Axis C1511 User manual

AXISC15Series
AXISC1510NetworkPendantSpeaker
AXISC1511NetworkPendantSpeaker
Usermanual

AXISC15Series
TableofContents
Solutionoverview...........................................3
Installation................................................4
Getstarted................................................5
Findthedeviceonthenetwork....................................5
Accessthedevice...............................................5
Additionalsettings..........................................7
Calibrateandrunaremotespeakertest.............................7
SetupdirectSIP(PP)...........................................7
SetupSIPthroughaserver(PBX)..................................8
Setuprulesforevents...........................................8
Learnmore................................................13
SessionInitiationProtocol(SIP)....................................13
Peer-to-peerSIP(PPSIP).........................................13
PrivateBranchExchange(PBX)....................................13
NATtraversal...................................................14
Applications....................................................14
Thewebinterface...........................................15
Status........................................................15
Audio.........................................................16
Recordings.....................................................18
Apps..........................................................19
System........................................................19
Maintenance...................................................39
Troubleshooting............................................41
Resettofactorydefaultsettings...................................41
Checkthecurrentrmwareversion.................................41
Upgradethermware............................................41
Technicalissues,cluesandsolutions................................41
Performanceconsiderations.......................................43
Specications..............................................44
Productoverview................................................44
LEDIndicators..................................................44
SDcardslot....................................................45
Buttons.......................................................45
Connectors....................................................45
APIcommands.............................................48
2

AXISC15Series
Solutionoverview
Solutionoverview
Thismanualdescribeshowyoumakethedeviceaccessibletoyouraudiosystem,andhowtocongurethedevicedirectlyfromits
interface(forinstancewhenyouusethedevicewithoutanaudioorvideomanagementsoftware).
Ifyouareusinganaudioorvideomanagementsoftware,youcanusethatsoftwareforconguringthedevice.Thefollowing
managementsoftwareareavailableforcontrollingyouraudiosystem:
•AXISAudioManagerdge—Audiomanagementsoftwareforsmallsystems.Comespre-installedonallaudiodevices
witharmwareequaltoorhigherthan10.0.
-AXISAudioManagerEdgeusermanual
•AXISAudioManagerPro—Advancedaudiomanagementsoftwareforlargesystems.
-AXISAudioManagerProusermanual
•AXISCameraStation—Advancedvideomanagementsoftwareforlargesystems.
-AXISCameraStationusermanual
•AXISCompanion—Videomanagementsoftwareforsmallsystems.
-AXISCompanionusermanual
Formoreinformation,seeAudiomanagementsoftware.
Towatchthisvideo,gotothewebversionofthisdocument.
help.axis.com/?&piaId74869&sectionsolution-overview
Anoverviewofhownetworkaudioworks.
3

AXISC15Series
Installation
Installation
Towatchthisvideo,gotothewebversionofthisdocument.
help.axis.com/?&piaId74869&sectionsolution-overview
Downloadtheinstallationguide(pdf):
•AXISC1510NetworkPendantSpeaker
axis.com/products/axis-c1510/support#support-resources
•AXISC1511NetworkPendantSpeaker
axis.com/products/axis-c1511/support#support-resources
4

AXISC15Series
Getstarted
Getstarted
Findthedeviceonthenetwork
TondAxisdevicesonthenetworkandassignthemIPaddressesinWindows®,useAXISIPUtilityorAXISDeviceManager.Both
applicationsarefreeandcanbedownloadedfromaxis.com/support.
FormoreinformationabouthowtondandassignIPaddresses,gotoHowtoassignanIPaddressandaccessyourdevice.
Browsersupport
Youcanusethedevicewiththefollowingbrowsers:
ChromeTMFirefox®EdgeTMSafari®
Windows®recommendedrecommended
macOS®recommendedrecommended
Linux®recommendedrecommended
Otheroperatingsystems*
*TouseAXISOSwebinterfacewithiOS15oriPadOS15,gotoSettings Settings
Settings> > >Safari Safari Safari> > >Advanced Advanced Advanced> > >Experimental Experimental ExperimentalFeatures Features Featuresanddisable
NSURLSessionWebsocket.
Ifyouneedmoreinformationaboutrecommendedbrowsers,gotoAXISOSPortal.
Accessthedevice
1.OpenabrowserandentertheIPaddressorhostnameoftheAxisdevice.
.Entertheusernameandpassword.Ifyouaccessthedeviceforthersttime,youmustsettherootpassword.SeeSeta
newpasswordfortherootaccountonpage5.
Setanewpasswordortherootaccount
Important
Thedefaultadministratorusernameisroot.Ifthepasswordforrootislost,resetthedevicetofactorydefaultsettings.See
Resettofactorydefaultsettingsonpage41
Towatchthisvideo,gotothewebversionofthisdocument.
help.axis.com/?&piaId74869&sectionset-a-new-password-for-the-root-account
Supporttip:Passwordsecurityconrmationcheck
1.Typeapassword.Followtheinstructionsaboutsecurepasswords.SeeSecurepasswordsonpage6.
.Retypethepasswordtoconrmthespelling.
5

