AZUD HELIX AUTOMATIC 201 DLP User manual

MASF0044-02
USER’S MANUAL
Water Filtration Solutions
Sistema Azud, S.A. Tel. + 34 968 80 84 02 Fax: + 34 968 80 83 02 E-mail: [email protected] www.azud.com
AZUD HELIX AUTOMATIC 201 DLP

Water Filtration Solutions
2
System of symbols used in this manual:
In the reading of this manual you will find some signs used as information points to warn and to identify
risks. This is the format and content of these messages:
It Indicates instructions and warnings which failure to follow could cause
damages to people, the Equipment and its surroundings.
This manual is subject to modifications without prior warning.

Water Filtration Solutions
1. INTRODUCTION 4
2. FEATURES OF THE FILTRATION EQUIPMENT 4
2.1 Exclusive use of the Filtration Equipment.
2.2 Identification of the Product.
2.3 Operation Description.
2.4 Components and Spares.
2.5 Backflushing Valves.
3. TECHNICAL DATA 9
3.1 AZUD HELIX AUTOMATIC General Features and requirements. Serie 201.
3.2 Dimensions.
3.3 Azud Helix Automatic Filter.
4. SECURITY INFORMATION 11
5. INSTALLATION INSTRUCTIONS 12
5.1. Separation of the Equipment from the pallet.
5.2 Adjustment of the supports of the Equipment
5.3 Fastening the equipment to the floor.
5.4 Connection of the equipment.
5.5 Neumatic connection of the equipment and the Control Unit.
6. OPERATION INSTRUCTIONS 15
6.1 Start-up AZUD HELIX AUTOMATIC equipment.
6.2 Opening and closure of AZUD filters.
7. MAINTENANCE INSTRUCTIONS. 16
7.1 Maintenance Chart.
7.2. General inspection of the Equipment
7.3 Inspection of the filters
7.3.1 Cleaning of discs
7.3.2 Inspection of the gaskets.
7.3.3 Inspection of the movable elements of the base of the filtering element.
7.3.4 Inspection of the Piston elements
7.4 Inspection of the components.
7.4.1 ¾” Auxiliary Filter inspection.
7.4.2 ¼” Intake filter inspection.
7.4.3 Grooved couplings maintenance.
8. POSSIBLE PROBLEMS – CAUSES – SOLUTIONS. 21
9. WARRANTY. 24
INDEX

Water Filtration Solutions
4
2. Features of the Filtration System.
1. Introduction.
Thank you for trusting in AZUD HELIX AUTOMATIC equipments to solve your filtration
requirements. Please read carefully this manual and you will find answer to most of your questions.
IF YOU HAVE ANY QUESTION OR NEED ADITIONAL INFORMATION; PLEASE CONTACT US IN
[phone] OR [e-mail]
All the equipments manufactured in Sistema AZUD are subject to strict quality control tests and are
manufactured under a productive process which complies with the requirements of the standard ISO
9001/2000.
Sistema AZUD is also committed with the environment, and is certified under the Environmental
Management System of the standard ISO 14001.
This manual includes instructions and warnings to a correct installation, operation
and maintenance of the Equipment.
2.1. Exclusive Use of the filtration Equipment.
Sistema AZUD filtration equipments have been designed to exclusively filter water,
according to the Operational Conditions indicated in the Technical data and the
Industrial label of the Equipment. In any case to the filtration of dangerous liquids
(understood as such the specific in the charter 2 of article 2 of Directive
67/548/CEE, of 27th of June of 1967), or liquids for food use.
CLASSIFICATION ACCORDING TO THE DIRECTIVE OF PRESSURE
EQUIPMENTS.
PED 97/23/CEE: Art. 3.3 – Fluid Group 2

Water Filtration Solutions
5
2.2. Identification of the product.
In AZUD each filtration equipment is identified by an industrial label, placed in one of the main
manifolds, with the serial number. With this number the factory can always identify the equipment.
The modification or elimination of this label cancels any warranty; and impedes the
identification of the Equipment.
The industrial label indicates: manufacturer, address, model, year of manufacturing, serial
number, max. Pressure, max. Temperature and conformity with the Directive of Pressure
Equipments 97/23/CEE
The filters of the equipment,
are identified with a label in
which is indicated the model,
year of manufacturing, serial
number and max pressure.
AZUD HELIX AUTOMATIC consists of a filtering element which comprises
grooved discs, that allow the retention of particles of a size bigger than the
required filtration grade. The Equipment combines the advantages of the
disc filters with those of the helicocentrifugal effects of the helix.
AZUD grooved discs combine on-surface filtration and in-depth filtration
to achieve the maximum precision and safety in the filtration.
The particles are retained through the channel of the discs.
DISCS
2.3. Operation Description.

