avus C12 User manual

C12 Mobile Phone
C12_Betriebsanleitung_ENG_end.indd 1 29.10.10 01:35

3
Content
1. Specifications 4
2. Safety Information 6
3. General Information 7
4. Inserting the Battery and the SIM Card 8
5. Charging the Batteries 15
6. Keys and Connectors 18
7. Display and Status Symbols 19
8. Switsching On and Off 22
9. Voice Calls 28
10. Short Messages (SMS) 35
11. Call records 38
12. Phonebook 39
13. Profile 41
14. Settings 42
15. Clock 44
16. Calculator 45
17. Radio 46
18. Supplied Accessories 47
19. Care and user information 48
20. Additional Safety Information 50
The AVUS C12 is an ergonomic GSM telephone that was developed in cooperation with industrial designers for
customers that are looking for an elegant, reliable and easy to use mobile telephone.
C12_Betriebsanleitung_ENG_end.indd 3 29.10.10 01:35

4
1. Specifications
GSM Frequencies: Dual Band Operation GSM 900/1800
Talk Time: Up to 6 Hours
Standby Time: Up to 250 Hours
Display: Black and White Display, 35 x 22 mm with
Amber Backlit for Maximum Contrast
Ring tones: • 6 Different Polyphonic Ringtones
• Powerful Speaker
• Vibration Alarm
Phone features: • Re-Dial (20 Last Numbers)
• Integrated Handsfree Function, Mute, Keypad Lock
SMS features: 160 Characters Max., Stores up to 200 SMS
C12_Betriebsanleitung_ENG_end.indd 4 29.10.10 01:35

Security: Emergency Call Function and Emergency SMS
Multimedia: FM Radio - Can also be used with Handsfree Function
Organizer features: • Phonebook with 500 Entries (+ SIM)
• Clock with Alarm (Works when Phone is Switched Off)
• Calculator
Extras: Integrated LED Torch Light
Dimensions: Approx. ca. 108 x 51 x 17 mm
Weight: Approx. ca. 98 g (with Standard Battery)
Interfaces: Headset Connector (2.5 mm), Power Supply
Package content: AVUS C12 Mobile Phone, 900 mAh Li-Ion Battery,
AVUS C12 Stereo Headset, 100 – 240V Travel Charger, Manual
5
1. Specifications
GSM Frequencies: Dual Band Operation GSM 900/1800
Talk Time: Up to 6 Hours
Standby Time: Up to 250 Hours
Display: Black and White Display, 35 x 22 mm with
Amber Backlit for Maximum Contrast
Ring tones: • 6 Different Polyphonic Ringtones
• Powerful Speaker
• Vibration Alarm
Phone features: • Re-Dial (20 Last Numbers)
• Integrated Handsfree Function, Mute, Keypad Lock
SMS features: 160 Characters Max., Stores up to 200 SMS
C12_Betriebsanleitung_ENG_end.indd 5 29.10.10 01:35

Use the mobile telephone only in places where its use is not forbidden or could not pose a danger:
Do not use the telephone in airplanes, in hospitals, at fuelling stations, in demolition ranges or in an automobile
whilst you yourself are driving. Observe the valid laws and prohibitions and remember that they may change
from time to time.
Use only authorized accessories and in particular approved batteries. Incompatible accessories and faulty bat-
teries can cause damages, even explosions.
6
2. Safety Information
C12_Betriebsanleitung_ENG_end.indd 6 29.10.10 01:35

This mobile telephone has been developed for operation in EGSM 900 and 1800 networks – further informa-
tion on the services in these networks are available from your mobile communications provider. On direction of
the mobile communications provider certain functions of this mobile telephone may have been deactivated or
modified. For further information, please contact your mobile communications provider.
This mobile telephone is not water proof – therefore keep it away from liquids.
Keep the telephone, the power pack, the SIM card and other accessories out of the reach of children. Small
parts might come loose that may be swallowed. When disconnecting cables, always pull by the plug and never
by the cable. This telephone may be serviced and repaired only by authorized dealers.
3. General Information
7
C12_Betriebsanleitung_ENG_end.indd 7 29.10.10 01:35

To protect the battery during transport it is not inser-
ted in the mobile telephone. In case the dealer from
whom you purchased the telephone has not already
inserted the battery, follow the following steps.
1. Remove the battery cover on the back side by
sliding it to the case‘s base.
8
4. Inserting the Battery and the SIM Card
C12_Betriebsanleitung_ENG_end.indd 8 29.10.10 01:35

