BANDELIN SONOCOOL 255 User manual

User instructions
51346-007GB/2020-08
C
High-performance ultrasonic bath
C 255

2 / 46 51346-007 GB/2020-08
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
Copyright & limitation of liability
This document may not be reproduced, either in full or in extracts, without prior approval of BANDELIN electronic GmbH & Co.
KG, hereinafter referred to as BANDELIN.
The German original is the binding version of this document. Any differences in the translation are not binding and have no legal
effect. In case of any discrepancies between the translation and the original of this document, the original version has priority.
BANDELIN accepts no responsibility or liability for damages caused by improper handling or usage contrary to the intended
purpose.
The documentation was prepared with great care. Liability for indirect or direct damages arising because of incomplete or errone-
ous information in this documentation, as well as in its delivery and usage, is excluded.
All images are provided as examples and are not true to size. Decorative elements are not included in the scope of delivery.
Subject to technical changes. Measurements are subject to manufacturing tolerances.
© 2020
1 2 GmbH & Co. KG, Heinrichstrasse 3–4, Germany, 12207 Berlin,
Tel.: [phone] - 0, Fax: [phone], [email protected]

51346-007 GB/2020-08 3 / 46
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
General
The equipment, the accessories and the preparations are to be used in accordance with
the operating instructions and/or the product information.
The instructions are part of the scope of delivery and are to be stored in the vicinity of
the device for later reference. This also applies if possession of the device is transferred
elsewhere.
Before the device is put into operation, these Instructions for Use are to be read carefully
and completely in order for the user to become familiarised with all functions.
The warnings and safety precautions (section 1.5) are always to be followed during use.
The manufacturer will not assume any responsibility for the device's safety or functional
ability in the event of improper handling or usage contrary to the intended purpose. In
the event of unauthorised alterations/modifications, both the warranty claim and the CE
conformity will expire.
If Service is required, please contact the specialist dealer in charge or the manufacturer.
Symbols used:
Symbol Significance Explanation
Danger Identifies information that could signify a risk to life and limb,
especially through electric shock, if not observed.
Caution
Identifies information that is to be observed and adhered to
without fail, to prevent damage to the device and danger to
the user.
When device parts are labelled with this symbol, reference
must be made to the documentation.
Warning Warning of hot surface.
Important Identifies information that is important for execution.
Note Identifies information provided for explanatory purposes.
Medical note Identifies information that is important for medical use.
In vitro diagnostics
information
Identifies information that is important for in vitro diagnostics
applications.
Do not grip inside For health reasons, touching the oscillating fluid is prohibited.
Wear ear protectors For health reasons, standing for long periods of time in the
vicinity of the device without ear protectors is prohibited.
Operating sequence
instructions
Identifies instructions that are to be followed in the described
sequence.

4 / 46 51346-007 GB/2020-08
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
Contents
1 Product description ......................................................................................................6
1.1 Mode of operation ........................................................................................................8
1.2 Purpose ........................................................................................................................8
1.3 CE conformity ...............................................................................................................8
1.4 Technical data ..............................................................................................................9
1.4.1 Electromagnetic ambient conditions (EMC) ...............................................................10
1.4.2 Interfaces ...................................................................................................................11
1.4.2.1 D-Sub 15 - Pinning ....................................................................................................11
1.4.2.2 RS 232 - Pinning ........................................................................................................12
1.5 Warning and safety instructions .................................................................................12
2 Preparation .................................................................................................................14
2.1 Scope of delivery ........................................................................................................14
2.2 Set-up / assembly ......................................................................................................14
2.3 Start-up ......................................................................................................................15
3 Operation ...................................................................................................................16
3.1 Operating elements ....................................................................................................16
3.1.1 Turning the ultrasonic bath on/off...............................................................................16
3.1.2 Explanation of the display fields .................................................................................17
3.2 Signals on the ultrasonic bath ....................................................................................17
3.3 Types of operation ......................................................................................................18
3.4 Setting the operating parameters ...............................................................................19
3.4.1 Temperature setting ...................................................................................................19
3.4.2 Time setting ................................................................................................................20
3.4.3 Power setting .............................................................................................................20
3.5 Activating / deactivating the ultrasound ......................................................................21
4 Use .............................................................................................................................22
4.1 Fill the oscillating tank and de-air it ............................................................................22
4.2 Degassing the fluid .....................................................................................................23
4.3 Ultrasound operation ..................................................................................................24
4.4 Refresh / replace the contact liquid. ...........................................................................25
4.5 Further information .....................................................................................................26

