Avantco A34893 User manual

Side shift adapter
2018 1
Operator's Manual for Attachment
Side shift adapter
Side shift
Product number:
400 mm, to the right
A34893
600 mm, to the right
A37097
600 mm, to the left
A37166
English
A437031 2018 1 EN 2010-
www.avanttecno.com

Side shift adapter 2018 1

Side shift adapter 2018 1
CONTENTS
1. FOREWORD ............................................................................................................................................4
Warning symbols used in this manual ............................................................................................................................... 5
2. DESIGNED PURPOSE OF USE.............................................................................................................6
3. SAFETY INSTRUCTIONS FOR USING THE ATTACHMENT........................................................7
4. TECHNICAL SPECIFICATIONS ..........................................................................................................10
5. ASSEMBLING THE ATTACHMENT....................................................................................................11
5.1 Mounting attachment to the side shift adapter............................................................................................... 13
6. INSTRUCTIONS FOR USE....................................................................................................................14
6.1 Checks before use................................................................................................................................................. 14
6.2 Operating the side shift adapter......................................................................................................................... 16
6.2.1 Horizontal adjustment.................................................................................................................................. 16
6.2.2 Maximum load................................................................................................................................................ 17
6.3 Working on uneven ground................................................................................................................................ 17
6.4 Transport position ................................................................................................................................................ 18
6.5 Uncoupling and storage........................................................................................................................................ 18
7. MAINTENANCE AND SERVICE ..........................................................................................................19
7.1 Cleaning the attachment ...................................................................................................................................... 19
7.2 Inspection of metal structures............................................................................................................................ 19
8. WARRANTY TERMS..............................................................................................................................20

4 (22)
1. Foreword
Avant Tecno Oy would like to thank you for your purchase of this attachment for your Avant loader. It has
been designed and manufactured based on years of experience on product development and manufacturing.
By familiarising yourself with this manual and following the instructions, you ascertain your safety and ensure
the reliable operation and long service life of the equipment. Read the instructions carefully before starting to
use the equipment or performing maintenance.
The purpose of this manual is to help you to:
operate the equipment in a safe and efficient manner
observe and prevent any hazardous situations
keep the equipment intact and ensure a long service life
With these instructions, even an inexperienced user can use the attachment and loader safely. The manual
includes important instructions for experienced AVANT operators as well. Ensure that all persons using the
loader have received proper guidance and familiarised themselves with the manual of the loader, each
attachment that are used, and all safety instructions before using the equipment. Using the equipment for
other purposes or use in any other way than described in this manual is prohibited. Keep this manual at hand
throughout the service life of the equipment. If you sell or transfer the equipment, be sure to hand over this
manual to the new owner. If the manual is lost or damaged, you can request a new one from your Avant
dealer or from the manufacturer.
In addition to the safety instructions included in this manual, you must observe all occupational safety
regulations, local laws, and other regulations concerning the use of the equipment. Particularly the regulations
concerning the use of the equipment on public road areas must be observed. Contact your Avant dealer for
more information about local requirements before you operate the loader on road areas.
Contact your local AVANT dealer for any questions, service, spare parts or about any problems that may
occur with the operation of your machine.
This manual contains the original instructions in English. Due to continuous product development some of the
details shown in this manual may differ from your equipment. Pictures may also depict optional equipment or
features that are not currently available. We reserve the right to change the contents of the manual without
notification. Copyright © 2019 Avant Tecno Oy. All rights reserved.

5 (22)
.
Warning symbols used in this manual
The following warning symbols are used throughout this manual. They indicate factors that must be taken into
account to reduce the risk of personal injury or damage to property:
WARNING: SAFETY ALERT SYMBOL
This symbol means: “Warning, be alert! Your safety is involved!”
Carefully read the message that follows, it warns of an immediate hazard
that could cause serious personal injury.
The safety alert symbol by itself and with related safety statement
indicates important safety messages throughout this Manual. It is used to
draw attention to instructions involving your personal safety or the safety
of others. When you see this symbol, be alert, your safety is involved,
carefully read the message that follows, and inform other operators.
DANGER:
This signal word indicates a hazardous situation which, if not avoided, will cause
death or serious injury.
WARNING:
This signal word indicates a potentially hazardous situation which, if not avoided,
could cause serious injury or death.
CAUTION:
This signal word is used when minor injury could result if the instructions are not
followed properly.
This signal word indicates information about the correct operation and maintenance
of the equipment.
Failure to obse
rve the instructions accompanying the symbol can lead to equipment
breakdown or other property damage.

