Axis AXIS 207MW User manual

AXIS 207
AXIS 207W
AXIS 207MW
Installation Guide

AXIS 207/207W/207MW Installation Guide Page 3
AXIS 207/207W/207MW
Installation Guide
This installation guide provides instructions for installing the AXIS 207/207W/207MW
Network Camera on your network. For all other aspects of using the product, please see the
!"#$%"&'()*(+,&-./0.&/"&(1(/+(2+#&3)&4.#&CD included in this package, or from
www.axis.com/techsup
Installation steps
1. Check the package contents against the list below.
2. Hardware overview. Familiarize yourself with the camera. See page 4.
3. Install the hardware and make all cable connections. See page 7.
4. Set an IP address. See page 8.
5. Set the password. See page 12.
6. Configure the wireless connection. See page 13.
7. Adjust the focus. See page 15.
1. Package contents
Item Models/variants/notes
Network camera AXIS 207
AXIS 207W
AXIS 207MW
Indoor power supply
(country specific)
AXIS 207: type PS-L
AXIS 207MW/AXIS 207W: type PS-H
Power supply extension
cable
1.8 meters
Camera stand Supplied with 3 mounting screws. The extension section is ready fitted.
Flexible clamp For shelf mounting
Terminal block connector 4-pin connector block for connecting external devices to the I/O terminal con-
nector
Cable clip Self-adhesive - fixes to back panel for holding power cable
CD Axis Network Video Product CD, including installation tools and other software,
product documentation
Printed Materials AXIS 207/207W/207MW Installation Guide (this document)
Axis Warranty Document
Important!
This product must be used in
compliance with local laws
and regulations.

Page 4 AXIS 207/207W/207MW Installation Guide
2. Hardware overview
Product ID & Serial number (S/N).
The serial number may be
required during the installation.
Dimensions
AXIS 207: HxWxD = 85 x 55 x 34mm (3.3" x 2.2" x 1.3")
Weight = 177g (0.39 lb) (stand included, power supply excluded)
AXIS 207W/MW: HxWxD = 85 x 55 x 40mm (3.3" x 2.2" x 1.6") (antenna excluded)
Weight: 190g (0.42 lb) (stand included, power supply excluded)
Network connector
(see page 5)
I/O terminal connector
(see page 5)
Power connector
(see page 5)
Focus ring
Status indicator LED
(outer ring)
Lock ring
Microphone
Antenna
(wireless models)
Network indicator
LED
Control button
Wireless indicator LED
(wireless models)
Power indicator LED

AXIS 207/207W/207MW Installation Guide Page 5
Unit connectors
Network connector - RJ-45 Ethernet connector. Supports Auto-MDIX (AXIS 207W/MW
only) for automatic detection of straight or crossover cable. Using shielded cables is
recommended.
Power connector - Mini DC connector. 4.9-5.1V DC, max 4.0W. See product label for !
connection.
I/O terminal connector - Used in applications for e.g. motion detection, event triggering,
time lapse recording, alarm notifications, etc. It provides the interface to:
5 6&4$()"/"43$&3*47*4&8&93$&03))#04/):&#;4#rnal devices such as relays and LED:s.
Connected devices can be activated by Output buttons on the Live View page or
by an Event Type. The output will show as active (in Event Configuration > Port
Status) if the alarm device is activated.
5 6&</:/4(+&/)7*4&8&=)&(+($>&/)7*4&?3$&03))ecting devices that can toggle between
an open and closed circuit, for example: PIRs, door/window contacts, glass break
detectors, etc. When a signal is received the state changes and the input becomes
active (shown under Event Configuration > Port Status).
5 =*;/+/($@&73-#$&()<&ABC
Function Pin number Notes Specifications
Transistor
Output
Pin 4 Uses an open-collector NPN
transistor with the emitter con-
nected to the GND pin. If used
with an external relay, a diode
must be connected in parallel
with the load, for protection
against voltage transients.
Max load = 100mA
Max voltage = 24V DC
(to the transistor)
Digital Input Pin 3 Connect to GND to activate, or
leave floating (or unconnected)
to deactivate.
Must not be exposed to
voltages greater than
10V DC
GND AXIS 207 = Pin 2
AXIS 207W/MW = Pin 1
Ground
Auxiliary DC
Power Input
AXIS 207 = Pin 1
AXIS 207W/MW = Pin 2
Electrically connected in parallel
with the connector for the power
supply, this pin provides an
auxiliary connector for mains
power to the unit.
This pin can also be used to
power auxiliary equipment, with
a maximum current of 50mA.
Voltage = 4.9-5.1V DC
(all models)
Min power:
AXIS 207: 2.5W
AXIS 207W: 3.5W
AXIS 207MW: 4.0W
Pin layouts
1
4
1
4
AXIS 207MW
AXIS 207W
AXIS 207

