/15R Series
2 Rity8R/10R/12R/15R Series Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright 2015 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that

Quick Reference Guide
Rity8R/10R/12R/15R Series Quick Reference Guide
3
these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose
failure to perform can be reasonably expected to cause the failure of the life
support device or system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

Rity8R/10R/12R/15R Series
4 Rity8R/10R/12R/15R Series Quick Reference Guide
Content
1. Getting Started ........................................................................................................5
1.1 Safety Precautions....................................................................................................5
1.2 Packing List...............................................................................................................5
1.3 System Specifications...............................................................................................6
1.4 System Overview....................................................................................................10
1.4.1 Front View.............................................................................................................................. 10
1.4.2 Bottom View........................................................................................................................... 10
1.5 System Dimensions ................................................................................................12
1.5.1 Rity8R Front and Rear side................................................................................................... 12
1.5.2 Rity10R Front and Rear side................................................................................................. 13
1.5.3 Rity12R Front and Rear side................................................................................................. 14
1.5.4 Rity15R Front and Rear side................................................................................................. 15
2. Hardware Configuration .......................................................................................16
2.1 Rity8R/10R/12R/15R Series connector mapping....................................................17
2.1.1 Serial port 1/2 connector (COM1/2)....................................................................................... 17
2.2 Installing Memory & Mini PCI-e device.....................................................................18

Quick Reference Guide
Rity8R/10R/12R/15R Series Quick Reference Guide
5
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x Rity8R/10R/12R/15R Series
1 x 12V Adapter
1 x Power Cord
1 x VESA
Optional MSR (10R/12R/15R)
Optional VFD/ Stand (12R/15R)

Rity8R/10R/12R/15R Series
6 Rity8R/10R/12R/15R Series Quick Reference Guide
1.3 System Specifications
System
Model
Rity8R
Rity10R
Processor
Freescale i.MX 6 Dual Lite
Freescale i.MX 6 Quad Core
System Memory
1GB DDR3 RAM (Dual Lite)
2GB DDR3L RAM (Quad)
Expansion
Expansion
1 x Mini PCI Express slot (Supported WIFI & 3.5G module)
1 x Micro SD slot
1 x SIM card holder onboard
Storage
Storage
4GB eMMC up to 8GB (expansible by Mini SD)
I/O
USB
2 x USB 2.0
1 x OTG
COM Port
2 x RS232
External I/O
Connector
1 x USB Type A Double Deck
2 x RJ45 Connector with Indicate LED
1 x HDMI Connector (Vertical Type)
1 x Mini USB Connector
1 x RJ11 Connector for Cash Drawer
2 x DB9 Male Connector
1 x DC 12V Power Input by Power DC Jack
Internal I/O
Connector
1 x VGA (Quad core only)
3 x USB pin header
1 x 5-wire RES/PCT Touch Interface
1 x Dual Channel 24-bit LVDS
1 x Stereo Speaker-out (4ohm 0.5W x 2)
1 x Mini PCIe x 1 (with USB Signal Only)
1 x SIM Socket
1 x "Front Panel Connector with Power Button & Indicate LED for Power & LAN &
WIFI"
Display

Quick Reference Guide
Rity8R/10R/12R/15R Series Quick Reference Guide
7
Resolution
Max. resolution 1024 x 600
Max. resolution 1366 x 768
Multiple Display
LVDS + VGA (Only i.MX6 Quad core can be achieved)
LVDS + HDMI
Audio
Chipset
Wolfson WM8962
Audio Interface
2P Pin Header x 2 (Speaker-out R & L)
(Driver Per Channel Max 2W)
Ethernet
Chipset
LAN 1: From i.MX6 MAC, PHY is Micrel KSZ9031RNX
LAN 2: Intel 82574L by PCIe Interface (Optional)
Ethernet
Interface
RJ45 Connectors for G LAN
Mechanical & Environmental
Power
Requirement
DC 12 ~ 24V Power Input
Power Type
2.5mm DC Jack
Operating Temp.
0°C ~ 40°C
Storage Temp.
-10°C ~ 60°C
Operating
Humidity
0% ~ 90% Relative Humidity, Non-condensing
Dimension
(W x D x H)
231.7mm x 149.5mm x 42mm
260mm x 178mm x 42mm
Weight
1.48 Kgs
1.8 Kgs
Certifications
Certification
Information
CE Class B
FCC Class B
VCCI Class B
Software Support
OS Information
Android 4.4.2
Ubuntu 12.04
Yocto 1.5.1

