AXIOMTEK tBOX324-894-FL Series User manual

tBOX324-894-FL Series
Embedded System
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make
any commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
Copyright 2018 Axiomtek Co., Ltd.
All Rights Reserved
May 2018, Version A2
Printed in Taiwan

iii
Safety Precautions
Before getting started, please read the following important safety precautions.
1. User should not modify any unmentioned jumper setting without Axiomtek FAE’s
instruction. Any modification without instruction might cause system to become
damage
2. The tBOX324-894-FL does not come equipped with an operating system. An
operating system must be loaded first before installing any software into the
computer.
3. Be sure to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
4. Disconnect the power cord from the tBOX324-894-FL before making any installation.
Be sure both the system and the external devices are turned OFF. Sudden surge of
power could ruin sensitive components. Make sure the tBOX324-894-FL is properly
grounded.
5. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
6. Turn OFF the system power before cleaning. Clean the system using a cloth only.
Do not spray any liquid cleaner directly onto the screen.
7. Do not leave this equipment in an uncontrolled environment where the storage
temperature is below -40℃or above 85℃. It may damage the equipment.
8. Do not open the system’s back cover. If opening the cover for maintenance is a must,
only a trained technician is allowed to do so. Integrated circuits on computer boards
are sensitive to static electricity. To avoid damaging chips from electrostatic
discharge, observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help to discharge any static
electricity on your body.
When handling boards and components, wear a wrist-grounding strap, available
from most electronic component stores.

iv
Classification
1. Degree of production against electric shock: not classified
2. Degree of protection against the ingress of water: IP40
3. Equipment not suitable for use in the presence of a flammable anesthetic mixture
with air or with oxygen or nitrous oxide.
4. Mode of operation: Continuous
General Cleaning Tips
You may need the following precautions before you begin to clean the computer. When you
clean any single part or component for the computer, please read and understand the details
below fully.
When you need to clean the device, please rub it with a piece of dry cloth.
1. Be cautious of the tiny removable components when you use a vacuum cleaner to
absorb the dirt on the floor.
2. Turn the system off before you start to clean up the component or computer.
3. Never drop the components inside the computer or get circuit board damp or wet.
4. Be cautious of all kinds of cleaning solvents or chemicals when you use it for the
sake of cleaning. Some individuals may be allergic to the ingredients.
5. Try not to put any food, drink or cigarette around the computer.

v
Cleaning Tools:
Although many companies have created products to help improve the process of cleaning
your computer and peripherals users can also use household items to clean their computers
and peripherals. Below is a listing of items you may need or want to use while cleaning your
computer or computer peripherals.
Keep in mind that some components in your computer may only be able to be cleaned using
a product designed for cleaning that component, if this is the case it will be mentioned in the
cleaning.
Cloth: A piece of cloth is the best tool to use when rubbing up a component. Although
paper towels or tissues can be used on most hardware as well, we still recommend
you to rub it with a piece of cloth.
Water or rubbing alcohol: You may moisten a piece of cloth a bit with some water or
rubbing alcohol and rub it on the computer. Unknown solvents may be harmful to the
plastics parts.
Vacuum cleaner: Absorb the dust, dirt, hair, cigarette particles, and other particles
out of a computer can be one of the best methods of cleaning a computer. Over time
these items can restrict the airflow in a computer and cause the circuitry to corrode.
Cotton swabs: Cotton swaps moistened with rubbing alcohol or water are excellent
tools for wiping hard to reach areas in your keyboard, mouse, and other locations.
Foam swabs: Whenever possible it is better to use lint-free swabs such as foam
swabs.
NOTE: We strongly recommended that you should shut down the system before you
start to clean any single components.
Please follow the steps below:
1.Close all application programs
2.Close operating software
3.Turn off power switch
4.Remove all device
5.Pull out power cable

