Axis Video Server 242S IV User manual

 Intelligent one channel video server
 Dedicated Digital Signal Processor for
advanced video & audio analysis
 Simultaneous Motion JPEG and MPEG-4
streams in resolutions up to 704x576
 Pre/post alarm buffering for securing
critical images
 Support for PTZ and dome cameras
 HTTPS encryption for network security
AXIS 242S IV
Video Server
The AXIS 242S IV Video Server is a one channel video server, equipped
with a Digital Signal Processor (DSP) from Texas Instruments.
This gives unique possibilities for executing advanced embedded
applications such as people counting, trip wire detection and other
advanced Intelligent Video solutions. Tailor-made Intelligent Video
applications for retail, transportation and security can also be
downloaded to the AXIS 242S IV for high-demanding video and
audio analysis.
All the analyses are done on site, inside the video server, making the
scalability infinite. It is capable of handling both video and audio
analyses, and includes sophisticated functions such as built-in
motion detection and powerful event management.
The AXIS 242S IV Video Server delivers high quality video at 30/25
(NTSC/PAL) frames per second with a de-interlace filter which
improves image quality in the highest resolution (4CIF). This feature
eliminates the motion blur problems caused by the analog video
signal. In addition, the video server is equipped with a complete set
of security features, including multiple user access levels, HTTPS
encryption and IP address filtering.
Intelligent video & audio
analysis inside

26446/EN/R3/0603
AXIS 242S IV Video Server
Specifications
Video compression Motion JPEG
MPEG-4 Part 2 (ISO/IEC 14496-2), Profiles: ASP and SP
Resolutions 4CIF, 2CIFExp, 2CIF, CIF, QCIF
Max 704x576 (PAL) 704x480 (NTSC)
Min 176x144 (PAL) 160x120 (NTSC)
Frame rate
(NTSC/PAL)
Motion JPEG: Up to 30/25 fps at 4CIF
MPEG-4: Up to 30/25 fps at 2CIF
21/17 fps at 4CIF
Video streaming Simultaneous Motion JPEG and MPEG-4
Controllable frame rate and bandwidth
Constant and variable bit rate (MPEG-4)
Processor and
memory for Intelligent
Video analysis
Digital Signal Processor (DSP) TMS320DM642
8MB Flash
32MB RAM
Processors and
memory for video
streaming
CPU: ETRAX 100LX 32bit
Video processing and compression: ARTPEC-2
RAM: 32 MB, Flash: 8 MB
Image settings Compression levels: 11 (Motion JPEG)/23 (MPEG-4)
Rotation: 90º, 180º, 270º
Aspect ratio correction
Color: Color, black & white
Overlay capabilities: time, date, text or image
De-interlace filter
Audio Microphone and line in for audio analysis
Security Multiple user access levels with password protection
including configurable access to PTZ interface
IP address filtering
HTTPS encryption
Alarm and event
management
Events triggered by IV application, built-in multi-window
motion detection, external inputs or according to a
schedule
Image upload over FTP, email and HTTP
Notification over TCP, email, HTTP and external outputs
Pre- and post alarm buffer of 9 MB (approx 4 min of CIF
resolution video at 4 frames per sec)
Pan/tilt/zoom A wide range of analog PTZ dome cameras is supported,
free drivers available at www.axis.com
20 presets/camera, guard tour, PTZ control queuing
Connectors Analog composite video, PAL/NTSC auto sensing inputs:
1 BNC input, 1 BNC output, 1 Y/C input
Ethernet 10BaseT/100BaseTX, RJ-45
Terminal block: 4 alarm inputs, 4 outputs, RS-485/422 half
duplex port and alternative power connection
D-Sub for RS-232 port
Audio: 3.5 mm jack for Mic in (max 54 mVpp) or Line in
(max 2.6 Vpp, mono)
Casing Metal casing. Standalone, stackable or with brackets for
wall- or cage mounting
Power 12 V DC, max 8 W
Operating conditions 5 - 40 ºC (41 – 104 ºF),
humidity 20 - 80% RH (non condensing)
Installation,
management and
maintenance
AXIS Camera Management tool on CD and web-based
configuration, configuration backup and restore
Firmware upgrades over HTTP or FTP, firmware available at
www.axis.com
Video access from
Web browser
Camera live view, sequence tour capability for up to 20
PTZ presets or other Axis video sources, customizable HTML
pages
Minimum
Web browsing
requirements
Pentium III CPU 500 MHz or higher, or equivalent AMD
128 MB RAM
AGP graphic card, Direct Draw, 32 MB RAM
Windows XP, 2000, NT4.0, ME or 98, DirectX 9.0 or later
Internet Explorer 5.x or later
For other operating systems and browsers see
www.axis.com/techsup
System integration
support
Powerful API for software integration available at
www.axis.com including AXIS VAPIX API, AXIS Media
Control SDK, event trigger data in video stream, embedded
scripting and access to serial port peripherals over HTTP/TCP
Watchdog secures continuous operation, can be monitored
by other systems via event notification
Embedded operating system: Linux 2.4
SDK for TI TMS320DM642 is not included
Supported protocols IP, HTTP, HTTPS, SSL/TLS*, TCP, ICMP, SNMPv1/v2c/v3
(MIB-II), RTSP, RTP, UDP, IGMP, RTCP, SMTP, FTP, DHCP,
UPnP, ARP, DNS, DynDNS, SOCKS. More information on
protocol usage available at www.axis.com
* This product includes software developed by the Open SSL Project for
use in the Open SSL Tool kit (www.openssl.org)
Intelligent Video
modules (not incl.)
AXIS IVM120 People Counter* – Downloadable Intelligent
Video module
Video management
software (not incl.)
AXIS Camera Station – Surveillance application for viewing,
recording and archiving up to 25 cameras
AXIS Camera Explorer – Basic software for viewing and
manual recording
See www.axis.com/partner/adp_partners.htm
for more software applications via partners
Included accessories Installation Guide, CD with User’s Manual, demo soft-ware,
installation and management tools, connector kit,
MPEG-4 licenses (1 encoder, 1 decoder), MPEG-4 decoder
(Windows), mounting brackets, power supply 12 V DC
Accessories (not incl.) AXIS MPEG-4 Decoder 10 user license pack
Approvals EN55022: Class B, EN61000-3-2, EN61000-3-3, EN 55024,
FCC Part 15 Subpart B Class B, VCCI Class B,
AS/NZS CISPR 22, EN60950
UL, CSA (power supply)
Dimensions
and weight
140 x 230 x 42 mm (5.51” x 9.06” x 1.65”)
754 g (110/16) excl. power supply
©2006, Axis Communications AB. The Axis logo is a registered trademark of Axis Communications AB. All other company names and products are trademarks or registered trademarks of their respective companies. We reserve the right to introduce modifications without notice.
www.axis.com
AXIS IVM120 People Counter is a tamper-proof software application developed for the AXIS 242S IV Video
Server, intended for shops and other indoor places where you need to count people. Easy to set up, with this
software you can instantly monitor your customer per hour, day or week over the network. Integrated with your
network, it supports your staff planning and entrance management. Collect data such as customer flows, trend
analyses, evaluation of advertising and promotions and enhance your strategic marketing decisions through
effective monitoring of customer traffic. Improve your network video surveillance system with new cost-efficient
possibilities.
* AXIS IVM120 People Counter
