AZZA PYRAMID 804L User manual

INNOVATIVE TREMPERED GLASS GAMING CASE
CSAZ-804L

1. Specifications
2. Chassis Parts
3. Removing The Top Glass Panel
4. Overview
5. Power Supply Installation
6. 2.5"SSD / 3.5"HDD Installation
7. PCI-E Cable
8. Fan Installation
9. Digital RGB Fan Installation For Motherboard
Installation Instructions

Specifications
Specifications
Model
Type:
Model Name:
Model Number:
ATX Tower
PYRAMID 804L
CSAZ-804L
Color: 1.5~2.0mm SPCC+ 2.5mm Aluminum
Side Panel Window: 4 sides panel are tempered glass
UP to 95mm
Power Supply: ATX
Motherboard Compability:
External 5.25" Drive Bays: 0
Internal 2.5" Drive Bays: Up to 2
Internal 3.5" Drive Bays: Up to 1 (Converble with 2.5"SSDx1 )
Expansion Slots: 3
Front Ports: 2xUSB 3.0、HD Audio、Type C、Metal power buon
Physical Specifications
Metal Chassis Dimensions (HxWxD) 558x490x490/22x19.3x19.3 inch
Weight:
Tempered Glass Side Window: High-quality tempered glass side window allows for clear visuals to inner components.
Available Fan Ports: 5x120mm fan ports on the boom
Water Cooling:
Isolated Chamber: ATX Power supply inside its own isolated chamber,
prevenng its heat from aecng other components.
Easy Installaon Cooler: A pre-cut hole for easy installaon of CPU Cooler,
eliminang the need to remove the motherboard.
Accessories:
Adjustable video card holder
Another 20cm PCI-e 4.0 extension cable version is available
Features
Expansion
Max. CPU Cooler Height:
Max. GPU Length:
14.1kg /31.1lbs
<305x280mm E-ATX 、ATX、Micro ATX、Mini-ITX
589x490x490mm/23.2x19.3x19.3 inchDimensions with Case Stand(HxWxD)
2022 Update

Up to 330mm long Video card (Horizontal)
1x120mm Fan port in the Top(1x 120mm Hurricane III Digital RGB Fan included )
20cm PCI-E3.0 Extend cable for VGA card (included)

Chassis parts
2
3
4
5
6
8
9
10
11
12
TOP tempered glass panel cover
Pyramid structure
120mm/140mm fan bracket
12cm ARGB Fan
Power supply rack
Adiustable video card holder
Horizontal PCIe slot
I/O Ports: USB 3.0 x 2 , Type C, HD Audio
Spring bolt screw of top panel cover
Fan cable management cover
3.5"HDD /2.5"SSD spring bolt tray X1
2.5"SSD brackets X1
71
1
8
3
2
10
4
9
11
12
5
6
7

Removing The Top Glass Panel
Lift to remove top panel
Loosen the four screws

Overview
1
2
3
1
2
Pre-cut hole for CPU cooling
3
Power cord management hole
4
Water radiator management hole
motherboard mount
4
4

Overview

Power Supply Installation

2.5"SSD / 3.5"HDD Installation
(I) 2.5" SSD spring bolt tray: Supports up to 2.5" SSD x 2
(II) 3.5" HDD spring bolt tray: Supports 3.5 HDD x 1
(also compatible with a 2.5" SSD)
I
II
Supports up to 2 x 120mm fan on the hard drive bay

PCI-E Cable
J1
C4
C1 C3
C2
200 mm PCI-E 3.0 Cable(Support EATX、ATX Motherboard)
To fix potential compatibility issues with PCI-e Gen 4.0, please connect your graphics card
directly to the motherboard, enter the BIOS, and change the PCI-e x16 mode to 3.0 before
using the RGB PCI-e cable.
Another 20cm PCI-e 4.0 extension cable version is available

Fan Installation

Digital RGB Fan Installation For Motherboard
The addressable RGB fans can connect directly to the 5V addressable RGB headers of compatible motherboards,
such as those from MSI™, ASUS™, Gigabyte™ and AsRock™.
Please note: Only 5V addressable headers from compatible motherboards are supported. Please do NOT connect
the fan to a 12V non-addressable header.
Please check your motherboard’s specifications before use. Do not go past the motherboard’s allowed limits on
power rating and LED count when connecting multiple fans/LED strips.