vi
Scrap Computer Recycling
If the computer equipment need the maintenance or are beyond repair, we strongly
recommended that you should inform your Axiomtek distributor as soon as possible for the
suitable solution. For the computers that are no longer useful or no longer working well,
please contact your Axiomtek distributor for recycling and we will make the proper
arrangement.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Windows® is a trademark of Microsoft Corporation.
AMI® is a registered trademark of American Megatrends Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel® and Atom™ are trademarks of Intel Corporation.
Winbond is a trademark of Winbond Electronics Corp.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

vii
Table of Contents
Safety Precautions.................................................................................................. iii
Classification.......................................................................................................... iv
CHAPTER 1 INTRODUCTION.........................................................................1
1.1 General Description............................................................................. 1
1.2 System Specifications......................................................................... 2
1.2.1 CPU ......................................................................................................................2
1.2.2 System I/O ...........................................................................................................2
1.2.3 System Specification..........................................................................................2
1.2.4 Driver CD Content...............................................................................................3
1.3 Dimensions .......................................................................................... 4
1.4 I/O Outlets............................................................................................. 5
1.5 Packing List.......................................................................................... 6
CHAPTER 2 HARDWARE INSTALLATION....................................................7
2.1 Swappable HDD/SSD or CFast™Card................................................. 7
2.2Express Mini Card& DDR..................................................................... 8
CHAPTER 3 CONNECTOR ...........................................................................11
3.1 Connectors......................................................................................... 11
3.1.1 DVI / VGA / CANBUS Connector......................................................................11
3.1.2 Serial Port Connector.......................................................................................13
3.1.3 USB3.0 Stack Ports ..........................................................................................13
3.1.4 LED Indicators...................................................................................................14
3.1.5 DC Power Input connector...............................................................................14
3.1.6 LAN Connector (LAN1~ LAN4)........................................................................16
3.1.7 Digital I/O Connector........................................................................................17
3.1.8 SIM Card Connector .........................................................................................17
3.1.9 PCI-Express Mini Card Connector..................................................................18
3.1.10 CFast™Socket ..................................................................................................19
3.1.11 Antenna opening ..............................................................................................19
3.1.12 HDD tray locker.................................................................................................20
3.1.13 Remote switch Connector...............................................................................20
CHAPTER 4 AMI BIOS SETUP UTILITY.......................................................21
4.1 Starting............................................................................................... 21
4.2 Navigation Keys................................................................................. 22
4.3 Main Menu .......................................................................................... 23
4.4 Advanced Menu ................................................................................. 24
4.5 Chipset Menu ..................................................................................... 33
4.6Security Menu .................................................................................... 36
4.7Boot Menu.......................................................................................... 37
4.8 Save & Exit Menu............................................................................... 38
APPENDIX A WATCHDOG TIMER ...............................................................39
APPENDIX B DIGITAL I/O.............................................................................41

viii
This page is intentionally left blank.

tBOX324-894-FL Series User’s Manual
Introduction
1
CHAPTER 1
INTRODUCTION
This chapter contains general information and detailed specifications of the tBOX324-894-FL.
Chapter 1 includes the following sections:
General Description
System Specification
Dimensions
I/O Outlets
Package List
1.1 General Description
The tBOX324-894-FL is an embedded system that supports 7rd Gen. Intel®Celeron -3965U /
Core™i3-7100U / i5-7300U / i7-7600U processor (2.2 up to 2.8 GHz) onboard, to provide
Windows®10 and Linux, optimized for the most endurable operation. It features fanless
design with rich I/O, supports SO-DIMM up to 32GB, and enhanced system dependability by
built-in Watchdog Timer.
Features
7rd Generation Intel®Core™I (15W) processor onboard
Support SO-DIMM DDR4-2133 up to 32GB
CE ,IEC60945, EN50155 certificate
Fanless with operating temperature range of -40°C ~ +70°C with W.T. SSD
(0°C ~ +55°C with HDD)
Isolated RS-232/422/485 and DIO
Supports USB 3.0 and SATA3
2x removable & lockable 2.5” SATA drive bays and 1x CFast™
3x internal mini PCIe slots and 1x SIM socket
Lockable I/O ports, LAN connectors
Comply to fire protection of vehicles Europe standard PrCEN TS 45545-2
Reliable and Stable Design
The tBOX324-894-FL adopts the advanced cooling system and supporting CFast™,
which makes it especially suitable for vibration environments, the best for industrial
automation, digital signage, and gaming application.
Embedded O/S Supported
The tBOX324-894-FL is not only supported Windows®10, but also embedded O/S,
such as Windows®10 Embedded, and Linux. For storage device, the tBOX324-894-
FL is supported 2x 2.5" SATA drive bays and 1x CFast™slot.