6 (22)
2. Designed purpose of use
The AVANT Side shift adapter is an attachment suitable for use with AVANT multi purpose loaders shown in
Table 1. This adapter is intended for applications where an attachment needs to be shifted horizontally in
order to get the job done.
The Side shift adapter is mounted to the loader like other attachments, between the quick coupling plate and
the attachment that is going to be used. The side shift adapter is a rigid adapter plate which moves the
attachment 40 cm or 60 cm to the right or to the left side depending on the model of the adapter. The 60 cm
side shift adapter is equipped with two quick coupling brackets which make it possible to quickly position the
attachment either to the side shift position or in the middle position.
It is recommended to use the hydraulic side shift adapter only when counterweights are installed on the
loader. When using the side shift adapter with a heavy attachment, the loader may tip over as a result of
displacement of the centre of gravity. Using a side shift adapter decreases the lateral stability of the loader,
and also decrease the tipping load of the loader. Because of this the adapter should only be used when side
shift is needed. In other use the adapter must be removed from the loader. The Side side shift adapter is not
designed for any other use than what is specified in this manual and must not be used for any other purposes
than intended.
The attachment has been designed to require as little maintenance as possible. The operator can perform
regular maintenance tasks. All repair work can’t be performed by the operator, and demanding repair and
maintenance operations are to be left for professional maintenance. All maintenance work must be done using
proper safety equipment. Spare parts must be identical with original specifications, which can be ensured by
using only original spare parts. A separate spare parts catalogue may be available, consult your Avant dealer.
Familiarise yourself with the manual's instructions regarding service and maintenance. Please contact your
AVANT retailer if you have additional questions about the operation or maintenance of the equipment, or if
you require spare parts or maintenance services.
Table 1 - Side shift adapter - Compatibility with Avant loaders
Model
220
225
225LPG
313S
320S
420
423
520
523
R20
525LPG
R28
528
530
630
R35
635
640
745
750
755i
760i
e5
e6
A34893 •••••••
A37097 •••••••
A37166 •••••••

7 (22)
3. Safety instructions for using the attachment
Please bear in mind that safety is the result of several factors. The loader-attachment combination is highly
powerful and improper or careless use or maintenance may cause serious personal injury or property
damage. Due to this, all operators must carefully familiarise themselves about correct use and the operator's
manuals of both the loader and the attachment before starting operation. Do not use the attachment if you
have not completely familiarised yourself with its operation and the related hazards.
DANGER
Misuse, careless use, or using an attachment that is in poor condition, may
cause risk of serious injuries. Familiarise yourself with the co
ntrols of the loader,
correct coupling procedure, and the correct way to operate the attachment at a safe
area. Study especially how to stop the equipment in a safe manner. Read all safety
precautions carefully.
Read all safety instructions carefully before handling the attachment
WARNING
When attaching an attachment to the loader, ensure that the locking pins of the
loader's quick attach plate are in the lower position and that they have locked
the attachment to the loader. Never lift or move an unlocked attachment.

Make sure attachment is securely connected to the side shift adapter. Always refer
also to the operator's manual of the separate attachment.

