AXIOMTEK UST500-517-FL Series User manual

UST500-517-FL Series
Embedded System
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or rights of any
third party, or any liability arising from such uses.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update any information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted in
any forms or by any means, electronic, mechanical, photocopying, recording, among others,
without prior written permissions of Axiomtek Co., Ltd.
Copyright 2019 Axiomtek Co., Ltd.
All Rights Reserved
December 2019, Version A5
Printed in Taiwan

iii
Safety Precautions
Before getting started, please read the following important safety precautions.
1. The UST500-517-FL does not come with an operating system which must be loaded first
before installation of any software into the computer.
2. Be sure to ground yourself to prevent static charge when installing any internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
3. Disconnect the power cord from the UST500-517-FL prior to making any installation. Be
sure both the system and all external devices are turned OFF. Sudden surge of power
could ruin sensitive components. Make sure the UST500-517-FL is properly grounded.
4. Make sure the voltage of the power source is correct before connecting it to any power
outlet.
5. Turn OFF system power before cleaning. Clean the system using a cloth only. Do not
spray any liquid cleaner directly onto the screen.
6. Do not leave equipment in an uncontrolled environment where the storage temperature
is below -40℃or above 80℃as it may damage the equipment.
7. Do not open the system’s back cover. If opening the cover for maintenance is a must,
only a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help discharge any static electricity on
human body.
When handling boards and components, wear a grounding wrist strap available from
most electronic component stores.

iv
Classifications
1. Degree of production against electric shock: not classified
2. Degree of protection against ingress of water: IP40*
3. Equipment not suitable for use in the presence of a flammable anesthetic mixture with air,
oxygen or nitrous oxide.
4. Mode of operation: Continuous
*Please refer the IP rating for UST500 SKUs in 1.6 Model List.

v
General Cleaning Tips
Please keep the following precautions in mind while understanding the details fully before and
during any cleaning of the computer and any components within.
A piece of dry cloth is ideal to clean the device.
1. Be cautious of any tiny removable components when using a vacuum cleaner to absorb
dirt on the floor.
2. Turn the system off before cleaning up the computer or any components within.
3. Avoid dropping any components inside the computer or getting circuit board damp or wet.
4. For cleaning, be cautious of all kinds of cleaning solvents or chemicals which may cause
allergy to certain individuals.
5. Keep foods, drinks or cigarettes away from the computer.
Cleaning Tools:
Although many companies have created products to help improve the process of cleaning
computers and peripherals, users can also use house hold items accordingly for cleaning.
Listed below are items available for cleaning computers or computer peripherals.
Pay special attention to components requiring designated products for cleaning as mentioned
below.
Cloth: A piece of cloth is the best tool to use when rubbing up a component. Although
paper towels or tissues can be used on most hardware as well, it is recommended to use
a piece of cloth.
Water or rubbing alcohol: A piece of cloth may be somewhat moistened with water or
rubbing alcohol before being rubbed on the computer. Unknown solvents may be harmful
to plastic parts.
Vacuuming dust, dirt, hair, cigarette and other particles out of a computer can be one of
the best methods of cleaning a computer. Over time these items may restrict the airflow
in a computer and cause circuitry to corrode.
Cotton swabs: Cotton swabs moistened with rubbing alcohol or water are applicable to
reach areas in keyboard, mouse and other areas.
Foam swabs: If possible, it is better to use lint free swabs such as foam swabs.
【Note】: It is strongly recommended that the user should shut down the system before
starting to clean any single component.
Please follow the steps below:
1. Close all application programs;
2. Close operating software;
3. Turn off power button;
4. Remove all devices;
5. Pull out the power cable.

vi
Scrap Computer Recycling
Please inform the nearest Axiomtek distributor as soon as possible for suitable solutions in
case computers require maintenance or repair; or for recycling in case computers are out of
order.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel®and Pentium®are registered trademarks of Intel Corporation.
MS-DOS, Microsoft C and QuickBasic, Windows 10, Windows 8.1, Windows 8, Windows 7,
Windows XPE, Windows XP, Windows CE embedded, Linux are trademarks of Microsoft
Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

