Axis JS055 User manual

1
MOBILE SAFETY
JS055
5” LCD COLOUR MONITOR
This monitor is designed for car, caravan or truck rear vision.
2WARRANTY
YEAR
GENERAL
- TFT Panel: New Grade A LCD
LED Backlight
- LCD Size: 125mm (5-Inch) Diagonal
- Display Format: 16:9/4:3
- Resolution: 800 (H) x RGB x 480 (V)
- Brightness: < 480 CD/M2
- Contrast Ratio: 500:1
- Video System: Auto PAL/NTSC Select
- Video Input: AV1 - Video/Audio Input
AV2 - Auto Switching (For Reverse Camera)
- Main Menu: Brightness/Contrast/Colour/Volume/
IR Control/Reset
- Video Connections: 4-Pin (Female) x 2
- Audio: On Board Speaker
- Power Input: 11-32V DC (Negative Ground)
- Dimensions: 145W x 108H x 26D mm (excluding brackets)
INCLUDED
- Mounting Brackets: Stand Mount
U-Shape Mount
- Accessories: Sunshade
Remote Control
Power Cable Assembly

2
AV1: Monitor 4Pin(F)
AV2: Monitor 4Pin(F) [Activated by Trigger Wire]
:LULQJ'H¿QLWLRQ&RQQHFWLRQ)URQW9LHZ
U-shape Mount Remote control Reversing Power
cable
Sunshade (XGIQKZ
$FFHVVRULHV
5HPRWH&RQWURO
Power Cable
0RQLWRU

3
0RQLWRU
13 Pin Male 3LQ)HPDOH9LGHR9
4Pin )HPDOH Video V2
Green - Reverse Connection
Black - Grounding
Orange - Dimmer Control Input
Red - 12 - 24V
Note: Cam 2 has reverse trigger control.
1. Power Indicator Light Colour TFT
2. Remote Sensor
LCD Monitor
3. Decrease Button
4. Increase Button
5. Menu
6. Mode
7. Power Switch
1 2 3 4 5 6 7
)XQFWLRQV
• Volume +/-
• Adjust Settings in Menu
Menu Button
• Brightness
• Contrast
• Colour
• Volume
• Zoom
• Language
• Reset
Mode Button
Used to change between cameras
Power On/Off Button
&RQQHFWLRQV

4
JS055