51346-007 GB/2020-08 5 / 46
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
4.5.1 Contact fluid ...............................................................................................................26
4.5.2 Effect of the rubber stoppers on the oscillating tank's inlet and outlet .......................26
4.5.3 Degassing ..................................................................................................................27
4.5.4 Disposal of sonication fluids .......................................................................................27
5 Cleaning and maintenance of the ultrasonic bath ......................................................28
5.1 Cleaning and care ......................................................................................................28
5.2 Disinfection .................................................................................................................29
5.3 Warehousing / storing ................................................................................................29
6 Maintenance and repair .............................................................................................30
6.1 Maintenance.................................................................................................................30
6.2 Maintenance conducted by the manufacturer – every 2 years ..................................34
6.3 Malfunction / Fault analysis..........................................................................................34
6.3.1 Fault messages on the display. ..................................................................................35
6.3.2 Malfunctions .................................................................................................................36
6.3.2.1 Flush flow-through / rectify obstructions .....................................................................37
6.4 Repairs and service ...................................................................................................38
6.4.1 Decontamination certificate ........................................................................................38
6.4.2 Replacing fuses ..........................................................................................................38
6.4.3 Determining information on software version and report data ...................................39
7 Accessories ................................................................................................................40
7.1 Required accessories .................................................................................................40
7.2 Optional accessories ..................................................................................................41
7.3 Chemical agents ........................................................................................................42
8 Consumable materials - not applicable - ...................................................................42
9 Taking the unit out of service ......................................................................................42
10 Key words ..................................................................................................................43

6 / 46 51346-007 GB/2020-08
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
1 Product description
Ultrasonic bath with cooling of SONOCOOL type.
The exact type specification and serial number are found on the type plate.
Product features:
• Stainless steel oscillating tank (1) with transducers, ultrasound frequency 35 kHz
• Filling level mark for safe filling (2), electronic fill level sensor (2a)
• Operating and display panel (3) with LC-display (4)
• Lid (5), recess/support for glass lid (5a)
• Tank inlet (6) and outlet (7)
• Differentinterfaces (8) for logging and control
• Shut-offvalve for emptying (9), protective cap (9a) over emptying nozzle
• Mains switch (10), mains connector (11) and
• Exhaust air opening (12)
5a
4
3
5
9a
9

51346-007 GB/2020-08 7 / 46
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
12
10
8
11
2
2a
7
6
1

