Barbeques Galore BEEFMASTER V Series Operator's manual

Page 1
WELCOME TO THE WORLD OF BARBEQUES GALORE OUTDOOR COOKING
INSTRUCTIONS FOR ASSEMBLY AND USE
OF BEEFMASTER V-SERIES BARBEQUES
For the safe use and enjoyment of your new barbeque
These instructions contain important information that needs to be followed for the safe
assembly and use of your new barbeque. Please read through carefully and completely
prior to assembly.
Take care to remove all packaging materials & protective coatings from the bbq before first
use. When unpacking the barbeque, keep it resting on its polystyrene foam base until ready
to install onto the cart or build-in or island. This will avoid any damage to parts while the unit
is not fixed into place.
For Barbeque Head Models:
G2BV, G2PBV, G2PDXB, G4BV, G4PBV, G4DXBV, G6BV, G6PBV, G6DXBV
Tools required:Two adjustable spanners; One Phillips head screwdriver; One Regular
screwdriver. Special tools required as well for NG conversion. See inside for details.
See also instruction manuals provided separately with associated carts, side shelves, side
burners and build-in kits.

Page 2
Australia has an excellent safety record when it comes to gas appliances. This reflects
both the high quality of appliances sold, as well as growing consumer awareness about
safety. We urge you to follow the guidelines below together with these instructions for
safe use, to prevent overheating and to produce great cooking results.
• This barbeque is an outdoor appliance only. Under no circumstances should it be
used indoors. This barbeque has not been approved for marine or caravan use.
• DO NOT perform any servicing on the barbeque yourself. This includes internal
adjustment of the regulator and gas valves. Servicing can only be carried out by
authorised technicians. DO NOT modify this appliance.
• It is important that you install your barbeque exactly as described in these
instructions. In particular you should keep the barbeque clear of combustible
material, and you should check for leaks whenever a new connection is made.
• DO NOT store chemicals or flammable materials near this appliance.
• DO NOT place articles on or against, or enclose this appliance.
• DO NOT spray aerosols in the vicinity of this appliance while it is in operation.
• The barbeque gets extremely hot while in use. Keep pets, children and the infirm
away from the appliance until it has cooled to normal temperatures.
• It is a good idea to tie back long hair and loose clothing while cooking in case of
unexpected flare ups.
• Fat fires are the most common cause of problems in barbeques. They are caused
by a build-up of grease in the grease channeling tray and / or the inside of the
barbeque firebox. A fat fire can be difficult to put out, and will be very dangerous if it
spreads to the gas hose. You should keep your barbeque clean to avoid this
occurrence. Fat fires will void the warranty. If a fat fire occurs, DO NOT try and
extinguish with water, shut down the gas supply if safe to do so, close the hood if
safe to do so, call the Fire Brigade on 000 if necessary.
• DO NOT transport or move the barbeque whilst it is in use or still hot because there
is a risk that the contents of the grease cup will fall out.
• NEVER leave a barbeque unattended with any burners switched on. Always switch
off all burners and gas supply when the barbeque is not in use.

Page 3
• USE CAUTION when touching a hot barbeque, especially on surfaces close to the
firebox or roasting hood.
• It is fine to pre-heat with all burners on HI and the hood closed, but NEVER let the
temperature on the hood thermometer exceed 250°C on the hood thermometer.
• When cooking with the hood closed, turn one or more burners to LO or OFF as
required to keep the barbeque from getting too hot. NEVER let the temperature on
the hood thermometer exceed 250°C on the hood thermometer.
• The hood and side burner lid where used must be in the OPEN position before
lighting.
• For 2 burner barbeques, when cooking with the hood closed for more than 20
minutes: NEVER exceed maximum temperature of 250°C and use the main
burners on LO only.
• For 4 burner barbeques, when cooking with the hood closed for more than 20
minutes: NEVER exceed maximum temperature of 250°C and use no more than 3
main burners on LO only.
• For 6 burner barbeques, when cooking with the hood closed for more than 20
minutes: NEVER exceed maximum temperature of 250°C and use no more than 4
main burners on LO only.
• NEVER leave all burners on HI for more than 10 minutes, always stay in control by
adjusting burners to LO and OFF as required to maintain suitable cooking
temperatures.
• Periodically check for gas leaks. Check for gas leaks whenever a new gas
connection is made. See “Safety Leak Testing” section.

