Avenview MLT-EDGEPRO-2X2 User manual

VIDEO WALLS VIDEO PROCESSORS
VIDEO MATRIX SWITCHES
EXTENDERS SPLITTERS WIRELESS
CABLES & ACCESSORIES
Control Your Video
4K Dual Projector Edge Blending device
with IR/RS-232 Cascading Support
PRODUCT MANUAL
Model: MLT-EDGEPRO-2X2

www.avenview.com
Copyright
© 2017 Avenview Inc. All rights reserved.
The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview
makes no representations or warranties with respect to the accuracy or completeness of the contents of this publication
and reserves the right to make changes to specifications and product descriptions at any time without notice. No license,
whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set
forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any
express or implied warranty, relating to its products of Avenview Inc. is strictly prohibited.

TABLE OF CONTENTS
Getting Started ..........................................................................................................................3
1.1 Important Safeguards ................................................................................................................3
1.2 Safety Instructions .....................................................................................................................3
1.3 Regulatory Notices Federal Communications Commission (FCC)...........................................4
2
Introduction ...............................................................................................................................5
2.1 Package Contents .......................................................................................................................7
2.2 Before Installation.......................................................................................................................7
2.3 Application Diagram ...................................................................................................................9
Panel Description.......................................................................................................................10
3.1 INPUT PANEL (MLT-EDGEPRO-2X2) Front..........................................................................10
INPUT PANEL (MLT-EDGEPRO-2X2) Rear..........................................................................11
3.3 Remote Control .........................................................................................................................12
Specifications .................................................................................................................................539
3
3.2
4
1
3.4 Software Guide .........................................................................................................................15
2
3.5 OSD Menu and Operations ....................................................................................................18
3.6 Passive 3D Display...................................................................................................................25
3.7 Active 3D Applications.............................................................................................................28
3.8 Geometry Correction and Edge Blending................................................................................29
3.9 OSD Miscellaneous Functions - [Options] ...............................................................................45

SECTION 1: GETTING STARTED
1.1 IMPORTANT SAFEGUARDS
1.2 SAFETY INSTRUCTIONS
!Do not dismantle the housing or modify the module.
!Dismantling the housing or modifying the module may result in electrical shock or burn.
!Refer all servicing to qualified service personnel.
!Do not attempt to service this product yourself as opening or removing housing may expose you to dangerous voltage
or other hazards
!Keep the module away from liquids.
!Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid falls or spills on
to the housing, unplug the module immediately.
!Have the module checked by a qualified service engineer before using it again.
!Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning.
The Avenview MLT-EDGEPRO-2X2 Edge Blender processor has been tested for conformity to safety regulations and requirements,
and has been certified for international use. However, like all electronic equipment’s, the MLT-EDGEPRO-2X2 should be used with
care. Read the following safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
www.avenview.com Page 3
•Any product on which the serial number has been defaced, modified or removed.
•Damage, deterioration or malfunction resulting from:
•Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or failure to
follow instructions supplied with the product.
•Repair or attempted repair by anyone not authorized by us.
•Any damage of the product due to shipment.
•Removal or installation of the product.
•Causes external to the product, such as electric power fluctuation or failure.
•Use of supplies or parts not meeting our specifications.
•Normal wear and tear.
•Any other causes which does not relate to a product defect.
•Removal, installation, and set-up service charges.
Please read all of these instructions carefully before you use the device. Save this manual for future reference.
Avenview warranty certificate please refer to page #14
Warranty does not include:-

www.avenview.com Page
4
1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC)
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Warning symbols Description
ONLY USE THE PROVIDED POWER CABlE OR POWER
ADAPTER SUPPLIED. DO NOT TAMPER WITH THE
ELECTRICAL PARTS. THIS MAY RESULT IN
ELECTRICAL SHOCK OR BURN.
DO NOT TAMPER WITH THE UNIT. DOING SO WILL VOID
THE WARRANTY AND CONTINUED USE OF THE
PRODUCT.
THE VIDEO BOARDS ARE VERY SENSITIVE TO STATIC. PLEASE
ENSURE IF RACK MOUNTED OR INSTALLED ON A SURFACE,
IT SHOULD BE IN A GROUNDED ENVIROMENT.
THIS WARNING SYMBOL MEANS DANGER. WHEN THIS
SYMBOL IS PLACED, YOU ARE IN AN ENVIROMENT THAT
CAN CAUSE BODILY INJURY.
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Avenview is
not responsible for any radio or television interference caused by using other than recommended cables and connectors or
by unauthorized changes or modifications to this equipment.

