AXIOMTEK eBOX625-842-FL Series User manual

eBOX625-842-FL Series
Embedded System
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
Copyright 2019 Axiomtek Co., Ltd.
All Rights Reserved
Dec 2019, Version A2
Printed in Taiwan

iii
Safety Precautions
Before getting started, please read the following important safety precautions.
1. The eBOX625-842-FL does not come equipped with an operating system. An operating
system must be loaded first before installing any software into the computer.
2. Be sure to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
3. Disconnect the power cord from the eBOX625-842-FL before making any installation. Be
sure both the system and the external devices are turned OFF. Sudden surge of power
could ruin sensitive components. Make sure the eBOX625-842-FL is properly grounded.
4. Make sure the voltage of the power source is correct before connecting the equipment to
the power outlet.
5. Turn OFF the system power before cleaning. Clean the system using a cloth only. Do not
spray any liquid cleaner directly onto the screen.
6. Do not leave this equipment in an uncontrolled environment where the storage
temperature is below -40℃or above 80℃. It may damage the equipment.
7. Do not open the system’s back cover. If opening the cover for maintenance is a must,
only a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help to discharge any static electricity
on your body.
When handling boards and components, wear a wrist-grounding strap, available from
most electronic component stores.

iv
Classification
1. Degree of production against electric shock : not classified
2. Degree of protection against the ingress of water : IP40
3. Equipment not suitable for use in the presence of a flammable anesthetic mixture with air
or with oxygen or nitrous oxide.
4. Mode of operation : Continuous

v
General Cleaning Tips
You may need the following precautions before you begin to clean the computer. When you
clean any single part or component for the computer, please read and understand the details
below fully.
When you need to clean the device, please rub it with a piece of dry cloth.
1. Be cautious of the tiny removable components when you use a vacuum cleaner to
absorb the dirt on the floor.
2. Turn the system off before you start to clean up the component or computer.
3. Never drop the components inside the computer or get circuit board damp or wet.
4. Be cautious of all kinds of cleaning solvents or chemicals when you use it for the sake of
cleaning. Some individuals may be allergic to the ingredients.
5. Try not to put any food, drink or cigarette around the computer.
Cleaning Tools:
Although many companies have created products to help improve the process of cleaning
your computer and peripherals users can also use household items to clean their computers
and peripherals. Below is a listing of items you may need or want to use while cleaning your
computer or computer peripherals.
Keep in mind that some components in your computer may only be able to be cleaned using a
product designed for cleaning that component, if this is the case it will be mentioned in the
cleaning.
Cloth: A piece of cloth is the best tool to use when rubbing up a component. Although
paper towels or tissues can be used on most hardware as well, we still recommend you
to rub it with a piece of cloth.
Water or rubbing alcohol: You may moisten a piece of cloth a bit with some water or
rubbing alcohol and rub it on the computer. Unknown solvents may be harmful to the
plastics parts.
Vacuum cleaner: Absorb the dust, dirt, hair, cigarette particles, and other particles out of
a computer can be one of the best methods of cleaning a computer. Over time these
items can restrict the airflow in a computer and cause circuitry to corrode.
Cotton swabs: Cotton swaps moistened with rubbing alcohol or water are excellent tools
for wiping hard to reach areas in your keyboard, mouse, and other locations.
Foam swabs: Whenever possible it is better to use lint free swabs such as foam swabs.
Note: We strongly recommended that you should shut down the system before you
start to clean any single components.
Please follow the steps below:
1. Close all application programs
2. Close operating software
3. Turn off power switch
4. Remove all device
5. Pull out power cable

vi
Scrap Computer Recycling
If the computer equipment’s needs the maintenance or are beyond repair, we strongly
recommended that you should inform your Axiomtek distributor as soon as possible for the
suitable solution. For the computers that are no longer useful or no longer working well, please
contact your Axiomtek distributor for recycling and we will make the proper arrangement.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel®and Pentium®are registered trademarks of Intel Corporation.
MS-DOS, Microsoft C and QuickBasic are trademarks of Microsoft Corporation.
Windows 8.1, Windows 7, Windows XPE, Windows XP, Windows WinCE embedded, Linux,
MS-DOS, Microsoft C and
Other brand names and trademarks are the properties and registered brands of their
respective owners.