The side shift adapter and any attachment coupled to it are designed to be used by
one operator at
a time. Do not let others near the danger area of the equipment when
it is in use.
Risk of dropping of load or parts of attachments - Make sure load is secured on
the attachment, and that the attachment is set up properly. Make sure that a load
will no
t fall uncontrollably off from the attachment. Secure moving parts of the
attachment before using them with a tilt adapter. For example, if using pallet forks,
make sure that the fork arm retainer bolts are fixed so that fork arms will not slide off
from the frame of the pallet forks.
Sudden movements can cause the loader to tip over - Operate the controls of
the loader in a slow and calm manner.
Be careful when lifting load to high level or
lifting load from high. Avoid sudden changes in speed or direct
ion to maintain
balance of the loader especially when handling heavy loads. Drive slowly and
carefully especially on inclined terrain or slippery surfaces.
Risk of tipping over - Keep the loader articulation in straight position when
handling heavy loads. When turning the articulation, the loader may tilt forward
Tipping over hazard - Make sure that overhead clearance is sufficient. Hitting an
overhead obstacle may cause the loader to tip over. Keep a safe distance from
electric cables, lamps, or othe
r electric systems; hitting live parts may cause electric
shock.
Never leave the driver’s seat when the auxiliary hydraulics control lever is locked on.
The attachment mounted on the side shift adapter may move, if the auxiliary
hydraulics control leve
r of the loader is locked on and there is a horizontally uneven
load on the attachment. Watch out for crushing of limbs when going near the
attachment.

8 (22)
Do not leave the driver’s seat when the loader boom is lifted. Going under a raised
attachment or lo
ader boom is dangerous. Always remember that the boom may lower
due to loss of stability, mechanical fault, or if another person operates the controls of
the loader.
Use the attachment only for its intended use and only with original tools and spare
parts.
When unlocking and dismounting the attachment off from the loader, ensure that it is
secured against accidental movement. To secure the attachment from tipping over
lower it firmly on the ground and disconnect only on level surface. Ensure the
attachment is properly supported during storage. Never climb on the attachment.
Make sure that the attachment is properly supported before performing any
inspections, maintenance, or adjustments. If necessary, secure the attachment with
suitable lifting equipment, or lower it on firm blocks of wood, for example.
Shut down the loader and place the attachment to a safe position as shown in Safe
stopping procedure before any cleaning, maintenance, or adjustments.
Pay attention to the surroundings and any other persons and machines moving in the
vicinity. Pay attention to the contours of the terrain and other hazards, such as
branches and trees that can reach to the driver's area, loose rocks, and slippery
surfaces.
Make sure to use only an attachment that is in good condition. Do not modify the
attachment in any way that could affect its safety.
Use the attachment only for its intended purpose. Other use may create unnecessary
safety risks, and the equipment may get damaged.
Make sure that the loader is equipped with necessary safety components, and that
they are in working condition. Seat belt must be used. If there are specific hazards
related to the operating area, use appropriate safety equipment.
Also read the safety instructions and correct use of the loader from the operator's
manual of the loader.
DANGER
Wrong, improper, or careless use of the attachment causes serious risk of severe
injuries or death.
Familiarise yourself with the controls of the loader in a safe area. Pay
particula
r attention to the safe stopping of the attachment and the loader; follow the safe
stopping procedure shown in this manual before leaving the driver's seat.
WARNING

9 (22)
WARNING
Risk of crushing -
Never allow anyone to get under a
lifted attachment or loader boom.
Keep in mind that the
loader boom can be lowered or tilted even if the engine has
been shut down (crushing hazard). The loader is not intended
to be left to keep a load elevated for longer periods. Always
lower the attachment to a safe position before l
eaving the
driver's seat.
WARNING
Risk of crushing - Avoid tipping over the attachment.
Make sure the load on the
attachment or the moving parts of an attachment will not fall or swing when shifting the
attachment with the side shift adapter.
Remember to wear proper personal protective equipment:

The noise level at the driver's seat may exceed 85 dB(A) depending on loader
model and operating cycle. Extended exposure to loud noise can cause
hearing impairment. Wear hearing protection while working with the loader.
Wear protective gloves.
Wear safety boots whenever working with the loader.
. ..
Safe stopping of the attachment, before going near the attachment:
WARNING
Always stop the attachment following safe stopping procedu
re before leaving
the driver's seat.
Safe stopping procedure prevents all unintentional movements of
the attachment. Note that the loader boom can move down even if the engine of the
loader is turned off. Safe stopping procedure:
Lower the boom and the attachment on the ground.
Shut down the loader engine and lock the parking brake.

Release residual pressure from the hydraulic system; move all hydraulic control
levers to their extreme positions a couple of times.
Prevent starting of the machine, remove ignition key.