AXISC15Series
Getstarted
3.ClickSave.Thepasswordhasnowbeencongured.
Securepasswords
Important
Axisdevicessendtheinitiallysetpasswordincleartextoverthenetwork.Toprotectyourdeviceaftertherstlogin,set
upasecureandencryptedHTTPSconnectionandthenchangethepassword.
Thedevicepasswordistheprimaryprotectionforyourdataandservices.Axisdevicesdonotimposeapasswordpolicyasthey
maybeusedinvarioustypesofinstallations.
Toprotectyourdatawestronglyrecommendthatyou:
•Useapasswordwithatleast8characters,preferablycreatedbyapasswordgenerator.
•Don’texposethepassword.
•Changethepasswordatarecurringinterval,atleastonceayear.
6

AXISC15Series
Additionalsettings
Additionalsettings
Calibrateandrunaremotespeakertest
Youcanrunaspeakertesttoverifyfromaremotelocationthataspeakerisworkingasintended.Thespeakerperformsthetestby
playingaseriesoftesttonesthatareregisteredbythebuilt-inmicrophone.Everytimeyourunthetest,theregisteredvaluesare
comparedwiththevaluesthatwereregisteredduringthecalibration.
Note
Thetestmustbecalibratedfromitsmountedpositionattheinstallationsite.Ifthespeakerismovedorifitslocal
surroundingschange,forinstanceifawallisbuiltorremoved,thespeakershouldbere-calibrated
Duringcalibration,itisrecommendedthatsomeoneisphysicallypresentattheinstallationsitetolistentothetesttonesand
ensurethatthetesttonesarenotmufedorblockedbyanyunintendedobstructionsinthespeaker’sacousticpath.
1.Gotothedeviceinterface>Audio>Speakertest.
.Tocalibratetheaudiodevice,clickCalibrate.
Note
OncetheAxisproductiscalibrated,thespeakertestcanberunatanytime.
3.Torunthespeakertest,clickRunthetest.
Note
Itisalsopossibletorunthecalibrationbypressingthecontrolbuttononthephysicaldevice.SeeProductoverviewonpage
44toidentifythecontrolbutton.
SetupdirectSIP(P2P)
Usepeer-to-peerwhenthecommunicationisbetweenafewuseragentswithinthesameIPnetworkandthereisnoneedforextra
featuresthataPBX-servercouldprovide.TobetterunderstandhowPPworks,seePeer-to-peerSIP(P2PSIP)onpage13.
Formoreinformationaboutsettingoptions,seeSIPonpage32.
1.GotoSystem>SIP>SIPsettingsandselectnableSIP.
.Toallowthedevicetoreceiveincomingcalls,selectAllowincomingcalls.
3.UnderCallhandling,setthetimeoutanddurationforthecall.
4.UnderPorts,entertheportnumbers.
-SIPport–ThenetworkportusedforSIPcommunication.Thesignalingtrafcthroughthisportisnon-encrypted.
Thedefaultportnumberis5060.Enteradifferentportnumberifrequired.
-TLSport–ThenetworkportusedforencryptedSIPcommunication.Thesignalingtrafcthroughthisportis
encryptedwithTransportLayerSecurity(TLS).Thedefaultportnumberis5061.Enteradifferentportnumber
ifrequired.
-RTPstartport–EntertheportusedfortherstRTPmediastreaminaSIPcall.Thedefaultstartportfor
mediatransportis4000.SomerewallsmightblockRTPtrafconcertainportnumbers.Aportnumbermust
bebetween104and65535.
5.UnderNATtraversal,selecttheprotocolsyouwanttoenableforNATtraversal.
Note
UseNATtraversalwhenthedeviceisconnectedtothenetworkfrombehindaNATrouterorarewall.Formoreinformation
seeNATtraversalonpage14.
7