tBOX324-894-FL Series User’s Manual
Introduction
2
1.2 System Specifications
1.2.1 CPU
CPU
Onboard Intel®Core™Celeron -3965U / Core™i3-7100U / i5-7300U / i7-7600U
processor (2.2 up to 2.8 GHz) processor (2M / 3M Cache 2.2GHz up to 2.8 GHz)
BIOS
American Megatrends Inc. BIOS.
“Load Optimized Default” to backup customized Setting in the BIOS flash chip to
prevent from CMOS battery fail
System Memory
DDR4 SO-DIMM socket up to DDR4-2133 Memory
Graphics
Integrated Intel®HD Graphics 620 for DVI / VGA
1.2.2 System I/O
2x 10-pin Terminal Block connectors, COM3/4 for isolated RS-232/422/485
1x DVI-I / VGA female connector
2x screw audio connectors (Mic-IN/Line-OUT)
4x isolated Gbe LAN (M12 or RJ45) connectors for 10/100/1000Base-T
4x USB 3.0 connectors (front side)
1x 12-pin isolated 4-in/4-out DIO connector
1x 24VDC power input connector (M12-5P or Terminal Block-3P)
2x DB9 type COM1/2 for isolated RS232/422/485, COM2 (option CAN BUS)
1.2.3 System Specification
Watchdog Timer
Reset supported; 255 levels, 0~255 sec.
Power Supply
24 VDC-in power supply
Power Rate:2.2A@24VDC
Operation Temperature
-40℃~ +70℃(- 40ºF ~ 158ºF) with W.T. SSD
0°C ~ +55°C (+32°F ~ +131°F) with HDD
Storage Temperature
-40℃~ 85℃(- 40ºF ~ 176ºF)
Humidity
5% ~ 95% (non-condensation)
Vibration Endurance
3Grms w/ SSD (5 ~ 500Hz, X, Y, Z direction; random)
1Grms w/ HDD (5 ~ 500Hz, X, Y, Z direction; random)

tBOX324-894-FL Series User’s Manual
Introduction
3
Weight
5 kg (11lb) without package
6.5kg (14.33lb) with package
Dimensions
288.5mm(11.36”)(W) x 211.3mm(8.32”)(D) x 85.75mm(3.38”)(H)
NOTE: All specifications and images are subject to change without notice.
1.2.4 Driver CD Content
Chipset Driver
Graphic Driver
Audio Driver
Ethernet Driver
ME Driver
RST Driver
Utilites

tBOX324-894-FL Series User’s Manual
Introduction
4
1.3 Dimensions
The following diagrams show you dimensions and outlines of the tBOX324-894-FL.

tBOX324-894-FL Series User’s Manual
Introduction
5
1.4 I/O Outlets
The following figures show you I/O outlets on front view of the tBOX324-894-FL.
Front View
Front View Drawing
Rear View
Rear View Drawing

tBOX324-894-FL Series User’s Manual
Introduction
6
1.5 Packing List
The package bundled with your tBOX324-894-FL should contain the following items:
tBOX324-894-FL System Unit x 1
tBOX324-894-FL Quick Installation Guide x 1
CD x 1 (with Driver and User’s Manual)
Screws Pack x 1
Foot Pad x 4
Wallmount Bracket x 1
SATA Drive Key x 2
DRAM Thermal Pad x 4
DC-IN Connector (power terminal block)
SATA Drive (HDD or SSD) (optional)
Remote Switch cable x1(optional)
CFast (optional)
Express Mini Card Module (optional)
3G/4G/GPS module x 1 (optional)
Wi-Fi/Bluetooth module x 1 (optional)
M12 power cable x 1 (optional)
If you can not find this package or any items are missing, please contact Axiomtek distributors
immediately.

