DATASHEET
This versatile network camera has a built-in 26x optical
zoom, auto focus lens and a 12x digital zoom. It provides
wide coverage with its ability to pan 340 degrees,
tilt 100 degrees and zoom in on specic details.
AXIS 213 PTZ delivers simultaneous MPEG-4 and
Motion JPEG video streams, allowing for optimization in
image quality and bandwidth. The MPEG-4 compression
mode is ideal for applications where available bandwidth
is restricted and higher frame rates are required.
AXIS 213 PTZ Network Camera enables advanced remote monitoring with pan, tilt and zoom through
operator control from any PC connected to a local area network or the Internet. It is ideal for
monitoring people and property – indoors and outdoors – and for remote learning and
troubleshooting.
AXIS 213 PTZ Network camera
Pan, tilt and zoom live video directly over your network.
> 26x optical zoom and
12x digital zoom
> Superior image
quality
> Operates under all
light conditions
> 20 preset positions
> Optional two-way
audio
The camera can be manually controlled or scheduled for
switching between color image during daytime, and
black/white image in low light or nighttime conditions
using the built-in IR lighting or an external IR lamp for
longer distances.
The camera provides 20 preset positions and 1 preset
sequence to monitor specic areas.
Two-way audio and alarm inputs/outputs are available
with the optional AXIS 213CM Connection Module.

Technical specications – AXIS 213 PTZ Network Camera
www.axis.com
©2009 Axis Communications AB. AXIS COMMUNICATIONS, AXIS, ETRAX, ARTPEC and VAPIX are registered trademarks or trademark applications of Axis AB
in various jurisdictions. All other company names and products are trademarks or registered trademarks of their respective companies. We reserve the right
to introduce modications without notice.
33081/EN/R2/0909
Camera
Models AXIS 213 PTZ: 50 Hz (PAL)
AXIS 213 PTZ: 60 Hz (NTSC)
Supports both desktop and ceiling mounting
Image sensor 1⁄4” Interlaced CCD
Lens 3.5 – 91 mm, F1.6 – F4.0, motorized zoom lens, auto focus, manual
day/night
Angle of view, horizontal: 1.7° – 47°
Minimum
illumination
Color mode: 1 lux, F1.6
IR mode: 0.1 lux, F1.6; using built-in IR light in complete darkness up
to 3 m (9.8ft)
Pan/Tilt/Zoom 20 preset positions
Pan: ±170°, 1 – 90°/sec
Tilt: -10 – 90°, 1 – 70°/sec
Zoom: 26x optical, 12x digital
Sequence mode, control queue
Supports Windows compatible joysticks
Designed for operator control*
* Not designed for continuous movements
Video
Video
compression
MPEG-4 Part 2 (ISO/IEC 14496-2)
Motion JPEG
Resolutions 160x90 to 704x576
Frame rate
MPEG-4
Up to 21/17 fps at 4CIF/2CIFExp
Up to 30/25 fps at 2CIF/CIF/QCIF
Frame rate
Motion JPEG
Up to 30/25 fps at 4 CIF
Video streaming Multi-stream Motion JPEG and MPEG-4
Controllable frame rate and bandwidth
VBR/CBR MPEG-4
Image settings Compression, backlight compensation, manual IR-cut filter
Day/Night, white balance, rotation, color/BW, brightness, noise
reduction, exposure control
Aspect ratio correction
Text and image overlay
De-interlace (4CIF Resolution)
Audio
Audio streaming Requires optional AXIS 213CM Connection Module
Two-way (full or half duplex) or one-way
Audio compression G.711 PCM 8 kHz 64kbit/s
G.726 ADPCM 8 kHz 32 or 24 kbit/s
Audio input/output AXIS 213CM Connection module
Network
Security Password protection, IP address filtering
Supported
protocols
IP, HTTP, FTP, SMTP, Bonjour, UPnP, DNS, DynDNS, NTP, RTSP, RTP,
TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
System integration
Application
Programming
Interface
Open API for software integration, including VAPIX®
from Axis Communications available at www.axis.com
Intelligent video Video motion detection
Alarm triggers Intelligent video and external input*
*Requires optional AXIS 213CM Connection Module
Alarm events File upload via FTP, HTTP and email
Notification via email, HTTP and TCP
External output activation
Video buffer 6 MB pre- and post alarm
General
Processors and
memory
ETRAX 100LX, ARTPEC-2, 32 MB RAM, 4 MB Flash
Power 11.5 – 14 V DC, max. 13 W
Connectors Ethernet 10BASE-T/100BASE-TX, RJ-45
26-pin multi-connector (to Connection Module)
Operating
conditions
5 – 40 ºC (41 – 104 ºF)
Humidity 20 – 80% RH (non-condensing)
Approvals EN 55022 Class B, EN55024, EN 61000-3-2, EN61000-3-3,
FCC Part 15 Subpart B Class B, VCCI Class B, ICES-003 Class B,
C-tick AS/NZS 3548, EN 60950-1
Power supply: EN 60950-1, UL, cUL
Dimensions
(HxWxD)
130 x 104 x 130 mm (5.1” x 4.1” x 5.1”)
Weight 700 g (1.55 lb.) excl. power supply
Included
accessories
Power supply, ceiling and desktop mount kit, Installation Guide,
CD with installation tools, recording software and User’s Manual,
Windows decoder 1-user license
More information is available at www.axis.com
Optional accessories
AXIS 295 Video Surveillance Joystick T90A IR illuminators
For information on AXIS Camera Station and
video management software from
Axis’ Application Development Partners,
see www.axis.com/products/video/software/
Various housings
AXIS 213CM Connection Module
Connectors 2 alarm inputs, 3 outputs
Composite video: 1 BNC output
Audio 3.5 mm line in, 3.5 mm line out
RS-232 9-pin D-Sub
Connection cable 1 m (3.3 ft)
AXIS 213CM Connection Module