8 / 46 51346-007 GB/2020-08
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
1.1 Mode of operation
Ultrasonic baths use the effect of cavitation. Under their oscillating tank bottoms they
contain piezoelectric transducers, the energy of which is transferred to the bath liquid with
ultrasound frequency as mechanical oscillations. As a result, microscopically small bubbles
are continuously formed in the bath liquid, which release energy upon imploding and
generate local microcurrents. This process is called cavitation.
1.2 Purpose
General use
The SONOCOOL ultrasonic bath is intended for use in analytical labs as well as for
industrial and scientific research and also in pathologies. With the bath it is possible to
use the catalytic effect of ultrasound for processes during which simultaneous cooling
is required. Heat-sensitive samples are protected by the cooling function and process
sequences can be designed to be faster and more effective than customary procedures.
Cooling is conducted automatically, the ultrasound can be separately switched on.
In addition to the temperature, the runtime can be set for up to 99:59:59 hours. In addition,
four different levels of ultrasonic power can be selected. The ultrasonic bath is table-
top operated using the keys on the front of the device, and is designed for unmonitored
continuous operation.
Caution!
The sonication takes place indirectly in inset beakers.
Ultrasound cleaning directly in the contact liquid is not allowed with the SONOCOOL.
In-vitro diagnostic use of the bath
The SONOCOOLcan be used for in vitro diagnostic treatment or laboratory procedures
(e.g. bone decalcification) in which medical information is gathered from the treatment of
organic or inorganic material. In this case, it is classified and treated in accordance with
Directive 98/79/EC on in vitro diagnostic medical devices (IVD).
1.3 CE conformity
The ultrasonic bath is declared as a IVD device and satisfies the CE marking criteria for the
European Union:
- IVD Directive
- Low-Voltage Directive
- Electromagnetic Compatibility Directive
- RoHS Directive
in their currently valid versions.
The declaration of conformity can be requested from the manufacturer.

51346-007 GB/2020-08 9 / 46
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
1.4 Technical data
SONOCOOL ultrasonic baths carry the CE - marking.
Safety: EN 61010-1,
EMC: EN 61326-1
Oscillating tank, interior: 280 × 150 × 150 mm (L × W × H)
External dimensions: 360 × 605 × 385 mm (L × W × H)
Housing: Coated aluminium
Oscillating tank: Stainless steel (AISI 316 L), 2 mm, welded
Operating volume: 5 litres (contact liquid
~4 litres in the tank +
1 litre in the cooling unit)
Adjustable bath temperature: 4–40 °C (in 20 °C environment)
Cooling capacity: 200 W
HF power: 180 W, adjustable to 4 levels
HF frequency: 35 kHz
Countdown operation: up to 100 h
Emptying: front left, concealed
Current consumption: 1.6 A
Nominal voltage: 230 V~ (± 10 %), 50 Hz
Cable length: 2 m
Protection class: Class I
Weight (net): 27.5 kg
Degree of protection: IP 31 according to EN 60529
Protected against access with tools to
dangerous parts
Protected against solid foreign bodies
with a diameter of 2.5 mm or larger
Protected from
dripping water

10 / 46 51346-007 GB/2020-08
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
Environmental conditions pursuant to EN 61 010-1
Overvoltage category: II
Degree of contamination: 2
Permissible ambient temperature: 5 to 35 °C
Permissible relative humidity up to 31 °C: 80 %
Permissible relative humidity up to 40 °C: 50 %
Altitude: up to 2000 m above sea level
No condensation allowed.
Only for indoor operation.
Specifications for use as a medical device
Name: SONOCOOL
UMDNS nomenclature (ECRI / DIMDI): 14-263 (ultrasound cleaning unit)
Purpose: See chapter 1.2
Medical device pursuant to
Directive 98/79/EC for in-vitro diagnostic medical devices: Device category 5 bath
Type, model, serial number, year of manufacture: See type plate for information
The ultrasonic bath has been inspected according to applicable standards and must be
installed and operated according to EMC directions; see appendix.
Specifications pursuant to the Medical Devices Operator Ordinance (MPBetreibV):
Start-up on location, functional check
and personnel training pursuant to section 4: not required
Technical safety controls (STK) pursuant to section 11: no specifications
(DIN EN 62353 / VDE 0750)
Technical measurement controls (MTK) pursuant to section 14: not applicable
1.4.1 Electromagnetic ambient conditions (EMC)
The device was tested to DIN EN 61326-1 for electromagnetic compatibility (EMC) and
complies with the requirements for class B devices according to EN 55011.
It is suitable for use in facilities and areas which are directly connected to a public low-
voltage supply network, e.g. medical laboratory facilities.