10 (22)
4. Technical specifications
Table 2 – Side shift adapter - Specifications
Product number A34893 A37097 A37166
Width: 930 mm 1150 mm 1150 mm
Weight: 37 kg 46 kg 46 kg
Height: 265 mm
Attachment displacement 110 mm
Side shift: 400 mm to the right 600 mm to the right 600 mm to the left
Suitable AVANT loader: See Table 1
. ..
. ..
Table 3 - Side shift adapter - Main components
1
Quick coupling plate for coupling the adapter to
an Avant loader
Side shift adapters A37097 and A37166 are
equipped with two quick coupling plates
2
Attachment coupling plate to couple an
attachment to the side shift adapter
3
Locking pins to lock an attachment to the side
shift adapter
4 Attachment identification plate
A421683 / A421834

11 (22)
5. Assembling the attachment
Attaching the attachment to the loader is quick and easy, but it must be done carefully. The attachment is
mounted to the loader boom by using the quick attach plate on the loader boom and the counterpart on the
attachment.
If the attachment is not locked to the loader, it may detach from the loader and cause a hazardous situation.
The loader must not be driven and the boom must never be lifted when the attachment has not been locked.
To prevent hazardous situations, always follow the coupling procedure shown below. Also remember the
safety instructions shown in this manual. The attachment is mounted to the loader as follows:
WARNING
Crushing risk - Make sure that an unlocked attachment will not move or fall over.
Do not stay in the area betw
een the attachment and the loader. Mount the attachment
only on level surface.
Never move or lift an attachment that has not been locked.
Avant quick coupling system:
Step 1:
Lift the quick attach plate locking pins up and turn them backwards into t
he slot
so that they are locked in the upper position.

If your loader is equipped with a hydraulic attachment locking system, see
additional instructions about the use of the locking system from the relevant
manuals.
Ensure that the hydraulic hoses and the
electric harness are not in the way
during installation.
Step 2:
Turn the quick attach plate hydraulically to an obliquely forward position.

Drive the loader onto the attachment. If your loader is equipped with a
telescopic boom, you can utilise this.

Align the upper pins of the loader’s quick coupling plate so that they are under
the corresponding brackets of the attachment.
Step 3:
Lift the boom slightly –
pull the boom control lever backward to raise the
attachment off the ground.
Turn the b
oom control lever left to turn the bottom section of the quick attach
plate onto the attachment.
Lock the locking pins manually or lock the hydraulic locking.
Always check the locking of both locking pins.

12 (22)
WARNING
Risk of crushing - Avoid tipping over the attachment.
Excessive tilting or lifting of an
unlocked attachment increases the risk of tipping the attachment over. Do not use the
automatic locking of the locking pins when the attachment is lifted more than one meter
from the ground. If the lock
ing pins do not return to the normal position when tilting, do
not tilt or raise the attachment any more. Lower the attachment on the ground and
secure the locking manually.
WARNING
Risk of falling objects -
Prevent dropping of
attachment.
An attach
ment that has not been completely locked to the
loader may fall on the boom or towards the operator, or
fall under the loader during driving, causing loss of
control of the loader. Never move or lift an attachment
that has not been locked. Before moving or
lifting the
attachment, make sure that the locking pins are in the
lower position and come through the fasteners on the
attachment on both sides.
WARNING
Make sure the loader is compatible with the attachment.
Stability of the loader,
poss
ible overload of the attachment, and compatibility of loader control systems must be
ensured in addition to mechanical compatibility of the attachment. If you use the
attachment with a loader that is not fit to be used with the attachment model you have,
r
isks include tipping over, damage to attachment due to overload, and risks related to
uncontrolled motion of attachment and its parts. If your loader is not listed in Table 1 on
page , ask your Avant dealer before using this attachment.

13 (22)
.
5.1 Mounting attachment to the side shift adapter
Attaching an attachment to the side shift adapter is easiest, when the side shift adapter is first mounted on the
quick attach plate of the loader. After this the attachment can be mounted to the side shift adapter in a similar
way as without the side shift adapter. Ensure that all four locking pins are in the lower position and they have
locked securely.

