Balt Study carrel 89788 User manual

123456789012345678901234567890121234567890123456789012345678901212345678901

#89788 Study Carrel

Adjustable Height Workcenter

Assembly Instructions

P8 Stability Brace 1 EA

P9 Metal Angle Bracket 8 EA

P1 Right Side Panel 1 EA

P2 Left SidePanel 1 EA

P3 TopPlatform 1 EA

P4 Upper ShelfPlatform 1 EA

P5 Back Panel 1 EA

P6 UpperLegReciever 2 EA

P7 Lower LegInsert 2 EA

Part Drawing Description Qty Part Drawing Description Qty

WOW

Adjustable Height Workcenter

Study Carrel

Hardware List

A ½” Socket Screw 4 EA

A1 1-½” Socket Screw 8 EA

B ThreadedNut 4 EA

C WoodScrew 24 EA

D Plastic Grommet 2 EA

E LevelingGlide 4 EA

F Allen Wrench 1 EA

G Cam Lock 16 EA

H Cam Post 16 EA

We recommend that you assemble this

unit on a table.

Toolsrequired: AdjustableCrescentWrench

Do not use unless all screws are tight. At least every six months, check all screws to be sure

they are tight. If parts are missing, broken, damaged, or worn, stop use of the product

until repairs are made by your dealer using factory authorized parts.

Should you require assistance during assembly,

please call our Customer Service Department

Monday - Friday 8 a.m. - 5 p.m.

Central Standard Time

1-800-749-2258

Missing Parts or UPS Damaged Parts

ForYourConvenience youcan

EMAILusat

[email protected]

24HOURS 7 DAYS A WEEK

StudyCarrel

AssemblyDiagram

IdentifyandSeparate allthe Parts

andHardware.

Illustration # 1

Illustration # 2

1.)

2.)

EAD

HROUGH

NSTRUCTIONS

FROM

BEGINNING

END

BEFORE

STARTING

ASSEMBLE

UNIT

PlacetheBack Panel (P5)withtheinsert nutsfacingupandinstall4

eachCamLocks (G) into thelargeholesas showninillustration# 2.

Install4each CamPosts(H) inthe4 threadedinsertnuts

(Pre-installed) asshown in illustration# 2.

Be sure that arrow on

top of Camlock (G)

alignswithcenterline of

EdgeDrilled hole.

Phillips

Screwdriver

Centerlineof

EdgeDrilled

hole.

Arrow

PlacetheUpper Shelf Platform(P4)withthe Holesfacing up andinstall6 each

CamLocks(G) into the largeholesasshown inillustration#1.

4.)

3.)

Illustration # 3

Illustration # 4

5.)

To SecureCamLocks,Insert Large

PhillipsHeadScrewdriver andturnCam

Lock1/4turn(90 degrees) clockwise.

PlacetheLeftSide Panel (P2) withthe

insertnutsfacingup.

Install6each CamPosts(H) in the6

threadedinsertnuts (Pre-installed) as

shown in illustration#3.

Repeat Steps 5 & 6 for the Right Side

Panel(P6).

PlacetheBackPanel (P5) withthe

insertnutsfacing up. Slide1each

UpperShelfPlatform (P4)overthe

Cam Posts (H)as shown in

illustration#5. Secureby turning

theCamLocks (H)1/4 Turn

untiltheylock.

Slide 1 each Top Platform (P3) over

theCamPosts(H)asshownin

illustration#5andsecurebyturning

theCamLocks(H)1/4Turnuntilthey

lock.

(Finger tighten only)

PlacetheTop Platform (P3)with the

Holesfacingup and install6each

CamLocks(G) intothelarge holes

asshownin illustration# 4.

6.)

7.)

8.)

9.)

10.)

Illustration # 5

Illustration #6

Attach totheRight Side Platform(P1)andthe Left

SidePanel(P2)tothe Top Platform (P-3),theBack

Panel(P5),and theUpperShelf Platform (P-4)as

showninillustration# 6.

11.)

Illustration #8

Attach2each MetalAngle Brackets

(P9)using6each(C) screwsas

showninillustration# 8.

P2 P3

12.)

13.)

(C)Screw#6 X ½

For Scale only

(C)Screw#6 X ½

For Scale only

Attach6each MetalAngle Brackets

(P9) using 18 each (C) screwsas

showninillustration# 7.

Illustration #7

Slide 2 Lower Leg Inserts (P7)

intotheUpper Leg Receivers

(P6).Secureatdesiredheight

using (4) each (A) Screwsas

showninillustration#10.

(Tighten all the screws at this

time using Allen Wrench (F)).

Attach4each (E)Leveling

Glides to the 2 each Lower

LegInserts(P7).

BA1

16.)

14.)

15.)

Illustration #10

P7 P7

Illustration #9

RotatetheCarrel Assembly

sothat theBottom Platform

(P-3)isfacingup.Attach 2

eachUpperReceivers(P6) to

theBottomPlatform (P-3)

using4each(A1) screwsas

showninillustration#9.

(Finger tighten only)

AttachStabilityBrace(P8) to

the2each Upper Receivers

(P6) using 4 Screws (A1) and

4ThreadedNuts (B) as

shownin illustration#6.

17.)

(A1)ScrewM6 X 1-½”

For Scale only

ForScaleonly

7StudyCarrelV1-07/19/04

TheBaltproductyouhavepurchased isguaranteedagainstmaterial andworkmanshipdefects. This

guaranteeextends 1yearfromdateofpurchase. Shouldthisproductfailto functionsatisfactorilyunder normal

useduetodefector imperfection, the defective part or productwillbereplaced. Damagecausedbycommon

carriersduringshipmentisnotincludedinthisguarantee.

This guarantee sets forth all applicable guarantees and remedies. No other warranty, expressed or

impliedshallapply. Failuretofollow instructionsfoundinImportantInformationSectionof Owner

Sheetshall void theguarantee. Consequentialorincidental damages andorcosts are notrefundable.

Important

Cap

Grommet(D) installation

Illustration #11

Sleeve

Grommet (D)

Sleeve

Cap

To installGrommet(D),separate partsandpress

GrommetSleevein Roundopeningsin Bottom

Platform(P3)andBack Panel (P4)asshown in

illustration#8.

Snap plastic Caps into Sleeves as shown in

illustration#11.

19.)

18.)

89788-StudyCarrel

Workcenter Formore information

1-800-749-2258

39½”

28”

8”

study carrel-10/27/04

ShippingInformation

5.1 Cubic Feet

92lbs.

35½ X 22

30½

35½ X 8¼

Clearance

AdjustableHeight

22 - 30

19½