Page 6 AXIS 207/207W/207MW Installation Guide
Connection diagram
LED indicators
LED Color Indication
Wireless Unlit Wired mode.
Green Steady for connection to a wireless network. Flashes for network activity.
Red Steady for no wireless network connection. Flashes when scanning for wireless
networks.
Network Green Steady for connection to a 100 Mbit/s network. Flashes for network activity.
Amber Steady for connection to 10 Mbit/s network. Flashes for network activity.
Unlit No wired network connection, or AXIS 207MW/AXIS 207W in wireless mode.
Status Green Steady green for normal operation.
Note: The Status LED can be configured to be unlit during normal operation, or to
flash only when the camera is accessed. To configure, go to Setup > System
Options > LED settings. See the online help files for more information.
Amber Steady during startup, during reset to factory default or when restoring settings.
Red Slow flash for failed upgrade.
Power Green Normal operation.
Amber Flashes green/amber during firmware upgrade.
o
o
oo
oo
Camera
3.3V
Power - see table above.
e.g. pushbutton
Device
4
o3
o
Linear
Power
Supply
o
1
o
o
Relay
GND
+
2
Fuse
IMPORTANT!
This diagram applies to the AXIS
207W and AXIS 207MW. The AXIS
207 has a different pinout and
power - see the table above.
2
1
Fuse:
AXIS 207: 500mA
AXIS 207W/MW: 1A

AXIS 207/207W/207MW Installation Guide Page 7
3. Install the hardware
3a. Mount the camera
Make a note of the serial number (S/N) located on the product label. This number may be
required during installation.
Wall mounting
1. If required, use the 3 supplied screws to fix the base
plate to a flat (horizontal or vertical) surface.
2. To use a shorter stand, unscrew the lock ring to release
the camera, and remove the extension section.
3. Attach the camera, adjust the angle and tighten the
lock ring.
Shelf mounting
1. Position the clamp and tighten the fixing screw
securely.
2. Attach the clamp to the lock ring on the camera.
3. Adjust the angle and tighten the lock ring.
3b. Connect the cables
1. Using the self-adhesive strip, attach the supplied cable
clip to the rear panel and fasten the power cable to it. This will prevent accidental cable
disconnection.
2. Connect the camera to the network using a shielded network cable. For the wireless
models, this connection is temporary and allo-"&4.#&0(>#$(%"&"#44/):"&43&2#&03)?/:*$#<&
via the wired network before connecting to the wireless network.
3. Optionally connect external devices, e.g. alarm devices. See page 5 for information on
the terminal connector pins.
4. Connect power, using one of the methods listed below:
5 D3))#04&4.#&"*77+/#<&/)<33$&73-#$&"*77+@&43&4.#&73-#$&03))#043$&3)&4.#&0(>#$(E
5 D3))#04&73-#$&1/(&4.#&4#$>/)(+&03))#043r. See page 5 for information on the ter-
minal connector pins.
5. Check that the indicator LED:s indicate the correct conditions. See the table on page 6
for further details. Note that some LED:s can be disabled and may be unlit.
!IMPORTANT! - The AXIS 207/207W/207MW is designed for indoor use only,
and must always be positioned where it is not exposed to direct sunlight or
"4$3):&.(+3:#)&+/:.4,&-./0.&0()&0(*"#&7#$>()#)4&<(>(:#&43&4.#&0(>#$(%"&
image sensor. Damage as a result of exposure to strong light is not covered by
the Axis warranty.