AXISC15Series
Additionalsettings
6.UnderAudio,selectatleastoneaudiocodecwiththedesiredaudioqualityforSIPcalls.Drag-and-droptochange
thepriority.
7.UnderAdditional,selectadditionaloptions.
-UDP-to-TCPswitching–SelecttoallowcallstoswitchtransportprotocolsfromUDP(UserDatagramProtocol)
toTCP(TransmissionControlProtocol)temporarily.Thereasonforswitchingistoavoidfragmentation,and
theswitchcantakeplaceifarequestiswithin00bytesofthemaximumtransmissionunit(MTU)orlarger
than1300bytes.
-Allowviarewrite–SelecttosendthelocalIPaddressinsteadoftherouter'spublicIPaddress.
-Allowcontactrewrite–SelecttosendthelocalIPaddressinsteadoftherouter'spublicIPaddress.
-Registerwithserverevery–SethowoftenyouwantthedevicetoregisterwiththeSIPserverfortheexisting
SIPaccounts.
-DTMFpayloadtype–ChangesthedefaultpayloadtypeforDTMF.
8.ClickSave.
SetupSIPthroughaserver(PBX)
UseaPBX-serverwhenthecommunicationshouldbebetweenaninnitenumberofuseragentswithinandoutsidetheIPnetwork.
AdditionalfeaturescouldbeaddedtothesetupdependingonthePBX-provider.TobetterunderstandhowPPworks,seePrivate
BranchExchange(PBX)onpage13.
Formoreinformationaboutsettingoptions,seeSIPonpage32.
1.RequestthefollowinginformationfromyourPBXprovider:
-UserID
-Domain
-Password
-AuthenticationID
-CallerID
-Registrar
-RTPstartport
.Toaddanewaccount,gotoSystem>SIP>SIPaccountsandclick+Account.
3.EnterthedetailsyoureceivedfromyourPBXprovider.
4.SelectRegistered.
5.Selectatransportmode.
6.ClickSave.
7.SetuptheSIPsettingsthesamewayasforpeer-to-peer.SeeSetupdirectSIP(P2P)onpage7formoreinformation.
Setuprulesorevents
Youcancreaterulestomakeyourdeviceperformactionswhencertaineventsoccur.Aruleconsistsofconditionsandactions.The
conditionscanbeusedtotriggertheactions.Forexample,thedevicecanplayanaudioclipaccordingtoascheduleorwhenit
receivesacall,orsendanemailifthedevicechangesIPaddress.
8

AXISC15Series
Additionalsettings
Tolearnmore,checkoutourguideGetstartedwithrulesforevents.
Sendanemailiaspeakertestails
Inthisexampletheaudiodeviceisconguredtosendanemailtoadenedrecipientwhenaspeakertestfails.Thespeakertest
isconguredtobeperformed18:00everyday.
1.Setupascheduleforthespeakertest:
1.1Gotothedeviceinterface>System>vents>Schedules.
1.Createaschedulethatstartsat18:00andendsat18:01everyday.Nameit"Dailyat6pm".
.Createanemailrecipient:
.1Gotothedeviceinterface>System>vents>Recipients.
.ClickAddrecipient.
.3Nametherecipient"Speakertestrecipients"
.4UnderType,selectmail.
.5UnderSendemailto,entertheemailaddressesoftherecipients.Usecommastoseparatemultipleaddresses.
.6Enterthedetailsfortheemailaccountofthesender.
.7ClickTesttosendatestemail.
Note
Someemailprovidershavesecurityltersthatpreventusersfromreceivingorviewinglargeattachments,from
receivingscheduledemailsandsimilar.Checktheemailprovider’ssecuritypolicytoavoiddeliveryproblemsand
lockedemailaccounts.
.8ClickSave.
3.Setuptheautomatedspeakertest:
3.1Gotothedeviceinterface>System>vents>Rules.
3.ClickAddarule.
3.3Enteranamefortherule.
3.4UnderCondition,selectScheduleandselectfromthetriggerlist
3.5UnderSchedule,selectyourschedule(“Dailyat6pm”).
3.6UnderAction,selectRunautomaticspeakertest.
3.7ClickSave.
4.Setuptheconditionforsendinganemailwhenthespeakertestfails:
4.1Gotothedeviceinterface>System>vents>Rules.
4.ClickAddarule.
4.3Enteranamefortherule.
4.4UnderCondition,selectSpeakertestresult.
4.5UnderSpeakerteststatus,selectDidn’tpassthetest.
4.6UnderAction,selectSendnoticationtoemail.
9

