Axiom EP600 User manual

Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third grounding prong. e wide blade or the third prong are
provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart
is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
15. Do not expose this apparatus to dripping or splashing and ensure that no objects lled with liquids, such as vases, are placed
on the apparatus.
16. To completely disconnect this apparatus from the AC Mains, disconnect the power supply cord plug from the AC
receptacle.
17. e main plug of the power supply cord shall remain readily operable.
18. Do not expose batteries to excessive heat such as sunshine, re or the like.
Step-by-step instructions on conguring your subwoofer.
EP500 & EP600 Subwoofer
Owners Manual
To view this manual in French, go to www.axiomaudio.com/manual_index.html
SAFETY PROCEDURES
• EnsurethatyouconnectyourSubwooferonlytothetypeofpower
supply indicated on the amplier faceplate, and ensure that the
power cord cannot be walked on or otherwise damaged.
• Topreventelectricshock,matchwidebladeofplugtowideslot,
fully insert.
• Ensure that objects or liquids are not allowed to penetrate the
enclosure.
• YourAXIOMSubwoofersarenishedinadurablevinylandfrom
time to time should be wiped clean gently with a slightly damp cloth
to remove any dust or stains.
For any additional information or service, contact:
AXIOM, 2885 HWY 60 Phone: [phone]
DWIGHT ON CANADA
P01 1H0
e lightning ash with arrowhead symbol within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage“ within the
product’s enclosure that may be of sucient magnitude
to constitute a risk of electric shock to persons.
e exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the product.
WARNING : To reduce the risk of re or electric shock , do
not expose this apparatus to rain or moisture.
e Axiom Warranty
All our speaker models; towers, bookshelves, surrounds, centers, subwoofers and
all our ampliers; subwoofer and multichannel ampliers are warrantied against
manufacturer’s defects for 5 years.
AXIOM CANADA INC. warrants this audio loudspeaker system (the “Product”)
to be free from original manufacturing defects in materials and workmanship for
ve years from date of purchase from an authorized Axiom dealer. This warranty
extends only to the original consumer purchaser. AXIOM CANADA INC. does
not warrant goods used in commercial or industrial applications. This warranty
does not cover any expenses incurred in any removal or re-installation of the
product.
If the product should prove so defective within the warranty period, return the
product by prepaid delivery to AXIOM CANADA INC., along with the original
sales invoice or other proof of purchase, which establishes eligibility for warranty
service. AXIOM CANADA INC. will, at its option, replace or repair the product
free of charge and return the product by prepaid delivery. This warranty does not
apply to any product, which has been damaged, misused, altered or repaired by
anyone other than an AXIOM CANADA INC. authorized service facility.
Any implied warranties including tness for use and merchantability are limited
in duration to the period of the express warranties set forth above, and no person
is authorized to assume for Axiom Canada Inc. any other liability in connection
with the sale of the product. Axiom Canada Inc. expressly disclaims liability for
any incidental and consequential damages caused by the product. The remedies
provided under this warranty are exclusive and in lieu of all others.
This warranty gives specic legal rights. In addition, there may be other legal
rights arising from the sale of the product, which vary from province to province
or state to state. Some provinces / states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation or exclusion may
not apply in some areas.

Step 7:
TRIM: Set this to FLAT for normal subwoofer
operation in a large room. e subwoofer will
reproduce deep bass at normal levels from
the movie soundtrack or music sources. e
LOAD setting is for accessing the internal
microprocessor. Do not use this setting as it
will turn o the sub output and turn the light
amber.eREMOTEsettingisforoperation
withfuture Axiom remote-controlledproducts
that will enable remote-control adjustment of
subwoofer levels. If you are in a medium or
small room you should experiment with Half
and Full to compensate for room loading.
Setting the TRIM to Half will partially increase
frequencies above 33 Hz. e Full setting will
greatly increase frequencies above 33 Hz. is
may be necessary to overcome room loading
or boundary eects (too much or too little low
bass).
Step 8:
GROUND LOOP:
If your subwoofer is producing a 60 Hz hum,
remove the Chassis Ground Screw. If this does
not solve the 60 Hz hum, call 1-866-244-8796
or consult the troubleshooting page at www.
axiomaudio.com/troubleshooting_ep500.
html
POWER INDICATOR: e LED Power
indicatorglowsGreenwhenit’sonandYellow
indicating a fault.
USB: is is to be used for future soware
upgrades to the Digital Signal Processor inside
yourEP500andEP600.Youmayalsousethe
USB input to connect the accessory Axiom
light to ease visibility in making subwoofer
adjustments or connections. Visit www.
axiomaudio.com/manual_index.html for this
Owner’s Manual with live links to further
helpful information.
EP500 & EP600 Amplier
Step 5: (For 220 volt supply only)
If you are using the HIGH LEVEL (Speaker Level)
binding-post inputs, set the subwoofer crossover switch
to 80 Hz for initial setup. If you have oor-standing
speakers (M50, M60, or M80), try a 60 Hz crossover
frequency, for the M80 try 40 Hz. If your main speakers
are bookshelf models use the 80 Hz setting. Ultimately
you want to use a crossover frequency that produces the
smoothest blend of sound between the subwoofer and
your main speakers.