Page 4
This appliance must only be used in an above ground, open air situation with natural
ventilation, without stagnant areas, where gas leakage and products of combustion are
rapidly dispersed by wind and natural convection. Any enclosure in which the appliance is
used must comply with one of the following:
(1) Any enclosure with walls on all sides, but at
least one permanent opening at ground
level, and no overhead cover. See Figure 1.
(2) Within a partial enclosure that includes an
overhead cover and no more than two walls.
See Figure 2 and Figure 3.
(3) Within a partial enclosure that includes an
overhead cover and more than two walls (see
Figure 4 and Figure 5), the following shall apply:
(i) At least 25% of the total wall area is
completely open; and
(ii) At least 30% of the remaining wall
area is open and unrestricted.
(iii) In the case of balconies, at least 20%
of the total of the side, back and front
wall areas shall be and remain open
and unrestricted.
FIGURE F1—OUTDOOR AREA–EXAMPLE 1
FIGURE F2—OUTDOOR AREA–EXAMPLE 2
FIGURE F3—OUTDOOR AREA–EXAMPLE 3
Both ends open
FIGURE F4—OUTDOOR AREA–EXAMPLE 4
Open side at
least 25% of
total wall
30 percent or more in
total of the remaining
wall area is open and
unrestricted
FIGURE F5—OUTDOOR AREA–EXAMPLE 5
Open side at
least 25% of
total wall
30 percent or more in total
of the remaining wall area
is open and unrestricted

Page 5
• The support structure must be only non-combustible material. Clearances of the barbeque from
combustible materials (e.g. wooden fences and gyprock walls and painted surfaces): 300mm
from sides and rear; 1000mm vertically above; 10mm below. If part of the structure is composed
of combustible materials, ensure that the combustible material is separated from the sides and
rear of the barbeque by at least 300 mm.
• Adequate clearance around the barbeque must be provided for safe and efficient operation. The
clearances shown in the diagram below ensure that the burners have a supply of fresh air to
operate correctly. Failure to provide enough fresh air to the burners can cause the production of
potentially deadly noxious gases
• At least 72mm clearance is required from the rear of the build-in barbeque support bracket
body to allow the roasting hood to open freely. Refer to the diagram below for details.
• Structure and installation must comply with AS/NZS 5601 including:
(1) Cylinder compartments must have permanent openings ventilating directly to the outside of
the appliance consisting of either:
(a) Perforations uniformly distributed over the height of the enclosure and with a total free area
of not less than 25% of the wall area; or
(b) Separate openings at high and low level such that
(i) The total free area at the high level is not less than 20,000 square mm and is all within
125 mm of the top of the cylinder compartment; and
(ii) The total free area at the low level is not less than 20,000 square mm and
(A)At least 25% of the required total area is within 15mm of the base of the cylinder
compartment; and
(B)The total required area is within 125 mm of the base of the cylinder compartment; and
(C)The openings cannot be obstructed by the gas cylinder.
Note that if a range hood is installed, it must be a minimum of 1200mm above the primary
cooking surface.
(2) Where the cylinder is kept in an enclosed space underneath or near the build-in barbeque,
the following must be observed:
(a) The cylinder must rest on a firm base to ensure that water will not accumulate, and that the
cylinder is clear of the surrounding soil.
(b) There must be a separation panel between the gas cylinder and the barbeque so that if a
high pressure gas leak occurs, there is no direct path between the cylinder compartment and
the bbq firebox.

