AZZA Cube Mini 805 User manual

Installation Instructions
1. Specifications
2. Chassis Parts
3. Control Panel Functions
4. Removing Panels / SSD Tray
5. Power Supply / 2.5" SSD Installation
6. Mounting Stand
7. Cooling System Installation
8. AZZA Hurricane II Digital RGB Fan Installation For Motherboard

Specifications
Model
Model Name CUBE MINI 805
Model Number CSAZ-805
Specifications
Type
Color
Side Panel Window
Max CPU Cooler Height UP to 130mm
Max Video Card Length Up to 200mm long Video card
Power Supply Not included
Motherboard Compability Mini ITX
External 5.25" Drive Bays
Internal 2.5" Drive Bays
Internal 3.5" Drive Bays
Expansion Slots
Physical Specifications
Metal Chassis Dimensions (HxWxD) 260x260x260mm/10.2x10.2x10.2 inch
Dimension with Case Stand(HxWxD) 472x371x372mm / 18.6x14.6x14.6 inch
Weight 5.4kg /11.9lbs
Addressable RGB Light Effects Addressable RGB fan on the front. All addressable RGB light devices controlled
by motherboard.
Tempered Glass Side Window
Available Fan Ports
Isolated Chamber
Easy Installaon Cooler
0
3
USB3.0 x 2, HD Audio
Mini ITX Tower
Silver aluminum(exterior/interior)
Slidable tempered glass panelx2pcs and a magnec tempered glass.
Expansion
0
Up to 2
Dual-chamber design. Power Supply is housed in one of the chamber booms,
prevenng its heat from affecng other components.
A pre-cut hole for easy installaon of CPU Cooler,
eliminang the need to remove the motherboard
Features
High-quality tempered glass side window allows for clear visuals
to innercomponents
1x120mm or 1x140mm fan port on the front (1x140mm AZZA Hurricane II
Digital RGB fan included)
1x80mm fan port in the rear (1x80mm black fan included)
Front Ports

Chassis Parts
1
2
2
3
4
6
5
7
8
9
10
7
7
7
1
2
3
4
5
6
7
8
9
10
Magnetic tempered glass front panel
Stand
M3x8 screw x3
M3x6 screw x2
AZZA Hurricane II 140mm fan x1
80mm fan x1
Hand screw x4
SSD tray
PCIe slot cover x3
Slidable tempered glass panel x2

Control Panel Functions
Power SW button
USB3.0(Blue)
Audio
Mic

Removing The Front Panels
Removing The Side & Top Panel
Top panel
Side panel

Removing The SSD Tray
The Power Supply Installation

2.5" SSD Installation
SSD x2
A
B
B
C
CSupports the Video card with 3 slots
Supports a 80mm fan in the rear(installed)
ITX motherboard
A

Mounting Stand
(M3x10mm) x3
Suggestion:
When installing the stand on the chassis, we suggest you prepare a soft pad or cardboard on the flat table,
then, upside down the chassis to easily mount the stand with chassis by M3 screws.

Cooling System Installation
FrontRear
120mm x1 or 140mm x180mm x1
▪Install the fan between the chassis
and glass panel.

AZZA Hurricane II Digital RGB Fan Installation
For Motherboard
WARNING!
The addressable RGB fans can connect directly to the 5V addressable headers of compatible
motherboards,such as those from MSI™, ASUS™ Gigabyte™ and ASROCK™.
Please note: Only 5V addressable header from compatible motherboards are supported;
please do Not connect the fan to a 12V non-addressable header.
Please check your motherboard's specifications before use.Do not go past the motherboard's
allowed limits on power ratings and LED count when connecting multiple fans / LED strips.