tBOX324-894-FL Series User’s Manual
Hardware Installation
7
CHAPTER 2
HARDWARE INSTALLATION
The tBOX324-894-FL is convenient for your various hardware configurations, such as HDD
(Hard Disk Drive), CFast™card and mini PCIe card. The chapter 2 will show you how to install
the hardware.
2.1 Swappable HDD/SSD or CFast™Card
Step 1 Make sure system power is off, and then loosen the screw at HDD tray as
shown.
Step 2 Slide HDD into the cover as picture shown. Insert screws into each side of
the SATA drive through the corresponding holes.
Step 3 Install CFast and SATA drive to the slot.
Step 4 Secure CFast and SATA drive to complete the installation.

tBOX324-894-FL Series User’s Manual
Hardware Installation
8
2.2 Express Mini Card& DDR
Step 1 Make sure system power is off and unplug the power cord.
Step 2 Turn the system upside down and loosen the lateral cover screws as shown
to remove the bottom cover.
One slot contains an internal SIM card slot which can support
2G/3G/4G modules.
For the Express Mini card:
Step 3 Slide SIM or Mini card into slot cautiously.
Step 4 Fasten the screws to complete the installation.
For the DDR:
Step 5 Loosen the side screws as shown.

tBOX324-894-FL Series User’s Manual
Hardware Installation
9
Step 6 Pull out the front bezel and internal bracket as shown.
Step 7 Loosen below screws to remove cover and put on the thermal pad.
Step 8 Install the DDR cautiously and put on the thermal again.
Step 9 Secure DRAM cover and install the internal bracket, front bezel. Fasten the
all screws to complete the installation.

tBOX324-894-FL Series User’s Manual
Hardware Installation
10
This page is intentionally left blank.

tBOX324-894-FL Series User’s Manual
Connector
11
CHAPTER 3
CONNECTOR
3.1 Connectors
Connectors are connected the CPU board with other parts of the system. Loose or improper
connection might cause problems. Make sure all connectors are properly and firmly
connected before your turn on the system.
3.1.1 DVI / VGA / CANBUS Connector
DVI-I
Pin
Signal
Pin
Signal
1
TMDS Data 2-
2
TMDS Data 2+
3
GND
4
CRT_SPD_Clock
5
CRT_SPD_Data
6
DVI_SPD_Clock
7
DVI_SPD_Data
8
Analog Vsync
9
TMDS Data 1-
10
TMDS Data 1+
11
GND
12
N.C
13
N.C.
14
+5V
15
GND
16
Hot Plug Detect
17
TMDS Data 0-
18
TMDS Data 0+
19
GND
20
N.C
21
N.C
22
GND
23
TMDS Clock+
24
TMDS Clock-
C1
Analog RED
C2
Analog Green
C3
Analog Blue
C4
Analog Hsync
C5
GND

tBOX324-894-FL Series User’s Manual
Connector
12
VGA
Pin
Signal
Pin
Signal
Pin
Signal
1
Red
2
Green
3
Blue
4
N.C.
5
GND
6
GND
7
GND
8
GND
9
VCC
10
GND
11
N.C.
12
DDC DATA
13
Horizontal Sync
14
Vertical Sync
15
DDC CLK
CANBUS (optional)
Pin
Signal
1
N.C.
2
CAN_L, Low-Level CAN Voltage I/O
3
GND, CAN side GND
4
N.C.
5
N.C.
6
GND, CAN side GND
7
CAN_H, High-Level CAN Voltage I/O
8
N.C.
9
N.C.
