Eagle UHF
User guide

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
2/19
Table of content
1Background..............................................................................................................................3
2Product introduction.................................................................................................................4
2.1 Introduction.......................................................................................................................4
1.1 Precaution before using battery........................................................................................5
1.2 Charger.............................................................................................................................5
1.3 Notes................................................................................................................................6
3Installation Instructions ............................................................................................................7
3.1 Appearance......................................................................................................................7
3.2 Battery charge ..................................................................................................................8
3.3 Buttons and functions area display ...................................................................................9
4Manual of the Eagle racket unpaired......................................................................................10
4.1 Buttons and functions .....................................................................................................10
4.1.1 Turn on/off the device..............................................................................................10
4.1.2 Functions buttons ....................................................................................................10
4.2 Barcodes scanning.........................................................................................................11
4.3 RFID UHF scanning........................................................................................................11
5Demo test..............................................................................................................................13
5.1 Install demo-uhf-bt (1.0.8)...............................................................................................13
3.2 Pairing Device.................................................................................................................14
3.3 Scan Function.................................................................................................................16
3.4 UHF Configuration..........................................................................................................17
3.5 UHF Encryption ..............................................................................................................17
3.6 UHF Tag Reading and Writing........................................................................................17
3.7 UHF Tag Lock and Kill....................................................................................................18
5.1.1 Lock Function: .........................................................................................................18
5.1.2 Kill Function:............................................................................................................18
3.8 Firmware Upgrade..........................................................................................................18
3.9 Barcode Scan Test.........................................................................................................19

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
3/19
1Background
Description
Date
Version
Author
Auditor
First parution
27/05/2020
V1.0
CLO
ACA

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
4/19
2Product introduction
2.1 Introduction
The Eagle racket offers a powerful UHF RFID module up to 30dBm (adjustable from 5 to
30dBm) and 1D/2D barcode scanner.
It communicates with any mobile device or computer in Bluetooth communication.
The device is perfectly adapted to inventory management, asset management, inspection
etc.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
5/19
1.1 Precaution before using battery
▪Do not leave battery unused for long time, no matter it is in device or inventory. If battery has
been used for 6 months already, it should be check for charging function or it should be
disposed correctly.
▪The lifespan of Li-ion battery is around 2 to 3 years, it can be circularly charged for 300 to
500 times. (One full battery charge period means completely charged and completely
discharged.)
▪When Li-ion battery is not in used, it will continue discharge slowly. Therefore, battery
charging status should be checked frequently and take reference of the related battery
charging information on the manuals.
▪Observe and record the information of a new unused and non-fully charged battery. On the
basis of operating time of new battery and compare with a battery that has been used for
long time. According to product configuration and application program, the operating time of
battery would be different.
▪Check battery charging status at regular intervals.
▪When battery operating time drops below about 80%, charging time will be increased
remarkably.
▪If a battery is stored or otherwise unused for an extended period, be sure to follow the storage
instructions in this document. If you do not follow the instructions, and the battery has no
charge remaining when you check it, consider it to be damaged. Do not attempt to recharge
it or to use it. Replace it with a new battery.
▪Store the battery at temperatures between 5 °C and 20 °C (41 °F and 68 °F).
1.2 Charger
The charger type is GME10D-050200FGu, output voltage/current is 5V DC/2A. The plug considered
as disconnect device of adapter.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
6/19
1.3 Notes
Note 1:
Using the incorrect type battery has danger of explosion. Please dispose the used battery according
to instructions.
Note 2:
Due to the used enclosure material, the product shall only be connected to a USB Interface of version
2.0 or higher. The connection to so called power USB is prohibited.
Note 3:
The adapter shall be installed near the equipment and shall be easily accessible.
Note 4:
The suitable temperature for the product and accessories is 010℃to 50℃.
Note 5:
CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
7/19
3Installation Instructions
3.1 Appearance
The Eagle racket back and front appearances are showing as follows:

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
8/19
3.2 Battery charge
By using micro USB contact, the original adaptor should be used for charging the device. Make sure
not to use other adaptors to charge the device.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
9/19
3.3 Buttons and functions area display
Eagle racket UHF swing reader has 4 function buttons and 1 SCAN button, UHF scanning area, 1
display screen. Power key on the right side.
Buttons and Indicating Lamps instruction
Buttons and Lamps
Description
Indicating
Lamps
WIFI
Display WIFI connection status
Power
Display power status
Bluetooth
Display Bluetooth connection status
Main
button
UP
Move up cursor
DOWN
Move down cursor
OK
Press to confirm current selection.
···
Escape current page
Display
2D module
Function
Buttons
SCAN Button
Battery Slot
Power

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
10/19
Power
The LED is green when the device is turned on
Work
The LED is blue when the device is reading tags
Bluetooth
The LED is blue when Bluetooth is turn on
4Manual of the Eagle racket unpaired
4.1 Buttons and functions
4.1.1 Turn on/off the device
Press the power button to turn on or off the device.
4.1.2 Functions buttons
To access the menu, press the button . This button also allows you to go back in the menu.
To confirm press .
Sound, mode and language can be configured to in “Config” menu.
4.1.2.1 Sound
To turn on or off the sound, go to the menu by pressing the button . Select “Config”. Select
“Sound”. Choose “ON” or “OFF” by using the button
Sound, mode and language can be configured to .
4.1.2.2 Language
To switch language, go to the menu by pressing the button . Select “Config”. Select
“Language” and choose the language by using the button .

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
11/19
4.1.2.3 Mode
To switch from scanning mode, go to the menu by pressing the button . Select “Config”.
Select “Mode” and choose the mode “Auto” or “Once” by using the button .
4.2 Barcodes scanning
To scan barcodes, access the menu by pressing the button . Select “BarCode”.
Press the button
Be careful to position the racket so that it can read the barcode.
The barcode number is then displayed on the screen.
4.3 RFID UHF scanning
To scan tags, access the menu by pressing the button . Select “Inventory”.
Press the button
Be careful to position the racket so that it can read tags.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
12/19
The number of tags identified will be seen on the screen of the racket.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
13/19
5Demo test
5.1 Install demo-uhf-bt (1.0.8)
1. Copy demo-uhf-bt (1.0.8) into internal storage of smartphone or MBA5 device.
2. Click to install.
3. Click icon to open demo.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
14/19
3.2 Pairing Device
1. Switch on Bluetooth function of smartphone or MBA5 device.
2. Power on Eagle racket.
3. On your MBA5 or smartphone, click BLUETOOTH in the demo.
4. Click on SEARCH to search for Nordic_UART_CW.
5. Click on Nordic_UART_CW to connect.
6. After connecting successfully, user could click 3 dots on top right to check UHF version,
battery percentage and UHF module temperature.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
15/19

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
16/19
3.3 Scan Function
1. Click START in demo or press SCAN button on Eagle racket, the UHF tags could be read.
2. Click STOP in demo or click again on SCAN to stop reading of UHF tags.
3. Click CLEAR to clean all EPC information.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
17/19
3.4 UHF Configuration
1. Click CONFIG in demo to adjust working mode and output power.
3.5 UHF Encryption
1. Click ENCRYPTION to decrypt and encrypt the special zones of UHF tags such as USER,
EPC, etc.
3.6 UHF Tag Reading and Writing
1. The storage of one tag has 4 zones: RESERVED, EPC, TID and USER. Normally, the
default password is 00000000. And TID zone can only be read, other zones can be read
and written.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
18/19
3.7 UHF Tag Lock and Kill
5.1.1 Lock Function:
For example. User could try to lock down EPC zone.
5.1.2 Kill Function:
Kill function can be used to kill the tag permanently. Input the correct access password and
click kill.
3.8 Firmware Upgrade
1. Copy the firmware bin. file into internal storage.
2. Click Select file to search for bin.
3. Click Upgrade to upgrade firmware.

AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE –[email protected] –[phone] –www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
File : EAGUHF1311EU-UG-v1.0
Version : V1.0
19/19
3.9 Barcode Scan Test
Select BARCODE SCAN in the demo and click SCAN button on the screen to scan barcodes.