Page 6
BBQ DIMENSIONS AND REQUIRED HEIGHT
≥345 mm≥520 mm
≥920 mm (for Propane only)
620.3mm
WALL
9kg
cylinder
Cylinder compartment ventilation
587mm
≥72mm (for hood to open)
192.5mm
177.9mm 177.9mm
620.3mm 72mm
548.3mm
548.3mm
Min 895 mm, Max 900 mm (4B)
Min 1215 mm, Max 1220 mm (6B)
Min 575 mm, Max 580 mm (2B)
98.8mm
Min 50 mm gap behind the bbq for ventilation!
2B 558 mm
4B 878 mm
6B 1198 mm
CAVITY REQUIRED WIDTH AND DEPTH
100mm
2-100mm
Min 50mm gap behind the bbq
for ventilation!
284 mm

Page 7
Before assembling your barbeque, you must ensure your barbeque is correctly suited to the type
of gas which you are going to use:
LPG (Liquefied Petroleum Gas), also known as Propane or Universal LPG:
Beefmaster V-Series barbeques are configured when manufactured for LPG and should have a
red printed sticker near the data plate stating “UNIVERSAL LPG”.
This is most commonly supplied as a portable 4 kg or 9 kg gas cylinder, which can be refilled or
swapped at petrol stations or your place of purchase when empty. Follow the assembly instruction
steps for how to fit and connect your portable cylinder.
Some homes have twin 45 kg LPG cylinders permanently installed near an outside wall. These
cylinders supply LPG gas to multiple appliances in the home via copper pipes (reticulated), and
are filled as required by the gas supply company. Barbeques which are connected to twin 45 kg
LPG cylinders must be installed by a licensed gasfitter, in accordance with the requirement of
AS/NZS 5601,and local gas authority requirements.
To change the gas type of your barbeque:
Your Beefmaster barbeque was manufactured to use LPG. It can be connected to LPG without
any alteration. If you wish to connect your barbeque to natural gas, it will need to be converted
beforehand. This must be done only by a licensed gas fitter or an authorised gas appliance
technician using the correct injectors supplied with this instruction manual and following the
instructions detailed later in this manual. Connection to the natural gas supply must only be done
by a licensed gasfitter. The gasfitter must issue a compliance certificate including their license
details and the date of installation. Keep that certificate in a safe place in case any warranty or
servicing of the barbeque is required
Natural Gas:
Barbeques suited to natural gas should have a black printed sticker near the data plate stating
“NATURAL GAS”．This is reticulated (piped) to your home in a similar fashion to water, so there
are no cylinders to refill. You will need to contact your local gas company to determine if Natural
Gas is available in your area. Barbeques to be connected to Natural Gas must be installed by a
licensed gasfitter, in accordance with the requirement of AS/NZS 5601 and local gas authority
requirements. This Beefmaster V-Series barbeque was manufactured for use with LPG so would
need to be altered by an authorised person for use with Natural Gas following the conversion
instructions in this manual.
If connecting to a standard Natural Gas bayonet outlet, the correct hose and governor assembly
must be used (code: NGCK250VJQ) available at your nearest Barbeques Galore store. If
connecting direct to the Natural Gas supply, the gasfitter will need to use a Natural Gas governor
(code: RCV250Q) and appropriate pipes and fittings for your particular installation.
It is extremely dangerous to use the barbeque with the wrong type of gas. Fire or explosion
may result. Always conduct a leak test before use. Refer details later in this manual under
“Safety leak testing”.