51346-007 GB/2020-08 11 / 46
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
1.4.2 Interfaces
The SONOCOOL ultrasonic bath features two interfaces on its rear side which may be
optionally used by the operator.
Note:
Implementation of the technical programs required for communication is the responsibility
of the operator and is not supported by the manufacturer. The manufacturer only
guarantees the proper functioning of the interfaces.
Commercially-available cables may be used for the communication.
It is possible to use both interfaces simultaneously.
1.4.2.1 D-Sub 15 - Pinning
15-pin D-Sub interface for remote control, e.g. using an CLP.
SubD
pin Name of signal ML-pin Remark
1 PE 1 Ground potential connected to GND
2 TxD 13 SCI TxD
3 RxD 15 SCI RxD
4 -- 7 Not connected!
5 GND 9 Combined ground potential for all signals
6 PWR_down1 11 Ultrasound disconnection during bridging 2
7 PWR_down0 13
8--15
Not connected!9-- 2
10 -- 4
11 \M_HF_on 6 Signal contact 3for
ultrasonic emission
open against CLP_COMMON
12 \M_HF_on 8 closed against CLP_COMMON
13 CLP_COMMON 10 Combined contact for messages
14 \M_fail 12 Signal contact 3for
errors
open against CLP_COMMON
15 M_fail 14 closed against CLP_COMMON
1 Optional
2 Switching with potential-free contact. Internal connection with 12 kΩat +5V. Bridging voltage < 1V (e.g. with optocoupler).
Caution: Switching only with potential-free contact relay or optocoupler.
3 Contact may be loaded with 60V, 0.5A, maximum 10VA against CLP_COMMON

12 / 46 51346-007 GB/2020-08
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
1.4.2.2 RS 232 - Pinning
Communication is fundamentally conducted on the basis of the BANDELIN protocol with
the following settings:
SubD
pin Name of signal ML-pin Remark
1 1 Not connected!
2 TxD 3 SCI TxD
3 RxD 5 SCI RxD
4 -- 7 Not connected!
5 GND 9 SCI GND
62
Not connected!
74
8-- 6
9-- 8
The protocol and set of instructions (user information) can be made available by the
manufacturer upon request.
1.5 Warning and safety instructions
General
• Keep the ultrasonic bath out of the reach of children and of persons who have not been
instructed in its operation by reference to these instructions.
• We will not offer any guarantee for damages to the ultrasonic bath or oscillating tank,
or to the objects to be treated, as a result of use of inadequate disinfection agents or
detergents.
• Do not expose the ultrasonic bath directly to sunlight and do not position it in the vicinity
of heat sources.
• Keep the surface of the ultrasonic bath and operating elements clean and dry.
• Do not expose the ultrasonic bath to corroding influences.
• Only move the ultrasonic bath when it is empty. During transportation, the rubber
stoppers are to be plugged into the tank's inlet and outlet.
• Empty the ultrasonic bath only while turned off.
• Ultrasonic baths adhere to prescribed EMC limit values, such that it can be assumed
that the electromagnetic radiation emanating from the units is harmless to humans.
A binding statement for wearers of implants can only be made at the place of work
and together with the implant manufacturer. In case of doubt, information regarding
the allowable electromagnetic exposure level is to be obtained from the implant
manufacturer.
Operation
• Observe ambient and set-up conditions, see chapter 1.4.
• Only plug in the ultrasonic bath to an outlet with a grounded socket.
• Do not operate the ultrasonic bath without fluids.
• Do not fill the oscillating tank with hot water (> 30 °C). The filling temperature should be
between 15 and 25 °C.