2. INTRODUCTION
www.avenview.com Page 5
The Avenview MLT-EDGEPRO-2X2 is a professional edge- blending 4K video wall processor. Equipped with
advanced edge blending, image warping, projection mapping, and passive 3D, the device enables the user to achieve a
flawless unified image.
Configure the device using one of the five user-friendly control options; front panel keypad, IR controller, PC software
via USB, WEB GUI via Ethernet or RS232 for 3rd party control systems. The user can easily perform independent color
adjustments, black level uplift and an advanced geometric alignment of up to 17x17 grids to get live on-screen
optimized results.
The device supports five (5) multi-format input ports with resolutions ranging up to 2560x1600/3840x1080@60Hz and
4K/UHD 3840x2160@30Hz. The integrated (2) HDMI output ports support a full 4:4:4 color subsampling scheme
ensuring a seamless multi-projector solution for any market sector.
The MLT-EDGEPRO-2X2 processor supports a motion adaptive de-interlace which helps avoid visual artifacts by
performing high video optimization. The device is also capable of converting the film frame rate directly to a video
frame rate through the 3:2/2:2 pull down feature. Our product can tailor to unique setups that do not comply with
standard VESA timing specifications.
Easily create larger, more impressive displays without sacrificing signal integrity through the embedded HDMI loop our
port, available for daisy chain connection to cascade with multiple MLT-EDGEPRO- 2x2 devices. Users can now avoid
complex and costly solutions by replacing high end projectors with lower spec devices lacking integrated land-shift,
warping and edge blending capabilities.
4 Epson Projectors on curved screen for Passive 3D

FEATURES
www.avenview.com Page 6
A. Input and output:
1. Input ports: 2x HDMI, 1x DualLink DVI , 1x VGA, 1x DisplayPort
HDMI, DualLink-DVI and DisplayPort support 1920x1200, 4k/2k @30Hz, WQXGA & 3840x1080
@60Hz with 4:4:4 sampling without compression.
Connect with all kinds of video sources and support none VESA standard input resolution.
2.Output ports: 2x HDMII (optional DVI). Selectable output resolutions: 720x480, XGA, WXGA,
1280x1024, 1366x768,1400x1050, 1600x1200, 1920x1080 & 1920x1200.
3. Loop out port: 1x HDMII(supports 3840x2160@30Hz or 3840x1080@60Hz)
B. Image warp, geometry alignment and edge blending
1.Quick [4 Corner] alignment , vertical and horizontal keystone correction, Pin cushion & Barrel adjustment,
image warp and image 180 degrees flip.
2.Each unit controls two projectors and can be expanded with multiple MLT-EDGEPRO-2X2 to support
unlimited number of projectors.
3. Integrated with full function front panel keypads and IR remote controller. Manual geometry alignment up to 9x5 grid
patterns and 600 pixels adjustment range in horizontal direction in full HD output. It can meet most of the curved
screen edge blending requirements.
4. PC software tool for warp and geometry alignment up to 17x17 grid patterns with 1200 pixels adjustment range
in horizontal direction in full HD output. Parameters can be stored to the MLT-EDGEPRO-2X2 without the need
of a PC.
5. Execute 4 directions edge blending up to 1000 overlapped pixels.
6.Provide complete function for edge blending gamma selection and color fine-tune.
7.Precise black level uplift at selectable area to compensate light leakage in the projector.
8.White balance and individual color correction for each projector.
9.One PC tool can control dual processing channels simultaneously.
10.Optional Ethernet system control and geometry alignment through WiFi.
11.Able to perform flat & curved screen seamless edge blending including irregular double curved screen and 360
degrees curved screen
C. Passive and active 3D
1.Auto decode 3D signals for passive 3D display, including signal source from Blue Ray, STB, game console, media
player and PC.
2.Auto decode Stereoscopic Player/ Nvidia 3D Vision 1080p @120Hz 3D formats and Blue Ray 1080p 24Hz 3D signal
into 720p/XGA 120Hz signal for active 3D display.
3. Support standard HDMI 1.4a 3D format, including 1080p/24Hz full HD, Side by Side, Top-Bottom, frame
sequential & Line interleaved.
4. Support 3840x1080 Full HD Side by side 3D format and SONY 1080i/60Hz frame packed 3D.
5. “Perfect Sync” algorithm for Zero latency in RH/LH eye image to get the most comfortable 3D image.
6.3D display can be on curved screen and be enlarged by multi-projector stacking or edge blending.
-
-