14 (22)
6. Instructions for use
Check the attachment and the operating environment once more before starting to work, and that all obstacles
have been removed from the operating area. Quick inspection of the equipment and the operating area before
use are parts of ensuring safety and the best performance of the equipment.
WARNING
Risk of crushing - Never allow anyone to get
under a
lifted attachment or loader boom.
Keep in mind that the
loader boom can be lowered or tilted even if the engine has
been shut down (crushing hazard). The loader is not intended
to be left to keep a load elevated for longer periods. Always
lower the
attachment to a safe position before leaving the
driver's seat.
WARNING
Risk of tipping over - Avoid overload.
Loader can tip over
when handling too heavy loads, or because of dynamic
movements caused by driving with and handling of a heavy
load.
Do not extend the telescopic boom when the load
approaches the lifting capacity of the loader, or when the
loader boom is in horizontal position. When you notice that
the rear wheels of the loader are about to lift from the ground,
or if the load indicator of the loader (if fitted) signals:
Lower the load calmly and retract the telescopic boom
Avoid sudden changes in speed or direction whenever load is lifted
Use additional counterweights as needed
6.1 Checks before use
Drive carefully on uneven terrain and note the effect of heavy load at the front and side of the loader to
the stability and handling of the loader.
Practice the use of the attachment and the controls of the loader in a safe area. If you are unfamiliar
with the particular loader model, it is recommended to practice its use without any attachments.
Check the attachment you are planning to use with side shift adapter according to separate specific
instructions before operating the attachment. Make sure that there are no broken components.
Use only when all pins are locked and secured in place. The locking of the side shift adapter and the
attachment includes a total of four locking pins. Ensure that all four locking pins have locked securely.
When mounting an attachment onto the side shift adapter, note that the locking pins must always be
secured manually.

15 (22)
Ensure that bystanders are at a safe distance when operating the equipment. Do not let anyone to
enter danger area of the boom or to stay directly in front of the loader. Also make sure that it is safe to
reverse with the loader. Never assume that bystanders will remain where you last saw them;
especially children are often attracted to the moving equipment.
Check the general condition of the attachment and the loader, and check for possible hydraulic oil
leaks. The attachment must not be used, if there is a fault in the hydraulic system of the loader or the
attachment. Refer to Chapter 7 for maintenance instructions.
Operate the attachment and the controls of the loader only when seated on the driver’s seat. Ensure
that the loader and the attachment are used in a safe manner and as intended. Do not allow children
to operate the equipment.
Never operate the loader or attachments while under the influence of alcohol, drugs, medication that
may impair judgement or cause drowsiness, or if not otherwise medically fit to operate the equipment.
Remember correct working methods and avoid leaving the driver’s seat unnecessarily.
WARNING
Avoid running over persons - Check surroundings before driving.
Always look in the
direction the loader is moving. Before reversing, always ensure that bystanders,
especially children, are at a safe distance to avoid back-over accidents.
WARNING
Risk of tipping over - Avoid overload and keep heavy load close to the loader. Keep
loads close to the ground whenever driving, especially during turns and uneven
terrain.
Pay attention that a heavy load or long distance between the loader and the
centre of gravity of the load will affect the balance and handling of
the loader. The use of
additional counterweights is recommended especially when operating smaller loader
models. For 200-
series loader the wheel weights are recommended. With heavy loads,
the telescopic boom must be kept retracted while moving with the loa
der. Always wear
seat belt.

16 (22)
.
6.2 Operating the side shift adapter
The figure below shows the shifting to right of pallet forks attachment with the Side shift adapter A37097.
6.2.1 Horizontal adjustment
It is possible to set the 60 cm side shift adapter so, that the attachment is 60 cm on the side, or in the center
without side shift. These side shift adapters are equipped with two quick attach brackets as shown in the
figure below.
. ..

