AZZA CSAZ-804 User manual

INNOVATIVE TREMPERED GLASS GAMING CASE
CSAZ-804CSAZ-804

Installation Instructions
1. Specifications
2. Chassis Parts
3. Removing The Top Glass Panel
4. Overview
5. Supported Motherboards
6. Power Supply Installation
7. Video Card Installation
8. Water Radiator Installation
9. 2.5"SSD / 3.5"HDD Installation
10.PCI-E Cable
11. Fan Installation
12. Digital RGB Fan Installation For Motherboard

Model
Model Name: PYRAMID 804
Name: CSAZ-804
Specifications
Type:
Color:
Side Panel Window:
UP to 80mm
Power Supply: Not included
Motherboard Compability:
External 5.25" Drive Bays:
Internal 2.5" Drive Bays:
Internal 3.5" Drive Bays:
Expansion Slots:
Physical Specifications
Metal Chassis Dimensions (HxWxD) 558x490x490/22x19.3x19.3 inch
Physical Dimensions (HxWxD) 585x490x490mm/23x19.3x19.3 inch
Weight: 14kg /30.9lbs
Tempered Glass Side Window:
Available Fan Ports:
Water Cooling:
Isolated Chamber:
Easy Installaon Cooler: A pre-cut hole for easy installaon of CPU Cooler,
eliminang the need to remove the motherboard
Accessories
High-quality tempered glass side window allows for clear visuals to inner components
1x120mm Fan port in the Top(1x 120mm Hurricane II Digital RGB Fan included )
3x120mm Fan port on the Boom
Supports radiators up to 360mm on the boom
ATX Power supply inside its own isolated chamber,
prevenng its heat from aecng other components
Adjustable video card holder
Stand & Tempered glass (
Up to 1 (Converble with 2.5"SSDx1 )
2
2xUSB 3.0
、
HD Audio
、
Type C
、
Metal Power Buon
Features
ATX Tower
1.5~2.0mm SPCC+ 2.5mm Aluminum
4 sides of top panel are tempered glass
Expansion
0
Up to 2
<305 x280mm SSI-CEB 、ATX
15cm PCI-E 3.0 extension cable for VGA card(Support EATX 、ATX MB)
L=300 mm / W=132 mm / H=47 mm (Horizontal)
Front Ports:
Max. CPU Cooler Height:
Max. GPU Dimensions:

Chassis parts
2
3
4
5
6
8
9
10
11
12
TOP tempered glass panel cover
Pyramid structure
Fan bracket
12cm ARGB Fan
Power supply rack
Adiustable Video Card Holder
Horizontal PCIe slot
I/O Ports: USB 3.0 x 2 , Type C, HD Audio
Spring bolt screw of top panel cover
Fan Cable management Cover
3.5"HDD /2.5"SSD Spring Bolt Tray X1
2.5"SSD brackets X1
71
1
2
8
3
4
5
6
7
9
10
11
12

Removing The Top Glass Panel
Loosen the four screws
Lift to remove top panel
* Product photos are for reference only.

Overview
1
2
5
4
3
1
Adjustable video card holder
2
Pre-cut hole for CPU cooling
3
Power cord management hole
4
Water radiator management hole
5
motherboard mount
* Product photos are for reference only.

Supported Motherboards
Maximum: <305 x280mm SSI-CEB
Minimum : ATX Motherboard
* Product photos are for reference only.

Power Supply Installation
* Product photos are for reference only.

Video Card Installation
■Tighten the screws to secure the video card.
* Product photos are for reference only.

Water Radiator Installation
Bottom View
■ Secure the screws of the water radiator.
* Product photos are for reference only.

Water Radiator Installation
■ Supports up to 120mm fans x 3 / 240 / 360mm water radiator
* Product photos are for reference only.

2.5"SSD / 3.5"HDD Installation
(װ)
(ן)
1
32
23
4
1 4
(I) 2.5" SSD spring bolt tray: Supports up to 2.5" SSD x 2
(II) 3.5" HDD spring bolt tray: Supports 3.5 HDD x 1
(also compatible with a 2.5" SSD)
1
Loosen the spring bolt screw
2
Slide left or right to remove the tray.
3
Install the 2.5"SSD or 3.5"HDD
4
Fasten the spring bolt screw
STEP:
* Product photos are for reference only.

PCI-E Cable
J1
C4
C1 C3
C2
150 mm PCI-E 3.0 Cable(Support EATX、ATX Motherboard)
To fix potential compatibility issues with PCI-e Gen 4.0, please connect your graphics card
directly to the motherboard, enter the BIOS, and change the PCI-e x16 mode to 3.0 before
using the RGB PCI-e cable.

Fan Installation
■ Fasten the fan screws
■ Manage the fan cables by hiding them.
■ Secure the fan to the top of the Pyramid.

Digital RGB Fan Installation For Motherboard
The addressable RGB fans can connect directly to the 5V addressable RGB headers of compatible motherboards,
such as those from MSI™, ASUS™, Gigabyte™ and AsRock™.
Please note: Only 5V addressable headers from compatible motherboards are supported. Please do NOT connect
the fan to a 12V non-addressable header.
Please check your motherboard’s specifications before use. Do not go past the motherboard’s allowed limits on
power rating and LED count when connecting multiple fans/LED strips.

Complete
* Product photos are for reference only.