Step 4:
VOLUME: Set the volume to the 9 o’clock position for
the time being. Later, when you have nished the hookup
of your subwoofer, you will return to this volume setting
to balance the output of the subwoofer to the other
speakers. Avoid the use of the auto-setup feature in your
receiver if it is equipped with one. ese devices rarely
work properly. e best method is to balance your sub
to the other speakers using a variety of music you are
very familiar with. Setting up sub levels and proper sub
placement in your room can be tricky but worth putting
some eort into as the results will be signicant. For a
detailed description please go to http://www.axiomaudio.
com/sub_setup.html
Step 5:
ON/OFF AC POWER/VOLTAGE SETTING: Your
subwoofer is supplied with a pop-out voltage regulator
set for use with 100 - 120 volts from the A/C line. It can
beeasilyremovedandturnedovertosetyourEP500or
EP600to220voltsfromtheA/Cline.Seediagramson
thenextpage.eEP500& EP600comewithathree-
prong power cord compatible throughout the United
States and Canada. Residents of other countries will need
to purchase a converter/adaptor or the proper power cord
that ts your specic socket.
Once you have made appropriate connections from the
A/Vreceiverorpreamp/processortotheEP500orEP600
and set the subwoofer’s voltage regulator to the proper
voltage, nd a nearby AC wall outlet and connect the
main power cord to the three-wire socket at the bottom
of the control panel. Move the power switch to the ON
setting.eLEDPOWERindicatorshouldglowGreen.
e EP500/EP600 has an instantaneous Standby mode
that enables itself whenever there is no signal input from
your AV receiver or preamp. e Green LED POWER
indicator does NOT change color when the EP500/
EP600entersitsidlemode,howeverpowerconsumption
is reduced to 10 watts or less. Leave the switch at the ON
setting unless you go away for an extended period. Moving
it to OFF will shut down all power to the subwoofer.
WARNING: Do not plug this into a power conditioner.
Power conditioners are known to cause overvoltage
which will damage your amplier.
Step 1:
LINE IN: e RCA line-level female input, second row,
accepts a standard RCA male plug. Connect a shielded
coaxial cable, with male RCA plugs on each end, from
the A/V receiver or A/V preamp processor’s Subwoofer
Output jack to the RCA LINE IN female jack on the
EP500orEP600.
3.5mm MINI-Jack: is is for any 3-Volt to 30-Volt
power-on trigger. It is also intended for trigger-controlled
operation with future Axiom products.
BALANCED XLR LINE IN: If the A/V receiver or A/V
preamp-processor has balanced XLR subwoofer line-
outconnections,youmayconnectaBalancedXLRmale
connector to the XLR female input. Otherwise, ignore
this connector. Do not use a combination of RCA and
XLRinputoroutputconnectors.
HIGH LEVEL INPUT: Use these “speaker-level” or high-
level 5-way binding post connectors only if your receiver
or preamp lacks a dedicated line-level subwoofer output
jack. Connect speaker cables from your amplier’s le-
channel and right-channel speaker output binding posts
to the high-level inputs using banana plugs (single or
dual), spade connectors, pins, or bare cable if you wish
(unscrew the top of each binding post and insert the cable
into the hole in the post; tighten the knurled knob against
the cable). Run a second pair of speaker cables from these
jacks to your main le and right front speakers. Do not
use these connectors if you are already using an RCA or
XLRline-levelconnectionfromthereceiverorpreamp
to the subwoofer. NOTE: BE SURE TO CONNECT
BLACK TO BLACK AND RED TO RED.
Step 2:
LINE OUT (RCA, Trigger and XLR Balanced):
An RCA line-level (female) output and balanced XLR
output (male) are provided for connection to a second
subwoofer. Use a standard shielded coaxial cable for
connection of the RCA Line Out to the second subwoofer.
IfyouareusingbalancedXLRconnectors,thenusethe
balancedLineOut for operationofasecondEP500or
EP600.
Step 3:
CROSSOVER: If you are using the Bass Management
crossovermenu settingsinyourA/Vreceiver orprocessor,
turn the subwoofer crossover control to the setting at or
just above the highest crossover point you selected on
your AV receiver menu, i.e. for a 90-Hz or higher receiver
menu setting, use “Bypass” on the sub (“Bypass” selects
a 150-Hz crossover), for 70 – 80 Hz on the AV receiver’s
menu, use 80 Hz on the sub, and so on. If your le and
right front satellite speakers have a woofer diameter of 4
inches or less, use the 150-Hz “Bypass” setting on your
subwoofer to enable a smoother transition between your
subwoofer and satellites.
Step 6:
0 & 180 PHASE: is synchronizes the in/out movement of the subwoofer cone driver with the other speakers in your system.
Once you have chosen the best location for your subwoofer, try ipping the phase switch between 0 and 180 to see if one or
the other setting produces deeper and smoother bass output in your room. Leave the switch at the setting that results in the
smoothest and deepest bass at several listening locations in the room. If you hear no dierence, leave the switch at the 0 position.
Quite oen the phase switch makes no dierence, but it’s dependent on your particular room’s dimensions and subwoofer
location.