AXISC15Series
Additionalsettings
4.7UnderRecipient,selectyourrecipient(“Speakertestrecipients”)
4.8Enterasubjectandamessage,andclickSave.
Playaudiowhenacameradetectsmotion
ThisexampleexplainshowtosetuptheaudiodevicetoplayanaudioclipwhenanAxisnetworkcameradetectsmotion.
Prerequisites
•TheAxisaudiodeviceandAxisnetworkcameraarelocatedonthesamenetwork.
•Themotiondetectionapplicationisconguredandrunninginthecamera.
1.Prepareanaudiocliplink:
1.1GotoAudio>Audioclips.
1.Click>Createlinkforanaudioclip.
1.3Setthevolumeandnumberoftimestorepeattheclip.
1.4Clickthecopyicontocopythelink.
.Createanactionrule:
.1GotoSystem>vents>Recipients.
.Click+Addrecipient.
.3Typeanamefortherecipient,forexample“Speaker”.
.4SelectHTTPfromtheTypedrop-downlist.
.5PastetheconguredlinkfromtheaudiodeviceintheURLeld.
.6Entertheusernameandpasswordoftheaudiodevice.
.7ClickSave.
.8GotoRulesandclick+Addarule.
.9Typeanamefortheactionrule,forexample"Playclip".
.10FromtheConditionlist,selectavideomotiondetectionalternativeunderApplications.
Note
Iftherearenooptionsforvideomotiondetection,thengotoApps,clickAXISVideoMotionDetectionand
turnonmotiondetection.
.11FromtheActionlist,selectSendnoticationthroughHTTP.
.1UnderRecipient,selectyourrecipient.
.13ClickSave.
StopaudiowithDTMF
Thisexampleexplainshowto:
•CongureDTMFonadevice.
•SetupaneventtostoptheaudiowhenaDTMFcommandissenttothedevice.
10

AXISC15Series
Additionalsettings
1.GotoSystem>SIP>SIPsettings.
.MakesurenableSIPisturnedon.
Ifyouneedtoturniton,remembertoclickSaveafterwards.
3.GotoSIPaccounts.
4.NexttotheSIPaccount,click>dit.
5.UnderDTMF,click+DTMFsequence.
6.UnderSequence,enter"1".
7.UnderDescription,enter"stopaudio".
8.ClickSave.
9.GotoSystem>vents>Rulesandclick+Addarule.
10.UnderName,enter"DTMFstopaudio".
11.UnderCondition,selectDTMF.
1.UnderDTMFventID,selectstopaudio.
13.UnderAction,selectStopplayingaudioclip.
14.ClickSave.
SetupaudioorincomingSIPcalls
YoucansetuparulethatplaysanaudioclipwhenyoureceiveaSIPcall.
YoucanalsosetupanadditionalrulethatanswerstheSIPcallautomaticallyaftertheaudiocliphasended.Thiscanbeusefulin
caseswhereanalarmoperatorwantstocalltheattentionofsomeonenearanaudiodeviceandestablishalineofcommunication.
ThisisdonebymakingaSIPcalltotheaudiodevice,whichwillplayanaudiocliptoalertthepersonsneartheaudiodevice.When
theaudiocliphasstoppedplaying,theSIPcallisautomaticallyansweredbytheaudiodeviceandcommunicationbetweenthealarm
operatorandthepersonsneartheaudiodevicecantakeplace.
EnableSIPsettings:
1.Gotothedeviceinterfaceofthespeaker,byenteringitsIPaddressinawebbrowser.
.GotoSystem>SIP>SIPsettingsandselectnableSIP.
3.Toallowthedevicetoreceiveincomingcalls,selectAllowincomingcalls.
4.ClickSave.
5.GotoSIPaccounts.
6.NexttotheSIPaccount,click>dit.
7.UncheckAnswerautomatically.
PlayaudiowhenaSIPcallisreceived:
1.GotoSettings>System>vents>Rulesandaddarule.
.Typeanamefortherule.
3.Inthelistofconditions,selectState.
11