Water Filtration Solutions
6
FILTRATION
STAGE
INLET
OUTLET
The system carries out two independent phases called FILTRATION PHASE and
BACKFLUSHING PHASE.
TECHNOLOGY
Valve 1 Valve 2
Filtration
Stage
Backflushing
Stage
Through the feeding of the three-ways
valves chambers, the inlet of water to the
filter closes, communicating the inner of
the filter with the drainage manifold,
starting the backflushing cleaning.
BACKFLUSHING
STAGE
INLET
DRAINAGE
Valve 1
Valve 2
Special
Backflushing T
FILTRACIÓN STAGE
BACKFLUSHING STAGE
Filtration
Stage
Backflushing
Stage
LOWER SIDE OF
THE FILTERING
ELEMENT
PISTON CAP WITH
SPRING
The end of the backflushing coincides with the closure of the drainage outlet and the opening of
the outlet manifold, allowing water coming from the feeder manifold to come into the interior of
the filter and in this way, to re-establish the filtration phase conditions.
In the filtration process, water is carried from the feeder
manifold (inlet manifold), through the backflushing three-
way valve (valve 1), to the interior of the filter through its
inlet.
Once the water come in the filter, the only track the water
of its interior can follow, are the discs channels whose
discs form a stack. This stack is compressed by the spring
action and the hydraulic power itself.
The filtered water goes through the 2” hydraulic valve
and goes to the rest of the installation.
The filtered water given by the Special
backflushing T, is introduced in the filter.
The available hydraulic power is used to
overcome the pressure exerted by the
spring on the discs stack generating in
this way its own decompression due to
the piston displacement (raising).
The discs release makes possible its
rotation due to the tangential projection
of the water coming from the feeder
bars which at the same time are used
as structural shoulder of the discs stack.

Water Filtration Solutions
7
COMPONENTS AZUD HELIX AUTOMATIC EQUIPMENT
Nº DESCRIPCTION MATERIAL
1 AZUD HELIX AUTOMATIC 2”S DLP FILTER --
2 GROOVED COUPLING PVC 2”
3 STAINLESSSTEELTHREADEDCONNECTORS -
4 SUPPORTS -
5 GROOVED COUPLING 2” -
6 TE 90 63 2”AUXILAIRYFILTER -
7 3 WAYS HYDRAULICVALVE2” -
8 MANOMETER -
9 COMMAND 8x6 mm – 12 mm PE
10 FILTERINGELEMENT AUXILIARYFILTER --
11 GROOVED ADAPTERTUBE AUXILIARY FILTER 2” PE
2
3
1
7
5
4
8
6
3
SPARE AZUD HELIX AUTOMATIC FILTER
Nº CODE DESCRIPCTION MATERIAL un
16 17RXP010 PLASTIC LID 3" RPA 1
17 FILTERING ELEMENT AZUDHELIX AUTOMATIC - 1
18 70RX0001 CLAMP SAFETY AZUD HELIX AUTOMATIC A. INOX. 1
19 17RXP012 SEALINGGASKETBASE NBR 1
20 18R60003 BASE 2NV RPA 1
35 17RXP013 BASECAP
36 O-RING CAP 1
LA TE
6
11
6
10
2.4. AZUD HELIX AUTOMATIC SERIE 201 DLP Components and Spares.
*: OPTION
RPA: POLYAMIDE REINFORCED WITH GLASS FIBER
PP: POLYPROPYLENE
NBR: NITRIL RUBBER
PE: POLYETHYLENE
A, INOX.: STAINLESS STEEL
Please indicate the serial number of the
equipment when requesting spares.
16
17
18
19
20
36
35

Water Filtration Solutions
8
AZUD HELIX AUTOMATIC FILTERING ELEMENT
21
28
29
30
32
31
17
21
22
23
24
25
26
27
21
22
20
33
FILTERING ELEMENT SPARE PARTS
NUMBER CODE DESCRIPTION un
21 18R60115 PISTON FRAMEAZUD HELIX AUTOMATIC 1
22 --- DISCS KIT AZUD HELIXAUTOMATIC 1
23 18R60037 PISTON OGASKET92,6x 100x 4 mm 1
24 ---------- FRAME WIITHOUT CHECK VALVE 1
25 ---------- CHECK VALVE 1
26 ---------- STEM Check Valve 1
27 18R60026 O-RING 103X4 2
28 ---------- A PISTON COMPONENT 1
29 ---------- SPRING 1
30 ---------- B PISTON COMPONENT 1
31 ---------- O-RING 13X2 2
32 ---------- CLIP 1
SPARE PARTS KITS
NUMBER CODE DESCRIPTION un
23-27x2-31-32 18R60116 O-RINGS KIT AUTOMATIC FILTER3.0 1
23-31-32 18R60117 PISTON SET OF O-RINGS AUTOMATIC FILTER3.0 1
23-27x2-29-31-32 18R60118 MAINTENANCEKIT AUTOMATICFILTER 3.0 1
20 18R60119 FRAME AUTOMATIC FILTER DEP3.0 1
25x2-26x2 18R60120 CHECKVALVEAUTOMATICFILTER 3.0 1
26 ---------- STEM Check Valve 1
27 18R60026 O RING 103X4 2
28 ---------- A PISTONCOMPONENT 1
29 ---------- SPRING 1
30 ---------- B PISTONCOMPONENT 1
31 ---------- O RING 13X2 2
32 ---------- CLIP 1
33 17RXP020 HELICALELEMENT 1
AZUD HELIX AUTOMATIC DISCS KIT
NUMBER CODE DESCRIPTION un
22
18R60033 S-DISC KIT AUTOMATIC FILTER 130 MICRON 1
18R60039 S-DISC KIT AUTOMATIC FILTER 100 MICRON 1
18R60034 S-DISC KIT AUTOMATIC FILTER50 MICRON 1
18R60035 S-DISC KIT AUTOMATIC FILTER 20 MICRON 1
18R60038 S-DISC KIT AUTOMATIC FILTER 10 MICRON 1
18R60036 S-DISC KIT AUTOMATIC FILTER 5 MICRON 1
22 18R60040 DISC KIT AUTOMATICFILTER 400 MICRON 1
18R60012 DISC KIT AUTOMATICFILTER 200 MICRON 1
18R60011 DISC KIT AUTOMATICFILTER 130 MICRON 1
18R60010 DISC KIT AUTOMATICFILTER 100 MICRON 1