Page 8 AXIS 207/207W/207MW Installation Guide
4. Set an IP address
To make it accessible on the network, the AXIS 207/207W/207MW must be assigned an IP
address.
Depending on the number of cameras you wish to install, the recommended method for
setting IP addresses in Windows is either AXIS IP Utility or AXIS Camera Management. Use
the method that best suits your purpose.
Both of these free applications are available on the Axis Network Video Product CD supplied
with this product, or they can be downloaded from www.axis.com/techsup
Notes:
! "#$%&'()*#+,-.#/%)0%)#1/#(2&1($345#
! 67%#"89:#;<=>;<=?>;<=@?#73/#&7%#A%B3C4&#9.#3AA)%//#DE;5DFG5<5E<
! 9B#/%&&1$H#&7%#9.#3AA)%//#B314/I#J7%J*#&73&#there is no firewall blocking the operation.
! K()#(&7%)#L%&7(A/#(B#/%&&1$H#()#A1/J(0%)1$H#&7%#IP address of the AXIS 207/207W/207MW, e.g. in
other operating systems, see page 11.
Method Recommended for Operating system
AXIS IP Utility
See page 9.
Single cameras
Small installations
Windows
AXIS Camera Management
See page 10.
Multiple cameras
Large installations
Installations on other subnets
Windows 2000
Windows XP Pro
Windows 2003 Server

AXIS 207/207W/207MW Installation Guide Page 9
AXIS IP Utility - single camera/small installation
AXIS IP Utility automatically discovers
and displays Axis devices on your
network. The application can also be used
to manually set a static IP address.
Note that the computer running AXIS IP
Utility must be on the same network
segment (physical subnet) as the AXIS
207/207W/207MW.
Automatic discovery
1. Check that the AXIS 207/207W/
207MW is connected to the network
and that power has been applied.
2. Start AXIS IP Utility.
3. When the camera appears in the window, double-click it to open its home page.
4. See page 12 for instructions on how to set the password.
Set the IP address manually
1. Acquire an unused IP address on the same network segment your computer is connected
to.
2. Click the button Set IP address using serial number and enter the serial number
and IP address for the AXIS 207/207W/207MW. The serial number is located on the
product label.
3. Click the Set IP button and follow the instructions.
4. Click View Home Page&2*443)&43&(00#""&4.#&0(>#$(%"&-#2&7(:#"E
5. See page 12 for instructions on how to set the password.

Page 10 AXIS 207/207W/207MW Installation Guide
AXIS Camera Management - multiple cameras/large installations
AXIS Camera Management can automatically find and set IP addresses, show connection
status, and manage firmware upgrades for multiple Axis video products.
Set the IP address
for a single device
1. Check that the
camera is con-
nected to the net-
work and that
power has been
applied.
2. Start AXIS
Camera
Management.
When the AXIS
207/207W/
FGH'I&(77#($"&/)&4.#&-/)<3-,&<3*2+#80+/0J&/4&43&37#)&4.#&0(>#$(%"&.3>#&7(:#E&
3. See page 12 for instructions on how to set the password.
Set the IP address in multiple devices
AXIS Camera Management speeds up the process of assigning IP addresses to multiple
devices, by suggesting IP addresses from a specified range.
1. Select the devices you wish to configure (different models can be selected) and click the
Assign IP button.
2. Select Obtain IP addresses automatically (DHCP), click the Update button and the
program will search in the specified range and suggest an IP address for each device.
-or-
Enter the range of IP addresses, the subnet mask and default router that devices can use
and click the Update button.