51346-007 GB/2020-08 13 / 46
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
• Do not stand or lay any objects directly on the tank bottom. Use accessories, see
chapter 7.
• Do not immerse any parts of the body (e.g. hands, feet) or living beings (animals
or plants) into the tank; in particular, do not touch the bath liquid during ultrasound
operation. Danger: Ultrasound has a cell-destroying effect.
• In the event of continuous activity within a 2 m radius, adequate hearing protection must
be used. Danger: Hearing disturbances during operation are possible if not wearing
hearing protection – the typical ultrasound cavitation noise can be very uncomfortable.
• Fully replace used fluids, do not refresh them by adding more fluids. Follow the
manufacturer's dosage instructions.
Cooling
• About the cooling unit in the ultrasonic bath SONOCOOL according to regulation (EU)
No 517/2014..:
- Refrigerant: 134a; Quantity: 100 g
- GWP: max. 1,430 (limit according to EU VO = 2,500)
- CO2 Äquvalent: 0.143 t (limit according to EU VO = 5 t)
The cooling unit is considered to be a “hermetically sealed device”.
There is no check for leakage and no service documentation required in a test book.
• The cooling circuit may not be damaged!
If the cooling circuit is damaged, immediately disconnect the power plug and ventilate
the installation room well. Send the ultrasonic bath for repair to the manufacturer.
• Never cover or close the incoming or outgoing air openings on the ultrasonic bath.
Damage
• If damage to the ultrasonic bath is detected, do not connect the ultrasonic bath to the
mains.
• In the event of defects, disconnect the power plug immediately.
• Repairs are only to be conducted by authorised skilled personnel or by the manufacturer.
• Defective parts may only be replaced with original parts.
Advice for the medical and laboratory field
• The ultrasonic bath is exclusively intended for use by medical skilled personnel. It
may generate radio interferences or disrupt the operation of devices nearby. It may be
necessary to take remedial measures such as realigning the device or reconfiguring the
ultrasonic bath or the shield.
• During operation, portable or mobile HF communication systems in the vicinity of the
ultrasonic bath should be turned off- their operation may be disrupted.
• Operate the ultrasonic bath with the lid on.
• Any incidents during operation of the ultrasonic bath which result, could have resulted,
or might result in severe injury or even the death of a person must be immediately
notified to the manufacturer and to the user’s competent authorities.

14 / 46 51346-007 GB/2020-08
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
2 Preparation
Carefully unpack the ultrasonic bath and accessories and inspect them for completeness
or possible transportation damages. If any damages or defects are found, these are to be
immediately notified in writing to the transportation company and to the supplier.
Before startup, the ultrasonic bath is to be left to stand at its operating location for 2 hours
so that it may adapt to the ambient conditions.
2.1 Scope of delivery
1 × ultrasonic bath with integrated cooling unit (order No.: 3500) including:
1 × beaker holder PH 255-11
1 × lid D 255 G
20 × inset beakers SD 01.2
1 × drain hose ¼"
1 × mains cable
2 × rubber stoppers (as transport safety devices)
1 × TICKOPUR TR 3 250 ml
1 Instruction manual
Additional accessories according to order – see delivery note
2.2 Set-up / assembly
• Place the ultrasonic bath on a firm, level, dry surface, on a location away from direct
sunlight if possible. In the process
- Observe the maximum weight of the ultrasonic bath, including fluid.
For net weight, see technical data chapter 1.4.
- Observe the minimum distances for the incoming and outgoing air.
At least 5 cm on the side and at least 10 cm on the rear.
- Guard against moisture and wetness - risk of electric shock.
• The ultrasonic bath must be positioned in such a way that disconnection from the power
supply is easily possible.
5 cm
5 cm
10 cm

51346-007 GB/2020-08 15 / 46
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
2.3 Start-up
Important!
During delivery, rubber stoppers are plugged into the tank's inlet and outlet so that any
residual water from the manufacturer's final inspection does not leak into the internal fluids
circuit during transportation.
Leave these stoppers in place for the time being!
Thoroughly wipe clean the ultrasonic bath's oscillating tank before its first use.
Note:
In order to protect the surface during transport and storage, all outer surfaces (and also
the inner walls of the oscillating tank) are covered with an oily preservative. This should
be removed with a suitable cleanser before first use, see Chapter 5.
Connect the ultrasonic bath up to the power supply (grounded socket).
To conduct a function test, fill and ventilate the oscillating tank in accordance with
chapter 4. Briefly activate the ultrasound on the switched-on ultrasonic bath. A hissing
noise should be heard.
Check whether the cooling unit starts: An air current should be detectable on the rear
side of the outgoing air opening, the fan motor should be running audibly.
It is recommended that a foil test be conducted as part of quality assurance prior to the
first use, see chapter 6.1.
Next, empty out and switch offthe ultrasonic bath in accordance with chapter 4.
Hang the beaker holder in the oscillating tank and place the lid on top.
Caution!
Safely store the rubber stoppers for later emptying or refilling of the tank, or for safe
transportation.