AXISC15Series
Additionalsettings
4.Inthelistofstates,selectRinging.
5.Inthelistofactions,selectPlayaudioclip.
6.Inthelistofclips,selecttheaudioclipyouwanttoplay.
7.Selecthowmanytimestorepeattheaudioclip.0means“playonce”.
8.ClickSave.
AnswertheSIPcallautomaticallyaftertheaudiocliphasended:
1.GotoSettings>System>vents>Rulesandaddarule.
.Typeanamefortherule.
3.Inthelistofconditions,selectAudioclipplaying.
4.CheckUsethisconditionasatrigger.
5.CheckInvertthiscondition.
6.Click+Addaconditiontoaddasecondconditiontotheevent.
7.Inthelistofconditions,selectState.
8.Inthelistofstates,selectRinging.
9.Inthelistofactions,selectAnswercall.
10.ClickSave.
12

AXISC15Series
Learnmore
Learnmore
SessionInitiationProtocol(SIP)
TheSessionInitiationProtocol(SIP)isusedtosetup,maintainandterminateVoIPcalls.Youcanmakecallsbetweentwoormore
parties,calledSIPuseragents.TomakeaSIPcallyoucanuse,forexample,SIPphones,softphonesorSIP-enabledAxisdevices.
TheactualaudioorvideoisexchangedbetweentheSIPuseragentswithatransportprotocol,forexampleRTP(Real-Time
TransportProtocol).
Youcanmakecallsonlocalnetworksusingapeer-to-peersetup,oracrossnetworksusingaPBX.
Peer-to-peerSIP(P2PSIP)
ThemostbasictypeofSIPcommunicationtakesplacedirectlybetweentwoormoreSIPuseragents.Thisiscalledpeer-to-peerSIP
(PPSIP).Ifittakesplaceonalocalnetwork,allthat’sneededaretheSIPaddressesoftheuseragents.AtypicalSIPaddressinthis
casewouldbesip:<local-ip>.
xample
SIP
sip:192.168.1.101 sip:192.168.1.100
YoucansetupaSIP-enabledphonetocallanaudiodeviceonthesamenetworkusingapeer-to-peerSIPsetup.
PrivateBranchExchange(PBX)
WhenyoumakeSIPcallsoutsideyourlocalIPnetwork,aPrivateBranchExchange(PBX)canactasacentralhub.Themain
componentofaPBXisaSIPserver,whichisalsoreferredtoasaSIPproxyoraregistrar.APBXworkslikeatraditionalswitchboard,
showingtheclient'scurrentstatusandallowingforexamplecalltransfers,voicemail,andredirections.
ThePBXSIPservercanbesetupasalocalentityoroffsite.Itcanbehostedonanintranetorbyathirdpartyprovider.Whenyou
makeSIPcallsbetweennetworks,callsareroutedthroughasetofPBXs,thatquerythelocationoftheSIPaddresstobereached.
EachSIPuseragentregisterswiththePBX,andcanthenreachtheothersbydialingthecorrectextension.AtypicalSIPaddressin
thiscasewouldbesip:<user>@<domain>orsip:<user>@<registrar-ip>.TheSIPaddressisindependentofitsIP
addressandthePBXmakesthedeviceaccessibleaslongasitisregisteredtothePBX.
xample
13

AXISC15Series
Learnmore
SIP
SIP
SIP
sip:[e-mail]
PBX
sip.company.com
sip:[e-mail]
sip:[e-mail]
NATtraversal
UseNAT(NetworkAddressTranslation)traversalwhentheAxisdeviceislocatedonanprivatenetwork(LAN)andyouwantto
accessitfromoutsideofthatnetwork.
Note
TheroutermustsupportNATtraversalandUPnP®.
EachNATtraversalprotocolcanbeusedseparatelyorindifferentcombinationsdependingonthenetworkenvironment.
•ICTheICEInteractiveConnectivityEstablishment)protocolincreasesthechancesofndingthemostefcientpathto
successfulcommunicationbetweenpeerdevices.IfyoualsoenableSTUNandTURN,youimprovetheICEprotocol’s
chances.
•STUN-STUN(SessionTraversalUtilitiesforNAT)isaclient-servernetworkprotocolthatletstheAxisdevicedetermineif
itislocatedbehindaNATorrewall,andifsoobtainthemappedpublicIPaddressandportnumberallocatedfor
connectionstoremotehosts.EntertheSTUNserveraddress,forexample,anIPaddress.
•TURN-TURN(TraversalUsingRelaysaroundNAT)isaprotocolthatletsadevicebehindaNATrouterorrewallreceive
incomingdatafromotherhostsoverTCPorUDP.EnterTURNserveraddressandthelogininformation.
Applications
Withapplications,youcangetmoreoutofyourAxisdevice.AXISCameraApplicationPlatform(ACAP)isanopenplatformthat
makesitpossibleforthirdpartiestodevelopanalyticsandotherapplicationsforAxisdevices.Applicationscanbepreinstalledonthe
device,availablefordownloadforfree,orforalicensefee.
TondtheusermanualsforAxisapplications,gotohelp.axis.com.
14

