Avalue Technology RITY102 User manual

Part No. E2017RIT2A1R
RITY102
10” ALL IN ONE Fanless POS Terminal
Quick Reference Guide
2nd Ed –12 June 2017
Copyright Notice
Copyright 20174 Avalue Technology Inc., ALL RIGHTS RESERVED.

RITY102
2 RITY102 Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

Quick Reference Guide
RITY102 Quick Reference Guide
3
Content
1. Getting Started ........................................................................................................4
1.1 Safety Precautions....................................................................................................4
1.2 Packing List...............................................................................................................4
1.3 System Specifications...............................................................................................5
1.4 System Overview......................................................................................................7
1.4.1 Rear View................................................................................................................................ 7
1.5 System Dimensions ..................................................................................................8
2. Hardware Configuration .........................................................................................9
2.1 RITY102 connector mapping ..................................................................................10
2.2.1 External Serial Port 1 connector (COM1).............................................................................. 10
2.2.2 External Serial Port 2 connector (COM2).............................................................................. 11

RITY102
4 RITY102 Quick Reference Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x RITY Series Panel PC
1 x Power Adapter
1 x Power Cord
1 x VESA Kits

Quick Reference Guide
RITY102 Quick Reference Guide
5
1.3 System Specifications
LCD Data
LCD size
10.1"
Display Type
WSVGA TFT
Resolution
1024 x 600
Color
262K color by 6 bit RGB signal
Luminance
350 cd/m²
Contrast ratio
500
Viewing angle
70(U), 70(D), 70(L), 70(R)
Backlight
LED
Touch Data
Type
5 Wires resistive / PCT
Light
transmission
RES 75% / PCT 90%
Interface
RES RS232 / PCT USB
CPU
Intel® Celeron Processor J1900 4-Core 2GHz (D, 10W)
Intel® Celeron Processor N2910 4-Core 1.86GHz (M, SDP, 4.5W/TDP,
7.5W)
Intel® Atom Processor E3845 4-Core 1.91GHz (I, 10W)
Cooling method
Fanless
System chipset
Intel® Valleyview SoC integrated
Memory
1 x 204-pin SODIMM Socket Up to 8GB DDR3L 1066/1333 SDRAM
Rear panel I/O
2 x RS-232
COM1 & 2 supported RS422/485. Setting by BIOS
All Pin9 supported RI / 5V / 12V. Setting by BIOS
2 x LAN ( Intel I210AT GbE controller)
3 x USB 3.0, 1 x USB 2.0
1 x RJ11 for Cash Drawer, Supported DC12V / 24V 1A out. Setting by BIOS
HDMI
1 x Power minidin 4P for DC in w/ lock type
HDD
SATA SLim
SSD
One mSATA socket
Speaker
2W, 8Ω
Expansion
mPCIe socket w/ SIM holder for 3G application
WIFI
Optional USB WIFI 802.11 b,g (Will occupy one USB pin header)
Color
Default Black
Optional White

RITY102
6 RITY102 Quick Reference Guide
Mounting
Wall/Stand/VESA 75 mm x 75 mm
Dimensions
260 mm X 178 mm X 42 mm
Weight
TBD
Operating
temperature
0°C to 35°C.
Storage
temperature
-10°C to 60°C.
Relative humidity
10% to 95% @ 40℃( Non Condensing )
Power input
+24VDC in 90W, optional 120W & 130W for 24V DC out SKU.

Quick Reference Guide
RITY102 Quick Reference Guide
7
1.4 System Overview
1.4.1 Rear View
Connectors
Label
Function
Note
COM1/2
External Serial Port 1/2 connector
DB-9 male connector
COM3/VGA
External Serial Port 3 connector/ VGA
connector
C/D
Cash Drawer connector
USB
3 x USB 3.0 connector
1 x USB 2.0 connector
LAN
2 x RJ-45 Ethernet connector
HDMI
HDMI connector
DC-IN
DC Power-in connector

RITY102
8 RITY102 Quick Reference Guide
1.5 System Dimensions
(Unit: mm)

Quick Reference Guide
RITY102 Quick Reference Guide
9
2.Hardware
Configuration
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

RITY102
10 RITY102 Quick Reference Guide
2.1 RITY102 connector mapping
2.2.1 External Serial Port 1 connector (COM1)
In RS-232 Mode
Signal
PIN
PIN
Signal
DCDA#
1
2
RXDA
TXDA
3
4
DTRA#
GND
5
6
DSRA#
RTSA#
7
8
CTSA#
RIA#
9
In RS-422 Mode
Signal
PIN
PIN
Signal
TxD1-
1
2
TxD1+
RxD1+
3
4
RxD1-
GND
5
6
NC
NC
7
8
NC
NC
9
In RS-485 Mode
Signal
PIN
PIN
Signal
DATA1-
1
2
DATA1+
NC
3
4
NC
GND
5
6
NC
NC
7
8
NC
NC
9

Quick Reference Guide
RITY102 Quick Reference Guide
11
2.2.2 External Serial Port 2 connector (COM2)
In RS-232 Mode
Signal
PIN
PIN
Signal
DCDB#
1
2
RXDB
TXDB
3
4
DTRB#
GND
5
6
DSRB#
RTSB#
7
8
CTSB#
RIB#
9
In RS-422 Mode
Signal
PIN
PIN
Signal
TxD1-
1
2
TxD1+
RxD1+
3
4
RxD1-
GND
5
6
NC
NC
7
8
NC
NC
9
In RS-485 Mode
Signal
PIN
PIN
Signal
DATA1-
1
2
DATA1+
NC
3
4
NC
GND
5
6
NC
NC
7
8
NC
NC
9