vii
Table of Contents
Disclaimers ........................................................................................................ii
Safety Precautions ...........................................................................................iii
Classification....................................................................................................iv
General Cleaning Tips....................................................................................... v
Scrap Computer Recycling.............................................................................. vi
CHAPTER 1 INTRODUCTION .......................................................................1
1.1 General Description...........................................................................1
1.2 System Specifications.......................................................................2
1.2.1 CPU ...................................................................................................................2
1.2.2 I/O System ........................................................................................................2
1.2.3 System Specification.......................................................................................2
1.2.4 Driver CD Content............................................................................................3
1.3 Dimensions ........................................................................................4
1.3.1 System Dimension...........................................................................................4
1.3.2 Wall mount Bracket Dimension......................................................................5
1.4 I/O Outlets ..........................................................................................6
1.5 Packing List........................................................................................8
1.6Model List........................................................................................... 8
CHAPTER 2 HARDWARE INSTALLATION...................................................9
2.1Installing the Memory module........................................................... 9
2.2Installing the 2.5” SATA HDD/SSD..................................................11
2.3Installing the Express Mini Card.....................................................14
CHAPTER 3 JUMPER SETTING & CONNECTOR......................................17
3.1 SBC Layout....................................................................................... 17
3.2 Jumper Setting Summary................................................................19
3.2.1 Restore BIOS Optimal Defaults (JP4) ..........................................................19
3.2.2 Auto power on (JP10)....................................................................................20
3.2.3 COM2 Data/Power Selection (JP11).............................................................20
3.2.4 COM1 Data/Power Selection (JP12).............................................................20
3.3 Connectors.......................................................................................21
3.3.1 AC-DC Jack Power In Connector .................................................................22
3.3.2 COM1~COM2 Serial Port Connector............................................................22
3.3.3VGA Connector ..............................................................................................23
3.3.4HDMI Connector.............................................................................................23
3.3.5LAN Connector (LAN1, LAN2).......................................................................24
3.3.6USB Connector ..............................................................................................24
3.3.7ATX Power On/OFF Button ...........................................................................24
3.3.8Audio Connector............................................................................................25
3.3.98-CH Digital I/O Connector............................................................................25
3.3.10 SATA Connector.............................................................................................25
3.3.11 SATA Power Connector.................................................................................26
3.3.12SIM Card Slot (SCN3).....................................................................................26
3.3.13 Half-Size PCI Express Mini card Slot (SCN1)...............................................27

viii
3.3.14Full-Size PCI Express Mini Card Slot (SCN2) .............................................28
CHAPTER 4 BIOS SETUP UTILITY ............................................................29
4.1 Starting.............................................................................................29
4.2 Navigation Keys............................................................................... 29
4.3 Main Menu........................................................................................ 30
4.4 Advanced Menu................................................................................ 31
4.5 Chipset Menu ...................................................................................42
4.6 Boot Menu........................................................................................ 45
4.7 Security Menu .................................................................................. 46
4.8 Save & Exit Menu............................................................................. 47
APPENDIX A WATCHDOG TIMER..............................................................49
About Watchdog Timer ................................................................................... 49
How to Use Watchdog Timer.......................................................................... 49
Appendix B Digital I/O ................................................................................51
About Digital I/O ..............................................................................................51
Digital I/O Programming.................................................................................. 52

eBOX625-842-FL Series User’s Manual
Introduction
1
CHAPTER 1
INTRODUCTION
This chapter contains general information and detailed specifications of the eBOX625-842-FL.
The Chapter 1 includes the following sections:
General Description
System Specification
Dimensions
I/O Outlets
Packing List
Model List
1.1 General Description
The eBOX625-842-FL is an embedded system that supports onboard quad core
Intel®Celeron®J1900 (2.0 GHz) single chip design to provide Windows 8.1,
Windows 7 , Windows 8 Embedded, Windows 7 Embedded or Linux, suitable for the
most endurable operation. It features fan less design with full feature I/O, one 204-
pin unbuffered SODIMM socket for singe channel DDR3L-1066/1333 MHz memory,
and enhanced system dependability by built-in Watchdog Timer.
Features
1. Intel® Celeron®2.0 GHz quad core SoC
2. Maximum to 8GB DDR3L-1066/1333 memory for J1900
3. Ultra slim and compact design
4. VGA & HDMI for display output
5. Supports 4 USB 2.0 ports
6. Supports 2 RS-232/422/485
7. Supports 8-CH Programmable Digital I/O
8. Supports dual 10/100/1000Mbps Ethernet ports
9. One 2.5” SATA HDD drive bay
10. One Full-Size Mini PCI Express Mini Card w/mSATA supported
11. One Half-Size Mini PCI Express Mini Card
12. One SIM slot
13. Watchdog timer
14. 12V / 36W AC-DC Adapter
15. Wide temperature: -20°C~55°C supported (with W.T. SSD & Memory)
Reliable and Stable Design
The eBOX625-842-FL adopts the advanced cooling system and supporting the mSATA
device, which makes it especially suitable for vibration environments, best for industrial
automation, digital signage and gaming application.
Embedded O.S. Supported
The eBOX625-842-FL not only supports Windows 8.1, Windows 7, but also supports
embedded OS, such as Windows 8 Embedded, Windows 7 Embedded, WinCE and
Linux.
Various Storage devices supported
For storage device, the eBOX625-842-FL supports one 2.5" SATA storage drive bay and
mSATA supported.