Page 8
There are two approaches to permanent piped installations:
(1) Direct Permanent Piped Connection: Your barbeque may be permanently connected to the
Natural Gas main gas lines or LPG cylinder via copper pipe. This must be done entirely by the
gasfitter, in accordance with requirements of AS/NZS 5601, and local gas authority
requirements. Your gasfitter will ensure that your barbeque is permanently connected to the
supply via copper pipe, the gas pressure in the line is adequate for the complete system, pipe
sizes are correct, all connections are secure, and that all necessary components (such as
secondary regulators and manual shutoffs) are included where regulations require them. Once
this is done, the barbeque cannot be moved. It is a permanent fixture of the property. Build-in
barbeques most often are connected this way.
(2) Bayonet Point:Alternatively, you can have the gas fitter terminate the gas line using a
“bayonet point”. This allows you to connect and disconnect the barbeque using a special hose
and bayonet termination. Such a hose is provided in the Natural Gas conversion kit
NGCK250VJQ. Follow the instructions supplied with the kit to complete the connection. For
LPG bayonet installations, an appropriate hose is available from most barbeque retailers.
Even if your barbeque area already has a bayonet point, you will still need to call upon a gas fitter
to ensure that gas pressure is appropriate for your barbeque and associated appliances on the
same supply, and to ensure your barbeque is adjusted and functions correctly before leaving.
Where a gas fitter is required, the gasfitter must test the safety and operation of the appliance
before leaving, including gas pressure, ignition and burner operation. The gasfitter must issue a
compliance certificate for the installation showing their licence number and the date of the
installation. Keep that certificate in a safe place in case any warranty or servicing of the barbeque
is required.
To the installer: You must instruct the consumer on safe operation, and ensure these instructions
are left with the consumer before leaving the site.

Page 9
For Beefmaster Two Burner Barbeque (G2BV) & Premium Beefmaster Two Burner
Barbeque G2PBV: Before you start, check that you have all the contents as below.
Remove all items including any packing materials from the firebox and hood
assembly. Discard any packaging materials and protective coatings once you have
accounted for all the parts.
Firebox & Hood Assembly
Hotplate Cooking Grill Folding Warming Rack
Cart Top Panel /Separator
Panel
Grease Channeling Tray
Two Grease Channeling
Tray Support Brackets Flame Tamer
Two Spare Silicone
Washers
Two M6*60mm Screws
Four M6*16mm Screws
Six M6*12mm Flat Head
Screws
Four M4*8mm Screws
Two M6 Nuts
Eight M6 Washers
Six Spring Washers
Two NG Injectors 1.7mm
Contents list. Carefully unpack the carton and check all the parts:

Page 10
For Beefmaster Deluxe Two Burner Barbeque (G2DXBV): Before you start, check that
you have all the contents as below. Remove all items including any packing materials
from the firebox and hood assembly. Discard any packaging materials and protective
coatings once you have accounted for all the parts.
Firebox & Hood Assembly
Hotplate
Cooking Grill Folding Warming Rack
Cart Top Panel /
Separator Panel
Two Grease Channeling
Tray Support Brackets
Grease Channeling Tray
AC Transformer
Ceramic Tile Bracket Two Ceramic Tiles
Two M6*60mm Screws
Four M6*16mm Screws
Four M4*8mm Screws
Six M6*12mm Flat Head
Screws
Eight M6 Washers
Six Spring Washers
Two M6 Nuts
Two Spare Silicone
Washers
Two NG Injectors 1.7mm
Contents list. Carefully unpack the carton and check all the parts:

Page 11
For Beefmaster Four Burner Barbeque (G4BV), Premium Beefmaster Four Burner
Barbeque (G4PBV) , Beefmaster Six Burner Barbeque (G6BV), & Premium Beefmaster Six
Burner Barbeque (G6PBV): Before you start, check that you have all the contents as
below. Remove all items including any packing materials from the firebox and hood
assembly. Discard any packaging materials and protective coatings once you have
accounted for all the parts.
Firebox & Hood Assembly
Hotplate Two Cooking Grills
Folding Warming Rack
Cart Top Panel /
Separator Panel
Two Grease Channeling
Tray Support Brackets
Two x Flame Tamer (4B)
Four x Flame Tamer (6B)
Grease Channeling Tray
Grease Cup Foil Dish
Two M6*60mm Screws
Four M6*16mm Screw
Seven M6*12mm Flat
Head Screws
Four M4*8mm Screws
Two M6 Nuts
Eight M6 Washers
Six Spring Washers Two Spare Silicone
Washers
NG Injectors 1.7mm
Four for 4B;
Six for 6B
Contents list. Carefully unpack the carton and check all the parts:

Page 12
For Beefmaster Deluxe Four Burner Barbeque (G4DXBV) & Beefmaster Deluxe Six Burner
Barbeque (G6DXBV): Before you start, check that you have all the contents as below.
Remove all items including any packing materials from the firebox and hood
assembly. Discard any packaging materials and protective coatings once you have
accounted for all the parts.
Firebox & Hood Assembly
Rotisserie Set Motor Bracket
Hotplate
Two Cooking Grills
Folding Warming Rack DC Motor
AAA 1.5V Battery
AC Transformer
Ignition Module
Motor 240V Adaptor
Cart Top Panel /
Separator Panel
Two Grease Channeling
Tray Support Brackets Grease Channeling Tray
Grease Cup
Foil Dish
Four x Ceramic Tiles (4B)
Eight x Ceramic Tiles (6B)
One Ceramic Tile Rack (4B)
Two Ceramic Tile Racks (6B)
Two M6*60mm Screws
Four M6*16mm Screws
Seven M6*12mm Flat
Head Screws
Eight M4*8mm Screws
Two M6 Nuts
Eight M6 Washers
Six Spring Washers
Two Spare Silicone
Washers
NG Injectors 1.7mm
Four for 4B;
Six for 6B
NG Injector Cap 1.54mm
Contents list. Carefully unpack the carton and check all the parts:

Page 13
If you are assembling a cart model or steel island, make sure you have the separately
supplied steel cart (code MC2BV or MC2DXB for 2 burner, code MC4BV or MC4DXB
for 4 burner, code MC6BV or MC6DXB for 6 burner). Assemble the cart(s) before you
start on the barbeque head assembly using the instruction manual supplied separately
with the cart.
If you are assembling multiple units together (e.g. 2 burner and a 4 burner and a Range
unit to make one bbq island), assemble each of the bbqs / heads to their respective carts
before joining the carts.
If you are fitting side shelves and / or side burners, make sure you have the separately
supplied pack of two folding shelves (code MCBFOLDV) or pack of one Premium shelf +
one stainless steel side burner (code MCBSBSHELFV) or pack of one Deluxe shelf + one
cast iron side burner (code MCDXBSBSHELFV).
If you are assembling a build-in or an island, make sure you have the separately supplied
build-in kit (code BRBIKV). Double check all dimensions and clearances before committing
to any design or construction expense.
If you purchased a pre-fabricated island, verify that you have matching size island and
barbeque head, and assemble the island before you start on the barbeque head assembly.
If you want to run up to two adjacent gas modules (e.g. 2 burner and 4 burner) from a single
gas supply, you will need separately supplied corrugated gas extension pipe (code:
CBGASEXT). Check with a gasfitter before connecting multiple items from the one gas
supply to ensure it can be done safely.
Assembly instructions

Page 14
STEP 1 (ALL MODELS): Position the Grease Channeling Tray Support Brackets.
WHAT YOU NEED
Two Grease Channeling Tray
Support Brackets
Four M4*8mm Screws
Screw the left and rights Grease Channeling Tray Support Brackets to the Separator
Panel. Make sure the pre-fitted stopper nuts are at the top back inner positions as shown
below. Tighten the screws firmly.
STEP 2 (DELUXE MODELS ONLY): Fit the transformer
WHAT YOU NEED
One Transformer with Integral Bracket.
Four M4*8mm Screws
Locate the Transformer into place on
the underside of the top panel as shown below
and lock into place with four M4*8mm screws.
Note the stopper nuts inwards upper positions
Grease Channeling Tray BracketFour M4*8mm Screws
Back
Front
Assembly instructions (continued)

Page 15
STEP 3 (FOR DELUXE MODELS 4B AND 6B ONLY): Attach the rear burner ignitor
WHAT YOU NEED
One ignition module and cover box
One AAA 1.5V battery
(a) Open the cap of the Ignition Module and insert the Battery with the positive terminal
outwards as shown.
(b) The Cover Box has two flat tabs. Slide the tab into the flat bracket on the underside of the
separator panel until the cover box is firmly in place.
These next two steps assume that you have already assembled the cart using the
instructions included separately with the cart. (For build-in or island models, skip
now to STEP 7.)
STEP 4 (CART MODELS ONLY): Fix the cart/ cabinet separator panel into place.
WHAT YOU NEED
Six M6*12mm Flat Head Screws (2B)
Seven M6*12mm Flat Head Screws (4B,6B)
Assembly instructions (continued)