vii
Table of Contents
Disclaimers..............................................................................................................i
Safety Precautions................................................................................................iii
Classifications.......................................................................................................iv
General Cleaning Tips ...........................................................................................v
Scrap Computer Recycling................................................................................... vi
SECTION 1 INTRODUCTION ........................................................................1
1.1 General Descriptions.........................................................................1
1.2 System Specifications.......................................................................2
1.2.1 Driver Contents................................................................................................4
1.3 Dimensions ........................................................................................5
1.3.1 UST500-517-FL FOR 4SATA TRAY Dimensions ...........................................5
1.3.2 UST500-517-FL FOR 2SATA TRAY Dimensions...........................................6
1.3.3 UST500-517-FL FOR NO TRAY Dimensions .................................................7
1.4 I/O Outlets ..........................................................................................8
1.5Packing List...................................................................................... 12
1.6Model List......................................................................................... 13
SECTION 2 HARDWARE INSTALLATION..................................................15
2.1 Installing CPU ..................................................................................15
2.2 Installing SO-DIMM.......................................................................... 18
2.3 Installing thermal pads.................................................................... 19
2.4 Installing 2.5” SATA Device ............................................................ 20
2.4.1 Installing 2.5” SATA Device for 4SATA........................................................20
2.4.2 Installing 2.5” SATA Device for 2SATA........................................................21
2.4.3 Installing 2.5” SATA Device for No Tray......................................................22
2.5 Installing Mini PCIe Module ............................................................ 24
2.5.1 Installing Mini PCIe Module for 4SATA........................................................24
2.5.2 Installing Mini PCIe Module for 2SATA........................................................25
2.5.3 Installing Mini PCIe Module for No Tray......................................................26
2.6 Installing 4G/3G Module..................................................................27
2.6.1 Installing 4G/3G Module for 4SATA .............................................................27
2.6.2 Installing 4G/3G Module for 2SATA .............................................................31
2.6.3 Installing 4G/3G Module for No Tray...........................................................35
2.7 Installing the Wall Mount Kit........................................................... 38
2.7.1 Installing the Wall Mount Kit for 2SATA/4SATA.........................................38
2.7.2 Installing the Wall Mount Kit for No Tray....................................................38
2.8 Installing the Cable Fixing Plate.....................................................39
2.8.1 Installing the HDMI Cable Fixing Plate ........................................................39
2.8.2 Audio Cable Installation................................................................................39
SECTION 3 DIP SWITCH, BUTTON & CONNECTOR SETTINGS .............41
3.1Summary of DIP Switch Settings.................................................... 41
3.2 Buttons ............................................................................................ 42
3.2.1 Power Button..................................................................................................42

viii
3.2.2 Reset Button ..................................................................................................42
3.3 Connectors ..................................................................................... 42
3.3.1 DC-in Power Connector ................................................................................42
3.3.2 HDMI Connector.............................................................................................43
3.3.3 DVI-D Connector ............................................................................................43
3.3.4 VGA Connector ..............................................................................................43
3.3.5 Serial Port Connector(COM1~COM2) ..........................................................44
3.3.6 Ethernet Connector (LAN1~LAN16) .............................................................44
3.3.7 USB 3.0 Connector ........................................................................................45
3.3.8 Audio Connector............................................................................................45
3.3.9 Digital I/O ........................................................................................................45
3.3.10 SATA Connector (SATA 1~4).........................................................................46
3.3.11 SATA Power Connector.................................................................................46
3.3.12SIM Card Slots (S1~S2).................................................................................46
3.3.13 PCI Express Mini Card Slot ..........................................................................46
SECTION 4 BIOS SETUP UTILITY..............................................................49
4.1 Starting.............................................................................................49
4.2 Navigation Keys............................................................................... 49
4.3 Main Menu........................................................................................ 50
4.4 Advanced Menu................................................................................51
4.5 Chipset Menu ................................................................................... 71
4.6 Boot Menu........................................................................................76
4.7Save & Exit Menu............................................................................. 77
APPENDIX A WATCHDOG TIMER..............................................................79
About Watchdog Timer ..................................................................................79
How to Use the Watchdog Timer.................................................................... 79
Sample Program.............................................................................................. 79
APPENDIX B DIGITAL I/O...........................................................................81
APPENDIX C CONFIGURING SATA FOR RAID.........................................87