www.avenview.com Page 7
D. High end 10-bit video processor
1. 10-bit high end processor with 3D motion adaptive de-interlace, low angle smooth algorithm and 3:2/2:2 film
mode detection and recovery function.
2. Complete colour adjustment function, including brightness, contrast, hue, saturation, preset colour mode and
independent RGB color adjustment.
E. Edge mask
Edge Mask at any edge up to 500 pixels with black background without changing image position and aspect ratio.
F. Video wall function
1. Image splitting and location assignment
2. Overlap pixel adjustments up to 900 pixels for image position shift, bezel compensation and creating overlap
region for edge blending.
3. Connect with 4k/2k input signal and split the image for display devices without additional PC, image splitter or other
devices.
4. Serve as video wall controller for irregular video wall display up to 15x15 matrix display from single signal input
source.
G. Image rotation and flip
Image 180 degrees mirror and flip.
H. System control
1. 1U housing for easy rack installation. Professional design and reliable.
2.
3.
Full function front panel keypads, IR remote controller and RS232.
4.
Optional Ethernet control. User can control the system and do geometry alignment through wired or WiFi by PC
or mobile phone.
5.
USB interface for code update and PC tool operation.
6.
Internal grid pattern for easy geometry alignment.
7.
Programmable EDID for user to create any EDID with timing between 1024x768 and 3840x2160.
8.
BOX ID for convenient multiple units control at the same time.
9.
Five preset Profiles to save user settings and can be recalled at any time.
10.
Automatic power ON/OFF through input signal control. While no input signal is detected, it will shut down
output so that user can power ON/OFF complete system through the control in signal source.
Dimension and weight: 440x189x45mm, 2.4kg (Body only)

2.1 PACKAGE CONTENTS
Before you start the installation of the MLT-EDGEPRO-2X2, please ensure that the packaging has the listed items below.
1MLT-EDGEPRO-2X2 X 1
2X 1
3IR REMOTE 28 KEYS X 1
4USER MANUAL X 1
2.2 BEFORE INSTALLATION
www.avenview.com Page 2
www.avenview.com Page 8
POWER BRICK (12V 3A) + C13
Either Standard US power cord *
or International power cord (UK,EU,AUS)
* Based on the order request.
•Place the product on an even and stable surface. If the product falls, it may cause an injury to a person or malfunction.
•Do not place the product in high temperatures (over 50°C), or low temperature (under 0°C) or high humidity.
•Use the DC power adapter with correct specifications. If inappropriate power supply is used then it may cause a fire.
•Do not twist or pull by force ends of the UTP /HDMI cable. It can cause malfunction.
•Keep the device away from water. If the unit becomes wet, power off immediately.
•Installation of the equipment must comply with local and national electrical codes.
•Take care when connecting units to the electrical power circuit, incase the maximum rated circuit is not overloaded
ATTENTION
•To prevent airflow restriction, allow clearance around the ventilation openings to be at least: ONE Inch (25.4 mm).
•Unauthorized changes or modifications could void the user's authority to operate the equipment.
Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard
practices for preventing accidents.
•
IR Extender cable X 1