16 / 46 51346-007 GB/2020-08
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
3 Operation
3.1 Operating elements
The unit is operated from the front:
12 345
1 LC display
2 Arrow keys [],[], [], []
3 Key [SET]
4 Key [START/STOP]
5 Status LED
3.1.1 Turning the ultrasonic bath on/off
The ultrasonic bath is turned on or offusing the mains switch on the rear side. After turning
on, the LC display must light up. Initialisation occurs automatically.
=====================
BANDELIN electronic
* S O N O C O O L *
=====================
- initialising -
Next, the ultrasonic bath will be on stand-by mode and will be ready for operation.
The status LED (5) will be lighted, the most recently-set values for runtime, temperature
and ultrasonic power will be displayed.
(Values during first-time activation: target temperature 17 °C, target runtime 00:10:00
hh:mm:ss, target power 100 %).
The last-selected parameters (runtime, target temperature, target power) will be saved and
accessed the next time the device is turned on.

51346-007 GB/2020-08 17 / 46
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
3.1.2 Explanation of the display fields
All relevant operating parameters and the status are shown on the LC display (e.g.: stand-
by mode).
12:00:00 17.0°C 50%
12:00:00
17.2°C
12:00:00
Runtime
Current (remaining) runtime for the ultra-
sound operation.
If [START/STOP] has not yet been pressed,
the time will correspond to the target runt-
ime.
Actual temperature
Actual temperature in the oscillating tank
Power specification
Specified value for the ultrasonic power during
sonication (in %)
Target tempera-
ture
Specified value for
the temperature in
the oscillating tank
(in °C)
Target runtime
Specified value for the duration
of the ultrasound operation (in
hh:mm:ss format)
Note:
As soon as the ultrasonic bath is turned on, the cooling will run automatically according to
the set target temperature. If cooling is not desired, it can be temporarily deactivated by
adjusting the target temperature, e.g. by setting the temperature to 30 °C.
The ultrasound is switched on separately (see chapter 3.4).
3.2 Signals on the ultrasonic bath
Meaning of the colours of the status LED
LED Explanation
green Ultrasonic bath is operating faultlessly.
yellow Warning. Ultrasonic bath may still be operated, however.
red Error (see error number). The ultrasonic bath or ultrasound cannot be started.
Newly-occurring errors are notified with a short audible signal and sometimes with a
blinking warning sign .