3. Cover the battery, insuring the battery cover en-
tirely closed with a “Click” sound.
2. Put the battery in the battery slot 3 metal contact
points towards back and be in line with the metal
bolts at the bottom line of the cell phone, ensu
ring the battery‘s 3 metal contact points are in
close alignment with the 3 metal bolts of the cell
phone.
4. Einlegen der SIM-Karte und des Akkus
9
C12_Betriebsanleitung_ENG_end.indd 9 29.10.10 01:35

Before using the mobile telephone you also need to
insert a SIM card. Disconnect the mobile telephone
from the power source for that and switch off the
mobile telephone.
1. Remove the battery cover on the back side by
sliding it to the case‘s base.
10
4. Inserting the Battery and the SIM Card
C12_Betriebsanleitung_ENG_end.indd 10 29.10.10 01:35

2. The battery could easily be removed by pressing
the edge of it and making a lift with your fingers.
3. Make sure the SIM card’s metal contacts poin-
ting downward and gap upward, and then slide
the SIM card towards the direction pointed by
the battery slot arrow until it is properly placed in
the SIM card slot.
4. Inserting the Battery and the SIM Card
11
C12_Betriebsanleitung_ENG_end.indd 11 29.10.10 01:35

4. Put the battery in the battery slot 3 metal contact
points towards back and be in line with the metal
bolts at the bottom line of the cell phone, ensu-
ring the battery‘s 3 metal contact points are in
close alignment with the 3 metal bolts of the cell
phone.
5. Cover the battery, insuring the battery cover en-
tirely closed with a „Click” sound.
12
4. Inserting the Battery and the SIM Card
C12_Betriebsanleitung_ENG_end.indd 12 29.10.10 01:35

The battery should be fully charged before starting up the mobile telephone. Use only the supplied power pack
for that or the approved vehicle charging adapter. Use only the supplied battery or the approved substitute type.
Appropriate instructions are available from your dealer or from the service hotline.
The usage of other charging adapters or batteries may possibly invalidate the authorization or guaranty/warranty
and may have dangerous consequences. Under no circumstances may you charge the telephone using the
USB connection of a computer, because this may damage the computer and/or the telephone.
5. Charging the Batteries
13
C12_Betriebsanleitung_ENG_end.indd 13 29.10.10 01:35

Plug the charger in the power socket.
After charging finished: unplug the charger from the
power socket, unplug its other end from the phone.
If the battery is completely discharged, it may take a
few minutes before the telephone indicates that it is
being charged and that it can be used for telephony.
The telephone will indicate when the charging pro-
cess has been completed.
14
5. Charging the Battery
C12_Betriebsanleitung_ENG_end.indd 14 29.10.10 01:35

If the battery is completely discharged, it may take a few minutes before the telephone indicates that it is being
charged and that it can be used for telephony. The telephone will indicate when the charging process has been
completed.
Battery Level Indicator
Low Battery Warning
Should low battery occur, the cell phone will sound a warning alarm and show a message of “low battery”. If
you receive a “low battery” warning during your making / answering call time, please charge the phone so as
to continue the call.
Charging Charging Finished
5. Charging the Battery
15
C12_Betriebsanleitung_ENG_end.indd 15 29.10.10 01:35

Headset
Connector
Up
Navigatio-
ne Key
Down
Navigation
Key
Call Key End Key
Hearing Aid Key
Quick Dial Keys
Girl/Boy
Flash-
light
Charger Connector
16
6. Keys and Connectors
C12_Betriebsanleitung_ENG_end.indd 16 29.10.10 01:35

EIN AUS Volume Key
Flashlight Key
Radio
Key
Key
Lock
Emergency
Key
6. Keys and Connectors
17
C12_Betriebsanleitung_ENG_end.indd 17 29.10.10 01:35

Please note that you can the volume keys inside
menu’s to move the cursor / selection up and
down.
18
6. Keys and Connectors
C12_Betriebsanleitung_ENG_end.indd 18 29.10.10 01:35

The display has six areas: The status of the mobile telephone is indicated in the top area, the middle area shows
call numbers or text messages, and selection functions in the menu or for the function keys are displayed at
the bottom.
1. Signal Status
2. Battery Status
3. Certain Flowing Signals
4. Time
5. Date
6. Menu
1 3
4
5
6
2
7. Display and Status Symbols
19
C12_Betriebsanleitung_ENG_end.indd 19 29.10.10 01:35

The status symbols in the top area have the following meaning:
Battery status
Signa status
Alarm clock
Unread messages
Ring
Vibration
Call transfer
20
7. Display and Status Symbols
C12_Betriebsanleitung_ENG_end.indd 20 29.10.10 01:35

Missed calls
Please insert the headphone
Keyboard unlocked
Keyboard unlocked
New messages received while keyboard locked
Missed calls while keyboard locked
New messages and missed calls while keyboard locked
7. Display and Status Symbols
21
