AXISC1004-ENetworkCabinetSpeaker
UserManual

AXISC1004-ENetworkCabinetSpeaker
Solutionoverview
Solutionoverview
Towatchthisvideo,gotothewebversionofthisdocument.
www.axis.com/products/online-manual/25379
Anoverviewofhownetworkaudioworks.
2

AXISC1004-ENetworkCabinetSpeaker
Findthedevieonthenetwork
Findthedevieonthenetwork
TondAxisdevicesonthenetworkandassignthemIPaddressesinWindows®,useAXISIPtilityorAXISDeviceManager.Both
applicationsarefreeandcanbedownloadedfromaxis.com/support.
FormoreinformationabouthowtondandassignIPaddresses,seethedocumentHowtoassignanPaddressandaccessyour
deviceonthedevicepageataxis.com.
Browsersupport
Youcanusethedevicewiththefollowingbrowsers:
ChromeTMFirefox®Edge®Safari®
Windows®recommendedxx
OSX®recommendedx
Otheroperatingsystemsxx
Ifyouneedmoreinformationaboutrecommendedbrowsers,gotoaxis.com/browser-support.
3

AXISC1004-ENetworkCabinetSpeaker
Aessthedevie
Aessthedevie
1.OpenabrowserandentertheIPaddressorhostnameoftheAxisdevice.
IfyouhaveaMaccomputer(OSX),gotoSafari,clickBonjourandselectthedevicefromthedrop-downlist.Toadd
Bonjourasabrowserbookmark,gotoSafari>Preferences.
2.Entertheusernameandpassword.Ifyouaccessthedeviceforthersttime,youmustsettherootpassword.SeeSeta
newpasswordfortherootaccountonpage4.
Setanewpasswordfortherootaccount
Important
Thedefaultadministratorusernameisroot.Ifthepasswordforrootislost,resetthedevicetofactorydefaultsettings.
1.Typeapassword.Followtheinstructionsaboutsecurepasswords.SeeSecurepasswordsonpage4.
2.Retypethepasswordtoconrmthespelling.
3.ClickSave.Thepasswordhasnowbeencongured.
Securepasswords
Important
Axisdevicessendtheinitiallysetpasswordincleartextoverthenetwork.Toprotectyourdeviceaftertherstlogin,set
upasecureandencryptedHTTPSconnectionandthenchangethepassword.
Thedevicepasswordistheprimaryprotectionforyourdataandservices.Axisdevicesdonotimposeapasswordpolicyasthey
maybeusedinvarioustypesofinstallations.
Toprotectyourdatawestronglyrecommendthatyou:
•seapasswordwithatleast8characters,preferablycreatedbyapasswordgenerator.
•Don’texposethepassword.
•Changethepasswordatarecurringinterval,atleastonceayear.
4

AXISC1004-ENetworkCabinetSpeaker
Additionalsettings
Additionalsettings
Chanetherootpassword
1.Logintotheproduct’swebpageandgotoSystem>Users.
2.Fortherootuser,clickEdit.
3.Enteranewpasswordandsave.
Setupanewzone
1.Logintotheaudiodevicethatyouwanttosetastheleaderintheaudiosystem.
2.GotoAudio>Systemsettings.
3.Edittheleaderaudiodevice:
3.1Clickthepencil.
3.2Enteraudiodevicenameandenterusernameandpassword.
3.3ClickApply
4.Ifpossible,changetoMulticast.
5.Addaudiodevicestotheaudiosystem:
5.1nderAvailableaudiodevices,clicktheplussigntoaddanaudiodevicetothezone.Ifyourdeviceisnot
listed,clickAdddevicemanuallytoaddthedevice.
5.2Foreachaudiodevice,settheaudiodevicenameandenterusernameandpasswordforthatdevice.
5.3ClickApply.
Setvolumeandain
Volume
1.GotoAudio>Systemoverview.
2.sethesliderSystemunderVolumetosetthesystemvolume.
AxisAudioPlayer
1.GotoServicesandappsandopenAxisAudioPlayer.
2.Setthevolumelevelforsystem,announcementsandmusic.
Note
Themaximalvolumeforannouncementsandmusiccanneverbehigherthanthemaximalvolumeforthesystem.
Gain
1.GotoAudio>Devicesettings.
2.Ontheutput,settheutputgain.
3.OntheInputtab,settheInputgain.
5