18 / 46 51346-007 GB/2020-08
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
3.3 Types of operation
The operation of the SONOCOOL ultrasonic bath is conducted using four different
operating modes.
Name and sample display Brief description / display To achieve...
Stand-by mode Basic state of the ultrasonic bath
The runtime (shown inversely)
and the current temperature are
displayed in the upper portion
of the display. In the bottom
rows, the target values for the
time, temperature and power are
displayed.
The cooling is activated, the
ultrasound is turned off.
- After turning on
+ initialisation
- When the runtime
has elapsed
- When interrupting
a process from the
Pause mode
+ pressing and
holding the [SET]
key for a long time
Editing mode Menu to change the operating
parameters (see chapter 3.4).
The selected parameter and the
current value are shown on the
top portion of the display. All valid
target values are shown on the
bottom rows.
- Stand-by mode
+ [SET] key
- Active mode
+ [SET] key
- Pause mode
+ [SET] key
Active mode The ultrasound is activated.
The residual runtime (remaining
runtime) is shown in non-inverted
format and runs as a second-by-
second countdown. Below it, the
actual temperature is displayed.
All valid target values are shown on
the bottom rows.
- Stand-by mode +
[START/STOP] key
- Editing mode (from
Stand-by and Pause)
+ [START/STOP] key
- Pause mode +
[START/STOP] key
Pause mode Interruption of the active mode
The remaining runtime is shown in
inverted form (dark text on a light
background). The process can be
continued thereafter.
The display is similar to the one
for Stand-by mode; however the
message "p-a-u-s-e" appears
on the next to last row.
- Active mode
+ [START/STOP] key
12:00:00 17.0°C 50%
Temperature:
17.2°C17
12:00:00 17.0°C 50%
12:00:00
17.2°C
12:00:00
12:00:00 17.0°C 50%
11:59:57
17.2°C
12:00:00 17.0°C 50%
===== p-a-u-s-e =====
12:00:00
17.2°C
09:15:21

51346-007 GB/2020-08 19 / 46
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
3.4 Setting the operating parameters
By pressing the [SET] key, the editing mode is activated.
Depending on the operating mode used to call up the editing mode, it will be possible to
change different operating parameters:
Call-up from Editable parameters
Stand-by mode Target runtime, target temperature and target power
Active mode Target temperature and target power
Pause mode Remaining runtime (without changing the target runtime!), target
temperature and target power
It is possible to switch between the individual parameters by pressing the [] key or []
key. By pressing the [] and [] keys, the setting values can be changed. Each of the
editable parameter positions is displayed inversely. Changes made become immediately
active.
3.4.1 Temperature setting
The temperature can be changed at any time in editing mode.
Setting limits: 4 - 40 °C
Notes:
• If the actual temperature exceeds the value of the target temperature by more than
+ 0.7 °C, the ultrasonic bath will shut offthe ultrasound for safety reasons (ultrasound
energy heats up the liquid). If the limit value is exceeded before the start, it will not be
possible to activate the ultrasound. The status LED will blink red.
• The ultrasonic bath will independently activate the ultrasound if the actual temperature is
once again within the stated tolerance range.
• The set time will only be counted during active ultrasound emission.
• If the target value for the temperature is higher than the actual temperature, only a
warning will be issued and the ultrasound may be started. The status LED will blink
yellow.
• With a target temperature below 15 °C, the ultrasound may be occasionally switched off
under normal ambient conditions (approx. 20 °C).
This can be prevented by reducing the ultrasound power setting.
Example: taken from stand-by mode Editing mode (temperature)
12:00:00 17.0°C 50%
Temperature:
17.2°C17
12:00:00 17.0°C 50%
12:00:00
17.2°C
12:00:00
SET

20 / 46 51346-007 GB/2020-08
1electronic GmbH & Co. KG • Heinrichstraße 3-4 • 12207 Berlin • Deutschland • [email protected]
3.4.2 Time setting
The target runtime can only be edited from stand-by mode. It cannot be edited while under
active operation (active mode) since the ultrasound continues to be active while in editing
mode.
From the pause mode, only the remaining runtime can be edited.
This setting, however, will not change the runtime specification (saved value in stand-by
mode).
Setting limits: 00:00:10 – 99:59:59 (hh:mm:ss)
3.4.3 Power setting
The power can be changed at any time in editing mode.
Setting values: 25%, 50%, 75% and 100%.
+
Example: taken from stand-by mode Editing mode (time)
12:00:00 17.0°C 50%
Time:
12:00:0012:00:00
12:00:00 17.0°C 50%
12:00:00
17.2°C
12:00:00
SET 
+
2
Example: taken from stand-by mode Editing mode (power)
12:00:00 17.0°C 50%
Power:
50 %50 %
12:00:00 17.0°C 50%
12:00:00
17.2°C
12:00:00

SET
