Axminster Universal Sub Base User manual

Axminster Universal Sub Base
Instruction Manual
718650
Axminster Universal Base
210118
Fixing Kit
702699
Optional Accessories
Steel Guide Bushes
340924-340936

Some routers can be difficult to match up with
suitable guide bushes and a universal sub base can
be the only solution. A round base can be
preferable in many circumstances too.The
Axminster sub base is precision machined from
aluminium and fitted with a low friction surface for
ease of use. It is designed to accept standard
Axminster or Trend style guide bushes and holes
for these are drilled with an M4 thread. It is also
designed for mounting to a very wide range of
different routers, including Bosch, Makita, Elu,
Dewalt, Festool, Trend, Ryobi and Hitachi models to
name a few.
Dimentions: 176mm diameter x 7mm thickness.
ATLAS COPCO OFSE2000 2 Fx3
BOSCH GOF1600,1700ACE POF52, 1 Fx2
400,500A,600ACE 3 Fx2
POF800ACE.GOF900A <2003 4 Gx3
GOF1300ACE,900A>2003 5 Gx3
GMF1400 0 Ix4
CASALS FT750,1000E,2000VCE 2 Fx3
CMT CMT1E,CMT2E 1 Fx2
DEWALT DW613,614,615,620,621, 1 Fx2
DW625EK.629 1 Fx2
DRAPER R1900V 2 Fx3
PT1200V 1 Fx3
ELU OF97(E),MOF177(E),131,98, 1 Fx2
MOF77,96(E) MK2,69' 1 Fx2
FELISATTI TP246(E) 6 Ex2
R346EC 1 Ex2
FESTO OF2000(E) 7 Ex3
OF1E,900(E),1000(E) 8 Bx4
FREUD FT1000(E),2000E 2 Fx3
HITACHI FM8,ZK2008 9 Ex2
M8(V) 10 Dx4
M12V,M12SA 11 Dx4
TR12 11&12 Dx4
MAFELL L050E 8 Bx4
MAKITA 3620,3612BR,3600B 13 Dx2
3612(C) 14 Ex2
RP0910,1110C 1 Fx2
METABO OF1028,1612,OFE1229,1812 6 Ex2
PERFORMANCE CLM1250R<11/03 18 Ax3
PRO CLM1250R >11/03,CLM2050R 1 Fx2
PERLES OF808(E)>1999',2-808(E) 1 Hx2
OF9(E) 1 Hx2
PEUGEOT DEF570E.DF55E 15 Ex2
RYOBI RE600N,R600N,RE601 13 Dx2
ERT1500V 13 Dx2
R500,502 16 Ax4
R150,151,RE120,155K 15 Ex2
SKIL 1835U.1875U1 17 Cx3
SPARKY X52E 9 Ex2
TREND T3,T4,T5,T5MK2',T9,T10,T11 1 Hx2
WADKIN R500 16 Ax4
Introduction
Router Chart
Router Model
Hole

Precision Steel Guide Bushes
(Avaliable Separately)
%
340924 10.0mm OD Guide Bush
340925 12.0mm OD Guide Bush
340926 14.0mm OD Guide Bush
340927 16.0mm OD Guide Bush
340928 18.0mm OD Guide Bush
340929 20.0mm OD Guide Bush
340930 22.0mm OD Guide Bush
340931 24.0mm OD Guide Bush
340932 26.0mm OD Guide Bush
340933 28.0mm OD Guide Bush
340934 30.0mm OD Guide Bush
340935 32.0mm OD Guide Bush
340936 Set of 12 Bushes Guide Bushes
Order No Description
1
2
3
4
5
ø
Universal Base
A
M4x10mm
B
M4x12mm
C
UNF10
x1/2"
D
M5x16mm
E
M5x20mm
F
M6x16mm
G
M6x30mm
H
M6x12mm
I
M4x6mm
176mm
7mm

Axminster universal Sub Base
Instruction Manual
www.axminster.co.uk
freephone 0800 371822
Axminster, Devon EX13 5PH