AXISC1004-ENetworkCabinetSpeaker
Additionalsettings
4.GotoAudio>Systemoverview.
5.setheslidersbesideafollowertoadjustthegainforanaudiodevice.
Calibrateandrunremotespeakertest
Thespeakertestisatestthatcanbeinitiatedfromaremotelocationtoverifythatthespeakerisworkingasintended.Formore
information,seeSpeakertestonpage14.
Note
Duringcalibration,itisrecommendedthatsomeoneisphysicallypresentattheinstallationsitetolistentothetesttonesand
ensurethatthetesttonesarenotmufedorblockedbyanyunintendedobstructionsinthespeaker’sacousticpath.
Calibratetheaudiodevice:
1.GotoAudio>Devicesettings.
2.ClickCalibratetocalibratetheaudiodevice.
OncetheAxisproductiscalibrated,thespeakertestcanberunatanytime:
1.GotoAudio>Audiosettings.
2.ClickTesttorunthespeakertest.
Note
Itisalsopossibletorunthecalibrationbypressingthecontrolbutton.SeeProductoverviewonpage20toidentifythe
controlbutton.
Prepareanaudiocliplink
Audioclipscanbesettoplaywhenaneventoccurs.
Toprepareanaudiocliplink:
1.GotoAudio>Audioclips.
2.Clickforanaudioclip.
3.Setthevolumeandnumberoftimestorepeattheclip.
4.Clickthecopyicontocopythelink.
SetupdirectSIP(P2P)
VoIP(VoiceoverIP)isagroupoftechnologiesthatenablesvoiceandmultimediacommunicationoverIPnetworks.Formore,
seeVoiceoverP(VoP)onpage14.
InthisproductVoIPisenabledthroughtheSIPprotocol.FormoreinformationaboutSIP,seeSessionnitiationProtocol(SP)on
page14
TherearetwotypesofsetupsforSIP.Peer-to-peerisoneofthem.sepeer-to-peerwhenthecommunicationisbetweenafewuser
agentswithinthesameIPnetworkandthereisnoneedforextrafeaturesthataPBX-servercouldprovide.Forinformationon
howtosetitup,seePeer-to-peerSP(P2PSP)onpage14.
1.GotoVoIP>SIPsettingsandselectEnableSIP.
2.InCalltimeout,setthenumberofsecondsthatacallwilllastbeforeitendsifthereisnoanswer.
3.Toallowthedevicetoreceiveincomingcalls,selectAllowincomingcalls.
6

AXISC1004-ENetworkCabinetSpeaker
Additionalsettings
4.Setthenumberofsecondsbeforetimeoutforincomingcalls.
5.ClickSave.
6.InPortsettings,entertheSIPportnumberandSIPTLSportnumber.
Note
•SIPport–forSIPsessions.Signallingtrafcthroughthisportisnon-encrypted.Thedefaultportnumberis5060.
•SIPTLSport–forSIPSandTLSsecuredSIPsessions.SignallingtrafcthroughthisportisencryptedwithTransportLayer
Security(TLS).Thedefaultportnumberis5061.
•RTPstartport–EntertheportusedfortherstRTPmediastreaminaSIPcall.Thedefaultstartportformediatransportis
4000.SomerewallsmightblockRTPtrafconcertainportnumbers.Aportnumbermustbebetween1024and65535.
7.ClickSave.
8.InNATtraversal,selecttheprotocolsyouwanttoenableforNATtraversal.
Note
seNATtraversalwhenthedeviceisconnectedtothenetworkfrombehindaNATrouterorarewall.Formoreinformation
seeNATtraversalonpage15.
SetupSIPthrouhaserver(PBX)
VoIP(VoiceoverIP)isagroupoftechnologiesthatenablesvoiceandmultimediacommunicationoverIPnetworks.Formore,
seeVoiceoverP(VoP)onpage14.
InthisproductVoIPisenabledthroughtheSIPprotocol.FormoreinformationaboutSIP,seeSessionnitiationProtocol(SP)on
page14
TherearetwotypesofsetupsforSIP.APBX-serverisoneofthem.seaPBX-serverwhenthecommunicationshouldbebetweenan
innitenumberofuseragentswithinandoutsidetheIPnetwork.Additionalfeaturescouldbeaddedtothesetupdependingonthe
PBX-provider.Formoreinformationsee,PrivateBranchExchange(PBX)onpage15.
1.RequestthefollowinginformationfromyourPBXprovider:
-serID
-Domain
-Password
-AuthenticationID
-CallerID
-Registrar
-RTPstartport
2.GotoVoIP>SIPaccounts>Createaccount.
3.EnteraNamefortheaccount.
4.SelectRegistrar.
5.Selectatransportmode.
6.AddtheaccountinformationfromthePBXprovider.
7.ClickSave.
8.SetuptheSIPsettingsthesamewayasforpeer-to-peer.SeeSetupdirectSP(P2P)onpage6formoreinformation.
7