UST500-517-FL Series user’s Manual
Introduction
1
SECTION 1
INTRODUCTION
This section contains general information and detailed specifications of the UST500-517-
FL.Section 1 consists of the following sub-sections:
General Descriptions
System Specifications
Dimensions
I/O Outlets
Packing List
Model List
1.1 General Descriptions
The UST500-517-FL is a fanless embedded system powered by the 7th / 6th generation Intel®
Core™ i7/i5/i3 and Celeron® processor (formally codenamed: Kaby Lake / Skylake) and
comes with flexible I/O design. To fulfill different application needs, the flexible embedded
system supports WE8S, WES7, Windows®10 and Linux, and can be wall-mounted or DIN-rail
mounted as an optional request.
The UST500-517-FL is built with an IP40-rated* heavy-duty aluminum extrusion, enabling
reliable operation in harsh environments. Moreover, it features a wide range of 9 to 36V DC
power input with power protection and -40 °C to +70 °C extended operating temperature
support. To help minimize deployment time, this fanless embedded PC provides one optional
I/O door for customers to easily install additional I/O output, making it perfectly suitable for any
industrial grade applications.
*Please refer the IP rating for UST500 SKUs in 1.6 Model List.

UST500-517-FL Series user’s Manual
Introduction
2
Features
LGA1151 socket 7th / 6th generation Intel®Core™ i7/i5/i3 & Celeron®
processor (Kaby Lake / Skylake) with Intel®Q170
Supporting wide range of DC power input from 9 to 36VDC
One DVI-D, one HDMI and VGA with triple view supported
Multiple flexible I/O modules supported
Reliable and Stable Design
The UST500-517-FL embedded system supports 7th / 6th generation Intel®Core™ i7/i5/i3
and Celeron®processors, with high flexibility and multi-functional design to present the
best solution for any industrial field applications.
Flexible Connectivity
The UST500-517-FL comes with rich I/O interfaces including two RS-232/422/485 ports,
four USB 3.0 ports, 6-CH isolated digital Input / 2-CH isolated digital Output, and sixteen
GbE LAN ports.
Embedded O.S. Supported
With the Skylake processor, UST500-517-FL can support WIN 7/8/10 and Linux
With the Kabylake processor, UST500-517-FL can support Windows®10 64 Bit.
1.2 System Specifications
CPU
LGA1151 socket 7th / 6th generation Intel® Core™i7/i5/i3 & Celeron® processor,
CPU TDP max. up to 35W/65W
Chipset
Intel®Q170
BIOS
American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS.
System Memory
Two 260-pin unbuffered DDR4-2133 MHz SO-DIMM sockets, up to 32 GB at
the maximum for 6th / 7th generation Intel® Core™processor
Display
1 x HDMI (Resolution:4K/2K@60Hz)
1 x DVI-D (Resolution:4K/2K@60Hz)
1 x VGA (Resolution: 1920X1200@@60Hz)
Ethernet
All Ethernet ports use the I211-AT controller, which can support 10/100/1000 Mb/s speed,
and different types of connectors can be provided for different skews for access.
No Tray
--8 ports RJ45
2 Tray
--8 ports RJ45
--16 ports RJ45
4 Tray
--8 ports M12
--8 ports RJ45 and 8ports M12
--16 ports RJ45

UST500-517-FL Series user’s Manual
Introduction
3
USB Ports
4 x USB 3.0
Serial Ports
2 x RS-232/422/485 (COM1~2)
DIO
Isolated programmable 6DI / 2DO
Audio
2 x Audio (Mic-in, Line-out)
Mini Card Interface
2 x full-size PCI Express Mini Card Slots (USB + PCI Express signal)
1 x half-size PCI Express Mini Card Slot (mSATA + USB + PCI Express signal)
1 x half-size USB Mini Card Slots
2 x SIM slots
Storage
2/4 x 2.5” SATA HDD/SSD drive tray
1 x mSATA
Indicator
1 x Green LED as indicator for PWR status
1 x Green LED as indicator for HDD active
2 x Green LED as indicator for programmable
Button
1 x Power button
1 x Reset button
Antenna
5 x SMA type connector openings for antenna
Watchdog Timer
1~255 seconds or minutes; up to 255 levels.
Power Supply
9~36VDC input (typical 24VDC input)
Operation Temperature
-40 °C ~+70 °C (-40 °F ~ 158 °F), with W.T. SSD & Memory : Skylake/ Kaby
Lake (Operating environment varies depending on the CPU model in use.)
Storage Temperature
-40 °C ~+85 °C (-40 °F ~ 185 °F)
Humidity
10% ~ 95% (non-condensation)
Vibration Endurance
No Tray
---3Grm with SSD (5-500Hz, X, Y, Z directions)
---2Grm with HDD (5~500Hz, X,Y, Z directions) (must be used with the
Axiomtek Anti-Vibration Kit; please contact Axiomtek for details)
2 SATA Tray
---3Grm with SSD (5-500Hz, X, Y, Z directions)
---2Grm with HDD (5~500Hz, X,Y, Z directions) (must be used with the
Axiomtek Anti-Vibration Kit; please contact Axiomtek for details)
4 SATA Tray
---2Grm with SSD (5-500Hz, X, Y, Z directions)
---2Grm with HDD (5~500Hz, X,Y, Z directions) (must be used with the
Axiomtek Anti-Vibration Kit; please contact Axiomtek for details)

