USER MANUAL
SW2100P
passive subwoofer
KEY FEATURES
• Band-Pass/Bass-Reex Acve Subwoofer • Very compact enclosure
• Single 21” Neodymium woofer with 4” ISV voice coil • Very good output-to-weight rao
• Water repellent cone
INTRODUCTION
The SW2100P is a very compact Band-Pass/Bass-Reex subwoofer providing high
output and extended low frequency response. It is equipped with a single 21”
neodymium transducer with a 4” ISV voice coil, large displacement suspension
system, and composite reinforced, water repellent cone, able to provide clean and
undistorted LF reproducon at very high SPL.
The loudspeaker is designed with a unique motor featuring a high grade neodymium
magnet assembly in a structure opmized for thermal and magnec eciency. Its
features include a large displacement suspension system which, in conjuncon with a
composite reinforced, straight ribbed cone and the proprietary Double Silicon Spider
(DSS) technology, allows an ultra-linear piston acon and provides full mechanical
control across the enre working range. The 100mm (4 in) state-of-the-art voice-coil
ulizing Interleaved Sandwich Voice coil (ISV) technology, provides high levels of
thermal stability and durability. The ISV technology achieves a balanced linear motor
unit exerng an exceponally high force factor.
The phenolic birch plywood cabinet is equipped with pole mount socket,
stacking feet, ush handles, and heavy duty wheels to enable easy handling and
transportaon.
It will deliver high level and extended low bass performance from a very compact cabinet, and thanks to the integral pole mount socket partners
well with any of the ED point source and AXIOM line array loudspeakers in any audio applicaons, while its small size enables it to be easily ed
into ght venue spaces.
TECHNICAL SPECIFICATION
Acouscal Connectors
System’s Acousc Principle Band-pass / bass-reex Connector Type Neutrik® Speakon® NL4 x 2
Transducer
21” Neodymium magnet, 4” (100mm) VC
High sness, water repellent cone,
Interleaved Sandwich Voice coil (ISV),
Triple-roll suspension
Input Wiring Pin 1+/1-; (Pin 2+/2- pass thru)
Mechanical
Width 760 mm (29.9”)
Height 511 mm (20.1”)
Depth 770 mm (30.3”)
Frequency response (-6 dB) 34 Hz - 180 Hz (Processed) Depth Including Wheels 881 mm (34.6”)
Sensivity (1.41V @ 1m, 2Pi) 94 dB Construcon 18mm, reinforced phenolic birch
Maximum Peak SPL @ 1m 132 dB Paint Black High resistance, water based paint
Electrical Wheels 4 x heavy duty ø 100mm (4”) castors
Nominal Impedance 4 Ω Transport 8 handles
Minimum Impedance 3 Ω @ 30 Hz Net Weight 56 Kg (123.5 lbs)
60 Kg (132.3 lbs) including wheels
Power Handling Connuous* 1600 W
Power Handling Program 3200 W
Power Handling Peak 7200 W
Power Compression
@ -10 dB Power (320 W) = 0.62 dB
@ -3 dB Power (1600 W) = 2.18 dB
@ 0 dB Power (3200 W) = 3.57 dB
* AES Pink Noise Power
revision 2022-03-07

MECHANICAL DRAWING
OPTIONAL ACCESSORIES
NL4FX Neutrik Speakon® PLUG
DHSS10M20 Sub-Speaker ø35mm 1-1.7m Pole with Handle and M20 screw
KP210S Sub-Speaker ø35mm 0.7-1.2m Pole with M20 screw
see hp://www.axiomproaudio.com/ for detailed descripon and other available accessories.
SPARE PARTS
AC103GS 100 mm Swivel castor without brake
98SW2100WZ4 21’’ woofer - 4” VC - 4 ohm
NL4MP Neutrik Speakon® panel socket
51 cm
20.1"
76 cm
29.9"
77 cm
30.3"
88 cm
34.7"
M20 Pole Adaptor

REAR PANEL
INPUT - Power input for the external amplier. The SW2100P does not include a passive crossover for ltering the signal. The connecons are
the following:
INPUT - LINK
NL4 pin number internal connecon
1+ LF+
1- LF-
2+ + pass thru
2- - pass thru
LINK - Power output in parallel with the INPUT socket for connecng the unit to another speaker. The number of SW2100P cabinets that can be
connected in parallel depends on the amplier load capacity.

LIMITED WARRANTY
Proel warrants all materials, workmanship and proper operaon of this product for a period of two years from the original date of purchase. If any defects are found
in the materials or workmanship or if the product fails to funcon properly during the applicable warranty period, the owner should inform about these defects the
dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed descripon. This warranty does not extend to damage resulng from
improper installaon, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned units, and when the unit has been properly used and warranty is sll
valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible for any “direct damage” or “indirect damage” caused by product defecveness.
• This unit package has been submied to ISTA 1A integrity tests. We suggest you control the unit condions immediately aer unpacking it.
• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspecon.
• Proel is not responsible for any damage that occurs during shipment.
• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
• Possible damages to unit should be immediately noed to forwarder. Each complaint for package tampered with should be done within eight days from product
receipt.
SAFETY INSTRUCTIONS
– To reduce the risk, close supervision is necessary when the product is used near children.
– Protect the apparatus from atmospheric agents and keep it away from water, rain and high humidity places.
– This product should be site away from heat sources such as radiators, lamps and any other device that generate heat.
– This product should be located so that its locaon or posion does not interfere with its proper venlaon and heang dissipaon.
– Care should be taken so that objects and liquids do not go inside the product.
– The product should be connected to a power supply mains line only of the type described on the operang instrucons or as marked on the product. Connect the
apparatus to a power supply using only power cord included making always sure it is in good condions.
– WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
– Do not cancel the safety feature assured by means of a polarized line plug (one blade wider than the other) or with a earth connecon.
– Make sure that power supply mains line has a proper earth connecon.
– Power supply cord should be unplugged from the outlet during strong thunderstorm or when le unused for a long period of me.
CE CONFORMITY
Proel products comply with direcve 2014/30/UE (EMC), as stated in EN 55103-1 and EN 55103-2 standards and with direcve 2014/35/UE (LVD),
as stated in EN 60065 standard.
