AZZA ECLIPSE 440 User manual

ECLIPSE 440

Installation Instructions
1. Specifications
2. Chassis Parts
3. Control Panel Functions
4. 3.5”/2.5” HDD/SSD Installation
5. Cooling System Installation
6. ARGB Control Board
7. ARGB Control Modes Switching

Specifications
Model
Model Name:
Model Number: CSAZ-440
Specifications
Type:
Color: Black/Black(interior)
Side Panel Window: Leside panel: tempered glass with rubber mounts
Max CPU Cooler Height: UP to 160mm
Max Video Card Length: Up to 390mm long video card
Power Supply: Not included
Motherboard Compability: EATX、ATX、Micro ATX、ITX
External 5.25" Drive Bays: 0
Internal 2.5" Drive Bays: Up to 4
Internal 3.5" Drive Bays: Up to 2
Expansion Slots: 7
Top Ports: Power buon, reset buon,Led buon, HD Audio, USB 3.0 x 1, USB2.0x2
Physical Specifications
Case Dimension (HxWxD) 470x215x450/18.5x8.5x17.7 inches
Weight: 6.3kg /13.9lbs
Tempered Glass Sides Window: High-quality tempered glass side window allows for clear visuals to inner components
Addressable RGB Light Effects:
All ARGB light sync. devices connected to the ARGB control board, allowing the LED buon
to directly contrl the ARGB lighng.
Available Fan Ports:
3x120mm or 3x140mm Fan ports in the front
(1x120mm ARGB Fan included)
3x120mm or 2x140mm Fan ports on the top
2x120mm Fan ports on the top of PSU shroud
1x120mm Fan port in the rear
Water Cooling: Supports radiators up to 280/360mm in the Front
Supports radiators up to 240mm in the Top
Dust Filters: Removable (magnetic) mesh net on the top, Steel dust filter on bottom of chassis.
Power Supply Support:
Accessories:
Boom mounted ATX Power Supply
ARGB Controller Board
Expansion
Features
ATX Mid Tower
ECLIPSE 440

Chassis Parts
1
Chassis
2
Metal side panel
3
Sliding tempered glass panel
4
2.5” SSD tray x 2
5 Hard disk cage
6
3.5” HDD/ 2.5” SSD brackets
7
Front panel
8
9
10
Light guide panel
Removable magnetic mesh
Steel dust filter
1
2
3
4
5
6
7
8
9
10

Control Panel Functions
USB 3.0 (Blue)
USB 2.0 (Black)
Audio
Mic
POWER
RESET
LED

▪Multifunctional hard disk bracket support
3.5” HDD or 2.5” SSD x 1 ( )
3.5 ˝/ 2.5˝ HDD/SSD Installation
3.5″3.5″
2.5″2.5″
or
▪Supports up to 390mm long video cards.
B
C D
A
▪2.5" SSD metal tray support 2.5” SSD x 2
( )
▪Multifunctional hard disk cage support
3.5” HDD or 2.5” SSD x 1( )
A
B
CD
MAX 390mm video cardMAX 390mm video card
EF
▪Supports up to 120mm fan x2 ( )
EF

Cooling System Installation
Front
120mm x3
140mm x3
or
Max Height of
Radiator
360 mm

Cooling System Installation
Rear
120mm x1

Cooling System Installation
Top
120mm x2 140mm x2
or
Max Length of
Radiator
240 mm

ARGB Control Board

ARGB Control Modes Switching
※Press the LED button to cycle through different RGB lighting modes, controlled by
the LED button though the ARGB control board.
※Hold the LED button for 3 seconds to switch the RGB control function between
motherboard RGB software and LED button.