17 (22)
6.2.2 Maximum load
Maximum load for the Side shift adapter is 800 kg, and the Side shift adapter must be removed when handling
heavier pallets or large buckets. Always refer to the operator's manual of the loader for the safe load of the
loader in different operating conditions.
Use the Side shift adapter only when needed for shifting an attachment sideways. The side shift adapter may
get damaged, if it is used for other than lifting or handling of loads.
WARNING
Risk of tipping over - Use the side shift adapter only when needed.
The side shift
adapter reduces the tip
ping load of the loader by displacing the centre of gravity further
away from the loader. Take the reduction of the tipping load of the loader into account
when handling heavy loads: See the operator's manual of the loader for information about
the effect of distance of the load to the tipping load of the loader.
DANGER
Risk of serious personal injuries - Never leave the equipment running unattended.
Start the attachment only when it is ready to be used. Do not go near the equipment
when another person operates the controls of the loader.
6.3 Working on uneven ground
Extra caution is needed when using the equipment on inclined terrains and slopes. Drive slowly especially on
inclined, uneven, or slippery surfaces, and avoid sudden changes in speed or direction. Operate the controls
of the loader with careful and smooth movements. Watch out for ditches, holes on the ground, and other
obstacles, as hitting an obstacle may cause the loader to tip over.
Maximum lifting capacity can not be achieved on inclined terrain. On horizontally tilted terrain the load must
not be lifted high. The loader frame articulation should be kept straight when lifting heavy loads; turning the
load during lifting operation will affect the stability of the loader and may lead to overturning of the machine.

18 (22)
.
6.4 Transport position
Keep the loader stable. Always transport the
attachment as low and close to the ground as
possible.
If the side shift adapter can be coupled to the loader
so that the attachment is in the middle position,
a
lways set it in this position before driving over longer
distances.
Drive slow when the attachment is in side shift
position.
6.5 Uncoupling and storage
Uncouple and store the attachment on level ground. The best way to store the attachment is a place where it
is protected from direct sunlight, rain, and extreme temperatures.
Avoid leaving the attachment laying directly on the ground. Place it on blocks of wood or on a pallet, for
example.
Make sure that the attachment is secured against all movements during storage.
Never climb on the attachment.
CAUTION
Risk of impact and crushing of feet and legs -
Side shift adapter may cause the
attachment to tip over when coupled to an attachment during storage.
The side shift
adapter should not be uncoupled
from the loader when an attachment is coupled to it. All
light weight attachments, such as buckets and pallet forks, must be uncoupled from the
side shift adapter to ensure the stability of the attachment during storage.

19 (22)
7. Maintenance and Service
The attachment has been designed to be as maintenance free as possible. Continuous maintenance includes
regular cleaning and lubrication, and monitoring the condition of the attachment. Because of the crushing
hazard caused by lowering machine parts, all maintenance work must be done when moving parts have been
lowered down completely and the attachment is lowered flat against the ground.
DANGER
Risk of crushing - Never go under lifted attachment.
Make sure the attachment is
properly supported during all mainte
nance work. Never go under a lifted attachment. The
loader boom may lower unexpectedly during maintenance causing serious injuries from
crushing or impact even when the loader engine is not running. All maintenance and
service must be performed when the at
tachment has been lowered down to a safe
position.
7.1 Cleaning the attachment
Clean the attachment regularly to prevent accumulation of dirt which is more difficult to remove. A pressure
washer and mild detergent can be used for cleaning. Do not use strong solvents, and do not spray directly at
the hydraulic components, or at the labels on the attachment.
7.2 Inspection of metal structures
Also the metal structures of the attachment must be inspected regularly. Check visually for damages and
inspect the quick attach brackets and their surrounding area carefully. The attachment must not be used if it is
deformed, cracked, or torn.
Welding repairs are only allowed to be carried out by professional welders. When welding, only methods and
additives suited for steel used in attachment must be used. For more information about repairs contact your
nearest service point.

20 (22)
.
8. Warranty terms
Avant Tecno Oy grants a warranty of one year (12 months) from the date of purchase for the attachment it
manufactures.
The warranty covers repair costs as follows:
Work costs are covered, if the repair is not performed at the factory.
The factory replaces any defective components or consumables.
The factory may reimburse the price of components purchased by the customer in special cases that have
been agreed in advance.
The warranty does not cover:
Normal maintenance work or parts and consumables required for it.
Damages caused by unusual operating conditions or ways of use, negligence, structural changes made
without the consent of Avant Tecno Oy, use of non-original parts or lack of maintenance.
Consequences of a defect, such as interruption of work or other possible additional damages.
Travel and/or freight costs caused by the repair.