UST500-517-FL Series user’s Manual
Introduction
4
Weight
No Tray
---3.95 kg (8.71 lb ) without package
---4.97 kg (10.96 lb ) with package
2 SATA Tray
---4.92 kg (10.85 lb ) without package
---5.74 kg (12.65 lb ) with package
4 SATA Tray
---4.92 kg (10.85 lb ) without package
---5.74 kg (12.65 lb ) with package
Dimension
2 SATA internal drive without tray: 280 mm(11.02”)(W) x 210.5 mm(8.27”)(D)
x 70 mm(2.76”) (H)
2 SATA drive trays: 280 mm(11.02”)(W) x 210.5 mm(8.27”)(D) x 83.7
mm(3.30”)(H)
4 SATA drive trays: 280 mm(11.02”)(W) x 210.5 mm(8.27”)(D) x 99.2
mm(3.91”)(H)
1.2.1 Driver Contents
Please download the drivers from the Axiomtek official website.
Ethernet
Chipset
Graphic
Serial Port
USB 3.0
Intel® ME
Audio
User’s Manual
UST500 Digital I/O utility
【Note】: All specifications and images are subject to change without notice.

UST500-517-FL Series user’s Manual
Introduction
5
1.3 Dimensions
The following diagrams show the dimensions and outlines of the UST500-517-FL.
1.3.1 UST500-517-FL FOR 4SATA TRAY Dimensions

UST500-517-FL Series user’s Manual
Introduction
6
1.3.2 UST500-517-FL FOR 2SATA TRAY Dimensions

UST500-517-FL Series user’s Manual
Introduction
7
1.3.3 UST500-517-FL FOR NO TRAY Dimensions

UST500-517-FL Series user’s Manual
Introduction
8
1.4I/O Outlets
The following figures show I/O outlets on the UST500-517-FL.
Front View
UST500-517-FL-16RJ-4SATA-TDC / UST500-517-FL-8RJ8M12-4SATA-TDC
Rear View
UST500-517-FL-16RJ-4SATA-TDC

UST500-517-FL Series user’s Manual
Introduction
9
Rear View
UST500-517-FL-8RJ8M12-4SATA-TDC

UST500-517-FL Series user’s Manual
Introduction
10
Front View
UST500-517-FL-16RJ-2SATA-TDC / UST500-517-FL-8RJ-2SATA-TDC
Rear View
UST500-517-FL-16RJ-2SATA-TRAY-TDC
Rear View
UST500-517-FL-8RJ-2SATA-TRAY-TDC

UST500-517-FL Series user’s Manual
Introduction
11
Front View
UST500-517-FL 2SATA-TDC
Rear View
UST500-517-FL 2SATA-TDC

UST500-517-FL Series user’s Manual
Introduction
12
1.5 Packing List
The UST500-517-FL comes with the following bundle package:
No Tray
2 SATA Tray
4 SATA Tray
UST500-517-FL system unit x 1
CPU grease x 1
Audio cable fixture x 1
HDMI cable fixture x 1
Cable fixture screws x 3
cable tie x 3
HDD screws x 8
HDD holder x 2
HDD holder screws x 8
Terminal block x 1
Programming DI/DO connector
x 1
Wall mount kit x 1
Wall mount kit screws x 4
Mini Card slot screws x 8
RF isolated plastic spacer x 10
UST500-517-FL system unit x 1
CPU grease x 1
Audio cable fixture x 1
HDMI cable fixture x 1
Cable fixture screws x 3
Cable tie x 3
HDD screws x 8
Terminal block x 1
Programming DI/DO connector
x 1
Wall mount kit x 1
Wall mount kit screws x 4
Mini Card slot screws x 8
RF isolated plastic spacer x 10
UST500-517-FL system unit x 1
CPU grease x 1
Audio cable fixture x 1
HDMI cable fixture x 1
Cable fixture screws x 3
Cable tie x 3
HDD screws x16
Terminal block x 1
Programming DI/DO connector
x 1
Wall mount kit x1
Wall mount kit screws x 4
Mini Card Slot screws x 8
RF isolated plastic spacer x 10