eBOX625-842-FL Series User’s Manual
Introduction
2
1.2 System Specifications
1.2.1 CPU
CPU
Intel®Celeron®quad core J1900 2.0 GHz.
BIOS
American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS.
16Mbit SPI Flash, DMI, Plug and Play.
PXE Ethernet Boot ROM.
System Memory
One 204-pin unbuffered DDR3L SO-DIMM socket. (DDR3L Only)
Maximum to 8GB DDR3L 1066/1333 MHz memory.
1.2.2 I/O System
Two 9-pin D-Sub male connectors, COM1~COM2 for RS-232/422/485
One D-Sub female connector, 8-CH TTL Level Digital I/O
One 15-pin D-Sub female connector for VGA, up to 1600 x 1200 @60Hz
One HDMI port, up to 1080P
Two Audio connector (Mic-IN, Line-OUT), HD audio compliant with Realtek ALC662
Two RJ-45 connector for 10/100/1000Base-T Ethernet w/Wake-on-LAN and PXE
Boot ROM
Four USB 2.0 ports
One 12V DC Jack for power input connector
Two Indicators (System Power, HDD Active)
Three Antenna Opening
1.2.3 System Specification
Watchdog Timer
1~255 seconds or minutes; up to 255 levels.
Power Supply
External 12V@3A, 36W AC/DC power adapter
Operation Temperature
-20℃~ 55℃(-4 ºF ~ 133ºF), J1900 with W.T. SSD/RAM
Storage Temperature
-40℃~ 80℃(-40 ºF ~ 176ºF)
Humidity
10% ~ 90% (non-condensation)
Vibration Endurance
3Grm w/ SSD™(5-500Hz, X, Y, Z directions)
Weight
1.1kg(2.43lb) without package/ 1.8kg(3.97) with package
Dimensions
200mm (7.87”) (W) x 120mm (4.72”) (D) x 46mm(1.81") (H)

eBOX625-842-FL Series User’s Manual
Introduction
3
1.2.4 Driver CD Content
Driver
Audio
Chipset
Ethernet
Graphic
TPM
Manual
User Manual
Quick Manual
NOTE:All specifications and images are subject to change without notice.

eBOX625-842-FL Series User’s Manual
Introduction
4
1.3 Dimensions
The following diagrams show you dimensions and outlines of the eBOX625-842-FL.
1.3.1 System Dimension

eBOX625-842-FL Series User’s Manual
Introduction
5
1.3.2 Wall mount Bracket Dimension

eBOX625-842-FL Series User’s Manual
Introduction
6
1.4 I/O Outlets
The following figures show you I/O outlets on front view of the eBOX625-842-FL.
Front View
Front View drawing

eBOX625-842-FL Series User’s Manual
Introduction
7
Rear View
Rear View drawing

eBOX625-842-FL Series User’s Manual
Introduction
8
1.5 Packing List
The package bundled with your eBOX625-842-FL should contain the following items:
eBOX625-842-FL System Unit x 1
eBOX625-842-FL Quick Manual x 1
Power Cord x 1
CD x 1 (For Driver and User’s Manual)
Screws pack x1
Foot pad x4
Optional 12V/36W AC-DC Adapter
Optional Power cord
Optional Wall-mount Brackets
Optional VESA-mount Bracket
Optional Din-rail Bracket
Optional WIFI/ 3G/ GPS Modules
If you cannot find this package or any items are missing, please contact
Axiomtek distributors immediately.
1.6 Model List
eBOX625-842-FL-DC-J1900
Fanless embedded system with Intel®Celeron®J1900
2.0GHz quad core single chip design, 2 COM, 4 USB
and 8-CH DIO (w/o adapter and power cord)

eBOX625-842-FL Series User’s Manual
Hardware Installation
9
CHAPTER 2
HARDWARE INSTALLATION
The eBOX625-842-FL is convenient for your various hardware configurations, such as
Memory Module, HDD (Hard Disk Drive), SSD (Solid State Drive) and mSATA. The chapter 2
will show you how to install the hardware.
2.1 Installing the Memory module
Step 1 Turn off the system, and unplug the power cord.
Step 2 Turn the system upside down to locate screws at the bottom, loosen screws.
Step 3 Remove the bottom cover.
Step 4 Find the DDR3L SO-DIMM position.

eBOX625-842-FL Series User’s Manual
Hardware Installation
10
Step 5 Locate the memory module, insert the gold colored of memory to
contact into the socket.
Step 6 Push the module down, until it is firmly seated by locking two latches
on the sides.
Step 7 Fasten all screws of bottom cover to finish installation.

eBOX625-842-FL Series User’s Manual
Hardware Installation
11
2.2 Installing the 2.5”SATA HDD/SSD
Step 1 Turn off the system, and unplug the power cord.
Step 2 Turn the system upside down to locate screws at the bottom, loosen screws.
Step 3 Remove the bottom cover and then prepare your 2.5”HDD/SSD to
assemble with your bottom cover.
Step 4 Please refer to the below photo and you can see some marks on the
surface of bottom cover, assemble your HDD on bottom cover and
notice HDD’s connector position.

eBOX625-842-FL Series User’s Manual
Hardware Installation
12
Step 5 Assembly the HDD together with the SATA HDD.
Step 6 Fasten total four screws.
Step 7 Connect SATA PWR and SATA Signal cables.