2.3 APPLICATION DIAGRAM
www.avenview.com Page 2
www.avenview.com Page 9

*Some DLP projectors shows images with interference or cropped image, adjusting the display's picture size
setting will resolve the interference issue.
10 HDMI Loop out
13 IR Extender
12 HDMI-B Output
11 Loop out Source input
12 PC Tool Connection
5
67
3.1 INPUT PANEL (MLT-EDGEPRO-2X2) Front
www.avenview.com Page 10
1. 2
POWER SWITCH: Powers the device ON and OFF
3. 4.
5.
IR WINDOW: Receives IR signals from the device
remote control (Included in package)
6.
CURVE WARP: Quick access button to curve or warp
images.
7.
ACCESSORY BUTTON: Device info, display profile,
OSD lock and time control.
OSD KEYPADS: Menu list, Return, Exit, Output
Channel, Selection A/B and Grid Test Pattern display.
OUTPUT SELECTION: Quick access to most
commonly used resolutions (XGA,WXGA,1080p)
INPUT SELECTION: Select source between
HDMI, DP, DVI and VGA.
1234

www.avenview.com Page
11
3.2 R INPUT PANEL (MLT-EDGEPRO-2X2) Rear
8.HDMI-A OUTPUT:
10. 11.
14.
HDMI-B INPUT:
15.
HDMI-A INPUT:
HDMI-B OUTPUT:
DC IN POWER JACK:
VGA INPUT:
16.
8913
12 14
10 11 15 16 17 18
HDMI Channel A output
to the Left Side(1st) projector.
9. LOOP OUT: HDMI loop out port from
HDMI-A input for daisy chain connection.
HDMI Channel A input HDMI Channel B input.
12. DISPLAYPORT INPUT
source device.
Connects to Displayport 13.DUAL LINK DVI INPUT:TConnects to a
-DVI source.
Connects to VGA soruce.HDMI Channel B output
to the Right Side (2nd) projector.
12V 3A Power Supply.
17.IR EXT:
18.RS-232/USB/Ethernet: RS232 Serial, USB TypeB-
& Ethernet for PC control software.IR Extender for remote control

3.3. IR REMOTE CONTROL
www.avenview.com Page 12
0.PROFILE:Save up to 5 user profile settings for custom layouts with memory
for easy recall within the unit.
1.INFO:To view the input and output timing of the unit.
2.CH A/B:Allows the user to switch between Channel A and B for alignment .
3.OSD:Allows the user to control the OSD Menu function.
4.INPUT: Switch between the different video connections available
HDMI/DVI-DL/DisplayPort/VGA(YPbPr) .
4.OUT: Quick selection of preset ouput timmings
XGA/WXGA/1080p.
5.4 CORNER: Used for Quick Geometry alignment with just 4 corner adjustment
when the surface is flat and smooth. Also can correct image
keystone with vertical/horizontal position. Use this function to
adjust the image height/width to change the aspect ratio of the
output.
6.WARP: To create intricate goemetry alignment for uneven surfaces or
objects up to 17x17 grid pattern alignment.
7.EDGE
BLEND:
To create seamless edge blending images with multiple
projectors to create a large single image canvas.
8.VIDEO
WALL:
To create a stunning videowall with multiple screens or
projectors.
9.PATTERN:To activate the internal grid patterns to align two or
more projectors with a 32x32 pixel grid. Toggle
multiple times to change the color of the grid also to
select the external custom grid pattern.

3.2 INSTALLATION (MLT-EDGEPRO 2X2)
HHARDWARE SETUP
To setup the Avenview MLT-EDGEPRO-2X2 Dual Projector Edge Blender please follow these steps for connecting the devices:
2. Ensure the power is off on the MLT-EDGEPRO 2X2, also all source devices and displays that will be connected.
3. Connect (2) two HDMI cables to the (2) two HDMI ports label HDMI A/B with sources such as (Blu-ray player, laptop
or Set-Top-Box or Gaming Device.
4. Connect your HDMI cables to the dual HDMI ports to CH-A/B to the dual DLP Projectors that is receiving the video signals.
5. Power on all devices.
6. Connect your computer to MLT-EDGEPRO 2X2 via RS232, USB or Ethernet cable in order to control
via Telnet or RS232.
SERIAL PORT SETTING
RS-232 Wiring (Cable Connection)
HDM-SPLITPRO-4K
Remote Controller(PC)
PIN Assignment PIN De finition
1 NC 1 NC
2 TxD 2 RxD
3 RxD 3 TxD
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC


RS-232 SETTINGS
Baud Rate:115200bps
Data Bit: 8 bits
Parity: None
Flow Control: None
Stop Bit: 1
www.avenview.com Page 13
1. Mount or fix the MLT-EDGEPRO 2X2-4K on a secure shelf, AV rack or steady surface.