Water Filtration Solutions
9
Cod: 18CE1008
2.5.2 Backflushing Grooved valve 2”x2”x2”.
The reference of the backflushing valve will be different according the
manufacturer AZUD supplied in your filtration equipment.
Technical Plastic Valve
Bermad
2. With the Control Unit, when the minipilot valve is un AUTO position. Said Control Unit activates the
backflushing cycle under one of the four possible orders: pressure differential existing in the
equipment, following a preestablished frequency of time between backflushes,bydirectaction on
the keyboard or by external signal. The programmer, which incorporates the Control Unit, closes the
contact which supplies tension to the NC solenoid, converting the electricsignalinanhydraulicsignal
which is in charge of the feeding of the three-way valves chambers. In this way, is achieved the same
addressing of the flow of water that the one explained in the control manual.
The start of the backflushing process takes place in two ways:
1.When the ¼” three-way valve (minipilot) is put on OPEN position by hand. In
this position, the minipilot valve allows water to flow from the inlet manifold to
the chambers of the two three-way hydraulic valves . In this way, water is not
allowed to come into the filter through the feeder manifold and it allows water to
flow through the outlet. At the same time, the interior of the filter communicates
with the drainage manifold.

Water Filtration Solutions
3.2.- General Characteristic AZUD HELIX AUTOMATIC Filter.
Connections Dimensions (mm)
AB C E MHWXD
2” VIC 2” VIC 2” BSP ¾” BSP ¼” BSP 721 309 133 245
D
X
W
H
M
C
A
B
E
The failure to obey the instructions and
warnings could cause damage to people,
the equipment and the surrounding area.
CLASSIFICATION ACCORDING TO THE
DIRECTIVE OF PRESSURIZED EQUIPMENTS
PED 97/23/CE: Art. 3.3 – Fluid Group 2
3. Technical Data
3.1 AZUD HELIX AUTOMATIC SERIE 201 DLP General features and requirements.
BACKFLUSHING MG DISC WS DISC
Mini. Backflushing Pressure 1.5 bar
21 psi 1.3 bar 19 psi
Backflushing Flow 2.5 l/s
40 gpm 2 l/s 32 gpm
*Data with 0 bar pressure in the drainage manifold.
The differential pressure of the filter never must be higher than
0.2-0.3 bar
over the value of the filter has when it is clean
THE FLOW RATE
GIVEN BY FILTER
CONDITIONS THE
FREQUENCY OF
THE
BACKFLUSHING
ACTIVATION
MAX. PRESSURE
10 bar
145 psi
MIINIMUM
PRESSURE
1.2 bar
17 psi
MAX.
TEMPERATURE
60ºC
140ºF
pH 4-11
2”SUPER
FILTRACION 400
micron
200
micron
130
micron
100
micron
50
micron
20
micron
10
micron
5
micron
GOOD WATER 28 m3/h
123,27 gpm 27 m3/h 118,87 gpm 26 m3/h 114,47 gpm 24 m3/h 105,66 gpm 14 m3/h 61,63 gpm 8 m³/h 35,22 gpm 6 m³/h 26,41 gpm 5 m³/h 22,01 gpm
AVERAGE
WATER 26 m3/h
114,47 gpm 25 m³/h 110,07 gpm 24 m3/h 105,66 gpm 22 m3/h 96,86 gpm 13 m3/h 57,23 gpm 7 m3/h 30,81 gpm 5 m³/h 22,01 gpm 4 m³/h 17,61 gpm
POOR WATER 24 m3/h
105,66 gpm 23 m³/h 101,26 gpm 22 m3/h 96,86 gpm 20 m3/h 88,05 gpm 12 m3/h 52,83 gpm 6 m3/h 26,41 gpm 4 m³/h 17,61 gpm 3 m³/h 13,20 gpm
VERY POOR
WATER 22 m3/h
96,86 gpm 21 m³/h 92,45 gpm 20 m3/h 88,05 gpm 18 m3/h 79,25 gpm 11 m3/h 48,43 gpm 5 m3/h 22,01 gpm 3 m³/h 13,20 gpm 2 m³/h 8,80 gpm
