AXISQ2101-TEThermalCamera
Repaintinginstructions

AXISQ2101-TEThermalCamera
Impactonwarranty
Impactonwarranty
ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat
axis.com/warranty-implication-when-repainting.
Riskswithrepainting
ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training
ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:
ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD
damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.
Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.
Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.
Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems
withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe
parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.
2

AXISQ2101-TEThermalCamera
Repainttheproduct
Repainttheproduct
Preparations
•Ifapplicable,disassemblethedeviceaccordingtotheinstructionsinthisdocument.
•Cleanallpartsthatwillberepaintedthoroughlytoremovegrease,dust,oroil.
•Toensurereassemblyandfunctionalityoftheproduct,maskanyopenings(forexampleforscrews,LEDindicators,
ormicrophones)beforeyoupaint.
•Toavoidunwantedreections,masktheinsideoftheweathershieldbeforeyoupaint.
Pretreatmentofparts
Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto
adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.
Powdercoatedparts-Useaprimer.Alternatively,removetheoriginalpowdercoatingdowntothebasematerial,usingne
sandpaper,andcleanthepartsbeforepainting.
Anodisedandchromatedparts-Useaprimer.
Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.
Plastic-Useaprimer.
Thematerialsusedinthisproductare:
•Weathershield:plastic
•Therestofthechassis:powdercoated
3

AXISQ2101-TEThermalCamera
Repainttheproduct
isassembly
isassemblethehousing
1Screws(4x,T20)
2Bottomchassis
3Topcoer
1.Removethebottomchassisfromthetopcover.
4

AXISQ2101-TEThermalCamera
Repainttheproduct
1Screws(2x,T20)
2Weathershield
2.Removetheweathershieldfromthetopcover.
5

AXISQ2101-TEThermalCamera
Repainttheproduct
Masking
Maskingthetopcover
1Ventmembrane
2Label
3Inside
4Screwholes(4x)
5Frontwindow
Maskthefollowingpartsofthetopcover:
1.Theventmembrane.
2.Thelabel.
3.Everythingontheinsideincludingthesealingsurfacetothebottomchassis.
4.Thescrewholes.
5.Thefrontwindowincludingtheblackareas.
6

AXISQ2101-TEThermalCamera
Repainttheproduct
Maskingthebottomchassis
1Label
2Wallmountsurface
3Topside
Maskthefollowingpartsofthebottomchassis:
1.Theproductlabel.
2.Thesurfaceundertheadapterforthewallmount.
3.Everythingonthetopsideofthebottomchassis,includingthegasketandthefourscrewholes.
4.Thefourscrewholes.
7

AXISQ2101-TEThermalCamera
Repainttheproduct
Maskingtheweathershield
1Black
Masktheblackpartoftheweathershield.
Repainting
1.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.
2.Letthepaintdry.
3.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.
4.Whenthepaintisdry,removethemaskingandreassembletheproduct.
Reassembly
Reassembletheproductaccordingtotheinstructionsintheinstallationguideavailableataxis.com.
8

RepaintinginstructionsVer.M1.3
AXISQ2101-TEThermalCameraDate:February2023