3.3 INSTALLATION (MLT-EDGEPRO 2X2) with PC Control Software
www.avenview.com Page 14
Use the Edgepro setup file and review these two files: Readme.txt and Edgepro PC tool.
Connect Micro USB cable between PC and Edgepro (see below).
Install Nuvoton USB driver using the files under [Edgepro Setup File folder].
Check Device Manager to confirm [Nuvoton Virtual Com Port]
is correctly installed (see below).
GENERAL INSTRUCTIONS
HARDWARE CONNECTION
- HDMI Loop Out port on the rear panel is for daisy chain connection.
- Only the input signal from HDMI-A input port can be cascaded to another unit for larger installs.
Please dont use it as an input port.
- The Two outputs from EDGEPRO will be shown simultaneously, duplicated from the source.
NOTE: It is not designed to output to 2 independent displays. (Please contact sales@avenview for the model
that supports this feature.

www.avenview.com Page 15
Once the software is started, follow the steps outlined below Click [Connect] at
Edgepro PC tool to connect COM port. After connected, it will show Edgepro output
resolution and [Disconnect] icon at Top Right corner.
Once it is connected, the user will see input resolution in signal source. This resolution is related to
Video Wall [Overlap] setting value. We propose to apply 1080p signal during installing stage.
Channel A & Channel B, can be controlled separately within the software.
3.4
The Edgepro PC Tool executable file (.exe) will run on your desktop once double
clicked to start without installation.
Please see how the user can use each Tab to facilitate their project at hand, note below.
PLEASE NOTE:
[Video Wall] settings: after geometry alignment, it is required to capture image for each projector.
Click [INFO] to check if correct input and output timing modes are set in the system.
If no input signal is applied, [Overlap] value will be wrong.
[Video wall] settings ( three projector horizontal edge blending as example)
[ Zoom]: all units set to H=3, (V=1 (default))
[Pan]: LH projector (1st): H=1, Center projector (2nd): H=2, RH projector (3rd): H=3
[Overlap]: select the right edge and apply the value calculated from Excel file
[Edge Blend] setting: based on the actual overlap grid number.
1
st
projector: RH edge=[Grid #]x32
2
nd
projector: LH edge= [Grid #]x32, RH edge=[Grid #] x32
3
rd
projector: LH edge= [Grid #]x32
SOFTWARE GUIDE

For most of the applications, we propose to follow [2x2] [5x5] [9x9] [17x17] sequence for geometry
alignment. Please note that if you execute [9x9] or [17x17] and back to [5x5], it will only keep [5x5] data
and reset all the others.
[Show grid] checked, will only execute the image outline position adjustment.
The center image also will be changed proportionally with outline position.
[Internal Grid] checked, will only adjust the internal grid area. Best used for detailed image position and
precsion fine-tune.
When edge blending, please align both grids in the edge blending area, to ensure a clear image can be
obtained on the output.
When the geometry alignment is completed, user can execute [Video wall button ] setting and
[Edge Blend tab] in hardware system separately.
TAB [Warp Shift]
[Warp Shift] is similar to [2x2] for the adjustment of image corner positions. The difference is that [2x2]
will reset the other geometry adjustment [5x5] or [9x9].
However,[Warp Shift] will not reset the other adjustment result. It will be convenient for user to re-adjust
the image corner locations after finishing curve adjustment from [5x5] or [9x9]
[Save] file to Edgepro
After finish all operations, user can save the result in two locations: PC and the Edgepro.
[Save file] will only save the file in PC and [Load file] to download it to Edgepro.
User can create up to 10 different Presets as showed on page 17. Click any number and save the layout to
any of the file locations up to 1~10.
Once the file is saved, disable [Pattern] so OSD menu on Edgepro can load the result in file locations 1~10.
To quickly disable the grid pattern- continuously press [Pattern] key on IR Remote or the front panel.
Activate Edgepro OSD to select the Preset from [Anyplace Icon ] in the menu, along with [Video Wall]
and [Edge Blend] function to complete edge blending processes. Then save the final result into [Profile] in
the menu. Maximum 5 profiles can be saved.
Once select [Gwarp] geometry alignment, all geometry alignment result in Edgepro will be replaced.
PC Software TAB [Warp adjust]
Click [Pattern] and toggle to select one of the available colors and Enable test pattern to show grid pattern on
the screen. The max pattern size is 32x32 pixels. User can also show the source input image on the screen.
Select [Warp adjust tab], use the grid type and adjusting Step (default is 16 pixels) for the adjustment.
BLUE direction keys are for control point selection and RED direction keys are for value adjustment.
[2x2 button] alignment is for quick image corner alignment. Step1- [2x2] geometry alignment to draw image
corners to the required positons, then to [5x5] or [9x9] buttons for further geometry alignment. After [5x5]
or [9x9] alignment, if user reverts to [2x2] alignment button, then only [2x2] alignment will be reserved and
all other alignments will be reset.
www.avenview.com Page 16