Page 16
(a) If the cart Door Beam is already attached, detach it by removing the four screws
as shown. 门横梁
(b) Locate the Cart Top Panel in place and fix it to the cart, using two M6*12mm
screws each side and three screws at the back as shown. (Note that 2B has only
two screws at the back). Don’t fully tighten the screws yet.
(c) Refit the Door Beam into place using the four screws aside from part (a). Once the
Door Beam is in place, fully tighten all the screws holding the cart Top Panel and
the Door Beam.
门横梁
Door Beam
Door Beam
Assembly instructions (continued)

Page 17
STEP 5 (CART MODELS ONLY): Fix the firebox and hood assembly onto the cart.
WHAT YOU NEED
Four M6*16mm Screws
Four Spring Washers
Four M6 Washers
(a) With help, carefully position the firebox and hood assembly onto the cart. As it is
lowered into place, the gas hose and regulator (and the electrical leads for deluxe
models) will need to be carefully threaded through the rubber grommet access hole in
the cart top panel.
(b) Remove the firebox side panels as shown, and keep aside the twelve removed
screws and the side panels for use in part (d).
(c) Fit and firmly tighten the four M6*16mm Screws, Spring Washers and Washers as
shown below, so that the head is fixed to the cart. The spring washer fits against the
screw head. The M6 washer fits against the firebox.
(d) Replace the firebox side panels, fit and firmly tighten the twelve screws from part (a).
STEP 3a STEP 3b
STEP 3c STEP 3d
Four M6*16mm Screws Four M6 Washers Four Spring Washers
Assembly instructions (continued)

Page 18
STEP 6 (ONLY IF JOINING ADJACENT BARBEQUES): Join the carts and fireboxes.
If you are joining two carts and barbeques together, e.g. a 2B and 4B to make a 6B, then
first assemble each head onto its respective cart as above. Adjust the cart heights to match
each other as outlined in the cart assembly manual, and then join the adjacent carts and
fireboxes as detailed below.
(a) Bolt the adjacent carts together
WHAT YOU NEED
Four M6*16mm Screws
Four M6 Nuts
Join the two carts using Four M6*16mm Screws, and Four M6 Nuts as shown below:
Follow the instructions that came with the cart to properly level the carts and if necessary,
adjust the castors, so that all castors are simultaneously in contact with the ground once the
carts are level. Note that unless the ground is perfectly level, the castor heights may need
adjustment each time the cart is moved to a different position in order to level the doors.
Note that doors, cart top panels and barbeque heads are not shown here for clarity,
but should already be in place.
Assembly instructions (continued)
Note that doors, cart top panels and barbeque heads are not shown here for clarity,
but should already be in place.

Page 19
(b) Where applicable for two adjacent Barbeques only, bolt the fireboxes together
WHAT YOU NEED
Two M6*60mm Screws
Four M6 Washers
Two M6 Nuts
Two Spring Washers
Join the two heads using Two sets M6*60mm screws, M6 Washers and Nuts as shown
below (carts not shown for clarity, but they should already be levelled and joined).
Washers Screws
Spring
Washers
Washers
Nuts
Two M6 Screws Four M6 Washers Two M6 Nuts Two Spring Washers
Cutawa
y
view from front:
Assembly instructions (continued)

Page 20
STEP 7 (ONLY IF ATTACHING SIDE SHELVES, SIDE BURNER or BUILD-IN BRACKET):
Refer now to the instructions separately supplied with the Side Shelves, Side Burner
and Build-in Brackets. Follow those instructions to fit the side shelves and side
burner or build-in brackets.
Assembly instructions (continued)