AXISC15Series
Thewebinterface
Thewebinterface
Toreachthedevice’swebinterface,typethedevice’sIPaddressinawebbrowser.
Showorhidethemainmenu.
Accessthereleasenotes.
Accesstheproducthelp.
Changethelanguage.
Setlightthemeordarktheme.
Theusermenucontains:
•Informationabouttheuserwhoisloggedin.
•Changeaccount:Logoutfromthecurrentaccountandlogintoanewaccount.
•Logout:Logoutfromthecurrentaccount.
Thecontextmenucontains:
•Analyticsdata:Accepttosharenon-personalbrowserdata.
•Feedback:Shareanyfeedbacktohelpusimproveyouruserexperience.
•Legal:Viewinformationaboutcookiesandlicenses.
•About:Viewdeviceinformation,includingrmwareversionandserialnumber.
Status
Audiosysteminfo
ThisinformationisonlyshownfordevicesthatbelongtoanAXISAudioManagerEdgesite.
AXISAudioManagerdge:LaunchAXISAudioManagerEdge.
Locatedevice
Showsthelocatedeviceinformation,includingserialnumberandIPaddress.
Locatedevice:Playsasoundthathelpsyouidentifythespeaker.Forsomeproducts,thedevicewillashaLED.
Speakertest
Showswhetherthespeakerhasbeencalibratedornot.
Speakertest::Calibratethespeaker.TakesyoutotheSpeakertestpagewhereyoucandothecalibrationandrunthe
speakertest.
15

AXISC15Series
Thewebinterface
Deviceinfo
Showsthedeviceinformation,includingrmwareversionandserialnumber.
Upgradermware:Upgradethermwareonyourdevice.TakesyoutotheMaintenancepagewhereyoucandoarmware
upgrade.
Timesyncstatus
ShowsNTPsynchronizationinformation,includingifthedeviceisinsyncwithanNTPserverandthetimeremaininguntil
thenextsync.
NTPsettings:ViewandupdatetheNTPsettings.TakesyoutotheDateandtimepagewhereyoucanchangetheNTPsettings.
Security
Showswhatkindofaccesstothedevicethatisactive,andwhatencryptionprotocolsareinuse.Recommendationstothesettings
arebasedontheAXISOSHardeningGuide.
Hardeningguide:LinktoAXISOSHardeningguidewhereyoucanlearnmoreaboutcybersecurityonAxisdevicesandbest
practices.
Connectedclients
Showsthenumberofconnectionsandconnectedclients.
Viewdetails:Viewandupdatethelistoftheconnectedclients.ThelistshowsIPaddress,protocol,port,andPID/Process
ofeachclient.
Ongoingrecordings
Showsongoingrecordingsandtheirdesignatedstoragespace.
Recordings:Viewongoingandlteredrecordingsandtheirsource.Formoreinformation,seeRecordingsonpage18
Showsthestoragespacewheretherecordingissaved.
Audio
AXISAudioManagerEdge
AXISAudioManagerdge:Launchtheapplication.
Devicesettings
Input:Turnonoroffaudioinput.Showsthetypeofinput.
Gain:Usetheslidertochangethegain.Clickthemicrophoneicontomuteorunmute.
Inputtype:Selectthetypeofinput.
Powertype:Selectthetypeofpower.
Output:Showsthetypeofoutput.
16