Rity8R/10R/12R/15R Series
8 Rity8R/10R/12R/15R Series Quick Reference Guide
System
Model
Rity12R
Rity15R
Processor
Freescale i.MX 6 Dual Lite
Freescale i.MX 6 Quad Core
System Memory
1GB DDR3 RAM (Dual Lite)
2GB DDR3L RAM (Quad)
Expansion
Expansion
1 x Mini PCI Express slot (Supported WIFI & 3.5G module)
1 x Micro SD slot
1 x SIM card holder onboard
Storage
Storage
4GB eMMC up to 8GB (expansible by Mini SD)
I/O
USB
2 x USB 2.0
1 x OTG
COM Port
2 x RS232
External I/O
Connector
1 x USB Type A Double Deck
2 x RJ45 Connector with Indicate LED
1 x HDMI Connector (Vertical Type)
1 x Mini USB Connector
1 x RJ11 Connector for Cash Drawer
2 x DB9 Male Connector
1 x DC 12V Power Input by Power DC Jack
Internal I/O
Connector
1 x VGA (Quad core only)
3 x USB pin header
1 x 5-wire RES/PCT Touch Interface
1 x Dual Channel 24-bit LVDS
1 x Stereo Speaker-out (4ohm 0.5W x 2)
1 x Mini PCIe x 1 (with USB Signal Only)
1 x SIM Socket
1 x "Front Panel Connector with Power Button & Indicate LED for Power & LAN &
WIFI"
Display
Resolution
Max. resolution 1024 x 768
Multiple Display
LVDS + VGA (Only i.MX6 Quad core can be achieved)
LVDS + HDMI

Quick Reference Guide
Rity8R/10R/12R/15R Series Quick Reference Guide
9
Audio
Chipset
Wolfson WM8962
Audio Interface
2P Pin Header x 2 (Speaker-out R & L)
(Driver Per Channel Max 2W)
Ethernet
Chipset
LAN 1: From i.MX6 MAC, PHY is Micrel KSZ9031RNX
LAN 2: Intel 82574L by PCIe Interface (Optional)
Ethernet
Interface
RJ45 Connectors for G LAN
Mechanical & Environmental
Power
Requirement
DC 12 ~ 24V Power Input
Power Type
2.5mm DC Jack
Operating Temp.
0°C ~ 40°C
Storage Temp.
-10°C ~ 60°C
Operating
Humidity
0% ~ 90% Relative Humidity, Non-condensing
Dimension
(W x D x H)
322mm x 250mm x 47mm
362.1mm x 290.08mm x 51mm
Weight
2.35 Kgs
3.39 Kgs
Certifications
Certification
Information
CE Class B
FCC Class B
VCCI Class B
Software Support
OS Information
Android 4.4.2
Ubuntu 12.04
Yocto 1.5.1
Note: Specifications are subject to change without notice.

Rity8R/10R/12R/15R Series
10 Rity8R/10R/12R/15R Series Quick Reference Guide
1.4 System Overview
1.4.1 Front View
1.4.2 Bottom View Rity8R
Rity10R
Rity12R
Power Button

Quick Reference Guide
Rity8R/10R/12R/15R Series Quick Reference Guide
11
Rity15R
Connectors
Label
Function
Note
DC-IN
DC Power-in connector
C/D
Cash Drawer connector
USB
2 x USB2.0 connectors
OTG
Mini USB connector
HDMI
HDMI connector
LAN
2 x RJ45 connectors
COM1/2
Serial port 1/2 connector
DB-9 male connector

Rity8R/10R/12R/15R Series
12 Rity8R/10R/12R/15R Series Quick Reference Guide
1.5 System Dimensions
1.5.1 Rity8R Front and Rear side
(Unit: mm)

Quick Reference Guide
Rity8R/10R/12R/15R Series Quick Reference Guide
13
1.5.2 Rity10R Front and Rear side
(Unit: mm)

Rity8R/10R/12R/15R Series
14 Rity8R/10R/12R/15R Series Quick Reference Guide
1.5.3 Rity12R Front and Rear side
(Unit: mm)

Quick Reference Guide
Rity8R/10R/12R/15R Series Quick Reference Guide
15
1.5.4 Rity15R Front and Rear side
(Unit: mm)

Rity8R/10R/12R/15R Series
16 Rity8R/10R/12R/15R Series Quick Reference Guide
2.Hardware
Configuration
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

Quick Reference Guide
Rity8R/10R/12R/15R Series Quick Reference Guide
17
2.1 Rity8R/10R/12R/15R Series connector mapping
2.1.1 Serial port 1/2 connector (COM1/2)
Signal
PIN
PIN
Signal
DCD
1
6
DSR
RXD
2
7
RTS
TXD
3
8
CTS
DTR
4
9
RI
GND
5

Rity8R/10R/12R/15R Series
18 Rity8R/10R/12R/15R Series Quick Reference Guide
2.2 Installing Memory & Mini PCI-e device
Step 1. Unfasten 2 screws from the case. Then take off the top chassis.
Step 2. Insert the SIM card into the socket.

Quick Reference Guide
Rity8R/10R/12R/15R Series Quick Reference Guide
19
Step 3. Unfasten 2 screws from the case. Then take off the top chassis.
Step 4. Insert the Mini PCI-e device into the socket and fasten 2 screws.
Step 5. Re-assemble your system back through previous steps to complete the installation.