Please note the changes can only be saved in connected PC but not within the Edgepro.
To load the file from their PC to the Edgepro when the system is powered Off then On.
Except [Warp Adjustment] mode, all the other settings should be implemented in Edgepro
device memory.
TAB [Edge Blend]
To set the location and pixel number for edge blending based on geometry alignment.
To align the color in edge blending area through Gamma adjustment.
This function will extend the gamma adjustment to separate RGB in the future.
[Offset] to execute the black level to uplift.
This function can be implemented to EdgePro device memory.
TAB Color [Uniformity] correction
To set different gain and offset value in RGB separately for uniformity adjustment.
The minimum area for color uniformity adjustment is 64x64 pixels.
Please adjust the color uniformity in several steps in the surrounding area to avoid big transition in the color.
TAB [Color] adjustment
To perform white balance and color correction in each projector. Also to try to do color adjustment from the
projector first. When the color difference is not fixed, go to [Color] function to do independent RGB Gain and
Offset adjustment
Any color adjustment will reduce the color dynamic range.
Then apply color adjustment, different input sources may vary in results shown.
www.avenview.com Page 17

www.avenview.com Page 18
3.5 OSD Menu and Operation
[Picture] - Color Adustment


[Picture] menu will apply to both processing
This menu is only active under below conditions:
•[Picture] menu will be grayed out (when the color setting is in [Preset Mode] under -[Image Properties] menu.
Navigate to [Custom] menu and press [Save] menu to activate [Picture] menu.
•When the input signal is in YUV domain, all items under menu are free to be accessed.
•If the input signal is in RGB domain, only [Brightness] and [Contrast] can be adjusted.
User can do further separate RGB individual color adjustment under [Image Properies] menu.
•[Picture] menu has five options.
All the adjustments will be applied
to both processing channels.
•[Edge Blend] menu, user can adjust
the color on each projector.
[Image Setup] - For PC Graphics From VGA Input
[Automatic]: Automatic image position alignment.
• Note [Image Setup] menu can only be activated
when video signal input is connected to the analog
input port.
[Manual]: To manually set the signal Phase and Clock to eliminate image noise on the analog input .
[Horizontal Position]: To adjust the image horizontal position.
[Vertical Position]: To adjust the image vertical position.
When using a VGA signal, the unit will auto align the image and position.
NOTE: The unit will not auto alignment unless a new VGA input is connected.

3.5 OSD Menu and Operation
www.avenview.com Page 19
[Image Properties]
[Image properties] to select the image color for (Preset and discrete RGB), input port, aspect ratio, output
mode selection and image flip setting. The changes are made simultaneously to both processing channels.
[Color] - Preset Mode & Custom Color
•[Color] menu (Preset Mode and Custom)
•[Preset Mode] Neutral, sRGB, Reddish,Blush
•Default is [Neutral]
•Any changes will be applied to both processing
channels.
•[Custom] Discrete RGB color adjustment-
Red, Green, Blue,
•[Save] save thechanges made under [Picture]
section.
•Any changes will be applied to both processing
channels.