AXISC15Series
Thewebinterface
Gain:Usetheslidertochangethegain.Clickthespeakericontomuteorunmute.
Stream
ncoding:Selecttheencodingtousefortheinputsourcestreaming.Youcanonlychooseencodingifaudioinputisturnedon.If
audioinputisturnedoff,clicknableaudioinputtoturniton.
chocancellation:Turnontoremoveechoesduringtwo-waycommunication.
Audioclips
Addclip:Addanewaudioclip.Youcanuse.au,.mp3,.opus,.vorbis,.wavles.
Playtheaudioclip.
Stopplayingtheaudioclip.
Thecontextmenucontains:
•Rename:Changethenameoftheaudioclip.
•Createlink:CreateaURLthat,whenused,playstheaudiocliponthedevice.Specifythevolumeandnumber
oftimestoplaytheclip.
•Download:Downloadtheaudiocliptoyourcomputer.
•Delete:Deletetheaudioclipfromthedevice.
Listenandrecord
Clicktolisten.
Startacontinuousrecordingoftheliveaudiostream.Clickagaintostoptherecording.Ifarecordingisongoing,itwill
resumeautomaticallyafterareboot.
Note
Youcanonlylistenandrecordifinputisturnedonforthedevice.GotoAudio>Devicesettingstomakesureyou
turnoninput.
Showstheconguredstorageforthedevice.Tocongurethestorage,youneedtobeloggedinasanadministrator.
Audiositesecurity
CAcerticate:Selectthecerticatetousewhenyouadddevicestotheaudiosite.YouhavetoenableTLSauthenticationin
AXISAudioManagerEdge.
Save:Activateandsaveyourselection.
17

AXISC15Series
Thewebinterface
Speakertest
Youcanusethespeakertesttoverifyremotelythatthespeakerworksasintended.
Calibrate:Youneedtocalibratethespeakerbeforeitsrsttest.Duringcalibration,thespeakerplaysaseriesoftesttonesthatare
registeredbythebuilt-inmicrophone.Whenyoucalibratethespeaker,itmustbeinstalledinitsnalposition.Ifyoumovethe
speakerlater,orifitssurroundingschange,forexample,ifawallisbuiltorremoved,youneedtorecalibratethespeaker.
Runthetest:Playthesameseriesoftesttonesthatwereplayedduringcalibration,andcomparethemwiththecalibration’s
registeredvalues.
Recordings
Clicktoltertherecordings.
From:Showrecordingsdoneafteracertainpointintime.
To:Showrecordingsupuntilacertainpointintime.
Source:Showrecordingsbasedonsource.Thesourcereferstothesensor.
vent:Showrecordingsbasedonevents.
Storage:Showrecordingsbasedonstoragetype.
Ongoingrecordings:Showallongoingrecordingsonthedevice.
Startarecordingonthedevice.
Choosewhichstoragedevicetosaveto.
Stoparecordingonthedevice.
Triggeredrecordingswillendwhenmanuallystoppedorwhenthedeviceisshutdown.
Continuousrecordingswillcontinueuntilmanuallystopped.Evenifthedeviceisshutdown,therecordingwillcontinuewhen
thedevicestartsupagain.
Playtherecording.
Stopplayingtherecording.
Showorhideinformationandoptionsabouttherecording.
Setexportrange:Ifyouonlywanttoexportpartoftherecording,enteratimespan.
ncrypt:Selecttosetapasswordforexportedrecordings.Itwillnotbepossibletoopentheexportedlewithoutthepassword.
Clicktodeletearecording.
xport:Exportthewholeorapartoftherecording.
18