AXISC1004-ENetworkCabinetSpeaker
Additionalsettings
StopaudiowithDTMF
Thisexampleexplainshowto:
•CongureDTMFonadevice.
•SetupaneventtostoptheaudiowhenaDTMFcommandissenttothedevice.
Note
SIPmustbeactivatedbeforeyoucanusethisactionrule.
Note
FormoreinformationabouteventsseeSetuprulesandalertsonpage16.
1.GotoVoIP>DTMF.
2.Selectpeer-to-peerorregistraraccount.
3.ClickthepencilnexttotheSIPaccount.
4.ClickAdd.
5.IntheNameeld,enter"stopaudio".
6.IntheSequenceeld,enter"1".
7.ClickApplyandthenK.
8.GotoEvents>Management>ActionrulesandclickAdd.
9.IntheNameeld,enter"DTMFstopaudio".
10.Fromthelistoftriggers,selectCall,DTMFand“stop”.
11.Fromthelistofactions,selectStopaudioclipandthenclickK.
Sendanemailifaspeakertestfails
Severalactionsrulescanbecombined,orhavearelationtoeachother.Inthisexampletheaudiodeviceisconguredtosendan
emailtoadenedrecipientwhenaspeakertestfails.Thespeakertestisconguredtobeperformed18:00everyday.
Todothatthefollowingneedtobecongured:
•Arecurrence
•Aschedule
•Aspeakertestthatstartsaspecictime
•Anemailrecipient
•Theconditionofwhentosendtheemail
Note
Formoreinformationaboutspeakertest,seeSpeakertestonpage14.
1.Setuparecurrence:
1.1GotoEvents>Management>Recurrences.
1.2Createarecurrencethattriggersonceeveryday.Nameit"speakertestrecurrence".
8

AXISC1004-ENetworkCabinetSpeaker
Additionalsettings
2.Setupaschedule:
2.1GotoEvents>Management>Schedules.
2.2Createaschedulethatstartsat18:00andendsat18:01(everyday).Nameit"speakertestschedule".
3.Setupanautomatedspeakertest:
3.1GotoEvents>Management>ActionrulesandclickAdd.
3.2EnteranameandselectTimefromthetriggerlist.
3.3SelectRecurrenceandselect"speakertestrecurrence".
3.4Select"speakertestschedule".
3.5SelectRunspeakertestasactiontypeandclickK.
4.Createanemailrecipient:
4.1GotoEvents>Management>Recipients,andclickAdd.
4.2Nameit"speakertestrecipients"andselectEmailfromtheTypelist.
4.3EntertheemailaddressestosendemailstointheToeld.secommastoseparatemultipleaddresses.
4.4SelecttheemailproviderfromtheProviderlist.
4.5EntertheuserIDandpasswordfortheemailaccount.
4.6ClickTesttosendatestemail.
Note
Someemailprovidershavesecurityltersthatpreventusersfromreceivingorviewinglargeattachments,from
receivingscheduledemailsandsimilar.Checktheemailprovider’ssecuritypolicytoavoiddeliveryproblemsand
lockedemailaccounts.
5.Setuptheconditionofwhentosendtheemail:
5.1GotoEvents>Management>ActionrulesandclickAdd.
5.2EnteranameandselectSpeakertestfromthetriggerlist.
5.3SelectTestresultandselectFailed.
5.4SelectSendnoticationasactiontypeandselect"speakertestrecipients"asrecipient.
5.5EnterasubjectandamessageandclickK.
AXISAudioPlayer
seAXISAudioPlayertoadd,manageandschedulemusicplaylists,streamsandprerecordedannouncements.Tond
AXISAudioPlayer,gotothedevicewebpageandclickverview.
Addmusicandannouncementstothelibrary
1.GotoMUSIC.
2.Drag-and-droplesorbrowselestoaddmusictothelibrary.
Note
AllaudiolesarestoredontheSDcard.
9

AXISC1004-ENetworkCabinetSpeaker
Additionalsettings
Createaplaylist
1.ClickontheplussignnexttoPlayliststoaddanewplaylist.
2.EnteranameandclickSave.
Youcannowdraganddropmusiclesandannouncementsfromthelibrarytoyourplaylist.
NO NO
NOTCE TCE TCE
Whendeletingalefromtheplaylistitwillstillbeinthelibrary,butifyoudeletealeinthelibraryitwillbedeleted
bothinthelibraryandtheplaylist.
Addstreams
1.Ifyouhaveaproxy,clickthesettingsiconinthetoprightcornerandenteryourproxyaddress.Supportedstream
formatsareMP3,M3orPLS(playlistformat).
2.SelectMUSIC.
3.ClickontheplussignnexttoStreams.
4.WritethenameofthestreamandtheRLtoyourstream.
5.ClickSave.
Createaschedule
1.GototheScheduletab.
2.Clickanddragtocreateaboxoverthetimeslotyouwanttoplayaplaylistorstream.Thetimeanddatesettings
onthelocaldeviceareusedforallscheduledactivities.
3.InNewEvent:
-Choosetoplayeitherdirectlyfromthelibraryortoplayaplaylistorstream.
-Clickonthetimeforstartorendifyouwanttochangethetime.
4.ClickSave.
Scheduleannouncements
1.GototheScheduletab.
2.Click>.
3.Choosewhichannouncementtoplayandthetimetoplayit.
4.Theannouncementwillbemarkedintheschedulewith.