AXISC15Series
Thewebinterface
Apps
Addapp:Installanewapp.
Findmoreapps:Findmoreappstoinstall.YouwillbetakentoanoverviewpageofAxisapps.
Allowunsignedapps:Turnontoallowinstallationofunsignedapps.
Allowroot-privilegedapps:Turnontoallowappswithrootprivilegesfullaccesstothedevice.
ViewthesecurityupdatesinAXISOSandACAPapps.
Note
Thedevice’sperformancemightbeaffectedifyourunseveralappsatthesametime.
Usetheswitchnexttotheappnametostartorstoptheapp.
Open:Accesstheapp’ssettings.Theavailablesettingsdependontheapplication.Someapplicationsdon’thaveanysettings.
Thecontextmenucancontainoneormoreofthefollowingoptions:
•Open-sourcelicense:Viewinformationaboutopen-sourcelicensesusedintheapp.
•Applog:Viewalogoftheappevents.Thelogishelpfulwhenyoucontactsupport.
•Activatelicensewithakey:Iftheapprequiresalicense,youneedtoactivateit.Usethisoptionifyourdevice
doesn’thaveinternetaccess.
Ifyoudon’thavealicensekey,gotoaxis.com/products/analytics.YouneedalicensecodeandtheAxisproductserial
numbertogeneratealicensekey.
•Activatelicenseautomatically:Iftheapprequiresalicense,youneedtoactivateit.Usethisoptionifyourdevicehas
internetaccess.Youneedalicensecodetoactivatethelicense.
•Deactivatethelicense:Deactivatethelicensetoreplaceitwithanotherlicense,forexample,whenyouchangefroma
triallicensetoafulllicense.Ifyoudeactivatethelicense,youalsoremoveitfromthedevice.
•Settings:Conguretheparameters.
•Delete:Deletetheapppermanentlyfromthedevice.Ifyoudon’tdeactivatethelicenserst,itremainsactive.
System
Timeandlocation
Dateandtime
Thetimeformatdependsonthewebbrowser’slanguagesettings.
Note
Werecommendyousynchronizethedevice’sdateandtimewithanNTPserver.
19

AXISC15Series
Thewebinterface
Synchronization:Selectanoptionforthedevice’sdateandtimesynchronization.
•Automaticdateandtime(manualNTSKservers):SynchronizewiththesecureNTPkeyestablishmentservers
connectedtotheDHCPserver.
-ManualNTSKservers:EntertheIPaddressofoneortwoNTPservers.WhenyouusetwoNTPservers,
thedevicesynchronizesandadaptsitstimebasedoninputfromboth.
•Automaticdateandtime(NTPserversusingDHCP):SynchronizewiththeNTPserversconnectedtotheDHCPserver.
-FallbackNTPservers:EntertheIPaddressofoneortwofallbackservers.
•Automaticdateandtime(manualNTPservers):SynchronizewithNTPserversofyourchoice.
-ManualNTPservers:EntertheIPaddressofoneortwoNTPservers.WhenyouusetwoNTPservers,the
devicesynchronizesandadaptsitstimebasedoninputfromboth.
•Customdateandtime:Manuallysetthedateandtime.ClickGetfromsystemtofetchthedateandtimesettings
oncefromyourcomputerormobiledevice.
Timezone:Selectwhichtimezonetouse.Timewillautomaticallyadjusttodaylightsavingtimeandstandardtime.
Note
Thesystemusesthedateandtimesettingsinallrecordings,logs,andsystemsettings.
Devicelocation
Enterwherethedeviceislocated.Yourvideomanagementsystemcanusethisinformationtoplacethedeviceonamap.
•Latitude:Positivevaluesarenorthoftheequator.
•Longitude:Positivevaluesareeastoftheprimemeridian.
•Heading:Enterthecompassdirectionthatthedeviceisfacing.0isduenorth.
•Label:Enteradescriptivenameforthedevice.
•Save:Clicktosaveyourdevicelocation.
Network
IPv4
AssignIPv4automatically:SelecttoletthenetworkrouterassignanIPaddresstothedeviceautomatically.Werecommend
automaticIP(DHCP)formostnetworks.
IPaddress:EnterauniqueIPaddressforthedevice.StaticIPaddressescanbeassignedatrandomwithinisolatednetworks,
providedthateachaddressisunique.Toavoidconicts,werecommendyoucontactyournetworkadministratorbeforeyou
assignastaticIPaddress.
Subnetmask:Enterthesubnetmasktodenewhataddressesareinsidethelocalareanetwork.Anyaddressoutsidethelocal
areanetworkgoesthroughtherouter.
Router:EntertheIPaddressofthedefaultrouter(gateway)usedtoconnectdevicesthatareattachedtodifferentnetworksand
networksegments.
FallbacktostaticIPaddressifDHCPisn’tavailable:SelectifyouwanttoaddastaticIPaddresstouseasfallbackifDHCP
isunavailableandcan’tassignanIPaddressautomatically.
Note
IfDHCPisn’tavailableandthedeviceusesastaticaddressfallback,thestaticaddressisconguredwithalimitedscope.
IPv6
AssignIPv6automatically:SelecttoturnonIPv6andtoletthenetworkrouterassignanIPaddresstothedeviceautomatically.
Hostname
20
